Solarmodulbefestigungsvorrichtung

Resumen de: DE102023130837A1

Die Erfindung geht aus von einer Solarmodulbefestigungsvorrichtung mit einer Montageschiene (34, 36, 38, 40) zur Befestigung mehrerer Solarmodule(12, 14, 16, 18), wobei die Montageschiene (34, 36, 38, 40) zumindest eine zumindest im Wesentlichen durchgängige Auflagefläche (44, 46) aufweist, auf die die Solarmodule (12, 14, 16, 18) zur Befestigung aufschiebbar sind.Es wird vorgeschlagen, dass die Montageschiene (34, 36, 38, 40) zumindest ein Montagesicherungselement (66, 68) aufweist, das dazu vorgesehen ist, ein Aufschieben von Solarmodulen (12, 14, 16, 18) auf die Auflagefläche (44, 46) in einer Montagerichtung (204) zuzulassen und die Solarmodule (12, 14, 16, 18) in Montagepositionen gegen ein Verschieben entgegen der Montagerichtung (204) zu sichern.

Photovoltaik-Anlage und Verfahren zur Montage einer Photovoltaik-Anlage

Resumen de: DE102023130403A1

Photovoltaik-Anlage (1) mit einer Tragkonstruktion mit einer Vielzahl von in einem Untergrund (3) verankerbaren Pfosten (2) und mindestens einem bifazialen Photovoltaikmodul (4) zwischen zwei benachbarten Pfosten (2), wobei das mindestens eine bifaziale Photovoltaikmodul (4) an vier Ecken an jeweils einem Halteelement (5) gehalten ist und jedes Halteelement (5) an einem der Pfosten (2) fixiert ist. Ferner betrifft die Erfindung ein Verfahren zur Montage einer Photovoltaik-Anlage (1), die mit geringem Materialeinsatz aufgestellt werden kann und leicht zu montieren ist.

SOLAR CELL

Resumen de: EP4550424A1

A solar cell is provided, including: a substrate; a passivation layer formed over a surface of the substrate; fingers arranged in a first direction and extending in a second direction, where the fingers penetrate the passivation layer to be electrically connected to the substrate and include first fingers and second fingers which are alternatingly arranged; connection electrodes, where each of the connection electrodes is in electrical contact with end portions of at least two adjacent first fingers on a same side and includes one of the following: at least a first connection section and a second connection section connected to each other, where the first connection section is connected to an end portion of a respective finger of the at least two adjacent first fingers, the first connection section and the respective finger has an included angle that is not equal to 180°, and the first connection section and the second connection section has an included angle that is not equal to 180°; and a curved wave-like structure.

PHOTOVOLTAIC SYSTEM AND METHOD FOR ASSEMBLING A PHOTOVOLTAIC SYSTEM

Resumen de: EP4550659A1

Photovoltaik-Anlage (1) mit einer Tragkonstruktion mit einer Vielzahl von in einem Untergrund (3) verankerbaren Pfosten (2) und mindestens einem bifazialen Photovoltaikmodul (4) zwischen zwei benachbarten Pfosten (2), wobei das mindestens eine bifaziale Photovoltaikmodul (4) an vier Ecken an jeweils einem Halteelement (5) gehalten ist und jedes Halteelement (5) an einem der Pfosten (2) fixiert ist. Ferner betrifft die Erfindung ein Verfahren zur Montage einer Photovoltaik-Anlage (1), die mit geringem Materialeinsatz aufgestellt werden kann und leicht zu montieren ist.

PHOTOVOLTAIC ENERGY STORAGE SYSTEM, ENERGY CONVERSION SYSTEM, INVERTER, AND POWER BALANCING METHOD

Resumen de: EP4550603A1

This application provides a photovoltaic energy storage system, an energy conversion system, an inverter, and a power balancing method. The photovoltaic energy storage system includes an energy storage assembly, an inverter, a PCS, a load switch circuit, a BMS, and an EMS. The PCS is connected to the energy storage assembly and the load switch circuit, and the inverter is connected to a photovoltaic array and the PCS. Based on at least one of a first parameter, a second parameter, and a third parameter, the EMS adjusts a generation power of the photovoltaic array and/or controls, through the load switch circuit, a quantity of connected loads, to implement power balancing among the generation power, a total charge/discharge power of energy storage, and a consumption power. The first parameter includes a minimum power in a target charge/discharge power of the energy storage assembly and a charge/discharge power of the PCS, and the total charge/discharge power of the energy storage assembly. The second parameter includes minimum alternating current side voltages collected by the PCS and the inverter. The third parameter includes minimum alternating current side frequencies collected by the PCS and the inverter. Therefore, the EMS may integrate device information, and adjust the power based on the minimum parameter, to maintain power balancing and avoid device damage.

PHOTOVOLTAIC CELL FOR LASER BEAM POWER DETECTION

Resumen de: EP4550625A2

A wireless optical power transmission system comprising a transmitter and receiver, the transmitter comprising a laser emitting a beam, a scanning mirror for steering the beam towards said receiver and a control unit receiving signals from a detection unit on the receiver and controlling the beam power and the scanning mirror. The receiver has a photovoltaic cell having a bandgap energy of 0.75-1.2 eV, with a plurality of conductors on a beam receiving surface. A cover layer of material blocking illumination of wavelengths outside that of the laser, is disposed on the photovoltaic cell. The cover layer may have anti-reflective coatings on its top and bottom surfaces. The detection unit thus generates a signal representing the power of the laser beam impinging upon the receiver, independent of illuminations other than that of said laser beam. The control unit thus can maintain the laser power impinging on the receiver.

PEROVSKITE HALIDE THIN FILM FOR ABSORBING BLUE LIGHT AND ELECTRONIC DEVICE COMPRISING SAME

Resumen de: EP4549445A1

The present invention provides a thin film comprising a perovskite halide represented by chemical formula 1.        Chemical formula 1     AB(BrxCly)3wherein, A is a monovalent cation consisting of a combination of NH2CHNH2<+> (formamidinium, FA), CH3NH3<+> (methyl ammonium, MA) and Cs<+>, wherein FA is included in an amount of 0.2 - 0.8 moles with respect to 1 mole of the monovalent cation, B is at least one divalent cation selected from Pb<2+>, Sn<2+>, Ge<2+>, Ti<2+>, Zr<2+>, Mn<2+>, Ni<2+>, Fe<2+>, Zn<2+> and Cu<2+>, and x and y satisfy 0.5≤x≤0.8, 0.2≤y≤0.5, and x+y=1.

SOLAR POWER PLANT MANAGEMENT SYSTEM, ASSET MANAGEMENT PLATFORM, PROGRAM, MACHINE MANAGEMENT SYSTEM, AND INFORMATION PROCESSING METHOD

Resumen de: EP4550239A1

If the status survey and repair work for the photovoltaic equipment (52) cannot be handled by the asset management platform (10), the transmission unit (18) sends a request for information provision from the asset management platform (10) to the central platform (40), and the information about the maintenance companies capable of performing the work, which is stored in the database (44) of the central platform (40), can be accessed from the asset management platform (10).

RELIABLE AND SELF-SUFFICIENT LIGHTING SYSTEM AND METHOD THEREFOR

Resumen de: WO2024000058A1

A lighting apparatus has a lighting component, an energy storage unit, a photovoltaic (PV) panel for at least one of powering the lighting component and charging the energy storage unit, a wind turbine having a plurality of rotatable blades coupled to a generator for at least one of powering the lighting component and charging the energy storage unit, and a housing receiving therein at least the lighting component, the energy storage unit, and the PV panel. The wind turbine is physically coupled to the housing.

COATED SOLAR CELL

Resumen de: WO2024094872A1

A solar cell assembly comprising: adjacent layers defining an interior lumen, sealant between the adjacent layers to seal the interior lumen, and a solar cell within the sealed lumen, characterised in that the solar cell is a perovskite solar cell and in that a layer comprising ta-C is present on an external surface of the assembly, e.g. on a front and/or a back layer of the assembly, or on the sealant, e.g. at the junction between the sealant and each of the adjacent layers. The solar cell assembly is made by assembling the solar cell, adjacent layers and sealant, and depositing a ta-C coating onto an external surface of the assembly. The resultant assembly is resistant to water and/or air ingress and has improved stability in use.

HOUSING FOR FIXING A SOLAR MODULE

Resumen de: EP4549836A1

Die Erfindung betrifft ein Gehäuse (7) zum Befestigen eines Solarmoduls (1) in einem Dach und/oder in einer Wandverkleidung mit einer im betriebsbereiten Zustand der Sonne zugewandten flächigen Seite (8) und eine im betriebsbereiten Zustand der Sonne abgewandten flächigen Seite, das Gehäuse (7) aufweisendeinen Rahmen (9) zum Aufnehmen des Solarmoduls (1) umfassend eine im betriebsbereiten Zustand dem Erdboden abgewandte erste Querseite (T1), eine im betriebsbereiten Zustand dem Erdboden zugewandte zweite Querseite (T2) und zwei zwischen den Querseiten (Ta, T2) angeordneten Längsseiten (L1, L2), wobei der Rahmen (9) dazu ausgestaltet ist, das Solarmodul (1) in einer ersten Ebene anzuordnen,einen an der der Sonne abgewandten Seite angrenzenden Hohlraum (6), wobei der Hohlraum (6) in einer zweiten zu der ersten Ebene unterschiedlichen Ebene angeordnet ist,einen an der ersten Querseite (T1) angeordneten Einlass (10), der dazu ausgestaltet ist, ein Fluid in den Hohlraum (6) zu leiten und einen an der zweiten Querseite (T2) angeordneten Auslass (11), der dazu ausgestaltet ist, das Fluid aus dem Hohlraum (6) abzuleiten, undeine Auffangwanne (12), die derart in einer zu der ersten und zweiten Ebene unterschiedlichen dritten Ebene angeordnet ist, dass der Hohlraum (6) zwischen dem Solarmodul (1) und der Auffangwanne (12) eingeschlossen wird.Auf diese Weise wird ein Gehäuse für ein Solarmodul bereitgestellt, das eine dachintegrierte Montage auch ohne vorhandene Hinterlüftung er

SELF-CLEANING PHOTOVOLTAIC ROOF TILE

Resumen de: WO2024005657A1

The subject of the invention is a self-cleaning photovoltaic roof tile, that is characterized in that it consists of an upper transparent glass plate (4), the upper surface of which is coated with a coloured ceramic coating (5) printed thereon, with a thickness of < 45 µm, which is coated with a self- cleaning hydrophobic layer (6) with a thickness of 300 nm and 800 nm, and a lower transparent glass plate (7) with an identical profile, the lower surface of which is coated with the coloured ceramic coating (8), wherein between the lower surface of the upper glass plate (4) and the upper surface of the lower glass plate (7) there is at least one monocrystalline cell (9) located above their lower sides (2), and additionally both glass plates (4, 7) together with a monocrystalline cell (9) placed between them, with electric wires (11), are laminated together by means of laminating foil (10).

SOLAR CELL TEST PROCEDURE, SOLAR CELL PRODUCTION PROCEDURE, SOLAR CELL TEST SYSTEM AND SOLAR CELL PRODUCTION SYSTEM

Resumen de: WO2024003051A1

The invention relates to a solar cell test procedure, a solar cell production procedure, a solar cell test system and a solar cell production system. The solar cell test procedure for testing a plurality of solar cells at the respective end of one or more production lines comprises the following method steps: carrying out a primary measuring method (210) on the solar cell to determine a primary measurement result; evaluating the primary measurement result by means of an evaluation method (300) such that an evaluation result is determined, the evaluation result being positive if it is determined, by means of the evaluation result, that the solar cell can be classified into a predefined sort category on the basis of only the primary measurement result, and negative if it is determined, by means of the evaluation result, that the solar cell cannot be classified into a predefined sort category on the basis of only the primary measurement result; classifying (400) the solar cell into a sort category depending on the primary measurement result if the evaluation result was positive, carrying out a secondary measuring method (220) on the solar cell to determine a secondary measurement result and classifying (400) the solar cell into a sort category depending on the secondary measurement result and optionally the primary measurement result if the evaluation result was negative.

OPTOELECTRONIC COMPONENT WITH A PHOTOACTIVE LAYER DESIGNED AS A PLANAR HETEROJUNCTION

Resumen de: CN119452771A

The invention relates to an optoelectronic component comprising a bottom electrode (2), a top electrode (6) and a layer system (7) having at least one photoactive layer (4). The layer system is arranged between the bottom electrode and the top electrode, and at least one photoactive layer is designed as a planar heterojunction (PHJ), the at least one photoactive layer designed as a planar heterojunction having at least one compound of general formula I. The invention also relates to the use of such compounds of general formula I in optoelectronic components and to a compound of general formula II.

VERTICAL INSTALLATION FOR GENERATING ELECTRICITY BY MEANS OF PHOTOVOLTAICS

Resumen de: AU2023298293A1

The invention relates to an installation (1) for generating electricity by means of photovoltaics, wherein the installation (1) has at least four solar modules (2), wherein the solar modules (2) are distributed between at least two solar surfaces (3) so that each solar surface (3) has at least two solar modules (2), wherein the solar surfaces (3) are vertically one above another in a parallel offset arrangement, wherein the solar modules (2) are connected in at least two strings (4, 5), wherein each of the at least two strings (4, 5) comprises at least one solar module (2) on at least two different solar surfaces (3), wherein each string (4, 5) is assigned a usable depth (6, 7), wherein the usable depth (6, 7) corresponds to the maximum distance between the solar modules (2) of the string (4, 5) and an outer edge (8) of the solar surface (3) of the relevant solar module (2), wherein the strings (4, 5) have at least two different usable depths (6, 7).

FACADE SYSTEM AND ADAPTER DEVICE OF A CORRESPONDING FACADE SYSTEM

Resumen de: WO2024002836A1

The invention is based on a facade system having a holding device (10), which has at least one recess (12, 14, 98, 100), and having at least one first type of facade element (16, 18, 74), wherein the recess (12) is designed to receive at least one extension (20, 22) of the facade element (16, 18) of the first type in order to fasten the facade element (16, 18) of the first type to the holding device (10). It is proposed that the facade system has at least one adapter device (24, 118, 120) which is designed to be at least partially introduced into the recess (14, 98, 100) in order therefore to fasten at least one second type of facade element (26, 28), in particular a solar facade element, to the holding device (10).

LEPORELLO FOLD-TYPE SOLAR INSTALLATION AND METHOD FOR SETTING UP THE SOLAR INSTALLATION

Resumen de: WO2024002968A1

The invention relates to a solar installation having solar panels (2, 2') which are prefabricated in a Leporello fold (3), which can be unfolded in an unfolding direction (A), said installation having a substructure on which the solar panels are arranged, wherein the substructure is flexible in the unfolding direction (A) and is connected to the solar panels in a positionally fixed manner in such a way that the Leporello fold (3) of the solar panels can be unfolded with the substructure (8, 9, 10, 24) and determines angular positions of the solar panels (2, 2') relative to one another.

PHOTOVOLTAIC ROOF TILES

Resumen de: CN119403984A

Known photovoltaic roof tiles replace traditional roof tiles in a single lap arrangement. In order to prevent rainwater from passing between adjacent tiles and permeating into a building below, the photovoltaic roof tile is provided with interlocking edges; however, the manufacturing cost of these devices may be very high, and the installation is also time-consuming. One more economical choice of laying tiles is the use of a double lap tile arrangement. Because the planar tiles have no interlocking edges, water may leak through the joints between the tiles. This entails the placement of a third tile under the joint to intercept any passing water. However, when the double lap tiles are used, a substantial portion of each tile is still covered after installation, so that a relatively small surface area can be exposed to the sun. This is not effective utilization of expensive photovoltaic materials. The invention provides a photovoltaic roof tile 302 for use with a double lap tile 301, the tile width of the photovoltaic roof tile 302 being equal to an integer multiple of the width of the double lap tile. In this manner, such a photovoltaic roof tile 302 can be arranged with a conventional double lap roof tile 301 to increase the proportion it can be used to receive sunlight 305, 307 without the risk of water ingress.

Système de production d’énergie photovoltaïque et procédé de pilotage d’un tel système

Resumen de: FR3154890A1

Système de production d’énergie photovoltaïque et procédé de pilotage d’un tel système Système de production d’énergie photovoltaïque, comprenant une pluralité de panneaux (P1 à P2), chaque panneau (P1 à P2) comprenant un module photovoltaïque (6), et étant monté mobile en rotation sur une structure porteuse (2 à 4) autour d’un axe de rotation (A), un dispositif d’enroulement (10) porté par une première zone de fixation (Z1) d’un premier panneau (P1), une toile (14) configurée pour être accrochée par une première de ses extrémités (E1) au dispositif d’enroulement (10) et par une deuxième de ses extrémités (E2) à une deuxième zone de fixation (Z2) d’un deuxième panneau (P2) de manière à couvrir au moins une partie d’une zone (ZS) du sol située verticalement au-dessous de la toile (14), le système étant configuré pour que la toile (14) s’enroule dans le dispositif d’enroulement (10) en fonction d’une position relative des première et deuxième zones de fixation (Z1, Z2). Figure pour l’abrégé : Fig.1

BACKSHEETS FOR PHOTOVOLTAIC MODULES

Resumen de: US2025141395A1

A roofing system, including a roof deck and a plurality of photovoltaic modules installed on the roof deck. Each of the plurality of photovoltaic modules includes at least one solar cell, an encapsulant encapsulating the at least one solar cell, and a backsheet below the encapsulant. The backsheet includes a first layer, where the first layer contacts the roof deck, and where the first layer comprises a plurality of cavities or a plurality of ribs.

TRANSPORTABLE AND MULTI CONFIGURABLE, MODULAR SOLAR SYSTEMS AND METHODS FOR USE

Resumen de: US2025141399A1

Support platforms for one or more solar panels and systems and methods for securing support platforms are provided. In one embodiment, a frame of a support platform includes a plurality of support legs, each leg including a shoe plate. One or more toggle anchors with rod and/or cable are provided that include an anchor portion and a toggle portion pivotally coupled to the anchor portion, and a rod and/or cable is coupled to the toggle portion. Each anchor is driven into the ground with a driving rod such that an exposed end of the rod and/or cable extends from the ground. The driving rod is removed, and the rod and/or cable is pulled to deploy the anchor, and which the anchor is pull tested and measured in real time soil conditions whereupon the 10 exposed end is coupled to the shoe plate of one of the support legs to apply a desired tensile force between the exposed end and the anchor to secure the support leg and, consequently, the support platform relative to the ground.

CONTROLLING A SOLAR POWER PLANT

Resumen de: US2025141233A1

Method for optimizing a maximum power point of a solar cell stack having modules, each including an MLSD unit, and an inverter. The MLSD unit shuts down the module when module voltage falls below a first voltage threshold, and switches it on, when a predefined second voltage threshold is exceeded. For optimal performance, the solar cell stack carries out: Defining, changing an electrical control parameter to a first wait value so that the second voltage threshold is exceeded exceeded; maintaining first wait value for a first time period so the modules are switched on by the MLSD units; changing electrical control parameter to a threshold value in a variation range and determining current-voltage curves for the modules in variation range; determining maximum stack power from current-voltage curves of the modules in the variation range; and predefining the determined maximum stack power as the maximum performance point.

ROOFING SYSTEMS WITH WATER INGRESS PROTECTION

Resumen de: US2025141397A1

A roofing system includes a roof deck and at least one photovoltaic module installed on the roof deck. The first photovoltaic module includes at least one solar cell and a sealant. At least one fastener penetrates the sealant and the roof deck.

ROOFING SYSTEMS WITH WATER INGRESS PROTECTION

Resumen de: WO2025090902A1

A roofing system includes a roof deck and at least one photovoltaic module installed on the roof deck. The first photovoltaic module includes at least one solar cell and a sealant. At least one fastener penetrates the sealant and the roof deck.

IN-SERIES DC TO AC CONVERSION SYSTEM

Nº publicación: WO2025090662A1 01/05/2025

Solicitante:

UNIV TEXAS [US]
BOARD OF REGENTS, THE UNIVERSITY OF TEXAS SYSTEM

Resumen de: WO2025090662A1

An exemplary system and method employing a set of in-series DC-to-AC converters, also referred to as nanoinverters, that can provide an improved DC-to-AC conversion operation with multiple and individualized Maximum Power Point (MPP) for each respective DC-to-AC converter. The in-series DC-to-AC converters are beneficially coupled or integrated into a photovoltaic panel or a small subset thereof from the overall setup of PV panels to provide optimized routing and installation. The exemplary system can address issues related to string inverters, DC optimizers, and microinverters by providing such functionality but with minimal circuitry and hardware, as well as providing safe, flexible, and cost-effective operation when directly coupled to photovoltaic panels.
