Resumen de: CN120300241A
本发明公开了一种地下硐室铁铬液流电池系统及其容量恢复方法,系统包括储液单元、电堆单元、输送单元及容量恢复机构,储液单元包括设置于地下的两硐室,两个硐室均包括硐室主体及隔板;电堆单元包括反应器、第一质子交换膜及两第一极板;容量恢复机构包括电解器、纯水供应单元及循环单元。本发明的有益效果是:将铁铬液流电池系统安置于地下硐室,不占用大量宝贵的地表空间。在充电过程中,能够保证氧化物和还原物分别存储在隔板两侧,使得放电反应更加充分和稳定。通过两个隔板的高度差来判断是否需要进行容量调整以及容量调整是否到位,整个过程操作简单,无需大量的人力和时间投入,降低了维护成本,提高了电池系统的实用性和可靠性。
Resumen de: CN120300247A
本发明公开了一种大功率氢燃料电池电堆,包括第一端板、第一集流板、燃料电池单片、第二集流板、第二端板和特殊双极板组件,紧固螺杆穿过第一端板与第二端板并通过紧固螺母固定,特殊双极板组件包括特殊阴极侧双极板、特殊双极板隔板和特殊阳极侧双极板。本发明在特殊双极板隔板上不设置允许冷却液穿过的冷却液流道结构,或在特殊双极板隔板上不设置允许空气、冷却液穿过的流道结构,或在特殊双极板隔板上不设置允许氢气、冷却液穿过的流道结构,提高电堆的输出功率能力、电堆动态响应速率和使用寿命,能够适应功率范围更宽的应用场景需求。
Resumen de: US2025226427A1
A fuel cell bonding jig includes an upper jig and a lower jig. The fuel cell bonding jig is configured to be able to be set to a first state that corresponds to a state in which a first film is arranged on a lower surface of the upper jig, a second film is arranged on an upper surface of the lower jig, and an adhesive is applied to the film. A second state in which the first film and the second film face each other across an interval in a vertical direction is entered when the upper jig is attached onto the lower jig while the fuel cell bonding jig is in the first state. The fuel cell bonding jig is configured to be able to, from the second state, press the first film onto the second film.
Resumen de: CN120300235A
本申请提供了一种低成本质子交换膜及其制备方法,该低成本质子交换膜,包括以下质量份原料:100份磺化聚醚醚酮,1~10份改性MOFs材料;所述改性MOFs材料包括接枝有嵌段聚合物的MOFs材料,所述嵌段聚合物包括聚乙烯咪唑链段和疏水链段,所述聚乙烯咪唑链段设置在靠近MOFs材料一侧。该低成本质子交换膜以SPEEK作为主体材料,使用改性MOFs材料进行优化,具有较高的质子电导率和较低的溶胀率,可以用于改善燃料电池的整体性能。
Resumen de: JP2024099258A
To provide a kiln exhausts gas regenerating device that regenerates a gas mixture that contains noble gas and occluded gas into a reusable gas, the mixture gas being exhausted from a kiln that heats a metal storing the occluded gas and uses an atmosphere including the noble gas to cause the occluded gas to be discharged from the metal.SOLUTION: The kiln exhaust gas regeneration device comprises: noble gas extracting means that receives gas mixture including noble gas and occluded gas exhausted from a kiln, and uses a filter with different degrees of permeability for the occluded gas and the noble gas and/or a fuel cell that oxidizes the occluded gas to transform the received gas mixture into a gas with increased noble gas concentration. Here, preferably, the noble gas is argon gas. Additionally preferably, the kiln exhaust gas regeneration device further comprises noble gas delivery means to send the gas with increased noble gas concentration to the kiln or a gas reservoir for the kiln, in order to have the gas reused as the above-described atmosphere.SELECTED DRAWING: Figure 1
Resumen de: CN120300199A
本发明涉及聚合物电解质膜燃料电池技术领域,特别是一种多级孔结构Pt基阴极材料及其制备方法,该多级孔结构Pt基阴极材料中Pt/Ag不小于3且存在双连续多级孔结构,其中大孔的孔径范围为30‑90nm,小孔的孔径范围为3‑10nm、韧带范围为3‑10nm;其制备方法为:将银箔与铂置换溶液进行置换得到Pt‑Ag薄膜前驱体,其中Ag/Pt不小于6;在300‑500℃下退火至少10h;与金属Zn在真空、400‑600℃下热处理30min以上;脱合金处理去除Zn和部分Ag,使得终产物中Pt/Ag不小于3。本发明解决了传统Pt基合金薄膜不能兼具高效的传质性能和良好的催化活性的问题。
Resumen de: CN120300243A
本发明提供了一种燃料电池的装配方法及燃料电池,装配方法包括:获取第一气体扩散层信息,第一气体扩散层信息由对膜电极进行接触电阻测试得到,第一气体扩散层信息包括膜电极压紧力和电阻信息的映射关系;获取第二气体扩散层信息,第二气体扩散层信息由对膜电极进行压缩特性测试得到,第二气体扩散层信息包括膜电极压紧力和气体扩散层的形变量的映射关系;基于第一气体扩散层信息和第二气体扩散层信息确定装配工艺信息,装配工艺信息包括燃料电池装配过程中对气体扩散层施加的第一压紧力;基于装配工艺信息对燃料电池进行装配。本申请解决了现有技术中由于燃料电池装配压紧力不够准确导致的燃料电池的输出性能较差的问题。
Resumen de: CN120287852A
本发明公开了一种燃料电池车辆实时储氢量和剩余续航里程计算方法,属于燃料电池的固态储氢量测量技术。该方法首先对储氢材料进行标定和循环测试分析,包括建立燃料电池电堆全生命周期内的储氢量与温度、压力关系;接着在车辆启动时获取初始储氢量,获取方式包括基于FCU读取储氢装置的温度和压力传感器数据来转化计算初始储氢量;进而在车辆运行时,实时计算燃料电池电堆的氢气消耗量和储氢装置内的剩余储氢量,基于剩余的储氢量实时计算剩余续航里程,该计算包括基于在t1到t2时间内所行驶的里程和氢气消耗量来计算。本发明能克服现有技术在车辆运行过程中基于热力学估算储氢量误差过大的不足,提高储氢装置内实时储氢量的估计精度,能够促进氢能在新能源车辆、船舶及航空器上的应用,提高续航的精准预测。
Resumen de: CN120285946A
本发明公开了一种分子筛吸附剂的制备及其在对痕量氨气高精度、高选择性吸附分离中的应用。其是利用离子交换的方式,将过渡金属离子交换到比表面积高且孔道结构适宜的分子筛结构上,得到具有高吸附精度与高吸附量的分子筛吸附剂。本发明通过筛选具有丰富孔结构与高比表面积的分子筛载体,并把分子筛结构中的阳离子交换成过渡金属离子,利用过渡金属离子与氨气间的可逆配位作用,结合分子筛孔道传质特性,协同实现痕量氨的高效捕获。所得分子筛吸附剂对低浓度氨气展现出高的吸附容量、选择性及分离精度,并具有优异的热稳定性及循环可逆性,可有效解决氨能高效利用及转换系统中痕量氨毒化催化剂的问题。
Resumen de: CN120300203A
本发明公开了一种具有锐钛矿/金红石同质结和富氧空位的TiO2载钯的双功能催化剂的制备方法。通过界面能带工程与缺陷工程的协同作用,采用溶剂热法结合高温煅烧技术,并辅以湿化学还原法,制备了一种新型的富氧空位TiO2同质结载钯的负载型催化剂。锐钛矿/金红石同质结与氧空位结构的耦合有效调控了钯的电子结构,削弱了关键中间体在其表面的吸附能。在直接甲醇燃料电池的阴极氧还原反应中表现出优异的电催化活性、良好的稳定性及高效的四电子反应路径。在阳极甲醇氧化反应中,该催化剂同样表现出优异的甲醇氧化活性和卓越的抗CO中毒性,展现出广阔的实际应用前景。
Resumen de: CN120300200A
本发明涉及电池技术领域,提供一种用于可逆质子陶瓷电化学电池的错配层状空气电极材料及应用。该电极材料包括:表达式为Ca3Co4‑xMoxO9+δ的错配层状氧化物,其中,x的取值范围为0.1~0.3,δ为氧空位含量。本发明通过提供的新型的错配层状氧化物,其具有良好的电化学稳定性,同时对氧还原反应、氧析出反应表现出较高的电催化活性。将错配层状氧化物进一步作为电极材料制得可逆的质子陶瓷电化学电池,可同时适用于化学能与电能的转换。
Resumen de: CN120300242A
本发明属于废水处理技术领域,涉及一种利用电厂废水提高液流电池电解液导电性的装置及方法。本发明通过混合精处理阳树脂再生废水和精处理阴树脂再生废水,得到精处理树脂再生废水。通过反渗透装置对精处理树脂再生废水进行浓缩得到浓缩水,浓缩水进入除氨电解槽进行除氨处理,得到高浓度的氯化钠溶液,高浓度的氯化钠溶液存储至储液罐。通过第二计量泵将氯化钠溶液泵入负极储液罐。通过第一计量泵将高浓度的氯化钠溶液泵入正极储液罐。通过循环泵将电解液循环泵入锌溴液流电池组。本发明既解决了废水处理问题,又有效提升了锌溴液流电池的储能性能,实现资源的高效利用与环境保护的双重目标。
Resumen de: CN120300940A
本发明公开了一种多机燃料电池发电系统的双层功率分配方法,属于燃料电池发电系统功率分配领域,该方法包括:根据功率预测得到的系统负载功率以及多堆燃料电池发电系统的状态进行双层功率分配,首先进行上层切换控制,以系统的第一运行成本最小为目标,在第一预设约束下求解得到确定各个燃料电池发电子系统在切换控制周期内的最优开关状态和最优输出功率;然后在下层瞬时功率分配时以系统的第二运行成本最小、跟踪最优电流轨迹距离最小、各个燃料电池电堆健康状态趋同为目标,在第二预设约束下求解得到各个燃料电池发电子系统在瞬时控制周期内的最优输出瞬时功率,使得多堆燃料电池发电系统发电总收益最高,且寿命衰减趋于一致。
Resumen de: CN120300214A
本发明属于燃料电池结构领域,具体涉及一种阻塞型针肋燃料电池流场板及燃料电池,阻塞型针肋燃料电池流场板包括双极板和流道,双极板的一端开设气体入口,另一端开设气体出口;流道内设有多排阻塞结构,每排阻塞结构中设置多个支撑柱,支撑柱之间通过堵塞壁相连接,相邻两排阻塞结构中支撑柱错列布置,堵塞壁的高度低于支撑柱的高度;本发明通过调节燃料电池内反应物的分布,提高远离对角线和气体进出口的两个角落处的氧气浓度,从而有效改善了低电压工况下缺氧区域的氧气浓度。通过周期性设置堵塞壁,干扰反应气体流动,带来周期性垂直于流场底面的流速变化,促进氧气的传质并提升排水能力,有效避免液态水的过度积聚对氧气扩散的负面影响。
Resumen de: CN120300208A
本发明属于质子交换膜电池技术领域,公开了一种燃料电池用阴极石墨极板,包括公共通道、气体分配区和活性区;阴极石墨极板上设有氢气进口公共通道、冷却水进口公共通道、空气进口公共通道、氢气出口公共通道、冷却水出口公共通道、空气出口公共通道、空气进口分配口、空气出口分配口、定位孔、气体分配区、具有缩扩结构的三维通道。本发明的阴极石墨极板通道具有三维波形结构和缩扩结构相结合的特点。本发明的阴极石墨极板上流道之间成相互错位设计。在分配区内优化了导流板的间距、排布方式及导流角度,使气体均匀的分配至双极板各通道,有助于提升燃料电堆的性能和效率。阴极石墨极板通道均采用雕刻成型,加工方便,便于批量化生产。
Resumen de: US2025226426A1
To provide a separator configured to suppress a decrease in the power generation performance of fuel cells. A separator for fuel cells, wherein the separator comprises cathode-side gas flow paths; wherein each of the cathode-side gas flow paths comprises flow path portions and restrictor portions; wherein a flow path cross-sectional area of the restrictor portions is smaller than a flow path cross-sectional area of the flow path portions; wherein at least one of the restrictor portions is an upstream-side restrictor portion disposed in an upstream of the cathode-side gas flow paths; wherein at least one of the restrictor portions is a downstream-side restrictor portion disposed in a downstream of the cathode-side gas flow paths; and wherein a flow path cross-sectional area of the at least one upstream-side restrictor portion is larger than a flow path cross-sectional area of the at least one downstream-side restrictor portion.
Resumen de: CN120300204A
本发明提供了一种铂基金属间化合物的双功能催化剂,包括碳载体,以及负载于碳载体的合金纳米颗粒;所述合金纳米颗粒包括铂与其他过渡金属元素形成的金属间化合物核芯,以及包覆于所述核芯表面的铂层,所述其他过渡金属元素选自Mn、Ni、Co、Fe、Zn中的至少一种。本发明使用浸渍还原法合成了核壳结构的铂基金属间化合物,该化合物为兼具ORR、HER催化性能的双功能催化剂,本发明中的步骤不需要使用或产生任何有毒或污染性物质,能够较为便捷地大批量制备催化性能更为优越、更难合成的金属间化合物。
Resumen de: CN120289803A
本公开涉及一种导电金属有机骨架电催化剂及其制备方法和应用该方法包括如下步骤:S1、使有机配体化合物、金属前体与溶剂混合,得到第一混合液;S2、使所述第一混合液进行超声处理后,在目标反应条件下进行反应;其中,所述目标反应条件包括:温度为80‑100℃,搅拌速率为200‑400rmp,时间为6‑12h;所述有机配体化合物含有苯环。该方法制备得到的催化剂具有较高的电导率,催化性能较高,具有较好的电化学稳定性,且制备该催化剂的原料储量丰富、成本低廉,可规模化放大生产。
Resumen de: CN120300245A
本发明公开了一种大功率氢燃料电池电堆,包括第一端板、第一集流板、燃料电池单片、第二集流板、第二端板和特殊双极板组件,紧固螺杆穿过第一端板与第二端板并通过紧固螺母固定,特殊双极板组件包括依次排列的特殊阴极侧双极板、特殊双极板隔板和特殊阳极侧双极板,燃料电池单片为两组,特殊双极板组件位于两组燃料电池单片之间,特殊阴极侧双极板上设有与第一流道相通的第三流道,特殊阳极侧双极板上设有与第一流道相通的第四流道。本发明在特殊双极板隔板上不设置允许空气、氢气、冷却液穿过的流道结构,提高电堆的输出功率能力、电堆动态响应速率和使用寿命,能够适应功率范围更宽的应用场景需求。
Resumen de: CN120300211A
本发明公开了纳米二氧化硅修饰多孔膜及制备方法和在锌溴液流电池的应用,属于电池隔膜材料技术领域,将有机烷氧基硅烷与有机溶剂混合,然后加入去离子水和氨水溶液,经搅拌混合反应,除去溶剂并干燥后,得到纳米二氧化硅;再将纳米二氧化硅超声分散在分散剂中,得到纳米二氧化硅分散液;将预处理后的多孔膜浸泡在纳米二氧化硅分散液中,至纳米二氧化硅均匀负载于多孔膜的表面上,经二次真空干燥,得到纳米二氧化硅修饰多孔膜。通过溶胶‑凝胶法合成纳米二氧化硅,并利用超声分散与浸渍工艺将其均匀负载于多孔膜表面,形成具有尺寸筛分效应和表面负电荷特性的修饰层,通过静电排斥作用抑制了溴离子的扩散,降低了自放电和副反应,提升了库伦效率。
Resumen de: CN120300222A
本发明公开了一种用于全钒液流电池储能的监控系统,包括多维数据采集传感装置、智能分析与预测系统、大数据云平台、用户界面与智能报警系统和远程控制与自动优化系统;多维数据采集传感装置集成有多项采集传感器对电池系统多维度的实时数据采集,智能分析与预测系统利用大数据分析与机器学习算法对实时采集的数据进行智能分析,大数据云平台进行集中数据存储与管理,用户界面与智能报警系统提供友好的用户界面,远程控制与自动优化系统支持远程控制功能。本发明涉及储能技术领域,本方案集成多种传感器与智能分析算法,实时获取并处理储能系统的运行数据,确保储能系统高效、安全、可靠运行。
Resumen de: CN120300237A
本发明公开了一种液流电池用高性能离子交换膜及其应用。所述离子交换膜的制备方法包括如下步骤:S1、将聚合物a、聚合物b和聚合物c溶解于有机溶剂中,形成混合溶液;S2、向混合溶液中添加模板剂,得到铸膜液;S3、将铸膜液涂覆于基板表面,经干燥得到初始膜;S4、将初始膜浸入水或有机溶剂中,去除模板剂,形成多孔结构膜;S5、将多孔结构膜置于酸性溶液中浸泡处理,得到离子交换膜;聚合物a选自聚砜、聚醚砜、聚偏氟乙烯和聚苯并咪唑中的至少一种;聚合物b为含有磺酸基团的聚合物;聚合物c选自聚吡咯、聚乙烯吡咯烷酮和聚苯并咪唑中的至少一种。本发明所制备的离子交换可适用于液流电池且具有良好的电池性能。
Resumen de: CN120300223A
本申请涉及一种电导率的调整方法、装置及车辆,涉及电池技术领域,至少解决相关技术中如何在降低冷却液的电导率的过程中减少资源消耗的技术问题。该方法包括:获取燃料电池的运行状态和冷却液的电导率参数,电导率参数用于反映冷却液的电导率的变化情况;基于燃料电池的运行状态和电导率参数,确定目标唤醒时间;在目标唤醒时间,获取冷却液的第一当前电导率;基于第一当前电导率,调整冷却液流经去离子器的流量,去离子器用于调整冷却液的电导率;如此,可以减少资源消耗。
Resumen de: CN120300210A
本发明涉及质子交换膜燃料电池技术领域,公开了一种气体扩散层及其制备方法,该气体扩散层包括位于支撑层上的第一微孔层和位于第一位微孔层上的第二微孔层,第一微孔层的厚度为25~30 μm,第二微孔层的厚度为15~20 μm,第二微孔层表面设有裂纹,裂纹的单位裂纹面积为0.0038~0.0046 cm2,该气体扩散层表面裂纹数目少,裂纹的单位面积小,不会产生十字交叉裂纹,与催化层的接触电阻小,与质子扩散膜挤压接触时不会导致质子扩散膜破损。
Resumen de: CN120294114A
本申请涉及一种液流电池电堆内耦合场分析方法和装置。所述方法包括:确定液流电池电堆的预设工作状态,控制液流循环系统中的混合介质在预设工作状态下流经电池单元;在混合介质流经电池单元内流道时,针对混合介质中的示踪介质进行图像采集,得到目标图像,并进行图像处理;针对目标图像中示踪介质的图像处理结果进行运动学分析,得到耦合场目标位置的目标运动参数和对应的统计学参数;根据目标运动参数和对应的统计学参数针对耦合场目标位置的状态进行分析,得到耦合场目标位置的状态分析结果;状态分析结果用于表征液流电池电堆中耦合场目标位置的耦合场状态特性和液流时变状态特性,以提高分析结果的准确性和可靠性。
Resumen de: CN120300224A
本申请涉及新能源技术领域,公开了一种多套燃料电池系统故障处理方法,包括获取多套燃料电池系统的原生故障码;将原生故障码根据映射关系进行编码,得到一组只有唯一值的重排故障码;当燃料电池系统发生故障时,获取对应燃料电池系统的重排故障码,并轮询发送显示;根据显示的重排故障码以及重排故障码与对应燃料电池系统的原生故障码的映射关系,快速定位到具体的故障燃料电池系统及故障类型;本申请有效避免故障码重复,方便快速定位发生故障的燃料电池系统以及发生的故障类型,同时降低总线负载率,有效解决报文丢帧甚至通讯丢失问题。
Resumen de: CN223092907U
本实用新型公开了一种一体化电堆端板结构,包括:第一端板和第二端板,设置在第二端板一侧的连接弯管组件,设置在第一端板和第二端板之间的出入组件,以及设置在第二端板一侧的背压阀单元,第一端板和第二端板镶嵌连接,连接弯管组件位于第二端板的一侧,连接弯管组件从左至右分别包括:空气入口弯管,氢气出口弯管,冷却水入口弯管,冷却水出口弯管,氢气入口弯管和空气出口弯管,背压阀单元为:空气入口背压阀和空气出口背压阀;第一端板和第二端板一体化能够实现结构的紧凑和高集成度,与传统的分散式电堆端板相比,能够减少零件的数量,降低整体体积和重量节省空间,还有助于简化制造和装配过程,从而降低生产成本。
Resumen de: US2025226430A1
With the lamination method for fuel cell components, the gas diffusion layer is laminated to the intermediate layer during the manufacturing stage of a fuel cell that includes an intermediate layer and gas diffusion layers on both sides of the intermediate layer. The intermediate layer includes an electrolyte membrane and a resin film provided around the electrolyte membrane. With the method of laminating fuel cell components, a moisture-curing adhesive is applied to the resin film. Thereafter, the gas diffusion layer is brought into contact with the adhesive, thereby laminating the gas diffusion layer and the intermediate layer with the adhesive.
Resumen de: CN120300229A
本发明提供了一种全钒液流电池电解液综合价态及各离子浓度实时计算方法,属于全钒液流电池技术领域。该方法采用参比电压计算综合价态和各价态钒离子浓度,依次对多个一元函数进行求解,对电池系统BMS的数据处理模块的计算需求低,并且操作简单,计算结果稳定,避免了随着系统长时间运行导致计算结果产生累计偏差的现象发生。
Resumen de: WO2024115026A1
The invention relates to a bipolar plate (10) for a cell (11) of an electrochemical energy converter (12), having a first flow structure (13) and a second flow structure (14) adjacent to the first flow structure (13), wherein the first and the second flow structure (14) are arranged on one side of the bipolar plate (10), wherein the first flow structure (13) is designed to distribute a medium along a first longitudinal direction (X1) of the bipolar plate (10) and wherein the second flow structure (14) is designed to distribute the medium coming from the first flow structure (13) in a second longitudinal direction (X2) and/or in a transverse direction (Y) of the bipolar plate (10).
Resumen de: CN120301046A
本发明属于PEM制氢技术领域,涉及一种可移动集装箱式氢能热电联产及余热回收装置,包括:集装箱体内的控制箱、纯水机、PEM控制柜、储能交流器、PEM制氢柜、燃料电池、集装格,本发明通过将太阳能发电、风能发电、潮汐能发电以及市政供电接入后进行PEM制氢,将制得的氢气与氧气按照不同的使用方式进行使用或存储,将不便存储的新能源转化为可以存储的氢能,或者将制得的氢气通过氧化还原反应进行发电,将不稳定电能转化为稳定电能,并将PEM制氢、氢能源发电过程中产生的热量用于生产生活供应热水或供热,并且具有可移动功能,可作为移动电站或加氢站,因此,本发明能够根据不同的外接电源形式以及不同的能源供应需求进行多种供应方式的组合及互补。
Resumen de: CN120300227A
本申请涉及液流电池技术领域,公开了一种调频型液流电池的电极调节方法、装置、设备及介质,包括:在调频型液流电池运行前,获取液流电池的电极调节参数,其中,调节参数包括液流电池的电压、电解液的初始浓度、预设缓冲时间与预设调频功率;基于调节参数,确定液流电池的电极中电解液的预留体积。本申请能够针对不同类型的液流电池,根据其特定的电压、电解液初始浓度、预设缓冲时间和预设调频功率等参数,确定最合适的电解液预留体积,实现个性化优化。通过精确计算预留电解液的体积,可以避免过度预留导致的成本增加和空间占用,从而在保证电池性能的同时,降低整体运营成本。
Resumen de: CN223092904U
本申请提供了一种燃料电池、燃料电池系统、车辆及燃料电池性能恢复系统,该申请应用于燃料电池领域,该燃料电池包括:电池本体和设置于电池本体内部的电堆,其中,电堆包括多个单体电池,多个单体电池的每个单体电池上设置有活化开关,利用活化开关对对应的单体电池进行活化动作,其中,活化开关包括:开关本体;设置于开关本体上的第一端和第二端,其中,第一端与单体电池的正极相连,第二端与单体电池的负极相连;设置于开关本体上的可活动连接件。该申请能够利用单体电池对应的活化开关与单体电池正负极的连接,从而针对弱单电池或者弱电池区域进行局部活化,以实现对电堆的局部区域的性能恢复,提高系统的使用寿命。
Resumen de: CN223092903U
本实用新型公开了一种80kW燃料电池发动机结构,包括:电池电堆,设置在电池电堆底部的冷却子系统,设置在电池电堆一侧的氢气子系统,设置在电池电堆一侧的空气子系统,以及设置在电池电堆一侧的控制组件:电池电堆的底部固定连接有电堆连接组件,氢气子系统位于电池电堆的一侧,氢气子系统包括氢气引射器组件、氢气入堆组件、汽水分离器和氢气出堆组件,本实用新型中提供一种80kW燃料电池发动机结构,通过取消氢气循环泵和空气增湿器,显著简化系统架构,降低生产成本和维护成本,不仅减少整体系统的复杂性,还提高系统的可靠性和耐用性,同时,简化的结构也减小发动机的体积和重量,使其更加适用于多种应用场景。
Resumen de: CN223092906U
本申请提供了一种燃料电池系统机箱及燃料电池系统,属于燃料电池设备技术领域。燃料电池系统机箱包括:箱体,箱体内部形成适于容纳燃料电池组件的容纳腔;支撑部,支撑部设置于箱体的底部,支撑部适于与地面抵接以避免箱体倾倒。本申请提供的燃料电池系统机箱,具有防倾倒性能,可以提高燃料电池系统的稳定性和安全性。
Resumen de: CN223092900U
本实用新型涉及液流电池技术领域,具体的说是一种液流电池用液流框,包括板体,板体中部设有用于容置多孔电极的矩形通孔,板体一侧的板面上在矩形通孔上下两侧各设置有一个与矩形通孔连通的电解液流道;电解液流道与矩形通孔连通的一侧边线性间隔设置有若干导流块,若干导流块之间形成连通电解液流道和矩形通孔的若干分液流道;通过在连通矩形通孔一侧边,线性、间隔设置若干导流块,从而形成的若干分液流道,便于提高电解液进出多孔电极时的均匀性,从而提高电池内部电流密度的均匀性,提高电池运行的可靠性。
Resumen de: CN223092905U
本申请实施例公开了一种电堆及电堆保护组件,其中电堆保护组件包括能够支撑电堆的侧壁的支撑组件,支撑组件包括支撑板,电堆的上侧壁、下侧壁、左侧壁和右侧壁中的至少两个侧壁上设置支撑板,支撑板通过封装箱体压紧在侧壁上,以向侧壁提供支撑力。支撑板沿垂直于端板方向的长度设置,使得支撑板能够对两个端板之间的单体进行支撑。支撑组件与端板配合,实现在对电堆的端面支撑的基础上,增加了对电堆的侧面支撑,优选地,电堆的四个侧壁均通过支撑组件进行支撑,以减小电堆的单体在使用过程中发生的位移,从而解决了电堆结构不牢靠的问题,降低电堆损伤。
Resumen de: CN120300215A
本发明提供一种氢燃料电池双极板及其生产设备,涉及一种双极板结构,包括相贴合设置的阳极板和阴极板,阳极板和阴极板的中间部位分别压制成型有凹部,且阳极板的凹部和阴极板的凹部为一一对应设置,用以合围形成冷却液流道,阳极板的凹部之间通过阳极连板相连,阴极板的凹部之间则通过阴极连板相连,阳极连板和阴极连板之间也为一一对应贴合连接,且阳极连板和阴极连板上还设置有至少两组相互卡接设置的卡接槽口部,本发明可以达到优化阴极板、阳极板之间固化效果的目的,同时也可以实现更加便捷且自动化程度更高的阴极板、阳极板涂胶压合操作,以此来提升电池生产的加工效率。
Resumen de: CN120300197A
本发明公开了一种用于提升空冷电堆寿命和耐高温的工艺,包括以下步骤:S1、配置燃料电池浆料:原料A、1‑2%,纯水、10‑20%,树脂、1‑3%,醇类溶剂、60%‑80%;S2、配置导电透气保水层浆料:原料B、0.7‑1.2%,纯水、10‑15%,树脂、2‑4%,醇类溶剂、70%‑85%;S3、将质子交换膜放到喷涂机上先进行燃料电池浆料喷涂形成催化层,将导电透气保水层浆料喷涂到催化层或者气体扩散层上,厚度为4微米‑6微米;S4、将喷涂好的质子交换膜进行裁切、边框贴合、贴扩散层组成膜电极然后组装电堆。本发明,在催化层和气体扩散层中间加入了一层导电透气保水材料,形成了一种多层导电透气保水结构,改变了原有膜电极结构;特定的保水材料使得电堆在使用过程中保持相对的湿润。
Resumen de: CN120300220A
本申请提供一种燃料电池系统和循环气体在线收集方法,属于燃料电池技术领域。该燃料电池系统包括电堆和氢气供应子系统,氢气供应子系统包括引射器、气水分离器、集气阀、排氢排水阀以及设有进口阀和出口阀的集气袋;引射器的第一输入端用于接收氢气,引射器的输出端与电堆的阳极输入端连接,电堆的阳极输出端与气水分离器的输入端连接,引射器的第二输入端和集气阀的输入端均与气水分离器的第一输出端连接,集气阀的输出端与进口阀连接,气水分离器的第二输出端与排氢排水阀的输入端连接,排氢排水阀的输出端和出口阀均连通大气环境。本申请能够在电堆的运行过程中有效地收集循环气体以辅助后续分析。
Resumen de: CN120294589A
本发明公开了平板式固体氧化物燃料电池电流分布测试的方法和装置,测试方法包括:S1、电池非破坏性分区;S2、分区间的侧向电流控制;S3、分区与夹具绝缘;S4、分区电流采集与工作控制;S5、数据后处理,测试装置包括:模块化壳体机构、霍尔传感器阵列和PCB电路板组件,模块化壳体机构包括装置外壳和接线组件,霍尔传感器阵列包括霍尔电流传感器和霍尔电流传感器直流电源,PCB电路板组件包括供电线组件和数据连接组件。与现有技术相比,本发明的有益效果是,将创新电池分区测试方法与霍尔电流传感器测量结合起来,实现了电池非破坏、易实现、可调节的分区表征,测量过程中始终保持各分区处于等电势工作,可得电池真实服役状态下的电流分布规律。
Resumen de: CN223082436U
本实用新型公开了一种内置式管道系统过滤器及液流电池管道系统,属于液流电池技术领域,本实用新型提供的液流电池用内置式管道系统过滤器,包括滤网和支撑骨架,支撑骨架整体与锥形滤网相互匹配、可套接安装在一起,且其底部设有密封凸台;滤网底部设有与密封凸台相匹配的安装凸台,安装凸台与密封凸台连接,滤网和支撑骨架套接后设于第一管道内;密封凸台与第一管道连接。本实用新型能够解决现有技术液流电池循环系统中过滤装置具有占地面积大,成本高,泄露风险大,流体阻力大等技术问题。
Resumen de: CN223092902U
本实用新型涉及一种用于水冷和风冷结合冷却的燃料电池流场板,包括矩形的石墨板,石墨板的上、下侧均成型有水冷通道和氢气通道,石墨板的前端面上成型有若干道呈竖向分布的空气流槽,空气流槽的两端分别成型有贯穿石墨板后端面的出气孔和进气孔;所述石墨板的两侧边分别成型有与出气孔和进气孔相连通的出气槽口和进气槽口。本流场板流场板的侧边开设多个进气口,配合设计的大流量风槽,可采用普通风机送风供氧,同时可以采用水泵冷却配合电堆的冷水系统进行冷却,能保证均匀控温又满足供氧。
Resumen de: CN223092899U
本实用新型公开了一种大功率燃料电池双极板结构,包括两个进出口区、两个分配区和反应区;进出口区分为进口区和出口区位于双极板左右两侧区域,双极板左侧由上至下包括:第一冷却液腔、第二空气出口腔,氢气入口腔、第一空气出口腔和另一个第一冷却液腔;双极板右侧由上至下包括:第二冷却液腔、第一氢气出口腔、空气入口腔、第二氢气出口腔和另一个第三冷却液腔;通过空气导流组件和氢气导流组件的设置,例如空气在流道的作用下在到达来两个空气出口腔后分为两股,两股分别从两个空气出口腔流出,将常规的双极板一进一出改为一进两出后,氢气导流组件和空气导流组件的结构相同,从而使得空气流阻将会得到很多改善。
Resumen de: CN223092898U
本实用新型公开了一种燃料电池发动机端板结构,包括:燃料电池内侧端板和燃料电池外侧端板,设置在燃料电池内侧端板和燃料电池外侧端板之间的空气出入单元,以及设置在燃料电池内侧端板和燃料电池外侧端板之间的氢气出入单元;本实用新型中提供一种燃料电池发动机端板结构,内侧端板冷却水入口通道和外侧端板冷却水入口通道重合、内侧端板冷却水出口通道和外侧端板冷却水出口通道重合的设置,能够有效地利用出口高温冷却水对入口冷却水进行预热,不仅显著提高燃料电池发动机在低温环境下的冷启动时间和效率,还降低对发动机本身的潜在损害,其次,将冷却水入口的设置,使得冷却水在进入电堆内部之前能够先被电堆发出的热量加热。
Resumen de: CN223092901U
本实用新型公开了一种用于氢燃料电池电堆的集流板,涉及集流板技术领域。本实用新型包括第一集流板和第二集流板,第一集流板和第二集流板表面均开有氧化剂注入槽,第一集流板和第二集流板表面均开有冷却液注入槽,第一集流板和第二集流板表面均开有氢气注入槽;氧化剂注入槽一侧开有氧化剂通道,氧化剂通道远离氧化剂注入槽一端开有氧化剂流出口;冷却液注入槽一侧开有冷却液流通通道。本实用新型通过加强筋的作用,该装置在冷却液流通通道的空白处加设了加强筋,这种设置可以大大的加强第一集流板和第二集流板集成后的强度,避免在使用时由于振动或者摩擦导致第一集流板和第二集流板变形受损,以此延长该装置的使用寿命。
Resumen de: JP2024160406A
To provide a gas diffusion composite material for a fuel cell which is a thin layer and has reduced electric resistance such as contact resistance, and a solid polymer fuel cell having the same.SOLUTION: A gas diffusion composite material for a fuel cell has a porous base material sheet composed of a conductive material, and a microporous carbon layer containing a particulate and/or fibrous carbon material and a water-repellent resin and has any one structure of the following structures (A) to (E). (A): structure in which one surface of the porous base material sheet is covered with the microporous carbon layer. (B): structure in which both surfaces of the porous base material sheet are covered with the microporous carbon layer. (C): structure in which one surface of porous base material sheet is coated with microporous carbon layer, and at least part of the microporous carbon layer penetrates into inside of the porous base material sheet. (D): structure in which one surface of the porous base material sheet is covered with the microporous carbon layer and at least part of the microporous carbon layer penetrates into inside of the porous base material sheet, and the microporous carbon layer reaches opposite surface from one surface of the porous base material sheet. (E): structure in which all of the porous base material sheet is embedded in the microporous carbon layer.SELECTED DRAWING: Figure 12
Resumen de: TW202422920A
The present invention relates to a gas diffusion layer for fuel cells, wherein the gas diffusion layer comprises a microporous layer having a polymeric binder which is fluorine-free or has a lower proportion of fluorine-containing polymers than conventional binders. Furthermore, the present invention relates to a gas diffusion layers available by this method and a fuel cell containing such gas diffusion layer.
Resumen de: WO2024207147A1
A stack device for a water electrolysis stack or a fuel cell, comprising at least one stack unit. Each stack unit comprises a catalyst coating film, a cathode assembly, and an anode assembly; the cathode assembly and the anode assembly are respectively provided on two opposite sides of the catalyst coating film; the anode assembly comprises an anode diffusion layer, and the anode diffusion layer comprises a first diffusion layer and a second diffusion layer stacked on each other in the thickness direction of the stack unit; the first diffusion layer and the second diffusion layer are configured to allow a fluid to flow therethrough into and out of the catalyst coating film; a plurality of first conveying channels and a plurality of second conveying channels are formed between the first diffusion layer and the second diffusion layer; the plurality of first conveying channels and the plurality of second conveying channels extend in a direction perpendicular to the thickness direction of the stack unit, and the plurality of second conveying channels are provided closer to the first diffusion layer relative to the plurality of first conveying channels. Also provided are a water electrolysis stack and a fuel cell comprising the stack device.
Resumen de: CN120300228A
本申请提出一种燃料电池停机方法、装置、电子设备和存储介质,其中,方法包括响应于接收到的燃料电池的停机指令,调整燃料电池当前的放电电流并稳定运行,在运行一段时间后,衡量燃料电池性能的衰减率,来确定是否需要执行性能恢复程序,以及选取温度对应的吹扫参数,对燃料电池中的液态水或水蒸气进行吹扫,直至燃料电池的燃电阻抗满足阈值,结束吹扫,最后通过再次调整燃料电池的放电电流,在燃料电池满足预设条件的情况下,确定燃料电池停机。从而可以在燃料电池停机前,逐步降低燃料电池的输出电压,避免造成催化剂载体腐蚀,恢复电池性能,以及更彻底地排出电池内部液态水和水蒸气,使得燃料电池停机的安全性和可靠性更高,延长电池寿命。
Resumen de: CN120300209A
本发明公开了一种碳纤维石墨复合双极板及其制备方法,属于燃料电池技术领域。所述碳纤维石墨复合双极板的制备方法,包括如下步骤:S01:树脂和导电剂在碳纤维布两侧进行涂布;S02:按照极板活性区的尺寸裁剪涂布后碳纤维布;S03:将裁剪后的涂布后碳纤维布放置在第一模具中,压制成型出极板活性区所需流场,脱模后获得流场样品;S04:将脱模后的流场样品放置在第二模具中,通过注塑成型出与活性区结合良好的过渡区及密封区;S05:将步骤S04中获得的产品进行后处理后,获得碳纤维石墨复合双极板。本发明制备获得的碳纤维石墨复合双极板能提高分配区流场深度及细密程度,并进一步提高极板气密可靠性,降低电池间的短路风险。
Resumen de: US2025226425A1
The lamination jig for fuel cell components includes a lower jig with an upper surface configured to allow the intermediate layer to be arranged thereon; and an upper jig with a lower surface configured to allow the gas diffusion layer to be arranged thereon. The lamination jig for fuel cell components is configured to be settable to a state for lamination in which the gas diffusion layer is arranged on the lower surface of the upper jig, the intermediate layer is arranged on the upper surface of the lower jig, and an adhesive is applied to at least one of an upper surface of the intermediate layer or a lower surface of the gas diffusion layer. The upper jig is lowered from the state for lamination to press the gas diffusion layer against the intermediate layer, thereby laminating the gas diffusion layer to the intermediate layer using the adhesive.
Resumen de: US2025222485A1
An adhesive application system applies an adhesive to an intermediate layer at a stage of manufacturing a fuel cell including the intermediate layer and gas diffusion layers on both sides thereof. The adhesive application system includes an applier, a robot arm, and a controller. The applier applies the adhesive when a valve is opened. The robot arm is capable of moving the applier. The controller controls the valve and the robot arm. The controller opens the valve before the applier reaches a position immediately above an application start point while moving the applier by the robot arm, thereby applying the adhesive in the form of a line to the intermediate layer from the application start point.
Resumen de: CN120300246A
本发明申请涉及氢燃料电池组技术领域,具体涉及一种具有防泄漏组件的无人机用氢燃料电池组,包括层叠的氢燃料电池板和泄漏检测装置。泄漏检测装置含泄漏监测装置,层叠缝隙处均设引导结构,其引导管条一侧开口覆盖缝隙形成引流气道,与泄漏监测装置连通;引导管条贴合边设粘连胶层和密封胶条,连接处设卡接固定机构,含插装接头、固定卡接头。泄漏监测装置包括与卡接头出气口连通的集流管道,内设封闭装置和检测传感器。外侧设贴合限位机构,含固定安装架、拼装固定层和防尘过滤层,拼装固定层由按压和拼装包裹架组成,通过螺栓、卡轴固定。本发明申请可引导泄漏氢气至监测装置,及时报警并封闭管道,避免扩散同时保证散热,提升安全性和稳定性。
Resumen de: CN120300244A
本发明公开了一种大功率氢燃料电池电堆,包括第一端板、第一集流板、燃料电池单片、第二集流板、第二端板和特殊双极板组件,紧固螺杆穿过第一端板与第二端板并通过紧固螺母固定,特殊双极板组件包括特殊阴极侧双极板和特殊阳极侧双极板,燃料电池单片为两组,特殊双极板组件位于两组燃料电池单片之间。本发明在特殊阳极侧双极板上不设置允许空气穿过的空气流道结构,或在特殊阴极侧双极板上不设置允许氢气穿过的氢气流道结构,或在特殊阳极侧双极板上不设置允许空气穿过的空气流道结构,特殊阴极侧双极板上不设置允许氢气穿过的氢气流道结构,提高电堆的输出功率能力、电堆动态响应速率和使用寿命,能够适应功率范围更宽的应用场景需求。
Resumen de: CN120300234A
本公开涉及烃基动态共价聚合物电解质和包括其的燃料电池。具体描述了一种烃基动态共价聚合物电解质以及包括该烃基动态共价聚合物电解质的燃料电池,该燃料电池能够在高温和无湿度的条件下操作。
Resumen de: CN120300198A
本发明公开了一种铂修饰的非贵金属催化剂及其制备方法和燃料电池。所述制备方法包括:S1、利用非贵金属盐和含氮有机配体进行反应,制备ZIF材料,热处理,得到非贵金属催化剂;其中,非贵金属盐包括锌盐和掺杂元素的盐,掺杂元素选自Fe、Co、Ni、Cu、Mn、Mo和Cr中的至少一种;S2、将非贵金属催化剂与铂源在溶剂中分散,蒸干溶剂得到固体产物;S3、对固体产物进行热处理,得到铂修饰的非贵金属催化剂;铂修饰的非贵金属催化剂中的铂元素的质量含量在5%以下。本发明制备的催化剂具有优秀的氧还原反应活性和良好的稳定性。而且,反应条件容易控制,操作简单,生产效率高,成本低廉,有利于规模化生产。
Resumen de: JP2024077709A
To provide a carbon catalyst which exhibits high catalytic activity while effectively avoiding problems attributable to iron, an electrode, and a battery.SOLUTION: A carbon catalyst has a ratio L/La of at least 12, where L/La means a ratio of an average carbon mesh surface size L, obtained by temperature-programmed desorption analysis capable of temperature raising to 1600°C, to the crystallite size La, obtained from a diffraction peak near a diffraction angle (2θ) of 43° in an X-ray diffraction pattern based on powder X-ray diffraction using a CuKα ray. The carbon catalyst has an iron content of 3000 ppm or less.SELECTED DRAWING: None
Resumen de: CN120300225A
本发明公开了一种快速定位燃料电池内漏位置的检测方法,属于燃料电池技术领域。所述快速定位燃料电池内漏位置的检测方法,包括如下步骤:S01.电堆预处理:在测试台用氮气吹扫氢腔、氧腔及水腔,确保腔体无残留氢氧气体;S02.气体通入:氢腔、氧腔通入氮气;水腔通入氢气,电堆产生初始电压并记录;S03.电堆升压控制:水腔进行升压到水腔压P,氢氧腔进行升压到氢氧腔压P1,要求P1<P,在维持时间内记录单电池电压数据;S04.泄漏判定:若某单节电池电压在维持时间内监测到有下降显著变化则判断该单电池水窜氧,若电压有上升显著变化则判断为水窜氢。本发明的检测方法能够精准定位、快速高效、无需复杂设备、模式区分明确。
Resumen de: CN120300221A
本申请公开了一种燃料电池系统运行模式切换控制方法、装置、设备及介质,应用于燃料电池技术领域,包括确定燃料电池系统满足热待机模式切换条件时,控制燃料电池系统切换至热待机模式运行;在燃料电池系统运行在热待机模式的过程中,控制阴极系统间歇性向电堆提供第一压力的空气以及控制阳极系统间隙性向电堆提供第二压力的氢气,以使电堆的阳极系统不存在氢空界面,电堆的阳极系统不存在氢空界面包括使电堆的开路电压维持在目标电压范围内,从而通过使燃料电池系统的开路电压维持在较高电压值,可以缩小燃料电池系统在热待机模式和正常发电模式的输出电压差,进而可以提高燃料电池系统在热待机模式与正常发电模式之间切换时的响应性能。
Resumen de: CN120289087A
本申请公开了结晶型封接玻璃粉及其制备方法、封接玻璃及金属支撑固体氧化物燃料电池,涉及车辆技术领域。应用于金属支撑固体氧化物燃料电池,其组成包括:SiO2、B2O3、Al2O3、ZnO、轻稀土氧化物及碱土金属氧化物。通过添加轻稀土氧化物能够有效抑制玻璃中硼的挥发,减少封接玻璃中孔洞的产生,提高封接玻璃的气密性,同时添加碱土金属氧化物和轻稀土氧化物能够有效调节膨胀系数和特征温度,使得封接流动性更好,膨胀系数更高,使得玻璃具有匹配固体燃料电池密封需求的膨胀系数和工作温度。本申请的结晶型封接玻璃粉在封接过程中发生晶化,与SOFC其他组件的热膨胀系数匹配。
Resumen de: CN120287571A
本发明提供了一种燃料电池用阳极支撑体的光固化3D打印制备方法,其步骤包括:取光敏树脂、三元共混光引发剂、流平剂、消泡剂混匀得树脂预混液;取8YSZ粉体、NiO粉体、分散剂加到树脂预混液中混匀并真空除泡得阳极支撑体浆料;对阳极支撑体进行包括流道整体结构设计、流道口截面设计、流道内表面设计的设计得阳极支撑体三维模型;将阳极支撑体三维模型按一定的分层厚度切片,并导入光固化3D打印设备,加入所述阳极支撑体浆料,逐层打印、固化,得阳极支撑体生坯;将阳极支撑体生坯依次脱脂与烧结得光固化3D打印阳极支撑体。本发明提供的燃料电池用阳极支撑体的光固化3D打印制备方法,方法简单可行,且制备的阳极支撑体质量较高。
Resumen de: WO2024176963A1
Provided is a hollow fiber membrane module which makes it possible to minimize a load imposed on a hollow fiber membrane. The present invention is characterized in that: the inner peripheral surface of a case 100 and a plurality of hollow fiber membranes 220 have provided therebetween a pair of planar parts 211, 212 that form a passage for a fluid flowing outside the hollow fiber membranes 220; the pair of planar parts 211, 212 are provided with a plurality of through-holes 211a, 212a that serve as passages for the fluid flowing outside the membranes; and in regions of the pair of planar parts 211, 212 where the plurality of through-holes 211a, 212a are provided, the total area occupied by the plurality of through-holes 211a, 212a accounts for 30% or more with respect to the total surface area of the sides where the plurality of hollow fiber membranes 220 are disposed, and the width of each of the through-holes in a direction parallel to the plurality of hollow fiber membranes 220 is 10 mm or less.
Resumen de: CN120300238A
本发明公开了一种空气电极支撑型质子陶瓷燃料电池的制备方法,首先球磨配制相转化浆料,然后通过相转化流延‑旋涂‑浸渍技术制备具有直通孔的BZCYYb支撑体,再利用旋涂法制备电解质层,通过丝网印刷‑烧结法制备NiO‑BZCYYb复合燃料极,最后浸渍空气极活性材料而得到具有纳米结构和规则且贯通的直通孔结构的空气电极支撑型质子陶瓷燃料电池。该方法能够解决极化阻抗增大的问题,以及避免空气极与电解质反应,提高电解质的电导率。
Resumen de: CN120292049A
一种含氧气储存装置和变压吸附装置的IGFC系统及方法,所述系统包括空气分离装置、氧气储存罐、气化炉、废热锅炉、飞灰处理装置、脱硫装置、变压吸附装置、空气压缩和透平装置、膨胀机、加热装置、固体氧化物燃料电池、富氧燃烧室、废气透平装置、蒸汽轮机、余热锅炉、甲烷合成装置、水供给装置、热交换器和燃气供热装置;该系统利用氧气储存装置将无法及时消纳的新能源转化为O2储存并供给IGFC系统内部元件;同时利用变压吸附装置分离IGFC系统净化气中的H2,并将分离出的H2与IGFC系统富氧燃烧室产生的高浓度CO2在甲烷合成装置中生成甲烷供给气负荷,提高系统整体的能源利用率,降低碳处理过程中的碳捕捉、压缩和运输的成本。
Resumen de: CN120300212A
本申请公开了一种流动型钒基电燃料储能供能系统,包括:电堆反应模块、电解液驱动模块以及介质存储模块,电堆反应模块包括两两相邻设置的析氧反应流动单元、钒电解液流动单元以及氧还原反应流动单元;析氧反应流动单元中第一流场板上设有仿生树突状叉指型的第一流道;钒电解液流动单元中第二流场板上设有双向螺旋叉指型的第二流道;氧还原反应流动单元中第三流场板上设有多级分形叉指型的第三流道;介质存储模块包括钒电解液储罐和反应介质储罐,钒电解液储罐和反应介质储罐设置于电堆反应模块的相对两侧,钒电解液储罐与第二流场板连接,反应介质储罐分别与第二流场板和第三流场板连接。该系统在降低成本的基础上提高了系统的集成度。
Resumen de: CN120300239A
本发明属于液流电池技术领域,提供一种延长硫铁氧化还原液流电池循环寿命的方法,具体包括:(1)绘制标准硫铁氧化还原液流电池的吸光度曲线作为标准曲线;(2)取待测硫铁氧化还原液流电池,绘制SOC低于标准硫铁氧化还原液流电池的吸光度曲线;(3)当待测硫铁氧化还原液流电池的吸光度曲线在多硫离子特征吸收波长的峰值低于标准曲线时,将电池硫侧电解液更换为新鲜电解液。本发明提供的硫铁电池电解液浓度的紫外测定方法不需要特殊的仪器,且操作过程简单、迅速,无需借助其他化学试剂辅助,分析结果准确可靠,通过对硫侧电解液中活性离子的补充来达到延长电池寿命的效果。
Resumen de: CN120300240A
本发明涉及一种全钒液流储能设备的储能方法,属于全钒液流储能技术领域。包括以下步骤:S1:选用电池堆;S2:选用合适大小的电解液储液罐;S3:准备电解液;S4:布设循环流动管路;S5:布设热交换器;S6:通入电流储能;S7:控制及监控:通过控制系统对全钒液流储能设备的开闭进行控制。本发明提供一种全钒液流储能设备的储能方法,通过选用电池堆、选用合适大小的电解液储液罐、准备合适浓度电解液、布设循环流动管路、布设热交换器、通入电流储能、控制及监控实现电能的储存与释放,使得全钒液流储能设备具有长寿命、高安全性、环境友好以及适合大规模储能的优点,为可再生能源的存储和利用提供了新的选择。
Resumen de: CN120289736A
本发明提供了一种超高分子量的碱性聚合物电解质及其制备方法,属于碱性聚合物电解质技术领域。本发明采用协同慢缩聚的方法在聚合反应过程中引入少量的具有多个反应位点、高反应活性的聚合单体,通过控制反应温度、加料方式、单体加入的节点以及反应结束的节点等制备得到碱性聚合物,进一步通过亲核取代改性制备得到超高分子量的碱性聚合物电解质。所述超高分子量的碱性聚合物电解质具有类似蛋白质折叠结构的“多级结构”,进而具备优异的力学性能以及加工能力,使其具有良好的应用和发展前景。
Resumen de: CN120300236A
本申请涉及电池材料领域,具体涉及一种MPC聚合物改性的多孔聚合物膜和复合质子交换膜。所述改性多孔聚合物膜表面修饰有式I化合物,#imgabs0#其中R为#imgabs1#n为200‑2000,其中多孔聚合物膜选自:多孔聚乙烯膜、多孔聚芳醚类膜、多孔聚丙烯膜、多孔聚氟乙烯膜、多孔聚偏氟乙烯膜。本申请实施例使用经2‑(甲基丙烯酰氧基)乙基磷酸胆碱聚合物修饰的多孔聚合物膜和全氟磺酸树脂制备的复合质子交换膜的强度大于63Mpa,断裂伸长率大于80%,电导率大于0.102S/cm,优于进口Gore质子交换膜,在质子交换膜领域具有广阔应用前景。
Resumen de: CN120300226A
本发明涉及一种燃料电池快速故障诊断方法及装置,属燃料电池领域。其中,该方法包括执行燃料电池初始化协议并读取燃料电池运行特征参数;基于燃料电池运行特征参数构建故障特征辨识体系,故障特征辨识体系用于热力学边界异常检测、空滤堵塞故障特征辨识、阀门泄漏诊断和空压机性能衰减诊断,其中阀门泄漏诊断融合温差自适应修正协议,温差自适应修正协议通过补偿进气介质通量触发。本发明实现了通过集成化的监测系统和智能化的诊断算法,实现对故障原因的快速、准确判断,从而提高燃料电池系统的可靠性和维护效率。
Resumen de: CN120300217A
本发明涉及燃料电池技术领域,尤其涉及一种燃料电池氢进系统及车辆,燃料电池氢进系统的结构包括氢气气源;加热部,连通于所述氢气气源,用于加热氢气;氢进模块,连通于所述加热部;电堆,连通于所述氢进模块;水分部,连通于所述电堆,所述氢进模块连通于所述水分部;以及尾气排放部件,连通于所述水分部。该燃料电池氢进系统及车辆能够解决在现有的燃料电池氢进系统中,电堆易受到液态水的影响的问题。
Resumen de: CN120300218A
本申请提供多堆共轨燃料电池阳极供气装置及其控制方法和控制设备,属于燃料电池技术领域。该装置包括第一均压腔、第二均压腔、至少两个喷射器、至少两个引射器和至少两个电堆,第一均压腔的输入端用于接收氢气,第一均压腔的输出端与至少两个喷射器的输入端连接,至少两个喷射器的输出端与至少两个引射器的第一输入端一一对应连接,至少两个引射器的输出端与至少两个电堆的阳极输入端一一对应连接,至少两个电堆的阳极输出端均与第二均压腔的输入端连接,第二均压腔的输出端与至少两个引射器的第二输入端连接。本申请能够使得供应至各电堆的氢气共轨均匀,确保各电堆稳定运行。
Resumen de: CN120300216A
本发明属于液流电池技术领域,公开了一种利用热泵技术实现热管理的全钒液流电池系统及控制方法,电解液换热系统由电解液储罐、电机和电解液换热器组成,三者形成闭合回路,电解液储罐内盛装有电解液,冷媒换热系统由换热介质、电机和冷媒换热器组成,三者形成闭合回路,电解液换热系统和冷媒换热系统之间的管道上设有调节阀,电解液储罐设有温度传感器,控制系统与换向阀、调节阀、温度传感器电连接,换向阀一端与压缩机进口和出口相连,换向阀另一端分别与电解液换热器和冷媒换热器内部管路进口相连。整合加热和制冷为一个系统,解决了当前全钒液流电池系统换热能耗高的问题,可以有效提升全钒液流电池系统的效率。
Resumen de: CN120294595A
本发明提供一种燃料电池电堆单片电压巡检模块及系统,通过在巡检模块中设置的电堆单片电压连接器、单片电压检测电路、辅助供电电路以及通信电路实现对电堆单片电池进行电压检测;本发明通过电堆向巡检模块提供低压辅助电源,避免了外部的辅助供电,简化了系统;并且检测回路与电源回路分别采用不共用的检测线和电源线与电堆单片电池连接,避免了辅助电源电流对检测的影响,提高了检测准确性和精度。
Resumen de: CN120300219A
本申请涉及新能源车辆技术领域,公开了一种混合循环供氢大功率燃料电池控制系统及控制方法,包括一端与氢气源连接的氢气换热器,所述氢气换热器的另一端连接有用于气体压力调节引射能力的比例阀,所述氢气换热器与所述比例阀的输入端之间设置有用于监测进比例阀前气体压力的高压传感器,所述比例阀的输出端与引射器的高压输入端连接,所述引射器的输出端与电堆的入口连接,所述引射器的低压输入端连接有旋转阀,所述旋转阀的第一输入端连接有氢泵,所述旋转阀的第二输入端与所述电堆的出口连接,所述氢泵的输入端与所述电堆的出口连接;本申请可满足系统压升需求,有效扩大应用范围,避免增加额外的电功耗。
Resumen de: CN120300230A
本发明提出一种耦合氨分解的混合动力系统,包括液氨罐(1)、换热器(2)、反应器(3)、氢氮分离装置、内燃机、燃料电池(5)、尾气换热装置(11),液氨罐储存的液氨先输出至换热器预热,然后通过反应器分解为富氢混合气,富氢混合气经氢氮分离装置(4)处理后的产物先通入燃料电池发电,然后将燃料电池输出的余气输入内燃机燃烧,使内燃气驱动发电机(7)发电,燃料电池和发电机均与储能电池相连以存储电能;本发明特别适用于清洁能源利用、高效发电和动力输出领域。该系统通过液氨分解、燃料电池发电、内燃机燃烧以及余热回收等技术的协同作用,能实现能源的高效利用和清洁排放。
Resumen de: WO2025147394A1
A method is disclosed for making a solid oxide electrochemical cell stack, including steps of providing a first moldable composition having a first liquid composition and first particles adapted to form an interconnect when sintered, providing a second moldable composition comprising having a second liquid composition and second particles adapted to form an anode when sintered, providing a third moldable composition having a third liquid composition and third particles adapted to form an electrolyte when sintered, and providing a fourth moldable composition having a fourth liquid composition and fourth particles adapted to form a cathode when sintered. An unsintered electrochemical cell stack is produced by sequentially printing a first layer mold and depositing within the first layer mold one of the first, second, third and fourth moldable compositions. Subsequent layer molds and are printed and another of the first, second, third and fourth moldable compositions is deposited within each of the subsequent layer mold.
Resumen de: WO2025146398A1
The invention relates to an electrochemical system (10a; 10b; 10c; 10d; 10e; 10f; 10g) comprising a first electrochemical unit (12a; 12b; 12c; 12d; 12e; 12f) and at least one other electrochemical unit (14a, 16a; 14b, 16b; 14c, 16c; 14d, 16d; 14e, 16e; 14f, 16f) which is fluidically connected in parallel to the first electrochemical unit (12a; 12b; 12c; 12d; 12e; 12f). According to the invention, the electrochemical system (10a; 10b; 10c; 10d; 10e; 10f; 10g) comprises a central fluid supply module (18a; 18b; 18c; 18d; 18e; 18f; 18g) with a fluid delivery unit (20a; 20b; 20c; 20d; 20e; 20f; 20g), in particular an individual fluid delivery unit, for supplying the first electrochemical unit (12a; 12b; 12c; 12d; 12e; 12f) and the at least one other electrochemical unit (14a, 16a; 14b, 16b; 14c, 16c; 14d, 16d; 14e, 16e; 14f, 16f) with an oxygen-containing fluid.
Resumen de: WO2025146930A1
Disclosed is a catalyst layer for a fuel cell having improved water repellency, thermal conductivity, and output. The catalyst layer according to one aspect comprises a catalyst and a functional surface layer disposed on at least one surface thereof, the functional surface layer comprising functional nanoparticles comprising any one or more selected from the group consisting of a first fluorinated carbon nanoparticles, boron nitride nanoparticles, fluorinated boron nitride nanoparticles, and a composite containing second fluorinated carbon nanoparticles and IrOx nanoparticles (x is 1, 2, or 3).
Resumen de: WO2025146932A1
The present invention relates to a method and an apparatus for processing an electrolyte solution containing vanadium ions, and performs a charge reaction, a discharge reaction and a reverse charge reaction so that, in the charge reaction, impurities contained in a first electrolyte solution can be removed and, in the reverse charge reaction, impurities contained in a second electrolyte solution can be removed. Therefore, impurities contained in the electrolyte solution containing vanadium ions can be efficiently removed without repeatedly performing, several times, a charging reaction on the electrolyte solution containing vanadium ions.
Resumen de: WO2025146933A1
The present invention relates to an apparatus and a method for processing of an electrolyte solution containing vanadium ions, the apparatus comprising: a first electrolyte solution storage part for storing an electrolyte solution containing vanadium ions; a first impurity removal part, which is connected to the electrolyte solution storage part and primarily removes, by means of a charge reaction, impurities from the electrolyte solution containing vanadium ions; a second impurity removal part, which reacts the electrolyte solution containing vanadium ions, that has passed through the first impurity removal part, with an extractant so as to secondarily remove impurities; and a second electrolyte solution storage part for recovering and storing the electrolyte solution containing vanadium ions, that has passed through the second impurity removal part, wherein the temperature required for the second impurity removal part is provided by the first impurity removal part.
Resumen de: WO2025147067A1
The present invention relates to a method and an apparatus for processing an electrolyte solution containing vanadium ions, wherein the impurities contained in a solution to be processed can be removed even at a relatively low voltage through a multi-stage oxidation-reduction reaction using a counter solution, so that the impurities contained in the electrolyte solution containing vanadium ions can be efficiently removed even without repeating a charging reaction of the electrolyte solution containing vanadium ions several times.
Resumen de: WO2025147075A1
The present invention relates to a membrane-electrode assembly for a fuel cell and a fuel cell comprising same and, more specifically, to a membrane-electrode assembly for a fuel cell and a fuel cell comprising same, wherein by forming a separate radical protective layer comprising fucoidan and a radical scavenger other than fucoidan between a polymer electrolyte membrane and an electrode layer, deterioration of the electrolyte membrane due to radicals can be prevented, thereby greatly improving chemical resistance.
Resumen de: US2025223707A1
Provided is a power generation system (100) comprising: a gas turbine (10) for combusting air compressed by a compressor (11) and a fuel gas using a combustor (12) to generate combustion gas and drive a turbine (13) and a compressor connected to the turbine using the combustion gas; a heat storage structure (30) heated by the combustion gas with which the turbine is driven; a boiler (40) for generating steam using heat stored in the heat storage structure (30); and a solid oxide electrolytic cell (50) having a hydrogen electrode (51), an oxygen electrode (52), and an electrolyte layer (53) positioned between the hydrogen electrode and the oxygen electrode, the solid oxide electrolytic cell (50) supplying steam generated by the boiler (40) to the hydrogen electrode (51) to generate hydrogen through steam electrolysis.
Resumen de: US2025222791A1
A method is for operating a vehicle with a fuel cell system having a cathode-side flow path, connected in a fluid-conducting manner to the surroundings, for transporting air from the surroundings toward the fuel cell system, and for transporting a cathode off-gas from the fuel cell system into the surroundings, and a fluid-conducting component connected in a fluid-conducting manner to the cathode-side flow path and being configured to receive accumulations of condensate from the air or the cathode off-gas. The vehicle has a compressed air supply independent of the fuel cell system and is configured to provide dry compressed air. The method includes injecting the dry compressed air via the compressed air supply into the cathode-side flow path such that the fluid-conducting component is flowed through by the dry compressed air and existing air or existing cathode off-gas and/or condensate is displaced from the fluid-conducting component toward the surroundings.
Resumen de: US2025222485A1
An adhesive application system applies an adhesive to an intermediate layer at a stage of manufacturing a fuel cell including the intermediate layer and gas diffusion layers on both sides thereof. The adhesive application system includes an applier, a robot arm, and a controller. The applier applies the adhesive when a valve is opened. The robot arm is capable of moving the applier. The controller controls the valve and the robot arm. The controller opens the valve before the applier reaches a position immediately above an application start point while moving the applier by the robot arm, thereby applying the adhesive in the form of a line to the intermediate layer from the application start point.
Resumen de: US2025226456A1
A method and apparatus for generating electricity using an electrochemical cell with a thin aluminum wire as the anode, oxygen extracted from ambient air as the cathode, and a bioplastic electrolyte. The invention teaches the use of inexpensive materials and simplified fuel cell construction and assembling of cells into modules, and modules into ultra-low-cost electricity generators.
Resumen de: US2025226426A1
To provide a separator configured to suppress a decrease in the power generation performance of fuel cells. A separator for fuel cells, wherein the separator comprises cathode-side gas flow paths; wherein each of the cathode-side gas flow paths comprises flow path portions and restrictor portions; wherein a flow path cross-sectional area of the restrictor portions is smaller than a flow path cross-sectional area of the flow path portions; wherein at least one of the restrictor portions is an upstream-side restrictor portion disposed in an upstream of the cathode-side gas flow paths; wherein at least one of the restrictor portions is a downstream-side restrictor portion disposed in a downstream of the cathode-side gas flow paths; and wherein a flow path cross-sectional area of the at least one upstream-side restrictor portion is larger than a flow path cross-sectional area of the at least one downstream-side restrictor portion.
Resumen de: US2025226424A1
The purpose of the present invention is to provide a gas diffusion electrode which reduces electrical resistance in a thickness direction without impairing gas diffusibility, and improves power generation performance when used in a fuel cell. The present invention relates to a gas diffusion electrode having a microporous layer on at least one surface of a conductive porous substrate. The gas diffusion electrode is characterized in that the microporous layer includes carbon black and graphite particles with an aspect ratio of 10 or more, and the ratio of the thickness of a portion in which the microporous layer is sunk of the conductive porous substrate to the thickness of a portion in which the microporous layer is not sunk of the conductive porous substrate is 5-20% inclusive.
Resumen de: US2025226430A1
With the lamination method for fuel cell components, the gas diffusion layer is laminated to the intermediate layer during the manufacturing stage of a fuel cell that includes an intermediate layer and gas diffusion layers on both sides of the intermediate layer. The intermediate layer includes an electrolyte membrane and a resin film provided around the electrolyte membrane. With the method of laminating fuel cell components, a moisture-curing adhesive is applied to the resin film. Thereafter, the gas diffusion layer is brought into contact with the adhesive, thereby laminating the gas diffusion layer and the intermediate layer with the adhesive.
Resumen de: US2025226429A1
In A fuel cell system and a method of controlling the same, the fuel cell system includes a coolant pump configured to circulate coolant along a coolant loop in which a fuel cell stack is disposed, an operating pressure regulating valve configured to adjust an operating pressure of the fuel cell stack and to control the flow of the exhaust gas emitted from the fuel cell stack, and an expander configured to selectively receive the flow of the exhaust gas by the adjusting of the operating pressure regulating valve and power the coolant pump.
Resumen de: US2025226428A1
The invention relates to a method for operating a fuel cell system (1) comprising at least one fuel cell stack (100) having a cathode (110) and an anode (120), wherein, during normal operation of the fuel cell system (1), the cathode (110) is supplied with air via a supply air path (111), and exhaust air exiting the fuel cell stack (100) is discharged via an exhaust air path (112), and wherein the anode (120) is supplied with hydrogen via an anode circuit (121). If poisoning of an anode catalyst of the fuel cell stack (100) is identified, regeneration of the anode catalyst is initiated, wherein exhaust air is diverted out of the exhaust path (112) or an exhaust path (212) of a further fuel cell stack (200) and is introduced into the anode circuit (121) of the anode (120).
Resumen de: US2025226427A1
A fuel cell bonding jig includes an upper jig and a lower jig. The fuel cell bonding jig is configured to be able to be set to a first state that corresponds to a state in which a first film is arranged on a lower surface of the upper jig, a second film is arranged on an upper surface of the lower jig, and an adhesive is applied to the film. A second state in which the first film and the second film face each other across an interval in a vertical direction is entered when the upper jig is attached onto the lower jig while the fuel cell bonding jig is in the first state. The fuel cell bonding jig is configured to be able to, from the second state, press the first film onto the second film.
Resumen de: US2025226425A1
The lamination jig for fuel cell components includes a lower jig with an upper surface configured to allow the intermediate layer to be arranged thereon; and an upper jig with a lower surface configured to allow the gas diffusion layer to be arranged thereon. The lamination jig for fuel cell components is configured to be settable to a state for lamination in which the gas diffusion layer is arranged on the lower surface of the upper jig, the intermediate layer is arranged on the upper surface of the lower jig, and an adhesive is applied to at least one of an upper surface of the intermediate layer or a lower surface of the gas diffusion layer. The upper jig is lowered from the state for lamination to press the gas diffusion layer against the intermediate layer, thereby laminating the gas diffusion layer to the intermediate layer using the adhesive.
Resumen de: DE102024139687A1
Bereitgestellt wird ein Separator, welcher derart konfiguriert ist, dass dieser eine Abnahme der Leistungserzeugungsperformanz von Brennstoffzellen unterdrückt. Ein Separator für Brennstoffzellen, wobei der Separator kathodenseitige Gasströmungspfade aufweist; wobei jeder der kathodenseitigen Gasströmungspfade Strömungspfadabschnitte und Begrenzerabschnitte aufweist; wobei ein Strömungspfadquerschnittsbereich der Begrenzerabschnitte kleiner ist als ein Strömungspfadquerschnittsbereich der Strömungspfadabschnitte; wobei zumindest einer der Begrenzerabschnitte ein stromaufwärtsseitiger Begrenzerabschnitt ist, der auf einer Stromaufwärtsseite der kathodenseitigen Gasströmungspfade angeordnet ist; wobei zumindest einer der Begrenzerabschnitte ein stromabwärtsseitiger Begrenzerabschnitt ist, der auf einer Stromabwärtsseite der kathodenseitigen Gasströmungspfade angeordnet ist; und wobei ein Strömungspfadquerschnittsbereich des zumindest einen stromaufwärtsseitigen Begrenzerabschnitts größer ist als ein Strömungspfadquerschnittsbereich des zumindest einen stromabwärtsseitigen Begrenzerabschnitts.
Resumen de: DE102024200128A1
Die vorgestellte Erfindung betrifft ein Druckerzeugungselement (100) zum Einstellen eines Drucks in einem Leitungssystem (205) eines Brennstoffzellensystems (300).Das Druckerzeugungselement (100) umfasst ein erstes Rückschlagventil (101), ein zweites Rückschlagventil (103), einen zwischen dem ersten Rückschlagventil (101) und dem zweiten Rückschlagventil (103) ausgebildeten Ventilraum (105) und ein Thermoelement (107).
Resumen de: DE102024135394A1
Eine erfindungsgemäße modulare Bipolarplatte umfasst einen Rahmen und eine oder mehrere Einlagen.
Resumen de: DE102024200139A1
Die Erfindung betrifft ein Brennstoffzellensystem (100) mit mindestens einem Brennstoffzellenstack (101) und zumindest einem Luftsystem (10),wobei in dem zumindest einem Luftsystem (10) zwischen einem Zuluftpfad (11) zu dem mindestens einen Brennstoffzellenstack (101) undeinem Abluftpfad (12) von dem mindestens einen Brennstoffzellenstack (101) oder von einem anderen Brennstoffzellenstack (101)ein Abgaspfad (EGR, EGT), insbesondere ein Abgasrezirkulationspfad (EGR) und/oder ein Abgastransferpfad (EGT), vorgesehen ist,wobei eine EGR/EGT-Einleitstelle des Abgaspfades (EGR, EGT) in den Zuluftpfad (11) stromabwärts eines Luftfilters (AF) und stromaufwärts einer, insbesondere einstufigen, Luftverdichtungsvorrichtung (Comp) angeordnet ist,wobei für einen Bereich (BB) im Zuluftpfad (11) zwischen der EGR/EGT-Einleitstelle und der Luftverdichtungsvorrichtung (Comp) eine thermische Temperiervorrichtung (3, 4, 5, 6, 7, 8) vorgesehen ist.
Resumen de: DE102024200053A1
Die vorliegende Erfindung schafft ein Verfahren zum Betreiben einer Tankvorrichtung (1) zum Speichern eines Gastreibstoffs für ein Fahrzeug, das Verfahren umfassend die Schritte: Einleiten (S1) des Gastreibstoffs in das Gasleitungssystem (GL) über einen ersten Tankbehälter (TB1), wobei die Ventileinrichtung (2) an dem ersten Tankbehälter (TB1) durch die Steuereinrichtung geöffnet wird; Erkennen (S2) eines Erreichens oder eines Überschreitens eines Differenzdrucks und/oder einer Differenzmenge des Gastreibstoffs in dem ersten Tankbehälter (TB1) relativ zu einem Anfangsdruck und/oder einer Anfangsmenge des Gastreibstoffs im ersten Tankbehälter (TB1); Erkennen (S3) eines Erreichens oder Unterschreitens eines vorbestimmten Wenigbedarfs an Gastreibstoff über das Gasleitungssystem (GL) durch die Steuereinrichtung; Schließen (S4) des ersten Tankbehälters (TB1) und Öffnen (S5) zumindest eines zweiten Tankbehälters (TB2, ..., TBn) bis ein Druckausgleich innerhalb eines vorbestimmten Rahmens an dem ersten Tankbehälter (TB1) und an dem zweiten Tankbehälter (TB2) erzielt worden ist, wobei der erste Tankbehälter (TB1) auch bei geschlossener Ventileinrichtung (2) mit dem Gastreibstoff aus dem Gasleitungssystem (GL) füllbar ist.
Resumen de: DE102024200086A1
Es wird ein Verfahren zum Betreiben eines Brennstoffzellensystems (100) vorgeschlagen, wobei das Brennstoffzellensystem (100) eine Brennstoffzellen-Einheit (120) und ein Anodengas-Versorgungssystem (110) zum Betreiben der Brennstoffzellen-Einheit (120) mit Anodengas aufweist, mit:Bestimmen eines aktuellen Fremdgas-Anteils von Fremdgas in Anodengas, welches in einem Anodergas-Speicher (112a, 112b) des Anodengas-Versorgungssystems (110) gespeichert ist, wobei das Fremdgas den Betrieb der Brennstoffzellen-Einheit (120) beeinträchtigt;Bestimmen von zumindest einem Betriebsparameter für den Betrieb der Brennstoffzellen-Einheit (120) mit dem Anodengas welches den aktuellen Fremdgas-Anteil aufweist; undBetreiben der Brennstoffzellen-Einheit (120) mit dem zumindest einen bestimmten Betriebsparameter.
Resumen de: DE102024200126A1
Die vorgestellte Erfindung betrifft eine Verteilervorrichtung (100) zum Verteilen von Fluid in einem Tanksystem (200), wobei die Verteilervorrichtung (100) umfasst:- eine Anzahl Verteilungsleitungen (101), die dazu konfiguriert ist, Fluid von einem Tank (201) zu einem Verbraucher (301) zu leiten,- eine Anzahl Tankschnittstellen (103), die dazu konfiguriert ist, die Anzahl Verteilungsleitungen (101) fluidleitend mit einem Tank (201) zu verbinden,- eine Anzahl Verbraucherschnittstellen (105), die dazu konfiguriert ist, die Anzahl Verteilungsleitungen (101) mit dem Verbraucher (301) fluidleitend zu verbinden,- eine Anzahl Versorgungsschnittstellen (107), die dazu konfiguriert ist, durch eine Versorgungseinrichtung zum Versorgen der Verteilervorrichtung (100) mit Fluid bereitgestelltes Fluid zu der Anzahl Verteilungsleitungen (101) zu leiten,- eine Anzahl Absorberelemente (109), die in der Anzahl Verteilungsleitungen (101) angeordnet und dazu konfiguriert ist, flüssiges Wasser zu absorbieren.
Resumen de: DE102024200081A1
Es wird ein Verfahren (400) zur Steuerung eines mehrstufigen Kathodengas-Kompressor-Systems (100) für ein Brennstoffzellensystem (300) vorgeschlagen, wobei das Kathodengas-Kompressor-System (100) einen ersten elektrisch betriebenen Kathodengas-Kompressor (110) und einem zweiten elektrisch betriebenen Kathodengas-Kompressor (120) aufweist, mit:Bereitstellen von Kriterien zur Überwachung (411) einer jeweiligen aktuellen Betriebs-Funktionalität der zumindest zwei Kathodengas-Kompressoren (110, 120);Bereitstellen von Betriebsmodi (401) für das Kathodengas-Kompressor-System;Bestimmung der jeweiligen aktuellen Betriebs-Funktionalität (403) der zumindest zwei Kathodengas-Kompressoren (110, 120), basierend auf den Kriterien zur Überwachung; und Anpassung des aktuellen Betriebsmodus (408) des Kathodengas-Kompressor-Systems (100) basierend auf der jeweiligen Betriebs-Funktionalität der zumindest zwei Kathodengas-Kompressoren (110, 120).
Resumen de: DE102024200110A1
Die Erfindung betrifft ein Verfahren zum Betreiben eines Brennstoffzellensystems (1), umfassend mindestens einen Brennstoffzellenstapel (2) mit einer Kathode (2.1) und einer Anode (2.2), wobei im Normalbetrieb- der Kathode (2.1) über einen Zuluftpfad (3) Luft zugeführt wird, die zuvor mit Hilfe mindestens eines in den Zuluftpfad (3) integrierten Luftverdichters (4) verdichtet worden ist und wobei die aus der Kathode (2.1) austretende Abluft über einen Abluftpfad (5) einer in den Abluftpfad (5) integrierten und mit dem Luftverdichter (4) wirkverbundenen Turbine (6) zugeführt wird,- der Anode (2.2) Wasserstoff aus einem Tanksystem (7) mit mindestens einem Druckgasbehälter zugeführt wird.Erfindungsgemäß wird das Tanksystem (7) vor, während und/oder nach einer Betankung gekühlt, wobei zum Kühlen Luft oder Abluft verwendet wird, die stromabwärts der Turbine (6) vom Abluftpfad (5) durch Öffnen eines Ventils (8) abgezweigt und dem Tanksystem (7) über einen Tankkühlungspfad (9) zugeführt wird.Darüber hinaus betrifft die Erfindung ein Brennstoffzellensystem (1), das zur Durchführung des Verfahrens geeignet bzw. nach dem Verfahren betreibbar ist.
Resumen de: DE102024200056A1
Die vorgestellte Erfindung betrifft ein Versorgungssystem (100) zum Versorgen eines Verbrauchers (201) mit Betriebsmedium, wobei das Versorgungssystem (100) einen Arbeitszylinder (107), einen Verdichterzylinder (109), einen Kolben (111) und ein thermisches Element (113) umfasst. Ferner betrifft die Erfindung ein Energiewandelsystem (200) zum Wandeln von Energie.
Resumen de: WO2025146290A1
The invention relates to a method for operating a fuel cell system (1) which comprises at least one fuel cell stack (2) having a cathode (2.1) and an anode (2.2), wherein, during normal operation, - air is supplied via a supply air path (3) to the cathode (2.1), said air having previously been compressed by means of at least one air compressor (4) which is integrated in the supply air path (3), and the exhaust air exiting the cathode (2.1) is supplied via an exhaust air path (5) to a turbine (6) which is integrated in the exhaust air path (5) and operatively connected to the air compressor (4), and - hydrogen is supplied to the anode (2.2) from a tank system (7) having at least one compressed-gas container. According to the invention, the tank system (7) is cooled before, during and/or after a refilling operation, wherein, for cooling purposes, use is made of air or exhaust air which is branched off from the exhaust air path (5) downstream of the turbine (6) by virtue of a valve (8) being opened and is supplied to the tank system (7) via a tank cooling path (9). The invention also relates to a fuel cell system (1) which is suitable for carrying out the method or can be operated according to the method.
Resumen de: DE102024200127A1
Die vorgestellte Erfindung betrifft ein Druckerzeugungselement (100) zum Einstellen eines Drucks in einem Leitungssystem (205) eines Brennstoffzellensystems (300), wobei das Druckerzeugungselement (100) ein erstes Rückschlagventil (101), ein zweites Rückschlagventil (103), einen zwischen dem ersten Rückschlagventil (101) und dem zweiten Rückschlagventil (103) ausgebildeten Ventilraum (105) und ein Heizelement (107) umfasst, wobei das Heizelement (107) dazu konfiguriert ist, in den Ventilraum (105) einströmendes Fluid zu verdampfen, um einen Druck in dem Ventilraum (105) zu maximieren, und wobei das zweite Rückschlagventil (103) dazu konfiguriert ist, sich erst dann zu öffnen, wenn ein Druck in dem Ventilraum (105) größer oder gleich einem Auslassdruck ist, wobei der Auslassdruck größer ist als ein Druck, bei dem sich das erste Rückschlagventil (101) schließt.
Resumen de: DE102024200143A1
Die Erfindung betrifft ein Verfahren zum Betreiben eines Fahrzeuges (Veh), insbesondere eines brennstoffangetriebenen Fahrzeuges, mit einem Brennstoffzellensystem (FCS) mit mindestens einem oder mehreren Brennstoffzellenstacks (S1, S2, S3),aufweisend:(1) Ermitteln, ob das Fahrzeug (Veh) mit einem lokalen Energienetz (GrLoc) verbunden werden soll,(3) Bestimmen, insbesondere in Abhängigkeit von dem Ermitteln, ob mindestens ein oder mehrere Brennstoffzellenstacks (S1, S2, S3) des Brennstoffzellensystems (FCS) ausgeschaltet werden soll,(4) Verbinden, vorzugsweise elektrisches Verbinden, des Fahrzeuges (Veh) mit dem lokalen Energienetz (GrLoc), insbesondere in Abhängigkeit von dem Ermitteln,(5) Überwachen eines Betriebsparameters (BP) des Brennstoffzellensystems (FCS) auf Verletzen eines kritischen Schwellenwerts (BPmin, BPmax), bei dem ein Start von mindestens einem Brennstoffzellenstack (S1, S2, S3) des Brennstoffzellensystems (FCS) unter kritischen Bedingungen erfolgen kann, die insbesondere einen Luft-zu-Luft-Start und/oder einen Gefrier-Start nach sich ziehen können,(7 oder 10) Betreiben mindestens eines oder mehrerer Brennstoffzellenstacks (S1, S2, S3) des Brennstoffzellensystems (FCS) in Abhängigkeit von dem Überwachen.
Resumen de: DE102024100514A1
Die vorliegende Erfindung betrifft ein Verspannelement (108), insbesondere zum Verspannen mehrerer Brennstoffzellenelemente (102) einer Brennstoffzellenvorrichtung (100), wobei das Verspannelement (108) zumindest bereichsweise eine Stützstruktur (114) aufweist oder zumindest bereichsweise durch eine Stützstruktur (114) gebildet ist, insbesondere zur Stützung der Brennstoffzellenelemente (102). Ferner betrifft die Erfindung eine Brennstoffzellenvorrichtung (100) mit einem derartigen Verspannelement (108).
Resumen de: WO2025146419A1
The invention essentially consists in integrating, into a receptacle (6), at least one electrochemical stack containing solid-oxide electrochemical cells (1), which stack is intended to operate at high temperature as an electrolysis or co-electrolysis reactor, a volume around the at least one electrochemical stack being filled with a material, at least one vitreous matrix of which material will act as a second gas-tight barrier, i.e. as an additional barrier to the barriers formed by the seals around the cathode and anode compartments of the stack.
Resumen de: WO2025146892A1
The present invention relates to an ammonia-based power pack integrated thermal management system, and disclosed herein is a liquid ammonia-based power pack integrated thermal management system capable of efficiently managing heat generated in a fuel cell, by vaporizing liquid ammonia using waste heat of fuel cell cooling water to decompose the liquid ammonia into nitrogen and hydrogen, which are then supplied to the fuel cell, and simultaneously, removing (cooling) residual heat of the fuel cell cooling water using cold energy released during the vaporization of the liquid ammonia.
Resumen de: WO2024047171A2
A temperature management system for a fuel cell unit includes a pump, a valve fluidly connected to the pump, and defining an inlet, and first, second and third outlets, a heater, a heat exchanger, a radiator. The valve is selectively adjustable between at least first, second and third configurations. In the first configuration, the valve is configured to direct fluid along a first path defined at least by the first outlet, the heater, the fuel cell unit, the pump, and the inlet. In the second configuration, the valve is configured to direct fluid along the first path and along a second path defined at least by the second outlet, the heat exchanger, the pump, and the inlet. In the third configuration, the valve is configured to direct fluid along a third path defined at least by the third outlet, the radiator, the fuel cell unit, the pump, and the inlet.
Resumen de: WO2024047477A1
The present disclosure relates to an acid-base polymer blend membrane for selective transport of water molecules from a gaseous mixture comprising: at least one first polymer (A) exhibiting acidic groups, at least one second polymer, wherein the at least one second polymer is a polymer (B1) exhibiting basic groups or a polymer (B2) exhibiting weak basic groups, and at least one third polymer, wherein the at least one third polymer is a neutral polymer (N); and wherein polymer (A) is comprised in an amount of from about 40 wt.-% to about 98 wt.-%, based on the total weight of the polymer blend membrane, and wherein the fluorine content of the acid-base polymer blend membrane is below 20 wt.-%.
Resumen de: WO2024047036A1
A heat storage unit and heat exchanger has a first fluid line, a second fluid line, a heat exchanger and a storage container. The heat exchanger is designed to transfer heat between the first fluid line and the second fluid line. The storage container is designed to receive a thermal storage medium. At least a portion of the heat exchanger is arranged in the storage container in order to allow heat transfer between the heat exchanger and the thermal storage medium.
Resumen de: CN119790264A
The present invention relates to a check valve, in particular of a hydrogenation installation, having an inlet and an outlet which define a flow direction which extends from the inlet to the outlet. The check valve has a piston (6) movably arranged relative to the inlet and the outlet to open and close the inlet of the check valve, where the piston (6) defines a piston axis (63) by means of a first end facing the inlet and a second end facing the outlet. The piston (6) has an outer surface along which a fluid flowing through the check valve in a flow direction flows. The outlet has outlet channels (35) in order to enable the fluid to flow outward from the check valve, all outlet channels (35) of the outlet running obliquely with respect to the piston axis (63). The check valve can be used for high pressure and allows soft closing even in the event of a reversal of the pressure action. The check valve is used in particular in hydrogen refueling stations.
Resumen de: CN119789903A
The invention relates to a semipermeable membrane (10), in particular for use in a membrane humidifier of a fuel cell system, comprising: a) a carrier layer (12) comprising a composite material comprising at least one plastic and at least one silicon-containing porous filler embedded in the plastic, and b) a cover layer (14) arranged on the carrier layer (12), the capping layer comprises at least one organosilicon compound.
Resumen de: EP4583213A1
A fuel cell system (10) includes:a fuel cell module (30) including a fuel cell stack (31) that generates power using fuel gas supplied to an anode and oxidant gas supplied to a cathode, a combustion unit (32) that burns combustible gas introduced from a combustion gas inlet, and a heat-insulating module case (35) that accommodates the fuel cell stack (31) and the combustion unit (32);a hydrogen supply system (40) including a hydrogen supply line connected to a hydrogen inlet of the fuel cell module (30) connecting with an inlet of the anode and a hydrogen supply source (1), and a hydrogen blower (43) provided in the hydrogen supply line; anda circulation system (60) including a hydrogen off-gas line connected to a hydrogen off-gas outlet of the fuel cell module (30) connecting with an outlet of the anode, a heat exchanger (71) provided in the hydrogen off-gas line, a combustion gas line connected to the combustion gas inlet of the fuel cell module (30), and a reflux line connected to the hydrogen supply line, the circulation system (60) distributing hydrogen off-gas discharged from the outlet of the anode and having passed through the heat exchanger (71) to the combustion gas line and the reflux line, whereinthe hydrogen supply system (40) includes a governor (44) provided upstream of the hydrogen blower (43) in the hydrogen supply line,the reflux line branches off from the hydrogen off-gas line and is connected between the hydrogen blower (43) and the governor (44) in the hy
Resumen de: EP4582474A1
Provided are: composite conductive filler particles 10 having graphite particles 2 and amorphous carbon 1 with which the graphite particles are coated; a conductive resin composition 20 having a resin material 3 and the composite conductive filler particles 10 dispersed in the resin material 3; and a conductive resin composition molded article formed by molding the conductive resin composition 20.
Resumen de: GB2637069A
A method of recycling a waste ionomer material, the method comprising: heating the waste ionomer material in a solvent to disperse the waste ionomer material forming a dispersion of ionomer in the solvent, the dispersion also containing fluoride anions in solution; contacting the dispersion with a precipitant or adsorbent to form a solid material comprising the fluoride anions; and separating the dispersion of ionomer from the solid material comprising the fluoride anions.
Resumen de: WO2024046712A1
The present invention relates to a method for producing a material for a membrane, the method comprising the following steps: - providing at least one starting material, at least one starting material containing at least one monomer or consisting thereof; - synthesizing a polymer from the starting material(s) by way of polyhdroxyalkylation (PHA); and - modifying the synthesized polymer in a subsequent reaction. The invention further relates to a material, a membrane and the use of a membrane.
Resumen de: EP4583212A1
One aspect of the present invention provides a polymer electrolyte membrane including: a porous substrate including a first part including a first polyolefin modified with a halogen-based compound, and a second part including a second polyolefin; and a halogen-based polymer electrolyte impregnated in pores of the porous substrate, wherein in the porous substrate, the first part and the second part constitute a discontinuous phase and a continuous phase, respectively, and a content of the halogen-based compound in the porous substrate is 0.5 to 10 wt%, and a method of manufacturing the same.
Resumen de: WO2024049837A2
The present disclosure provides systems and methods for generating and storing hydrogen and electricity. The systems generally include an electrolyzer stack, a fuel cell stack operably connected to the electrolyzer stack, and a hydrogen recirculation stack operably connected to the electrolyzer stack and to the fuel cell stack.
Resumen de: EP4582197A1
This metal member is a metal member having a three-dimensional regular framework structure with a porosity in a range of 50% or more and 95% or less, wherein the three-dimensional regular framework structure has a framework and a plurality of pores extending in a first direction, in a cross section perpendicular to the first direction, pore rows in which the pores and the frameworks are alternately arranged are periodically laminated to form a lamination structure. In addition, the electrode has a well-shaped sheet layer having a plurality of through-holes in a thickness direction, the porosity of the well-shaped sheet layer is in a range of 20% or more and 70% or less, and the thickness of the well-shaped sheet layer is in a range of 10 µm or more and 500 µm or less.
Resumen de: GB2637070A
A method of recycling a waste ionomer material comprising at least one ionomer and at least one platinum group metal catalyst, the method comprising: (a) mixing the waste ionomer material to homogenize the waste ionomer material; (b) taking a sample of the homogenized waste ionomer material; (c) assaying the sample of homogenized waste ionomer material to characterize ionomer content and platinum group metal content of the waste ionomer material; and (d) recycling the waste ionomer material to separate and recover both the ionomer and the platinum group metal materials on the basis of the ionomer content and the platinum group metal content determined by the assaying.
Resumen de: WO2024122535A1
Provided is a layered structure for a fuel-cell separator, and with the layered structure a stable reaction force at opposing reception parts can be ensured and over-compression of a bead part can be effectively suppressed even if set deviation has occurred in a layered separator. The present invention comprises: a first set 11 having one separator 12; and a second set 21 having another separator 22. Each of the one separator 21 and the other separator 22 includes: bead parts 14, 24; and reception parts 16, 26 for receiving an over-compression load of the bead parts14, 24. The one separator 12 and the other separator 22 are disposed opposing each other so that the surfaces on the sides at which the bead parts 14, 24 and the reception parts 16, 26 are protruding face each other. The separators are configured so that a direction in which the reception part 26 of the one separator 12 extends linearly and a direction in which the reception part 26 of the other separator 22 extends linearly are non-parallel, and also so that the opposing reception parts 16, 26 partially overlap each other.
Resumen de: CN120280514A
本发明涉及一种燃料电池系统及控制该燃料电池系统的方法。燃料电池系统包括:冷却液泵、工作压力调节阀以及膨胀装置,所述冷却液泵配置为使冷却液沿着冷却液回路循环,燃料电池堆布置在冷却液回路中;所述工作压力调节阀配置为调节燃料电池堆的工作压力并且控制从燃料电池堆排出的排出气体流;所述膨胀装置配置为通过工作压力调节阀的调节而选择性地接收排出气体流并且为冷却液泵提供动力。
Resumen de: US2025177898A1
A liquid separator for separating a liquid from a fluid flow includes a housing, a flow-conducting region arranged inside the housing and including an inner tube and an outer tube adjoining the inner tube, the inner tube being arranged downstream of the outer tube in a flow direction, a fluid conduit connected to the flow-conducting region and having a first diameter, the fluid conduit including a swirl generator for generating a swirl of the fluid flow, a separation region arranged at a radial outer side of the inner tube and the outer tube, a fluid outlet connected to the separation region and extending at a slant to an axial direction, and a flow-calmed region arranged between the separation region and the fluid outlet and including a flow-calming element for calming the fluid flow.
Resumen de: CN120280521A
本申请涉及全钒液流电池技术领域,公开了一种全钒液流电池储能系统异常分析方法、装置、设备及介质,其中,所述方法包括:获取全钒液流电池储能系统在预设电量范围内各电堆的运行数据,并基于所述运行数据确定每个电堆对应的单电堆能量效率;基于所述单电堆能量效率,构建三维效率矩阵;对所述三维效率矩阵进行量化分析,确定所述全钒液流电池储能系统中每条液路对应的液路效率和每条电路对应的电路效率;通过预先设定的异常阈值对所述液路效率和所述电路效率进行比对,基于比对结果确定相对应的目标异常位置。本申请提供的技术方案,能够实现故障排查的智能化运维。
Resumen de: CN120280513A
本公开涉及一种液氢燃料电池发动机热管理系统和车辆,其中的液氢燃料电池发动机热管理系统包括液氢系统和燃料电池发动机系统,其中,所述液氢系统包括依次连接的液氢储气瓶、水浴汽化器和缓气罐,所述燃料电池发动机系统包括燃料电池发动机模块和PTC加热器,所述燃料电池发动机模块和所述PTC加热器流体连通而构成第一循环回路,其中,所述缓气罐的出气端连接至所述燃料电池发动机模块,所述液氢燃料电池发动机热管理系统还包括循环水路,所述循环水路连通在所述水浴汽化器和所述第一循环回路之间。这样,将液氢系统的水浴结构与燃料电池发动机系统的PTC加热器结合,实现液氢系统有控制的汽化,满足系统多变的需求,保障汽化量精准的同时达成冷热能高效利用。
Resumen de: CN120280511A
本发明涉及气体扩散层的技术领域,公开了一种结晶性多孔材料掺杂的气体扩散层的制备方法及应用,包括如下步骤:S1、按质量份数计,将6~9份碳黑、结晶性多孔材料、0.1~0.2份增稠剂、2~4份疏水剂和5~8份分散剂加入75~85份溶剂中,其中碳黑与结晶性多孔材料的质量比为1:0.3~1.5,搅拌脱泡后得到微孔层浆料;S2、将微孔层浆料涂覆于经疏水处理的碳纸上,再依次经烘干、烧结,得到气体扩散层。本发明通过采用结构稳定且孔径大小均匀的结晶性多孔材料制备得到气体扩散层,可以增强气体扩散层的气液传输能力,进一步提高燃料电池的性能和使用寿命。
Resumen de: CN120280508A
本申请提供了一种高熵金属间化合物双功能催化剂及其制备方法与应用,属于能源材料技术领域。本申请采用湿化学合成法与可控退火工艺结合制备得到高熵金属间化合物双功能催化剂,该催化剂具有碳负载的铂‑钴‑铜‑钨‑钼五元高熵合金纳米粒子,该合金纳米粒子同时具备高熵效应和有序结构,粒径为4‑7nm,且金属原子的摩尔比为铂:钴:铜:钨:钼=4:(1.75‑2.5):(1.75‑2.5):(0.01‑0.5):(0.01‑0.5)。该催化剂中的铂负载量为20‑70wt%,用于氢燃料电池中阴极的氧还原反应催化和/或直接甲醇燃料电池中阳极的甲醇氧化反应催化,在酸性介质中的半波电位超过商业Pt/C催化剂30mV及以上,甲醇氧化峰值电流密度是商业Pt/C催化剂或商业PtRu/C催化剂的1.4‑2.5倍。
Resumen de: CN120280517A
本发明公开一种带氢气循环结构的燃料电池系统及其水管理方法。该系统包括氢气进气管路、电磁阀、燃料电池电堆、水泵、散热器和氢气循环结构;所述氢气进气管路与电磁阀、氢气循环结构、燃料电池电堆顺次连接;所述燃料电池电堆的冷却路出口与水泵、散热器顺次连接,所述散热器与燃料电池电堆的冷却路入口连接。本发明使用出堆的冷却水对氢气进行换热,可以把氢气加热到一个比较高的温度,有效避免液态水的形成;通过调节氢气温度对氢气侧进行水管理,不需要调节氢泵、排水阀,可以提高系统效率和氢气利用率。
Resumen de: CN120280522A
本发明提供了一种带高温阳极尾气循环的SOFC系统及运行方法,属于固定氧化物燃料电池领域。该系统包括混合腔、重整器、燃烧器、换热器和电堆,电堆包括阳极端和阴极端,阳极端分别与燃烧器和混合腔连接,阳极尾气一部分进入燃烧器燃烧发热,另一部分进入混合腔与燃气混合后,再通过重整器进入电堆进行电化学发应。采用本发明实施例所提供的一种带高温阳极尾气循环的SOFC系统及运行方法,能够解决现有技术中燃料的利用率较低的问题。
Resumen de: CN120271041A
本申请钒电池生产技术领域的一种钒电解液生产方法,包括如下步骤:S1、钒钛磁铁矿废渣经硫酸浸出、离子交换提纯得到钒液;S2、生物质炭改性:秸秆炭中添加碳纳米管(CNTs)(质量占比5~7%),在氮气中微波处理形成多级孔活性炭,浸渍0.1~0.3M Mn(NO3)2和0.1~0.3M Fe(NO3)3溶液,干燥后煅烧制得复合还原载体;S3、向钒液中通入脉冲臭氧60~70℃下反应30~60min,通入SO2气体50~60℃反应2~3小时,投加复合还原载体,施加微电流(0.1~0.3A/m2),常温下反应1.5~2小时;S4、加入MIL‑101(Cr)@磺酸化‑羧甲基双修饰壳聚糖复合稳定剂(0.1wt%),经膜浓缩得到钒电解液。
Resumen de: CN120280525A
本发明公开一种微生物燃料电池系统、控制方法及联产乙酸钠的方法,包括阳极室和阴极室,阳极室和阴极室之间通过质子交换膜分隔;所述阳极室和阴极室内分别设置阳极部件和阴极部件,所述阳极部件和阴极部件用于向外接电路供电;所述阳极室内填充有阳极介质,所述阳极部件的下侧部分浸入到阳极介质,形成阳极部件的浸没段;所述阳极介质的液面高度能够调节,阳极部件浸入到阳极介质的浸没段也能够跟随阳极介质的液面高度同步调节。本发明能够将生物质能转化为电能输出,并且能够借助反应过程中的中间产物作为原料,通过中和调节和提纯得到乙酸钠,实现清洁能源与副产物乙酸钠联产。
Resumen de: CN120270114A
本申请涉及热管理技术领域,公开了一种车辆、车辆的热管理系统及其控制方法,车辆包括:包括电堆和电堆附件的燃电系统、电驱系统,热管理系统包括控制器、氢燃料换热系统和电驱换热系统。氢燃料换热系统与电堆连接以对其进行热管理,电驱换热系统与电堆附件、电驱系统连接,用于对其进行热管理。控制器与氢燃料换热系统、电驱换热系统连接,以根据电堆温度控制氢燃料换热系统换热,根据电堆附件温度和电驱系统温度控制电驱换热系统行换热。通过氢燃料换热系统单独对电堆进行换热,实现对电堆温度的精准监控,电堆附件和电驱系统共用电驱换热系统,如此降低热管理系统的成本。
Resumen de: WO2024068539A1
The invention relates to a separator plate (21) which includes, in a first face: a plurality of corrugated channels (49) for the circulation of a first reactive gas, the corrugated channels (49) having respective end portions (50) all extending in the same first direction (D1) and forming corrugations having the same specific period (T1); a plurality of oblique channels (56), each extending in a second direction (D2) intersecting with the first direction (D1), the end portion (50) of each corrugated channel (49) connecting to one of the oblique channels (56) at a junction point (58); the junction points (58) defining projection points (p) projecting on a straight line (D) parallel to the first direction (D1), the projection being in a third direction (D3) perpendicular to the first direction (D1), the projection points (p) being regularly spaced apart from one another in the first direction (D1) and separated from one another by a constant spacing equal to a multiple of the specific period (T1).
Resumen de: CN120280518A
本申请涉及一种电池内部状态的识别方法、装置、计算机设备和存储介质。所述方法包括:获取第一电池的第一测量数据;将第一测量数据输入至状态重构模型,获取状态重构模型重构得到的第一电池的内部状态数据;其中,状态重构模型为将第二测量数据和与第二测量数据对应的内部状态数据作为训练集训练得到的,第二测量数据和第二测量数据对应的内部状态数据为基于第二电池的仿真模型获取的,内部状态数据包括阴极催化层氧气浓度、质子交换膜水含量、阴极流道水蒸气浓度、阴极催化层液态水饱和度中的至少一种,状态重构模型的算法架构与内部状态数据对应设置。提高了识别内部状态数据的准确度。
Resumen de: CN120280965A
本发明提供了一种输电线路新型电源储能装置,属于电力系统储能技术领域。该装置由混合储能模组、嵌入式故障预测单元、动态均衡控制器和复合散热壳体构成。混合储能模组集成全钒液流电池、固态锂电容和超级电容,协同满足输电线路能量与功率需求;嵌入式故障预测单元通过实时监测电流谐波和温度数据,利用神经网络加速器预测故障并提前应对;动态均衡控制器依据故障概率调节储能单元工作状态,优化能量管理;复合散热壳体采用相变材料与仿生风道设计,实现高效动态散热。本发明采用上述的一种输电线路新型电源储能装置,显著提升了储能装置的性能、可靠性和安全性,延长使用寿命,降低维护成本,适用于复杂工况的输电线路。
Resumen de: EP4279638A2
To provide an electrolyte membrane that exhibits high proton conductivity even at low humidity.The electrolyte membrane comprises a composite membrane comprising: a microporous polyolefin membrane that has an average pore diameter of 1 to 1000 nm and a porosity of 50 to 90% and that can be impregnated with a solvent having a surface free energy of 28 mJ/m<sup>2</sup> or more; and an electrolyte containing a perfluorosulfonic acid polymer having an EW of 250 to 850 loaded into the pores of the microporous polyolefin membrane; wherein the membrane thickness of the composite membrane is 1 to 20 µm.
Resumen de: CN120280504A
本发明公开了一种固体氧化物燃料电池阴极材料及其制备方法和应用,属于燃料电池技术领域。所述的固体氧化物燃料电池阴极材料的组成为:YBa2‑xSrxCu2Co0.7Cu0.3O7+δ。本发明将钇源、钡源、锶源、铜源和钴源溶解,加入EDTA和柠檬酸作为络合剂,调节pH至中性,60‑80℃下反应6‑10h;加热反应液至燃烧,燃烧后得到前驱体粉末;前驱体粉末研磨,350‑450℃煅烧6‑10h、800‑900℃下煅烧6‑10h、950‑1000℃下煅烧10‑15h,得固体氧化物燃料电池阴极材料。本发明制备的层状钙钛矿结构YBa2‑xSrxCu2Co0.7Cu0.3O7+δ材料提高了氧空位浓度和氧输运能力,改善了电化学性能。
Resumen de: CN120280519A
本发明涉及管式高温固体氧化物燃料电池密封测试夹具,包括燃料电池管;所述燃料电池管包括阴极层、电解质管、阳极层、出气管式夹具、进气管式夹具及进气管式夹具;阳极层位于电解质管的内壁上,阴极层位于电解质管的外壁上,且阴极层没有位于电解质的两端部;出气管式夹具上设有第一环形凹槽,燃料电池管的出气端部插装在第一环形凹槽中,第一环形凹槽的深度至少是5 mm,在出气管式夹具上设有用于穿过导线的穿孔;进气管式夹具上设有第二环形凹槽,燃料电池管的进气端部插装在第二环形凹槽中,第二环形凹槽的深度至少是5 mm。其优点夹取方便,夹具与燃料电池插接配合,操作难度小,无需高温陶瓷胶密封,提高测试效率。
Resumen de: CN120273816A
本发明提出了一种氢燃料电池‑旋转爆震组合燃烧室的新型动力系统,属于清洁能源新型动力领域。该系统包括氢燃料电池组、旋转爆震燃烧室、压气机、涡轮、发电机、逆变器;氢燃料电池组阳极和阴极的排气出口与旋转爆震燃烧室进气隔离段相连,同时进气隔离段上开有补氢孔和补空气孔。旋转爆震燃烧室在充分利用氢燃料电池组的尾气,同时维持整个燃气轮机系统的高效运转。该新型动力系统以氢气为燃料,既利用氢燃料电池能量转换效率高的优势,又通过旋转爆震燃烧室的高热效率特性,弥补了氢燃料电池功率密度低、燃料利用不完全的不足,形成了高经济性与高功率的相互耦合。
Resumen de: CN120271870A
本发明属于能源储存技术领域,公开了一种“三明治”结构共价有机框架膜及其制备方法和应用。本发明通过2,2'‑联苯胺二磺酸和三醛基间苯三酚缩合反应首先制备了自支撑共价有机框架膜,后采用将自支撑共价有机框架膜浸涂在聚苯并咪唑溶液中再相转化,制得“三明治”结构共价有机框架膜。本发明利用共价有机框架内部的孔结构和磺酸基团实现对质子的选择性传递,并阻碍钒离子渗透,同时在电池组装和运行过程中,两侧的聚苯并咪唑层起到保护共价有机框架膜的作用。所制备的膜有较高的质子选择性和电池效率。
Resumen de: CN120280528A
本发明适用于燃料电池技术领域,尤其涉及一种安全防爆的燃料电池,所述安全防爆的燃料电池包括:保护罩,所述保护罩内设置有多个通过插接连接的电池单元,保护罩上设置有温度传感器,温度传感器用于监测电池单元的温度,保护罩上设置有第一供气口和第二供气口,保护罩上还设置有接电口,接电口用于连接供电系统,保护罩底部设置有多个槽口,槽口为阶梯槽,槽口内设置有槽盖,槽盖也为阶梯型结构,槽盖与槽口之间通过磁力连接。本发明通过设置拔插式连接方式,能够在电池单元出现异常时及时断开其连接,并在出现极端高温的情况下舍弃电池单元以避免整个电池模组出现温度失控,避免了出现爆燃的情况,保证了电池模组的安全。
Resumen de: CN120280516A
本申请实施例涉及一种氮氧混气氢能发电系统,包括氢气罐、引射器、燃料电池电堆、气液分离器、冷却系统、鼓风机、电子三通阀、氮氧混气罐和背压阀;所述氢气罐、所述引射器、所述燃料电池电堆及所述气液分离器依次连接;所述气液分离器与所述引射器连接;所述冷却系统与所述燃料电池电堆连接;所述背压阀分别与所述气液分离器、所述燃料电池电堆连接;所述电子三通阀分别与所述鼓风机、所述燃料电池电堆、所述氮氧混气罐连接。本申请结构简单,增加了阴极侧的压力和流量,从而提高了燃料电池电堆的性能;简化控制,控制难度低,降低了系统的整体运行成本,整体安全性高,便于燃料电池系统进一步推广,易于规模化应用。
Resumen de: CN120280990A
本发明是一种基于可逆固体氧化物燃料电池的风光氢一体化供能系统,专为远海岛礁、边防哨所等特殊区域设计。系统集成风力发电模块(1)和光伏发电模块(2),将风能与太阳能转化为电能。多余电能由RSOC模块(3)在SOEC模式下电解水制氢,储存于固态储氢模块(4)。在能源需求高峰或风光电不足时,RSOC模块切换至SOFC模式,将氢气转化为电能输出。系统还配备海水淡化模块(5),利用RSOC余热淡化海水;超纯水生产模块(7)通过冷凝高温蒸汽产出工业级超纯水。智能监控模块(6)实时监测并控制各模块协同运行。本系统具备高效能量转换、高环境适应性和多功能拓展等优点,为特殊区域提供稳定、环保、经济的能源解决方案。
Resumen de: CN120280499A
本发明涉及一种钴基改性细粒径固体氧化物燃料电池阴极材料及其制备方法和应用。该阴极材料包括钴基活性材料LaCo0.6Ni0.4O3‑δ、粒径0.1‑1.0微米的SDC骨架和厚度5‑20微米的GDC阻挡层。通过浸渍法将LCN均匀分布在SDC骨架中,并在阴极与电解质之间引入GDC阻挡层,优化界面稳定性。制备方法包括丝网印刷SDC骨架、LCN的浸渍与煅烧以及GDC阻挡层的涂覆与烧结。该材料显著提高了阴极的氧还原反应(ORR)活性,并在700‑800℃条件下展现出优异的电化学性能和长期稳定性。测试结果显示,电池在750℃下的最大功率密度达到1.3W/cm2,连续运行100小时后性能衰减率小于5%。本发明的阴极材料适用于分布式发电、热电联供系统等领域,具有广阔的应用前景。
Resumen de: CN117505200A
The invention provides a slurry coating method, a catalyst coated film and a fuel cell. The slurry coating method comprises the following steps: setting a first parameter of a coating machine and acquiring a slurry parameter; setting a target platinum loading capacity, and calculating a second parameter of the coating machine based on the target platinum loading capacity, the first parameter and the slurry parameter; and coating on a substrate film based on the first parameter and the second parameter. According to the coating method for the basement membrane of the proton exchange membrane, accurate coating parameters of the coating machine can be obtained according to the target platinum loading capacity, the debugging frequency can be reduced, and the coating quality can be improved.
Resumen de: CN120271796A
本发明公开了一种聚咔唑基含氮衍生物、阴离子交换膜及其制备方法和应用,涉及高分子化合物技术领域。本发明提供的聚咔唑基阴离子交换膜为基体,表现出高稳定性,3‑甲基‑3,6‑重氮唑5,5‑6‑溴化铵具有双季铵阳离子结构,接枝在聚咔唑基的基体上可以大幅度提高膜的电导率。本发明采用超强酸催化聚合的方法制备了具有微相分离结构的高离子交换容量阴离子交换膜,制得的阴离子交换膜具有离子交换容量高、耐碱稳定性好,且方法简单、易于工业化等特点,该种阴离子交换膜在碱性燃料电池、电解水制氢、液流电池、电化学合成氨等涉及氢能源领域的行业具有重要的应用价值。
Resumen de: WO2024144787A1
A combustion system is provided. The combustion system includes a topping cycle. The combustion system further includes a fuel cell including an anode side, a cathode side, and an electrolyte. The anode side receives fuel via an anode inlet line and generates anode output products containing a first portion of hydrogen. The cathode side receives oxidants from a cathode inlet line. The combustion system further includes a separation system having a water gas shift reactor that produces a second portion of hydrogen from the anode output products. The topping cycle is fluidly coupled to the separation system such that the topping cycle receives the hydrogen produced from the anode output products.
Resumen de: CN120280527A
本发明涉及电池生产技术领域,尤其涉及一种电堆生产全自动装配装置,包括装配机、用于电堆自动上料的上料机构以及转运车,装配机两侧均设有储料台,储料台上均设有支撑架,支撑架下方均设有顶板,转运车上等距固定连接有若干个下板,若干个下板外壁四角均固定连接有L型板,L型板上设有用于固定电堆位置的锁紧机构,确保电堆在转运过程中的稳定性,顶板上设有用于解锁电堆位置并夹持电堆的夹料机构,本发明通过夹料机构、锁紧机构和限位机构等结构的设置,能够自动解除转运车上电堆的位置限制,随后将电堆夹出放在储料台上,从而实现对装置的自动补料功能,无需人工进行填料,减少因人为因素导致电堆损坏的现象,提高装置的自动化效率。
Resumen de: CN120280622A
本发明公开了一种可逆充放电耦合高附加值化学品生产的光电催化电池的构建方法,包括充电模块的组装和放电模块的组装。本发明可在光照下实现宽底物范围的多种高附加值化学品生产,同时放出电能;在充电时同样可借助自然光照显著降低充电所需电压,抑制了储能体系所需成本;本发明光电催化液流电池集成了传统液流电池和光电催化高附加值化学品绿色合成系统,实现了可再生电能及太阳能的高效储放与利用;本发明适用性广泛,为液流电池储能及有机化学品绿色合成领域提供了新思路。
Resumen de: CN120280524A
本发明公开了一种用于浓差电池的电解质膜及其制备方法,其步骤为:合成磺化聚醚醚酮聚合物;以所述磺化聚醚醚酮聚合物通过溶剂浇注法制备磺化聚醚醚酮膜,即为电解质膜,将该电解质膜作为浓差电池电解质膜,可以达到5W/m2以上的电池功率密度。本发明所述浓差电池电解质膜制备方法简单,产电性能优秀,机械性能良好,具有实际应用的潜力。
Resumen de: WO2024176959A1
Provided is a hollow fiber membrane module with which it is possible to limit manufacturing costs. The present invention is characterized in that: a case 100 has a first pipe part 111 and a second pipe part 112, and a holding member 210 which holds a plurality of hollow membranes 220 is provided in the case 100; the holding member 210 comprises a first plate part 211 and a second plate part 212 which are provided to as to sandwich the plurality of hollow fiber membranes 220 therebetween, and a connection part 215 which connects the plate parts; and a path from the first pipe part 111 to the first plate part 211 is formed between the first plate part 211 and the case 100, and a path from the second pipe part 112 to the second plate part 212 is formed between the second plate part 212 and the case 100.
Resumen de: CN120274960A
本发明涉及气密性检测技术领域,且公开了一种燃料电池电堆气密性检测装置,包括燃料电池电堆主体,所述燃料电池电堆主体的外壁安装有进气管,所述进气管的外壁套接有集气气囊。通过主动齿轮在气泵的带动下通过转杆进行转动,可带动齿环在外壳的内壁进行转动,使得多个驱动齿轮开始转动,可使齿条在驱动齿轮转动下沿驱动齿轮的方向进行移动,可使六个移动板的顶点处能够相接触,从而可使其能够将外界与进气管的内壁进行分割,可有效防止外界空气继续进入燃料电池电堆主体的内壁,且能够有效防止气体浪费的情况,确保燃料电池的安全性和可靠性,快速停止充气可以有效减少气体泄漏的量,从而降低火灾或爆炸的风险。
Resumen de: CN120280520A
一种具有操作条件自适应的PEMFC堆发电效率优化方法。包括:通通过对所建立的质子交换膜燃料电池堆发电效率理论模型分析可得,电堆发电过程受其堆内水管理、热管理状态的直接影响。在满足负载稳定运行的前提下,将PEMFC堆的输出功率设定为负载所需功率,并以燃料电池堆直流总内阻最小为控制目标,采用粒子群优化算法获得PEMFC堆在负载所需功率输出下直流总内阻达到最小时的工作温度、工作湿度及输出电压,此工况下可提高电堆的发电效率。将求得的工作温度、工作湿度以及输出电压代入燃料电池发电效率理论模型能够计算出燃料电池在当前功率输出下的发电效率。
Resumen de: CN120280515A
本发明公开了一种基于动态反馈的硼氢化钠供氢燃料电池控制系统。该系统通过传感器单元实时监测燃料电池输出功率、氢气流量、纯度、温度及压力,结合PID算法动态调节硼氢化钠溶液供给速率和反应温度,实现产氢速率与负载需求的精准匹配。控制器单元根据负载功率差值计算目标产氢速率,通过比例系数、积分时间和微分时间的优化组合生成控制信号,驱动可调流量泵和加热装置执行调节。系统在‑40℃环境下启动时间≤1min,响应时间<5s,稳态误差<3%,并具备氢气纯度<99.99%、压力>8bar时的自动保护功能。本发明解决了传统系统响应滞后、低温性能差及安全隐患问题,显著提升了供氢效率与系统可靠性。
Resumen de: CN120271159A
本发明公开了一种工业污水分级处理设备,属于工业污水处理技术领域,该设备包括污水处理装置机体,还包括三级处理室、电解极棒、分流组件和气体分离回收机构,所述三级处理室设置于污水处理装置机体内腔的一端;所述电解极棒设置于三级处理室内腔的底部;本发明通过设置分流组件和气体分离回收机构,当污水可通过分流组件导流至三级处理室的内部时,由于分流组件使得三级处理室内部污水被分流两侧,并且可对两侧的污水在电解极棒电解产生氢气和氧气形成的气泡进行分隔开,之后通过水流向上进入至气体分离回收机构内部,可实现对污水顶部气泡中的氢气和氧气低成本的回收,避免造成能量损坏,减少了成本。
Resumen de: CN120280512A
本发明涉及一种燃料电池散热器自动清洗系统,包括热交换系统、清洗系统、测控系统和定位系统;所述定位系统上设置有热交换系统、清洗系统和测控系统;所述热交换系统和清洗系统之间构成循环加热回路,所述热交换系统、和清洗系统与待清洗散热器构成循环清洗回路;所述热交换系统和清洗系统由测控系统控制连接。本发明整个清洗过程完全实现自动化,在提高清洗效率的同时,减少人员劳动强度。
Resumen de: CN120270791A
本发明涉及氢燃料电池生产技术领域,具体是涉及一种氢燃料电池生产用的贴合放料机械臂,包括安装在移动机械臂上的移动放料装置,移动放料装置包括堆叠限位框架,堆叠限位框架的侧部设有多个限位进料口,堆叠限位框架的内部设有堆叠检测区域,堆叠检测区域的侧部设有多个检查口,每个检查口位置均安装有视觉检测摄像头,堆叠限位框架的上方安装有推动板料向下移动的贴合推压机构,堆叠限位框架上安装有夹持调控装置,夹持调控装置设有两个用于夹持板材的夹持端,本发明可有效提高生产质量避免造成浪费,同时提高生产效率。
Resumen de: CN120280503A
本申请提供了一种碳载铂钴铜多功能合金催化剂及其制备方法与应用,属于能源材料技术领域。其中,将纳米碳载体溶液与氯铂酸溶液、氯化钴溶液以及氯化铜溶液混合,加入氢氧化钠水溶液调节pH值,超声分散,搅拌,得到悬浊液,其中,铂离子与钴离子、铜离子的摩尔比为2:(0.5‑1):(0.5‑1);接着,将悬浊液放置于反应釜中,在120‑250℃下反应1‑6h,得到黑色胶体溶液;然后,将黑色胶体溶液过滤,洗涤,干燥得到黑色粉末;最后,对黑色粉末进行酸处理,研磨,得到碳载铂钴铜多功能合金催化剂。该催化剂用于氢燃料电池和/或甲醇燃料电池中阴极的氧还原反应催化,和/或直接甲醇燃料电池中阳极的甲醇氧化反应催化。
Resumen de: CN120269763A
本发明涉及氢燃料电池汽车零部件制造领域,提供一种氢燃料电池用气液分离器二次包胶注塑成型方法,通过先成型作为基体的分水体和湿入腔体,再将成型的基体放入气液分离器注塑模具中往分水体和湿入腔体交接处注入与基体同样的注塑材料形成包胶功能层,这样可以将分水体和湿入腔体通过压力耦合实现分子链互熔在一起得到气液分离器总成,无需粘合剂,没有选用传统的动态硫化热塑性弹性体,选择了同种材料模腔内熔合的方式,提高了整体的强度以及气密效果。
Resumen de: WO2024196216A2
The present invention relates to a metal nanostructure and a method for manufacturing same. Provided is a method for manufacturing a metal nanostructure, the method comprising a step for reacting a precursor aqueous solution including a metal salt, glycerol, and oxalic acid.
Resumen de: CN223079142U
本实用新型公开了中冷增湿装置、燃料电池系统以及车辆,涉及车辆领域,中冷器包括第一壳体,第一壳体包括第一定位部,第一定位部设于第一壳体且位于第一壳体的边缘;增湿器包括第二壳体,第二壳体包括第二定位部,第二定位部设于第二壳体且位于第二壳体的边缘;第一壳体与第二壳体是通过第一定位部与第二定位部的定位配合而连接的。由此,通过使中冷器包括第一定位部,增湿器包括第二定位部,并使第一定位部与第二定位部定位配合,能够将尺寸链的计算点位移至第一定位部和第二定位部处,降低焊接变形带来的偏差,从而能够使中冷器与增湿器精准定位配合,便于螺栓与螺纹孔对位,降低中冷器、增湿器等零件损坏风险,并且,有利于提高装配效率。
Resumen de: CN223079144U
风光一体化氢燃料电池装置,包括氢燃料电池本体、水电解制氢设备、控制箱、直流风力发电机、太阳能电池板、气体压缩机、氢气罐、氧气罐、储氢罐、储氧罐、气压开关、蓄电池、底板、电磁阀、液位探测开关、短信模块;氢燃料电池本体、水电解制氢设备、控制箱、气体压缩机、氢气罐、氧气罐、储氢罐、储氧罐、气压开关、蓄电池、电磁阀、液位探测开关、短信模块安装在底板上,直流风力发电机、太阳能电池板安装在室外。本新型相较于现有蓄电池储能方式,能实现更好的能源存储效果;在储氢罐、储氧罐内气体减少到一定,能自动切换氢气罐、氧气罐供气,且在氢气罐、氧气罐内气体量及水箱内液体量减少到一定时,能提示不在现场的工作人员加水或加气。
Resumen de: CN223079136U
本实用新型公开了一种膜电极及单电池的密封结构,涉及燃料电池技术领域,质子交换膜的上下两侧均设有催化剂层,催化剂层的外侧两端均设有内密封框架层,内密封框架层的外侧均设有外密封框架层;内密封框架层的内侧一端设有嵌入槽,对应的嵌入槽之间设有气体扩散层,气体扩散层的外侧设有双极板。嵌入槽可以方便对气体扩散层进行定位,粘贴固定时不易产生褶皱,另外内密封框架层起保护质子交换膜和密封支撑的作用,外密封框架层防止气体扩散层受压损伤,同时外密封框起到与双极板粘结密封作用,避免双极板和膜电极之间再采用点胶或者橡胶垫的方式密封,有效保证各组件之间的固定装配和密封,电堆的整体发电性能一致性好,维护成本低。
Resumen de: CN223076524U
本实用新型涉及一种用于电堆测试的连接装置,包括:测试设备、电堆及快接装置,测试设备设有第一氢气进出口管件、第一氧气进出口管件及第一冷却水进出口管件,电堆设有第二氢气进出口管件、第二氧气进出口管件及第二冷却水进出口管件,快接装置包括基座、第三氢气进出口管件、第三氧气进出口管件、第三冷却水进出口管件及肘夹机构,第三冷却水进出口管件的其中一个自由末端与第二冷却水进出口管件相对接,第三冷却水进出口管件的另一个自由末端连接有自密封快插接头,自密封快插接头与第三软管的其中一个自由末端通过第三固定件连接,所述第三软管的另一个自由末端与第一冷却水进出口管件通过第四固定件连接,从而大大提高了工作效率。
Resumen de: CN223079138U
本实用新型涉及燃料电池技术领域,具体提供了一种燃料电池空路冷却系统,包括汽水分离器和中冷器,所述汽水分离器的一侧连通设置有电堆出口氢气管,所述汽水分离器的另一侧连通设置有出口管,所述汽水分离器用于分离氢气中的液态水,所述中冷器靠近汽水分离器的一端连通设置有冷却水进管,所述冷却水进管与汽水分离器之间设置有排水阀,所述排水阀的两端分别连接汽水分离器的水腔与中冷器上的冷却水进管。本方案中,利用燃料电池氢气回路中产生的低温液态水冷却空气,使中冷器出口空气温度更低,控制增湿后空气露点,避免空氢温差过高,从而改善空气在电堆中遇冷凝露的问题,避免了淹堆导致的电堆寿命缩减的问题。
Resumen de: CN223079143U
本申请涉及一种延伸式燃料电池极板电压采集结构,适用于极板,包括取电片,所述极板的一端设置有凹型槽,所述取电片卡设于所述凹型槽内;所述取电片包括第一连接部、第二连接部和第三连接部;所述第二连接部分别与所述第一连接部、所述第三连接部连接;所述第一连接部与所述第二连接部卡设于所述凹型槽内;所述第三连接部与连接器连接;所述第三连接部上设置有注塑胶条。通过本申请结构,极大的降低了取电片与极板的接触电阻,并且能够有效提高后续组装巡检的效率,减少对极板的损伤,便于后期维护。通过设置注塑胶条,使得取电片和极板连接稳定,并能增加取电片与连接器连接的可靠性,有效防止接触不良。
Resumen de: CN223079797U
本实用新型公开了一种可控温电电混联供电模块,属于混合供电技术领域,包括为负载供电并回收能量的高压高功率器件组、存储电能并为高压器件和负载充电的高压电池组,高压电池组通过DC‑DC控制器连接高压器件组。第一控制器控制高压电池组和DC‑DC控制器工作状态,控温组件通过循环管路为高压电池组和高压高功率器件组提供冷却,部分管路穿过高压电池组和高压器件内部。第二控制器控制控温单元和高功率器件的运行,BMS系统与各控制器交互。此设计提高了系统效率和稳定性,优化了温度管理。
Resumen de: CN223079145U
本实用新型公开一种基于单线制的燃料电池系统。该燃料电池系统采用金属壳体,所述燃料电池系统内部设置有一个以上的带电零部件,所述带电零部件采用单线连接,带电零部件的正极连接至整车或台架,负极连接至金属壳体,金属壳体与整车负极或测试台架负极相连接。采用单线制供电,负极搭铁的方式,通电后,源源不断的电子通过燃料电池系统的金属壳体与整车车架连通,如同在这些金属表面附着了防氧化层,使得这些壳体材料更加不易失去电子而被氧化,从而提高了燃料电池系统结构的抗腐蚀能力,保证其强度的延续性。
Resumen de: CN223078935U
本实用新型涉及一种燃料电池,包括供气管路,设置于供气管路上的电磁阀,其中电磁阀上设置有线圈和弹性密封圈,用于驱动所述电磁阀的电磁阀驱动电路,所述驱动电路包括:脉冲产生电路,其与电源和电磁阀连接,受所述电源驱动而产生脉冲驱动电压,脉冲驱动电压具有一频率,所述电源以相应的频率间歇性向所述电磁阀的线圈供电;放电回路,与所述电磁阀的线圈连接,在所述电源停止向所述电磁阀供电时,用于释放所述线圈的电感能量,以使所述线圈产生维持所述电磁阀开启或关闭状态的电磁力。本申请实现了较低功率维持电磁阀启动,降低了电磁阀线圈发热,降低了温度对线圈以及密封圈的影响,增加了电磁阀的使用寿命。
Resumen de: CN223079140U
本申请提出了一种空气子系统,其包括阴极供气管线、连接在阴极供气管线上的压缩机、阴极排气管线、连接在阴极排气管线上的涡轮机、以及连接在阴极供气管线和阴极排气管线上的第一换热装置。第一换热装置能够在第一状态与第二状态之间切换,其在处于第一状态下在压缩机的上游的空气流与涡轮机的下游的阴极废气流之间建立第一换热路径,以使空气流在进入压缩机之前与从涡轮机离开的阴极废气流换热,在处于第二状态下断开第一换热路径,而不使空气流在进入压缩机之前与从涡轮机离开的阴极废气流换热。第一换热装置使得能选择性地利用从涡轮机离开的阴极废气流在空气进入压缩机之前冷却空气。本申请还提出了包括该空气子系统的燃料电池系统。
Resumen de: CN223079146U
本申请公开了一种液流抽液混合储能装置,包括:电堆,其内设置有将电堆分隔成阳极室和阴极室的离子交换膜;储液容器,在沿着高度方向上,储液容器设置在相对电堆的下方,储液容器包括通过第一电解液循环管路与电堆的阳极室相连接的第一储液容器和通过第二电解液循环管路与电堆的阴极室相连接的第二储液容器,第一电解液循环管路和第二电解液循环管路上均设置有循环引流泵,第一电解液循环管路和第二电解液循环管路至少其中之一上设有发电机,在沿着高度方向上,发电机设置在相对电堆的下方;等等,本申请通过发电机做功将电解液的重力势能以及循环引流泵带给电解液的部分动能充分转化为电能,实现电解液的动能回收,提高能量利用率。
Resumen de: CN223079141U
本实用新型公开了一种燃料电池阳极排水加湿系统,包括燃料电池堆、气水分离器、用于阳极增湿的水喷射器,所述气水分离器与燃料电池堆的阳极出口相连,水喷射器设置在燃料电池堆的氢气输送管路上,还包括储水箱,储水箱的上端与气水分离器的出水口相连,储水箱通过水泵与水喷射器相连,并储水箱底部连有排水阀,所述储水箱内设有液位传感器,液位传感器与排水阀及水泵控制相连。其可消除阳极排水过程中阳极压力波动,使气水分离器中不存水,增加气水分离器分水效果,通过收集的排水对系统阳极湿度,替代当前普遍使用的增湿器,可显著降低成本。
Resumen de: CN223076281U
本实用新型公开了一种大功率燃料电池开关电磁阀,涉及电磁开关阀技术领域,包括流道阀室、执行机构仓以及加热组件,执行机构仓固定安装在流道阀室的一侧,加热组件通过加热连接线固接在流道阀室的另一侧;流道阀室的上下两侧分别固接有进气管与出气管,流道阀室的内部密封滑动安装有堵块,堵块靠近执行机构仓的一侧固接有连通管,流道阀室的内部滑动安装有滑动箱,滑动箱与连通管的另一侧固定连接;连通管的内壁上下两侧均限位滑动安装有密封衔接环,本实用新型通过在堵块上设置连通管,通过堵块在流道阀室内滑动,使连通管于进气管和出气管处在同一轴线上,进而形成直动式的常开型电磁阀结构,从而有效的降低了氢气经过电磁阀的流动阻力。
Resumen de: CN223076732U
本实用新型涉及压力容器技术领域,具体为一种用于燃料电池的液氢储氢设备,包括液氢瓶和管线总成,液氢瓶包括外胆和内胆,内胆前端与外胆固定连接,内胆后端与外胆活动连接,管线总成包括加注管、出液管、气相管、自增压管、置换管、放散管。本实用新型公开的用于燃料电池的液氢储氢设备,对管线总成进行优化设计,确保液氢加注、暂存和使用状态下的安全性。
Resumen de: CN223079139U
本实用新型涉及燃料电池冷却系统技术领域,具体是一种管带式真空钎焊芯体,由护板、散热带、单侧圆弧槽短封条、两侧弧槽短封条以及哈弗结构打点冷却管构成,所述护板安装在芯体两边的最外侧,紧贴护板的里侧为散热带,紧贴护板散热带的两头为单侧圆弧槽短封条,紧贴散热带的里侧为哈弗打点冷却管,哈弗打点冷却管的两端头为两侧弧槽短封条,依次排列散热带、哈弗结构打点冷却管、两侧弧槽短封条,至所需芯宽后,通过真空钎焊焊接成型为一个完整的管带式结构芯体。本实用新型与现有技术相比,具有热侧电导率小,散热密度大,体积小,结构紧凑的优点。
Resumen de: CN223079137U
本实用新型公开了一种燃料电池单电池结构,包括依次叠层设置的阳极板、膜电极以及阴极板,所述阳极板和膜电极之间设有阳极密封结构,所述膜电极和阴极板之间设有阴极密封结构,所述阳极密封结构和阴极密封结构均为半硫化注塑成型的一体密封胶条结构,所述阳极板、膜电极以及阴极板通过阳极密封结构及阴极密封结构形成整体单电池单元,并在单电池单元边部设有用于整体密封的边缘包胶。该燃料电池单电池结构设计合理,使极板成型时阳极场密封胶条处于半硫化状态,阴极板气场半硫化状态,水场密封与气场密封一次成型更加便捷,简化装配电堆,减少装配累积公差,提高一致性,并且成本相对较低。
Resumen de: CN223079135U
本实用新型提供一种燃料电池极板流道结构,适用于燃料电池极板,包括依次连接的第一端口、流道本体和第二端口;所述流道本体包括抛物面、第一侧面、第二侧面和平面底面;所述抛物面与所述平面底面相对设置;所述第一侧面分别与所述抛物面、所述平面底面连接,所述第二侧面分别与所述抛物面、所述平面底面连接;所述第一侧面与所述第二侧面相对设置;所述平面底面靠近气体扩散层设置。本申请还提供一种极板。通过本申请结构,能够更好的提高电堆的性能,有利于电堆的散热。本申请的结构简单美观、能耗较低,经济实用,可加工性好,可以应用于燃料电池系统中进行使用。
Resumen de: WO2024121430A2
This disclosure pertains to an advanced device for determining physical properties of an electrolysis cell. The device features an innovative energy harvesting mechanism, adeptly configured for secure attachment around an anode rod or busbar of the cell. Equipped with at least one sensor, the device accurately measures vital cell properties. Additionally, it includes a wireless transceiver unit for efficient data communication. A key aspect of this invention is the use of distributed computing capabilities, enabling sophisticated analysis and real-time data processing from the sensors. This enhances measurement precision and contributes to a deeper understanding and optimization of the electrolysis process. The integration of energy harvesting, precise measurement, and distributed computing represents a holistic approach to monitoring and analyzing electrolysis cells, signifying a notable advancement in the field.
Resumen de: WO2024112465A2
The present disclosure relates to a battery energy storage container. The energy storage container has a cylindrical housing and a pair of end caps disposed on opposite ends of the cylindrical housing. A diaphragm is positioned between each end cap selected from the pair of end caps and the corresponding end of the cylindrical housing. In one version, the energy storage container is configured to be installed below the ground surface for geological thermal management of the energy storage container. Embodiments of the present invention further disclose various types of electrode retainers. The energy storage container is configured for use in electrochemical battery cells, Li-ion batteries, intercalation batteries, metal-air batteries, flow batteries, fuel cells, reversible fuel cells, and capacitors.
Resumen de: CN120280526A
本发明公开了一种泥浆型质子空气液流电池,本发明采用嵌质子材料流动泥浆作为电子载体和H+嵌入脱出的负极电解液,以基于氧的氧化还原反应的空气电极为正极构建了泥浆型质子空气液流电池。其中,负极氧化还原电对为质子的嵌入和脱出,正极氧化还原电对为氧析出和氧还原反应。由于该电池的充放电过程嵌入/脱出氢可提供不同的电位,而正极的空气电极的电位为1.23V vs.SHE,可以实现正负极的较大的电压差,空气电极由于发生氧的氧化还原反应,通过耦合质子的嵌入脱出与氧气的氧化还原反应,使得该泥浆型质子空气液流电池的能量密度和循环稳定寿命大幅提升。
Resumen de: CN120270964A
本申请公开了一种含有微波加热氨分解制氢装置的发电供气系统,包括氨罐、氨分解制氢装置、水循环机构、产气机构和发电机构,氨罐与氨分解制氢装置连通;水循环机构包括循环连通的水箱、第一换热和多个水冷器,分解气出口依次与第一换热器和水冷器连通;水冷器与发电机构相连;产气机构包括压缩机、第一缓冲罐、第二缓冲罐和第一变压吸附装置;压缩机与第一缓冲罐串联连接,第一缓冲罐再于第一变压吸附装置相连;第一变压吸附装置包括并联设置的第一分子筛和第二分子筛,第一分子筛和第二分子筛之间设置有多个氮气阀门。该含微波加热氨分解制氢的发电供气系统实现了氨分解制氢发电以及制氧制氮的有机结合,减少了整体系统运行过程中的能量消耗。
Resumen de: JP2024101896A
To suppress energy loss.SOLUTION: A work vehicle which is equipped with a drive source that uses hydrogen as fuel includes an electrolysis device which performs electrolysis of generated water generated from the drive source or stored water stored in a water tank by using the power.SELECTED DRAWING: Figure 2
Resumen de: WO2025141953A1
A fuel cell system (1) comprises an FC stack (11) that generates electric power upon receiving supply of hydrogen and air, but does not comprise a DC-DC converter. The fuel cell system comprises: a hydrogen system (21) that supplies hydrogen to the FC stack (11); and a control device (20) that controls an injector (53) of the hydrogen system (21). When the FC stack (11) stops intermittently, the control device (20) controls the injector (53) so as to lower the outlet hydrogen pressure at an ejector (54) of the hydrogen system (21) to a level higher than a prescribed cutoff hydrogen pressure. Prior to lowering the outlet hydrogen pressure to a level higher than the cutoff hydrogen pressure, the control device (20) controls the injector (53) so as to temporarily lower the outlet hydrogen pressure to the cutoff hydrogen pressure.
Resumen de: JP2025101560A
【課題】燃料電池システムの補助電池のメモリ効果を抑制することである。【解決手段】燃料電池システムは、燃料電池と、燃料電池の出力電力が燃料電池システムへの要求電力に対する余剰の電力を充電し、放電してその不足分を補う補助電池と、燃料電池の出力と補助電池の充放電を制御する制御部とを備え、設定した上限SOC:SCmaxと下限SOC:SCminの間で、中心SOC:SC1~SC5に基づいた複数の帯域Z1~Z5に区分され、補助電池SOC調整モードにおいて制御部は、補助電池のSOC:SBが、中心SOC:SCに基づいた所定の帯域にある場合に、カウンタにより一定のタイミングで、中心SOC:SCを変更する中心SOC変更処理の手順を実行する。このため、補助電池が使用されるSOCの帯域が分散されメモリ効果を抑制することができる。【選択図】図5
Resumen de: CN120261618A
一种层叠式真空焊接水冷中冷器结构,该结构的底板设有增压空气进口和增压空气出口、顶板设有冷却液进口和冷却液出口,底板和顶板之间由增压空气翅片、隔片和冷却液翅片按次序排列组合成多层层叠式结构。其中两个隔片之间设有增压空气翅片形成增压空气流道层;两个隔片之间设有冷却液翅片形成冷却液流道层,增压空气流道层和冷却液流道层依次排列。各个部件之间通过真空钎焊焊接组成一个整体。本发明与现有技术相比,具有低导电率性能确保燃料电池的长效稳定运行的优点,并且组装灵活、增减换热功率只需增减隔片、增压空气翅片和冷却液翅片的层数,不用重新开模气室和水室,降低生产成本。
Resumen de: CN120261650A
本发明公开了复合型全钒液流电池电解液添加剂及全钒液流电池电解液与制备方法,属于液流电池技术领域。该复合型全钒液流电池电解液添加剂包括摩尔比为(0.5~1.5):(1~3):(10~20)的MgCl2、(NH4)2SO4和CH3SO3H。该全钒液流电池电解液包括:钒离子、该复合型全钒液流电池电解液添加剂以及水。本发明可提高电解液中钒离子的浓度及高温稳定性,改善电解液能量密度低及稳定性差的问题,并且具有较低的成本。
Resumen de: CN120261610A
本发明属于氢燃料电池技术领域,公开了一种氢燃料电池钛双极板的处理方法、钛双极板,以解决燃料电池在氢电耦合系统中由于不稳定或波动工况而导致的钛双极板耐久性较差的问题。本发明处理方法包括步骤:对钛双极板进行预处理,以除去其表面的杂质和氧化膜;将经预处理的钛双极板进行渗氮处理;将经渗氮处理的钛双极板进行酸浸处理,形成钝化层;将酸浸处理后的钛双极板进行渗碳处理。本发明提出了渗氮‑酸浸‑渗碳的三级协同机制,在钛双极板表面构建“梯度功能化”防护体系——渗氮层提供基础耐蚀性、酸浸层确保致密性、渗碳层保障导电性,三者协同解决了波动工况下耐久性与导电性的矛盾问题。
Resumen de: CN120261652A
本发明涉及氢燃料电池领域,具体是涉及一种氢燃料电池电堆具有对位功能的堆叠装置。应用于若干单电池的堆叠,包括输送机构和能够沿垂直方向移动的载料台,载料台的正上方设有固定架,所述固定架上设有一对供单电池支撑的支撑件,所述支撑件能够在固定架上水平移动,所述固定架上还设有对位放料机构,所述对位放料机构包括下压组件和均布在固定架四周的限位板,下压组件上设有与每个限位板配合的第一联动件以及与每个支撑件配合的第二联动件。本发明通过第一联动件与限位板的联动配合,形成以已堆叠单电池为基准的居中对位通道,确保待堆叠单电池精准定位,同时通过第二联动件驱动支撑件平稳脱离,实现从支撑到限位的无缝过渡。
Resumen de: CN120261635A
本发明涉及一种可逆固体氧化物燃料电池调压测试方法,可按需求选常压或高压模式以及SOFC或SOEC模式;常压下SOFC模式通气体加热后经电子负载控功率,尾气冷却直排;常压下SOEC模式经直流电源控电解功率,燃气尾气冷却后处理测产量;高压模式先进入增压阶段,关闭燃气尾气直排流路,通过旁通支路使燃气与空气排放背压阀压力联动,向舱段通空气增压,借多背压阀联动控排放压力以稳定增压,完成后燃气极切换通燃气、关闭旁通支路,再进入SOFC或SOEC模式。本发明方法能满足不同正压测试需求,采用完备控制策略提供连续稳定压力,减小阴阳极压差保护电池,旁通管路及阀可避免两极压差波动。
Resumen de: CN120261629A
本发明公开了一种氢燃料电池堆水平衡检测装置,属于氢燃料电池堆技术领域。一种氢燃料电池堆水平衡检测装置,包括检测平台和电池堆模组,所述检测平台的上方设置有绝缘检测箱,其中,所述绝缘检测箱的内部设置有滑座,滑座的下方设置有导轨。为解决现有的燃料电池堆水平衡监测方法主要是从电池的阳极或阴极一侧冷凝和收集出水量,这种方法耗时长,不适合实时使用,且在检测过程中容易受环境温度以及工作温度的影响,从而导致检测结果存在误差的问题,本发明采用的拓扑结构具备输入电流纹波小、效率高、电压增益比高、结构紧凑和冗余度高的特点,并且可以在更高开关频率下延长燃料电池堆的寿命,同时实现高频阻抗的在线测量。
Resumen de: CN120261605A
本发明属于氢氧燃料电池催化剂技术领域,具体公开了一种碳负载型高熵合金纳米催化剂及其制备方法和应用。碳负载型高熵合金纳米催化剂中的高熵合金至少包括五种金属元素,其中至少一种金属元素为贵金属,贵金属和非贵金属原子比为1:1‑3:1,贵金属选自Pt、Ir、Ru中的至少一种,非贵金属选自Fe、Zn、Cu中的至少一种,贵金属元素的质量分数为5‑20wt%。本发明通过高熵合金组分设计、晶相定向调控及超细纳米结构构筑,在降低贵金属用量、提升催化活性/稳定性、抗毒化性能及工艺成本等方面实现了技术突破,特别适用于氢氧燃料电池、电解水等对CO耐受性要求严苛的领域。
Resumen de: CN120261641A
本发明属于燃料电池技术领域,公开了一种基于燃料电池系统与PEM电解水的热电联供方法。使用换热器带走PEM电解水设备和燃料电池系统的热量,付诸于自来水和冷却液,用于使用和供暖,将燃料电池系统产生的电供给循环使用和外部用电。本发明充分利用了PEM电解水产生的热能,燃料电池系统产生的热能和电能,通过循环利用,将燃料电池系统的效率从52%提高到70%。
Resumen de: CN120261645A
本发明涉及燃料电池技术领域,具体的,涉及一种质子交换膜及其制备方法与应用。制备原料包括:聚苯并咪唑粉末、聚乙烯醇、磷酸、交联剂和溶剂,所述聚乙烯醇的添加量为聚苯并咪唑粉末的10‑30wt%。本发明以聚苯并咪唑粉末、磷酸作为磷酸化试剂、聚乙烯醇作为功能化基团引入试剂,通过化学修饰和柔性侧链的引入,显著提高了质子交换膜的质子传导性能和机械强度,特别是在低湿度和高温条件下的性能表现优异,适用于燃料电池领域。
Resumen de: CN120261627A
本发明公开了一种电池电解液的温度控制系统和方法,控制系统中,第一温度检测单元用于采集第一电解液储液罐中电解液的温度;第二温度检测单元用于采集第二电解液储液罐中电解液的温度;冷却控制单元用于控制第一电解液储液罐中的电解液和/或第二电解液储液罐中的电解液流入换热单元进行冷却,加热控制单元用于控制第一电解液储液罐中的电解液和/或第二电解液储液罐中的电解液流入换热单元进行加热;换热单元位于第一电解液储液罐和第二电解液储液罐的外部,换热单元与第一电解液储液罐和第二电解液储液罐连接。本发明的温度控制系统中可同时对两个储液槽进行冷却和加热功能,实现一套系统两种功能,适应复杂工况需求。
Resumen de: CN120261646A
本发明涉及固体氧化物燃料电池技术领域,公开了一种复合型钪锆电解质薄膜及其制备方法与应用,本发明提供的复合型钪锆电解质薄膜的制备方法,包括如下步骤:将钪锆粉体、助烧结剂、分散剂、粘结剂、增塑剂、有机溶剂混合后得到钪锆电解质浆料;将钪锆电解质浆料经流延处理后,得到单层钪锆电解质生坯片;将至少两个单层钪锆电解质生坯片层叠放置后依次进行经热压、排胶、烧结处理,得到所述复合型钪锆电解质薄膜。本发明首先将流延成型、热压、排胶烧结技术组合应用,简化了复合型钪锆电解质薄膜的制备工艺路径,提高了生产效率和成品率,得到厚度可控、宏观平整、微观致密、高强度的复合型钪锆电解质薄膜。
Resumen de: CN120261628A
本发明公开了一种分布式全钒液流电池储能系统,包括全钒液流电池单元,功率转换装置、通讯控制模块和电池管理系统,所述全钒液流电池单元设有多组,多组所述全钒液流电池单元采用分布式组合,述功率转换装置用于将全钒液流电池单元提供的直流电能转化为交流电能,所述通讯控制模块通过无线网络或有线网络与电池管理系统连接通讯,用于实时监测电池单元的运行状态及电池单元的温度、电流和电压的参数,所述电池管理系统能够根据负荷需求实时调节电解液流量。本发明涉及电力储能设备技术领域,本系统具有较高的能量密度、长寿命以及更好的适应性和扩展性,用于解决现有集中式储能系统的缺点,适用于多个分布式场景。
Resumen de: CN120261653A
本发明涉及燃料电池技术领域,具体是涉及一种氢燃料电池箱体结构,包括箱体,用于安装氢燃料电池本体,内置有缓冲装置;缓冲装置包括至少一对缓冲组件以及一对安装在氢燃料电池本体上并与缓冲组件连接的连接板;同一对缓冲组件分列于氢燃料电池本体的相互平行的侧面处,每个缓冲组件至少具有一对压紧块和预紧机构,两个压紧块相互抵近处形成锥形槽,连接板上设有连接球头;通过在箱体内设置能够形成锥形槽的压紧块,并且通过锥形槽与连接球头的配合设计,使得氢燃料电池本体在沿横向、纵向或斜向运动时,都能通过球头与锥形槽的接触将运动转化为压紧块所受预紧力方向的位移,实现全方向缓冲,解决了单方向缓冲结构的局限性问题。
Resumen de: CN120245823A
本发明涉及供配电系统技术领域,提供了一种基于超级电容的燃料电池商用车功率优化方法及系统,燃料电池商用车功率优化方法包括如下步骤:联合燃料电池以及动力电池为负载电动机供电,根据动力电池的SOC状态,调整燃料电池在不同SOC状态下的功率输出;预测动力电池的SOC波动状态,以最小化燃料电池输出功率波动次数为目标,调整动力电池与超级电容之间的能量交换。本发明通过预测动力电池的SOC波动状态,适时调整动力电池与超级电容之间的能量交换,其以最小化燃料电池输出功率波动次数为目标来优化功率分配,可避免SOC在临界值附近波动所导致的燃料电池功率输出的不稳定,从而减少燃料电池的频繁功率变化,延长其使用寿命。
Resumen de: CN120261617A
本发明涉及一种大功率燃料电池热管理系统及方法,系统包括主散热回路、辅助散热回路和冷却水循环系统,主散热回路包括第一换热器、高温冷却液循环泵、电动调节阀、温度传感器、电子节温器和PTC加热器,辅助散热回路包括第二换热器和低温冷却液循环泵;第一换热器分别连接高温冷却液循环泵、PTC加热器和第二换热器,高温冷却液循环泵出口接管分别连接n个电堆组的冷却液进口,其冷却液出口接管汇流后连接电子节温器进口,电子节温器出口连接PTC加热器和第一换热器;第二换热器连接空压机、DC/DC和中冷器。该系统及方法有利于精确控制燃料电池电堆的预热温度和工作温度,使燃料电池工作在最佳工作温度范围内,进而提升燃料电池系统的工作效率和使用寿命。
Resumen de: CN120261615A
本发明公开了一种能量交互系统及储能电站,包括液冷系统、第一换热器、氢燃料电池系统和液态空气储能系统,第一换热器用于对电池包进行冷却,液冷系统包括第一进液口和第一出液口,第一换热器,包括第二进液口和第二出液口,第二进液口和第一出液口连通,第一换热器用于加热流经第一换热器的冷媒。氢燃料电池系统包括第三进液口和第三出液口,第三进液口和第二出液口连通,氢燃料电池系统用于为电池包供能。液态空气储能系统包括第四进液口和第四出液口,第四进液口和第三出液口连通,第四出液口和第一进液口连通。能量交互系统能够提高储能电站的能源利用率。
Resumen de: CN120261642A
本发明公开了一种燃料电池空气处理系统及其控制方法和燃料电池系统,涉及燃料电池技术领域,其中,燃料电池空气处理系统包括第一管路、第二管路和吸附部,第一管路具有用于通入空气的第一进气口,以及用于与电堆阴极连通的第一出气口,第二管路具有用于与电堆阴极连通的第二进气口,以及与第一管路连通的第一连通口,第一连通口位于第一进气口与第一出气口之间,用于将电堆阴极中的尾气通入至第一管路;吸附部设于第二管路,用于吸附尾气中的氮气,以提高尾气中的氧气浓度。本发明中的技术方案,通过设置第二管路与吸附部,从而对尾气进行脱氮,以得到高氧浓度混合气体,并将该气体重新通入到第一管道中,从而在提高电堆效率的同时,降低了能耗。
Resumen de: CN120261623A
本发明涉及一种无人机用氢燃料混合动力系统及其工作方法,所述混合动力系统中氢燃料电池系统和氢气发动机系统结合到一起,氢燃料电池系统中的供氧子系统的空气滤清器依次连接空压机、第一涡流管,第一涡流管的热流出口通过管道与氢气发动机系统连接;第一涡流管的冷流出口通过管道依次连接雾化器、电堆的冷却入口,电堆的冷却出口通过管道连接电堆的阴极入口,电堆的阴极出口通过管道与氢气发动机系统连接。通过将两种动力系统结合到一起,构成氢燃料混合动力系统,既为无人机提供了较强的飞行动力和较长的续航时间,同时也为无人机中的电气设备提供电能,保证电气设备正常运转的同时,无需通过冗长的能量转化链路,有效提高了能量利用率。
Resumen de: WO2024150467A1
Provided is a solid electrochemical device comprising: a solid electrolyte which has a first main surface and a second main surface that is opposite from the first main surface; a first electrode which has a third main surface and a fourth main surface that is opposite from the third main surface and which is provided such that the third main surface faces the first main surface; a first current collector which has a fifth main surface and a sixth main surface that is opposite from the fifth main surface and which is provided such that the fifth main surface faces the fourth main surface; and a first interconnector which has a seventh main surface and which is provided such that the seventh main surface faces the sixth main surface, wherein the seventh main surface of the first interconnector is a flat surface, the first current collector includes a first porous metal body that has a three-dimensional network structure, and the fifth main surface has a plurality of first through-holes that are formed so as to extend along a first direction from the fifth main surface to the sixth main surface.
Resumen de: US2024178502A1
Embodiments described herein relate to electrochemical cell assemblies with structural members for application of compressive force. In some aspects, an electrochemical cell assembly can include a plurality of electrochemical cells arranged in a stack, a first planar sheet in contact with a first side of the stack, a second planar sheet in contact with a second side of the stack, a first structural member in compressive contact with the first planar sheet, and a second structural member in compressive contact with the second planar sheet, wherein the compressive contact between the first structural member and the first planar sheet and the compressive contact between the second structural member and the second planar sheet collectively provide structural rigidity to the electrochemical cell assembly.
Resumen de: CN120261611A
本发明实施例公开一种复合极板单电池,包括第一复合极板、第一密封胶、膜电极、第二复合极板、第二密封胶和第三密封胶;所述膜电极设置于所述第一复合极板与所述第二复合极板之间,且所述膜电极分别与所述第一复合极板、所述第二复合极板抵接设置;所述第一密封胶设置于所述第一复合极板与所述膜电极之间,所述第二密封胶设置于所述第二复合极板与所述膜电极之间,所述第三密封胶围合设置于所述第二复合极板远离所述膜电极一侧面的边缘。本申请还提供一种电堆。本申请的复合极板单电池厚度薄、体积小,使用范围、场景更广,全周期使用成本更低,能够带来更高的经济效益。由该单电池制得的电堆的体积也相应减小,能够有效改善传统极板电堆的缺点。
Resumen de: CN120261621A
本申请涉及一种供氢系统及新能源汽车。该系统包括:液氢模块和气氢模块用于分别为增压模块提供第一增压处理后的氢气和高压氢气;回收模块的第一侧与液氢模块连接,用于接收液氢模块排出的回收气氢,并得到增压后的回收气氢;回收模块的第二侧与气氢模块连接,用于将增压后的回收气氢传输至气氢模块;增压模块用于对第一增压处理后的氢气以及高压氢气进行第二增压处理和第三增压处理,得到增压后的目标氢气;缓冲模块用于将增压后的目标氢气供应至发动机模块。采用本供氢系统能够在液氢低存储压力条件下,有效维持液氢供氢压力,保证燃料电池稳定运行,同时对液氢系统蒸发氢气进行回收,提高能源利用率,进而保障车辆的动力和续航能力。
Resumen de: CN120261651A
本发明公开了一种用于高面容量的锌溴液流电池电解液及其制备方法与应用。所述电池包括正极、负极、隔膜、正负极电解液、集流体和端板,其中,正负极均采用碳毡电极,隔膜为阳离子交换膜,正负极电解液由金属盐、支持电解质、有机磺酸盐络合剂及去离子水组成。所述有机磺酸盐络合剂能够调控锌离子的溶剂化结构,减少活性水含量,从而有效抑制析氢副反应。此外,该络合剂可吸附于沉积的锌原子表面,抑制锌在二维界面的扩散,并诱导Zn(002)晶面的优先沉积,从而有效缓解锌枝晶的形成,提高电池的面容量并实现长循环稳定运行。本发明提供的电解液配方及其应用,可显著提升锌溴液流电池的循环寿命与性能稳定性,具有广阔的应用前景。
Resumen de: CN120251771A
本发明公开了一种燃料电池系统电磁阀的控制方法,所述燃料电池系统包括燃料电池控制单元(FCD),所述FCD用于将燃料电池的电源电压平台的电压通过脉冲宽度调制(PWM)方式变换至电磁阀的电压平台所需要的供电电压;本发明创新性地采用了利用脉冲宽度调制(PWM)控制占空比的方式,通过精确的控制手段,可以有效地实现将不同电源电压平台的电压降至电磁阀所需要的供电电压。
Resumen de: CN120261630A
本发明提供了一种单室微生物燃料电池的自适应智能滑模控制方法及系统,属于燃料电池的控制技术领域。目的是通过自适应智能算法有效处理微生物燃料电池中的非线性不确定量,提高系统对负载变化的抗干扰能力,实现更高效的动态响应和稳定的电压输出。其核心步骤包括:首先构建微生物燃料电池的基础动力学模型;然后设计自适应动态滑模面,通过神经网络逼近不确定量的近似函数;最后,基于李雅普诺夫稳定性理论,设计控制策略以确保系统稳定运行。该方法结合神经网络与自适应滑模控制,显著增强系统的动态响应和抗干扰性能,优化电池电压输出,广泛应用于环境监测、废水处理等领域。
Resumen de: CN120253100A
本发明涉及燃料电池故障诊断技术领域,特别涉及一种基于多维传感数据的燃料电池氢气泄露诊断方法,步骤如下:S1.设置电压动态列表、电流动态列表、氢气动态列表、结果动态列表和用于判断氢气泄露的滚动窗口;S2.实时采集燃料电池的电压数据、负载的电流数据和环境中氢气浓度数据;S3.统计电压动态列表中数据个数,若数据个数达到滚动窗口预设容量,则执行步骤S4,否则返回步骤S2;S4.根据滚动窗口内电流动态列表判断电流状态,通过滚动窗口内电压动态列表或/和氢气动态列表给出判断结果,判断结果存储至结果动态列表;S5.根据预设循环窗个数和预设报警阈值判断是否触发故障报警;本发明基于多维传感数据对氢气泄露多维度监测,精准度高,可靠性强。
Resumen de: WO2024110569A1
Fuel cell, comprising: a base plate (11); a stack (20) bearing against the base plate (11); and a compression system, which comprises: a bearing plate (30), movable and bearing against the stack (20); springs (50), bearing against the bearing plate (30); and a flange (40), bearing against the springs (50). So that the fuel cell is particularly stable over time, the fuel cell comprises a first sliding connection (70), for guiding the bearing plate (30) in sliding movement relative to the base plate (11), and pulling plates (60) separated from one another and having anchors fastening them to the base plate (11) and to the flange (40) for holding the stack (20) in compression between the base plate (11) and the bearing plate (30) via the anchors, under the action of the springs (50).
Resumen de: CN120261637A
本发明提出了一种基于氢浓度与压力的燃料电池系统氢泄露诊断方法及系统,涉及氢燃料电池技术领域,该方法包括获取燃料电池系统的氢气压力数据和氢气浓度数据;基于离散小波变换对所述氢气压力数据和所述氢气浓度数据进行数据平滑处理,以获取时间序列数据;将所述时间序列数据输入预设的LSTM‑AE神经网络模型中,获取与所述时间序列数据对应的时序特征向量和传感器网络图数据;基于氢气泄漏检测神经网络模型对所述时序特征向量和所述传感器网络图数据进行数据提取和分析操作,获取氢气泄露检测结果。本申请有助于提升氢气泄露检测的检测精度。
Resumen de: CN120254613A
本发明涉及一种燃料电池供氢子系统测试台架及测试方法,所述测试台架包括氢源、第一减压阀、第一电磁阀、比例阀、氢气循环部件、缓冲罐、第一背压阀、第二减压阀、第二电磁阀、雾化喷嘴、板式换热器、气液分离器和第二背压阀。本申请所设计的燃料电池供氢子系统测试台架可实现氢气循环部件的回流比、气液分离器以及比例阀性能的同步测试,即该测试台架为高度集成的一体化测试台架,提高测试效率的同时有效降低测试成本。通过设计气液分离器的液态水分离效率的计算方法,在测试台架上仅通过布置低成本的流量计、压力传感器、温度传感器和湿度传感器,即可准确计算气液分离器的液态水分离效率,无需额外购买粒度测试仪,测试方便快捷且价格低廉。
Resumen de: CN120261614A
本发明属于电池技术领域,具体涉及界面渗透阻隔式质子交换膜燃料电池分域热管理系统,通过引入多个相互关联的模块,冷却介质分配模块、温度感知模块、流量控制模块、热量计算模块、分区调控模块、老化预防模块、反馈优化模块及用户交互界面模块,实现了对各区域冷却需求的精细化管理和动态调整。具体而言,该系统能够根据各区域的实际工作温度和热量需求,实时调节冷却介质的流速和温度,有效避免局部过热现象的发生,显著减缓催化剂层的老化进程,从而延长燃料电池的整体使用寿命。此外,通过闭环控制系统,用户可以实时监控系统状态并进行手动调整,进一步增强了系统的灵活性和可靠性。
Resumen de: CN120261607A
本发明属于燃料电池催化剂技术领域,具体涉及一种低温直接氨燃料电池催化剂及其制备方法与应用。包括以下步骤:以十六烷基三甲基溴化铵为模板剂和氮源,间苯二酚和甲醛树脂作为碳源,正硅酸乙酯为硅源,在碱性催化剂和溶剂的体系中,得到氮掺杂的介孔碳球前驱体;将氮掺杂的介孔碳球前驱体煅烧,得到氮掺杂的介孔碳球;将氮掺杂的介孔碳球溶于乙二醇溶液中,形成氮掺杂的介孔碳球溶液,向氮掺杂的介孔碳球溶液中加入可溶性铂盐和可溶性钴盐,进行微波反应,得到低温直接氨燃料电池催化剂。本发明以氮掺杂的介孔碳球为载体,负载铂钴双金属制备得到铂钴双金属催化剂,有助于暴露更多的铂活性位点,能够有效提升催化剂的AOR活性。
Resumen de: CN120261632A
本发明涉及新能源储能技术领域,尤其涉及一种全钒液流储能系统的电堆温度监测及控制设备。由分布式温度传感阵列、多参数耦合分析模块、自适应温度调控系统、主控单元、双循环热管理构架以及故障诊断模块组成。控制方法包括以下步骤:建立电堆三维温度场基准模型;实时监测温度分布及电解液参数;计算局部温差导致的效率损失系数;动态调节制冷功率和泵组转速;执行温度均衡度验证和系统自检。本发明提出了一种集成高精度三维温度监测、多参数动态耦合调控及智能故障诊断的电堆温度管理方案,以解决现有技术中监测盲区、调控迟滞及风险预测能力不足等问题,从而提升全钒液流储能系统的运行效率与安全性。
Resumen de: CN120261616A
本申请涉及一种用于新能源汽车上的电池冷却管路总成,包括底盘支架及设置在底盘支架内的循环冷却管,所述底盘支架上阵列设置有多组电池包,所述循环冷却管置于相邻电池包之间,所述循环冷却管设置有进水口及出水口;所述进水口处连接有循环泵体,所述出水口处设置有热交换器,所述循环泵体连接所述热交换器,所述进水口与所述出水口之间设置有连接管,所述循环泵体的出水口处设置有转换阀,所述转换阀上连接排水管,所述转换阀开断可控制循环泵体的出水由循环冷却管转至排水管;本申请具有通过冷却管进行冷却处理,同时当水流流出时避免引发起火的技术效果。
Resumen de: WO2024122150A1
A power generation plan revision method according to the present disclosure includes: a step for receiving a power generation plan for a fuel cell device including a plurality of fuel cell power generation units; and a step for revising the power generation plan for the fuel cell device such that the timing of changing the number of power generating units, of the fuel cell power generation units, is advanced with respect to the timing of the transition from the previous unit period to the next unit period, according to the magnitude of change in output of the fuel cell device when the transition is made from the previous unit period to the next unit period in the received power generation plan for the fuel cell device.
Resumen de: JP2024108382A
To provide a radical-curable seal member for fuel cells which is improved in compression crack resistance.SOLUTION: A radial-curable seal member for fuel cells is formed of a crosslinked body of a radical-curable composition which contains the components (A) to (D) described below, with the content of the component (B) being 5 parts by mass to 20 parts by mass relative to 100 parts by mass of the component (A): (A) polyisobutylene polymer having a (meth)acryloyl group in a molecular chain end, (B) multifunctional (meth)acryl polymer of 5 or more functions, (C) monofunctional (meth)acryl monomer, and (D) a radical polymerization initiator.SELECTED DRAWING: Figure 1
Resumen de: WO2024116527A1
A lifespan prediction method of this disclosure is for a fuel cell device that includes a fuel cell and that comprises a plurality of power generation units. The time at which the power generation units of the fuel cell device reach the end of the lifespan of said power generation units is predicted according to: the cumulative power generation time of the power generation units of the fuel cell device, the power generation units being determined to have reached the end of their lifespan; and the ratio of power generation units, among all the power generation units of the fuel cell device, that generate power over a prescribed period.
Resumen de: CN120242691A
本申请涉及气水分离领域,尤其涉及气水分离装置,包括分离装置本体,所述本体侧端底部设有气水输入管,本体内部设有水平腔,所述水平腔内设有若干并列设置的除湿气垫,所述除湿气垫下端固定安装有水平过滤挡板。本申请结合挡板式和离心式进行气水分离,大大提升分离效率。且通过湿度传感器和温度传感器的协同控制,实现精确的气水分离管理。湿度控制部分通过切换挡板路径确保气体进入适当的分离区域,而温度控制部分通过电热膜加热和散热铜片降温,使气水分离器始终运行在最佳温度区间。结合滞后控制机制,该系统能够有效避免因环境湿度波动导致的频繁切换,减少能耗,提高设备使用寿命,并确保燃料电池系统的长期稳定运行。
Resumen de: FR3157972A1
Plaque séparatrice, cellule électrochimique et dispositif électrochimique comprenant une telle plaque La plaque séparatrice (15, 17) comprend : - une zone active (39, 47) ; - une zone d’homogénéisation (68) présentant un champ (C) dans lequel est ménagé un groupe de canaux d’homogénéisation (69), les canaux d’homogénéisation (69) étant juxtaposés à partir d’un premier côté (C1) du champ (C) suivant la direction transversale; chaque canal d’homogénéisation (69) ayant un tronçon rectiligne (75) s’étendant selon une direction propre et de largeur sensiblement constante perpendiculairement à ladite direction propre, deux tronçons rectilignes (75) voisins étant séparés par une dent (79) ; les directions propres des tronçons rectilignes (75) des canaux d’homogénéisation (69) formant des angles aigus (α) avec la direction longitudinale, au moins deux des angles aigus (α) consécutifs étant différents, au moins certaines dents (79) ayant des bords opposés (81, 83) divergents. Figure pour l'abrégé : 3
Resumen de: FR3157969A1
Plaque polaire et composant polaire pour une cellule électrochimique d’une pile à combustible, ains i que cellule électrochimique, pile à combustible et véhicule électrique associés L’invention concerne une plaque polaire (7) pour une cellule électrochimique d’une pile à combustible, comprenant une partie centrale (73) qui forme un champ d’écoulement (73.1) pour un fluide fonctionnel, et une partie périphérique (74), qui entoure la partie centrale et qui comprend deux orifices de distribution (74.1, 74.2) disposés de part et d’autre de la partie centrale pour respectivement amener et évacuer le fluide fonctionnel vis-à-vis du champ d’écoulement. Pour chaque orifice de distribution, la partie périphérique comprend un rebord d’écoulement (74.1A, 74.2A), qui délimite en partie l’orifice de distribution sur une portion de l’orifice de distribution, tournée vers la partie centrale, et une pluralité de trous de passage fluidique (74.7, 74.8) qui sont tous situés entre le rebord d’écoulement de l’orifice de distribution et la partie centrale et chacun allongés suivant une direction principale qui est parallèle au rebord d’écoulement. Figure pour l'abrégé : 2
Resumen de: FR3157970A1
Plaque séparatrice, cellule électrochimique et dispositif électrochimique La plaque séparatrice (15, 17) comprend: - une zone active (39) ; - une zone d’homogénéisation (43) ; - une zone intermédiaire (45) interposée longitudinalement entre la zone active (39) et la zone d’homogénéisation (43) ; la plaque séparatrice (15, 17) présentant dans la zone d’homogénéisation (43) un fond d’homogénéisation (51) situé à une première altitude (a1); la plaque séparatrice (15, 17) présentant dans la zone intermédiaire (45) un fond intermédiaire (55) situé à une seconde altitude (a2) supérieure à la première altitude (a1), le fond intermédiaire (55) étant séparé du fond d’homogénéisation (51) par une marche (59) ; un volume tampon (60) étant délimité entre le fond intermédiaire (55), la marche (59) et l’extrémité des dents actives, et permettant d’équilibrer la répartition du fluide réactif arrivant de la zone d’homogénéisation (43) dans les canaux actifs (41). Figure pour l'abrégé : 3
Resumen de: FR3157874A1
Réacteur d’électrolyse ou de co-électrolyse (SOEC) à haute température comprenant un empilement à cellules électrochimiques et un récipient logeant l’empilement et rempli d’un matériau formant une barrière d’étanchéité aux gaz, Procédé de réalisation associé. L’invention consiste essentiellement à intégrer dans un récipient (6) au moins un empilement électrochimique à cellules électrochimiques à oxyde solide (1), destiné à fonctionner à haute température en tant que réacteur d’électrolyse ou de co-électrolyse, avec un volume entre eux qui est rempli par un matériau dont au moins une matrice vitreuse qui va agir comme deuxième barrière d’étanchéité aux gaz, c’est-à-dire comme barrière supplémentaire à celles des joints d’étanchéité autour des compartiments cathodique et anodique de l’empilement. Figure pour l’abrégé : fig.2
Resumen de: FR3157973A1
Embase collectrice (2) pour réacteur électrochimique à oxyde solide, formée d’un assemblage de couches de matière (9) superposées de manière étanche, suivant une direction d’empilement, et : - au moins l’une de ces couches de matière (9) comporte une rainure longitudinale traversant l’épaisseur de la couche de matière (9), et formant un conduit d’écoulement longitudinal qui est sensiblement perpendiculaire à la direction d’empilement ; - au moins l’une de ces couches de matière (9) comporte un orifice de traverse formant un conduit de traverse dans l’épaisseur de la couche de matière (9), ce conduit de traverse s’étendant sensiblement suivant la direction d’empilement et étant disposé en regard dudit conduit d’écoulement longitudinal. Figure pour l’abrégé : Fig.2
Resumen de: FR3157971A1
Plaque de séparation d’interconnecteur à bord plié et empilement associé L’invention concerne une plaque de séparation (1) d’interconnecteur comprenant une face supérieure et une face inférieure, parallèles l’une à l’autre et s’étendant suivant un plan principal, caractérisée en ce qu’elle comprend une partie centrale s’étendant selon le plan principal et un bord entourant intégralement la partie centrale, le bord étant plié pour former un angle A non nul avec le plan principal. L’invention concerne également l’interconnecteur (100) pour électrolyseur comprenant ladite plaque de séparation, une plaque supérieure (101) en contact avec la face supérieure (2) de la plaque de séparation (1) et une plaque inférieure (102) en contact avec la face inférieure (3) de la plaque de séparation (1). L’invention concerne également un empilement (300) comprenant au moins deux interconnecteurs (100) et au moins une cellule électrochimique élémentaire (200) intercalée entre les interconnecteurs (100) et un électrolyseur comprenant l’empilement, une plaque terminale supérieure 312 et une plaque terminale inférieure (311). Figure pour l’abrégé : Fig.6
Resumen de: FR3157857A1
La présente invention concerne une composition, de préférence sous la forme d’une pâte ou d’un solide, comprenant au moins un matériau inorganique à base de verre et/ou de vitrocéramique et au moins une source de lanthane, un joint d’étanchéité pour un dispositif électrochimique obtenu à partir de ladite composition, un procédé de fabrication dudit joint d’étanchéité, l’utilisation dudit joint d’étanchéité dans un dispositif électrochimique, et un dispositif électrochimique comprenant au moins ledit joint d’étanchéité.
Resumen de: FR3157851A1
L'invention concerne une unité génératrice pour avion, comportant une machine électrique (1) et une pile à combustible (3), et comportant encore un compresseur rotatif (5), une chambre de combustion (7) et une turbine (9), la turbine (9) étant propre à être couplée par l'intermédiaire d'un arbre à la machine électrique (1) par transmission de couple, et comportant une conduite de retour (11) pour la reconduite de l'air d'échappement de la pile à combustible (3) dans le flux de gaz en amont de la pile à combustible (3) comportant encore une conduite d'alimentation pour alimenter au moins une partie de l'air d'échappement de la chambre de combustion (7) à la pile à combustible (3), comportant encore une première conduite de dérivation qui, partant de la conduite d'alimentation, passe autour de la pile à combustible (3). Figure de l’abrégé : Figure 1
Resumen de: US2025192195A1
A method of sintering an electrochemical cell stack includes placing the electrochemical cell stack in a cage which applies a first compressive load to the electrochemical cell stack, moving the cage containing the electrochemical cell stack in a moving direction through a furnace containing a sintering region, sintering the electrochemical cell stack in the sintering region of the furnace, and applying a second compressive load greater than the first compressive load to the electrochemical cell stack during the sintering.
Resumen de: CN120261647A
本发明公开了一种分子笼结构的质子导体和制备方法及其在高温质子交换膜中的应用,所述分子笼结构的质子导体的结构式为:#imgabs0#其中,X=H2PO4。本发明提出一种全新的有机笼质子导体,其笼状分子含有大量的质子载体H2PO4‑,同时其胺基能与水分子形成广泛的氢键网络,为质子传输提供了丰富的通道,显著提升了其质子电导率,降低了活化能。
Resumen de: CN120245821A
本发明公开了一种车用燃料电池混动系统及低温启动控制方法,系统结构包括:氢气罐、减压阀、氢气调节阀、氢气循环泵、燃料电池电堆、空气压缩机、空气换热器、冷却循环泵、PTC电加热器、散热器、锂电池、双向DC/DC转换器、单向DC/DC转换器、DC/AC转换器。本发明低温启动控制方法,通过控制电堆氢气通入量控制电堆电流,通过模型预测控制方法控制PTC电加热器的功率和燃料电池输出电流,提供功率加热冷却循环水;通过循环泵加压后,冷却液循环流动与燃料电池进行热交换,实现加热燃料电池流道升温;保证燃料电池的温度快速达到启动状态、维持锂电池在稳定的荷电状态范围内工作。
Resumen de: CN120261643A
本申请涉及一种排氮阀的控制方法、装置及车辆,涉及电池技术领域,至少解决相关技术中无法准确控制排氮阀的开启和闭合的技术问题。该方法包括:获取排氮阀的开闭状态,排氮阀用于控制电池中氮气的排放;基于排氮阀的开闭状态,获取电池中电池堆阳极侧的反应状态参数,反应状态参数包括:氮气浓度、积聚水参数、氢气浓度,积聚水参数用于指示电池堆阳极侧的液态水的积聚量;基于排氮阀的开闭状态和反应状态参数,控制排氮阀的开闭状态;如此,可以更准确地控制排氮阀的开闭状态。
Resumen de: AU2023402207A1
The invention relates to a redox-flow battery comprising at least one cell, a cell being composed of two half-cells, each half-cell having at least one half-cell interior for receiving an electrolyte, at least one electrode and at least one membrane being associated with each cell and the half-cells being arranged in a stack, at least one electrolyte supply means and/or at least one electrolyte discharge means being assigned to each half-cell, and the electrolyte supply means being connected to an electrolyte reservoir via at least one supply line and the electrolyte discharge means being connected to an electrolyte reservoir via at least one discharge line. According to the invention: the at least one supply line is subdivided into supply sub-lines; the at least one discharge line is subdivided into discharge sub-lines; the at least one supply sub-line and/or the at least one discharge sub-line is/are assigned to at least two half-cells; and the supply sub-lines and the discharge sub-lines are arranged outside the stacking surfaces of the half-cells.
Resumen de: CN120261636A
本发明提供一种基于混合激励算子的氢能无人机健康监测与管理方法,属于氢能无人机领域,包括:建立基于在线参数辨识的氢燃料电池电压估计器,实时估计电压输出并与电压量测值生成电压残差,同时获取燃料电池最大输出功率;设计混合激励算子,通过DC/DC转换器向燃料电池注入高频激励,通过主动无人机机动注入不影响飞行稳定性的低频激励,利用注入的激励信号与响应电压信号在线计算特征频率阻抗,并将其作为故障诊断特征;设计故障分类器,基于特征频率阻抗将故障分类为水淹、膜干、欠氧三类;基于诊断的具体故障类型控制进气扇、排气阀等器部件进行故障恢复。本发明实现氢能无人机的在线健康管理,适用于需要在线健康管理的氢能无人机系统。
Resumen de: CN223066202U
本申请公开了一种用于车辆的低温启动系统及车辆,所述低温启动系统包括:电池;供气装置,所述供气装置与所述电池的进口端连通且适于向所述电池提供气体;排放装置,所述排放装置与所述电池的出口端连通且适于将所述电池工作所产生的液体排出至外界;泵部件,所述泵部件可选择地将所述电池和所述排放装置连通以将抽取所述电池内部的液体并导向至所述排放装置。由此,可以缩短系统启动时间,更好地提升整机效率,减少系统能量损失。
Resumen de: CN223066203U
本实用新型公开了一种燃料电池系统用的气水分离器,包括气水分离器本体,所述气水分离器本体具有与燃料电池系统的电堆端板贴合的贴合面,所述进口和出氢口位于所述贴合面上。本申请气水分离器是针对燃料电池发动机阳极采用内流道设计方案而专门设计的,对流口采用端面贴合法,不需要额外的流道连接,取消供氢路的胶管方案,降低了硅元素进入燃料电池发动机的风险。气水分离器与引射器流道内嵌在电堆端板内部,降低低温工况气水分离器到引射器管路降温造成冷凝量,同时让整个配气面板上的配气系统显得更紧凑。这种设计方法可以灵活的针对性地设计气水分离器,节省空间,缩短整体的流道距离,对高度集成的燃料电池发动机极为有利。
Resumen de: CN120252215A
本申请涉及光伏系统技术领域,具体涉及光伏光热产储供一体化系统及控制方法,该系统包括:电系统:光伏板的电力输出端通过逆变器连接至用户负载配电箱,所述逆变器的冗余电能输出端通过双向变流器连接至锂离子电池组;配电控制器输出端回接至用户负载配电箱;热系统:PVT组件的热介质出口通过第一板式换热器连接至吸收式热泵的蒸发器入口;辅助热源单元:地热井的出水口通过第一三通调节阀与空气源热泵的出水口并联,两者共同接入所述用户供暖管网的进水总管,本申请通过上述结构设计,可使能源综合利用效率提升,提高供能稳定性与可靠性,降低设备运维成本。
Resumen de: CN120246926A
本发明涉及氢气制备技术领域,具体为一种用于氢卡的氢气除杂方法,包括如下步骤:S1:氢气脱氧,将通过气水分离器分离出的粗氢利用输气管道输送到氢气纯化段,依次通过第一氢水分离器、脱氧塔和脱氧冷却器壳程,逐步进行出水、脱氧和降温,而后进入第二氢水分离器,脱除脱氧塔中生成的水分;S2:氢气三塔干燥,将第二氢水分离器输出的氢气进入A组塔、B组塔和C组塔其中一个处于运行状态的塔组内,具体为依次通过第三氢水分离器、氢气再生冷却器和氢气干燥塔,对氢气进行吸附并制得纯氢。本发明通过在对氢气制备过程中根据氢气的温度和纯度进行对应运行状态的调节,能够有效降低制备氢气时的功耗,进而实现环保和节能效果。
Resumen de: CN120262625A
本说明书实施例公开了一种液流电池储能系统故障调整方法及设备,包括:在液流电池储能系统中模块化级联所有DC/DC模块,并实时监测每个DC/DC模块的运行数据,运行数据包括输出电压、输出电流与输出功率,DC/DC模块包括相互连接的液流电池电堆与DC/DC变换器;若基于运行数据检测出指定DC/DC模块存在异常,启动故障应对机制,以便通过故障应对机制将指定DC/DC模块关闭,并调整剩余DC/DC模块的输出功率与输出电压分配;其中,故障应对机制基于剩余DC/DC模块的电压和功率分配以总功率损耗最小、荷电状态差异最小为调整目标。
Resumen de: CN120248398A
本申请公开了一种耐钒电池电解液氧化腐蚀复合膜的制备方法,包括:S1、采用磺化聚醚醚酮作为基底,在SPEEK基体表面均匀分散氧化石墨烯纳米片,得到SPEEK/GO基底;S2、将SPEEK/GO基底置于氧等离子体处理设备处理时间,用异丙醇超声清洗10~20分钟;S3、聚苯并咪唑溶解于N,N‑二甲基乙酰胺中(浓度3~5wt%),磁力搅拌至完全溶解;加入TiO2纳米颗粒(粒径20~25nm,经硅烷偶联剂KH‑570预处理),质量占比15~20%,超声分散并进行冰浴得到PBI‑TiO2分散液;S4、将S1处理后的SPEEK/GO基底垂直浸入PBI‑TiO2分散液,最终涂层厚度1.5±0.2μm,得到预处理膜;S5、预处理膜用热压机进行热压,然后梯度降温至室温得到最终的复合膜。本申请阻钒和耐腐蚀性更优,适合高功率密度钒电池。
Resumen de: CN223066208U
本实用新型公开了一种散热性能好的氢燃料电池叠片外壳,涉及氢燃料电池外壳技术领域,该散热性能好的氢燃料电池叠片外壳,包括外壳主体,所述外壳主体包括若干个叠片,所述外壳主体的两侧均设置有侧凹槽,所述外壳主体的上下表面均设置有连接凹槽,且侧凹槽和连接凹槽均是由若干个叠片组成成型,所述连接凹槽的外部设置有散热加强组件,所述外壳主体一侧的侧凹槽内部设置有第一连接头,所述外壳主体另一侧的侧凹槽内部设置有第二连接头,本方案解决了现有氢燃料电池外壳多为方形密封壳体,散热性能差,长时间使用电池容易过热,导致使用寿命短的问题。
Resumen de: CN223066207U
本实用新型提供了一种空气模块及具有其的燃料电池,空气模块包括:固定结构,用于固定在电堆上,固定结构具有固定本体,固定本体上设置有第一固定部和第二固定部,第一固定部和第二固定部高于固定本体设置;增湿器,设置在第一固定部上;中冷器,设置在第二固定部上,增湿器与中冷器可拆卸连接。通过本申请提供的技术方案,能够解决现有技术中的电堆壳体上的原固定点无法兼容更换后的增湿器或者中冷器的问题。
Resumen de: CN223066195U
本公开涉及一种燃料电池系统和车辆,燃料电池系统包括:电堆;电堆散热回路,包括散热器,电堆设置在电堆散热回路上;废水排放管路,与电堆相连通;换热器;电堆散热回路与废水排放管路通过换热器交换热量,其中:电堆散热回路配置成使得电堆的冷却介质的出口选择性地直接与散热器连通或者先经过换热器换热后与散热器连通。通过两级散热提高散热效果,这样,不仅可以提升散热效果,也可以节省燃料电池系统中例如为达到同样散热效果而额外增设的散热器的数量,从而实现在有限的布置空间内提高了燃料电池的散热效率的目的。
Resumen de: CN223066197U
本实用新型提供一种燃料电池装置及包含其的燃料电池系统,其中燃料电池装置包括制氢部、储氢部、燃料电池发电部、第一流量检测计、第二流量检测计、第三流量检测计和第四流量检测计,制氢部的出口分别与储氢部的进口和燃料电池发电部的进口连接并连通,储氢部的出口与燃料电池发电部的进口连接并连通;第一流量检测计设于制氢部的出口,用于检测制氢部的出口处的流量;第二流量检测计设于储氢部的进口,用于检测储氢部的进口处的流量;第三流量检测计设于储氢部的出口,用于检测储氢部的出口处的流量;第四流量检测计设于燃料电池发电部的进口,用于检测燃料电池发电部的进口处的流量。
Resumen de: CN223066206U
本实用新型涉及全钒液流电池技术领域,且公开了一种全钒液流储能电堆的导流板结构,包括:保护壳;导向组件,导向组件包括阻隔箱、侧盖、限位板、密封垫和滑动板,侧盖与阻隔箱拆卸连接并形成具有空腔的箱体结构,阻隔箱内壁对称设置两个限位板,两个限位板之间留有间隔,密封垫与限位板拆卸连接,滑动板与阻隔箱弹性连接并抵触密封垫底部将两个限位板之间的间隔密封,在停止送液后,弹性伸缩杆能够推动滑动板上移与密封垫贴合实现密封,进而达到抑制返液的效果,本方案对于返液的密封效果更好,通过滑动板竖直位移的方式,滑动板与密封垫进行面接触的密封效果显然更加稳定,可拆卸的侧盖能够便于后期拆解维护。
Resumen de: CN120261625A
本发明提供了一种个用于燃料电池(FC)系统的服务吹扫方法,其包括:FC系统的燃料电池控制单元(FCCU)接收吹扫启动信号;在接收到吹扫启动信号之后,FCCU获取FC系统的FC电堆的开路电压,并对开路电压的电位状态作出判定;当判定开路电压处于高电位状态时,FCCU指令在FC系统中的主继电器处于闭合状态的情况下实施服务吹扫,并且当判定开路电压处于低电位状态时,FCCU指令在主继电器处于断开状态的情况下实施服务吹扫。此外,本发明提供了一种实施该服务吹扫方法的燃料电池控制单元以及相关的燃料电池系统。利用其,在不存在影响实施吹扫操作的故障的前提下,能够实现在不受到OCV的影响的情况下对燃料电池实施吹扫操作。
Resumen de: CN120261649A
本发明公开了一种锌锰液流电池用正极电解液,包括锰盐、添加剂和支持电解质,其中,添加剂为氯化铬、氯化镁、硫酸镍、硫酸钴、硫酸亚铁、硫酸铜、硫酸铝中的一种或两种以上的组合。通过在电解液中引入金属离子能够催化和增强Mn2+/MnO2电解过程,同时利用金属离子的掺杂作用,能够显著增加MnO2中的氧空位,产生更活跃的电子态,促进电荷转移动力学,进一步优化MnO2的沉积和剥离性能,从而提高了锌锰液流电池的高倍率性能和循环稳定性。本发明提供的锌锰液流电池具有绿色无污染、成本低、安全环保等优点,因此具有广阔的应用前景。
Resumen de: CN120261604A
本发明涉及催化剂技术领域,尤其涉及一种高载量单原子、双原子多功能电催化剂的制备方法及应用,包括:先将定量的七钼酸铵、金属盐依次加入去离子水中得到金属离子前驱体溶液。再向溶液中加入三聚氰胺和瓜尔胶,静置后冷冻干燥、碳化、洗涤、真空干燥,得到金属单原子锚定在多孔N掺杂碳气凝胶上的双功能电催化剂。本发明单原子电催化剂表现出明显的电催化活性,尤其是Co‑SA@CA在析氢反应中,具有极低的起始电位(η0~12.5mV),非常接近商业贵金属20wt.%Pt/C(η0~6.7mV),在10mA·cm‑2电流密度下表现出较低的的过电位(η10~78.6mV)。本发明采用预交联的方法,简便易行,成本低廉,极大地提高原子利用率及催化效率,具有工业化应用前景。
Resumen de: CN120261633A
本发明提供了一种钒液电堆热管理装置及其控制方法,涉及钒液电堆热管理技术领域,目的是对温度不均匀的电解液的温度进行更合理的监测,设置第一温度传感器,第一温度传感器用于监测电解液容器的加热装置设置处的电解液温度,设置第二温度传感器,第二温度传感器用于监测电解液容器中距离加热装置设置处的高度差异最大处的电解液温度;获取第一温度传感器和第二温度传感器的高度差,并周期性获取第一温度传感器和第二温度传感器的监测数值;根据高度差和监测数值确定开始加热的时间;加热过程中,根据高度差和监测数值确定关闭加热的时间。本发明具有实现更可靠的温度控制的优点。
Resumen de: CN223066193U
本实用新型公开了一种便于拆装的氢燃料电池配电盒,包括盒体和盒盖,所述盒盖上设有四组对称分布的插板,所述盒体上开设有四组对称分布的插槽,所述插板与插槽对应设置,所述插板通过插槽与盒体活动卡接,所述盒体内设有安装板,所述安装板与盒体之间设有两组交叉分布的支架,两组所述支架的两端均通过转轴转动安装有滑块,所述安装板内设有两组对称分布的夹块,通过所设置的安装板以及安装板上对称分布的四组夹块实现对于不同型号电池的固定,并通过所设置的支架实现对于安装板在盒体内高度的调节,不仅方便工作人员在盒体内对于电池进行拆装和维修,且在安装板与夹块作用下有效扩大该配电盒的适用范围,方便对于不同型号电池的固定。
Resumen de: CN223065352U
本实用新型提供一种氢燃料电池电堆检测装置。所述氢燃料电池电堆检测装置包括:检测台;三个滑口,三个所述滑口开设在检测台的顶部,所述检测台的一侧安装有驱动组件,所述驱动组件的输出端安装有螺纹杆,所述检测台内壁的顶部靠近正面和背面的位置均安装有滑杆,所述螺纹杆的外表面螺纹连接有两个内螺纹架,两个所述内螺纹架的顶部均安装有三个连接栓,所述连接栓的顶部固定连接有放置板。本实用新型提供的氢燃料电池电堆检测装置,通过该结构可以让氢燃料电池电堆在不同温度下进行检测,并且防护柜内部通过三个分隔板分出的三个区域可以维持或者快速的达到设定的温度,在得到更加全面的检测数据同时也可以提高检测效率。
Resumen de: CN223065471U
本实用新型公开了一种SOFC电堆压缩量测试装置,包括控制器,还包括压缩支撑机构和压缩测试机构;所述压缩测试机构包括伺服电动缸和压缩杆,所述压缩杆悬设在电堆测试件的上方,且一端朝向所述电堆测试件,另一端与所述伺服电动缸连接,所述伺服电动缸固定连接在所述压缩支撑机构上;所述伺服电动缸与所述控制器连接;当所述伺服电动缸带动所述压缩杆压向所述电堆测试件时,所述压缩杆与所述电堆测试件接触后,所述伺服电动缸的行程变化为所述电堆测试件的压缩量。本方案通过伺服电动缸的行程变化直接反映出电堆测试件的压缩量,使电堆压缩量的测试结果更为精确。
Resumen de: CN223066201U
本实用新型涉及一种车辆尾排处理系统及具有其车辆,系统包括:除氢装置,其输入端与燃料电池系统的尾排出口相连,用于清除尾排出口的尾排气体中的氢气,得到待排出气体;水汽分离装置,其输入端与除氢装置的输出端相连,其第一输出端与大气相连,用于对待排出气体进行水汽分离后将分离后气体排放;储水装置,其输入端与水汽分离装置的第二输出端相连,用于存储待排出气体进行水汽分离后的液态水;设置于除氢装置和储水装置之间的导热装置,用于将除氢装置清除尾排气体中的氢气时产生的热量传导至储水装置,以加热储水装置内的液态水。根据本实用新型实施例的车辆尾排处理系统,通过增加导热装置,防止储水装置冻结,提升了尾排处理系统的稳定性。
Resumen de: AU2023389049A1
The invention relates to a method for producing flat fuel cell components (6), in particular bipolar plates, from thermoplastic material with an additional component that has good electrical and thermal conductivity, wherein the flat fuel cell component is produced by means of injection moulding using an injection moulding device (1) which has at least one injection unit (2) and at least one mould unit (3) with a wall surrounding a respective cavity. Efficient production of flat fuel cell components is achieved in that the melted thermoplastic material with the additional component is filled as melt mass by means of the at least one injection unit (2) under pressure into the hollow space of the respective cavity (31) of the at least one mould unit (3), said hollow space corresponding unchanged to the geometry of the fuel cell component, and the heat transfer via the wall (30) is adapted to the thermal conductivity and thermal capacity and filling speed of the melt mass in such a manner that the respective cavity (31) is completely filled with this as moulding mass (5) before the temperature of the melt mass falls below its melting temperature.
Resumen de: JP2024098213A
To provide a film that is superior in not only high-temperature mechanical characteristics and high-temperature hydrolysis resistance, but also thickness uniformity and punching workability, and a reinforcement member for electrolyte membrane of a solid-state polymer fuel cell using the same.SOLUTION: The present invention relates to a film that has at least one A layer including 90 mass% or more in total of a polymer A1 of 240°C or higher in fusion point and a resin A2 of 170°C or higher in glass transition temperature, the polymer A including 90 mol% or more of a constitutional unit derived from 4-methyl-1-pentene, wherein the mass ratio A1/A2 of the resin A2 to the polymer A1 is 95/5 to 50/50.SELECTED DRAWING: None
Resumen de: CN120261639A
本申请涉及一种电池系统以及热管理控制方法,热管理控制方法包括获取所述燃料电池中服务液的液位信息;根据所述液位信息判断所述燃料电池中的服务液液位是否低于最小预设阈值;当所述燃料电池中的服务液液位低于所述最小预设阈值时,控制所述冷却泵开启。本申请的热管理控制方法通过实时监测燃料电池中服务液的液位信息,能够及时发现服务液液位低于最小预设阈值的情况。当液位低于最小预设阈值时,控制器控制冷却泵及时开启,从而确保燃料电池的工作环境温度不会产生较大波动,避免因过热或温度波动导致燃料电池的性能衰减的情况,显著提升了燃料电池的工作效率以及安全性。
Resumen de: CN120242885A
本发明涉及氢气制备技术领域,提供一种基于固态储氢材料的储氢装置及其制氢方法,装置包括:燃料罐,内形成有反应腔,用于设置氢化铝材料以及混合粉料;加热器,设置在燃料罐外侧;水回收组件,第一端与反应腔连通,第二端用于与燃料电池系统连通,以用于将燃料电池系统产生的水回收至反应腔;排氢组件,第一端与反应腔连通,第二端用于与燃料电池系统连通。本发明提供的储氢装置,通过可在常压存储同时较低温度释氢的高比能固态储氢材料氢化铝的应用,优化燃料罐中金属氢化物热分解及与水的耦合反应过程,利用氢化铝热分解反应物单质铝与水的水解反应制氢,同时利用水解反应释放热量促使氢化铝热分解,耦合释氢,实现热量的有效利用。
Resumen de: CN223066199U
本实用新型公开了一种氢燃料电池汽车排气消声器,包括:壳体,具有空腔,其相对两侧分别设有与所述空腔连通的进气口和出气口;所述壳体的底部靠近所述出气口的一端还设有与所述空腔连通的排水口;水汽分离膜隔板,设置在靠近所述进气口的一侧的所述空腔内;内芯,设置在所述空腔内,并具有贯穿的通道;所述通道的尾部与所述出气口连通;其中,所述水汽分离膜隔板的底部和所述内芯的底部均与所述壳体的内底部具有间隙,所述间隙与排水口连通,形成排水槽。本实用新型通过上述方案,具有低阻力,同时达到消除排气噪声且满足排水储水要求,适用于采用涡轮膨胀机的氢燃料电池汽车。
Resumen de: CN223066194U
本申请涉及用于双堆燃料电池系统的歧管组件,其包括:用于氧化剂和冷却剂中的一者的递送的第一歧管结构,其包括第一分支沟道和与第一分支沟道流体连通且至少部分地叠覆在第一分支沟道上延伸的第一总支流道,其中第一分支沟道在背离第一总支流道的一侧上开敞以密封连接到电堆端板的表面使得所述氧化剂和冷却剂中的一者沿着电堆端板的表面在其中被引导;和用于氧化剂和冷却剂中的另一者的递送的第二歧管结构,其包括配置为垂直于电堆端板的表面地连接到电堆端板的两个端板接口、流体连接两个端板接口的第二分支通道以及与第二分支通道流体连通且至少部分地叠覆在第二分支通道上延伸的第二总支流道。还提供电堆端板及双堆燃料电池系统。
Resumen de: CN223066204U
本实用新型公开了一种液流双室微生物燃料电池实验装置,主要由数据采集系统、第一导线、第二导线、第三导线、第四导线、第五导线、第六导线、第七导线、第八导线、第九导线、第十导线、第十一导线、负载、多孔阳极电极、多孔阴极电极、质子交换膜、阳极室、阴极室、第一循环泵、第二循环泵、阳极电解液储存罐、阴极电解液储存罐、第一温控加热器、第二温控加热器、第一温度传感器、第二温度传感器、pH传感器、第一电热丝、第二电热丝、第一电解液导管、第二电解液导管、第三电解液导管、第四电解液导管、第五电解液导管、第六电解液导管组成;提高微生物燃料电池的输出功率和运行稳定性,提高实验变量的可控性,实现快捷的参数调控和获取。
Resumen de: CN223066205U
本实用新型涉及燃料电池技术领域,具体而言,涉及一种燃料电池电堆堆叠装置和系统。燃料电池电堆堆叠装置包括工作台、存料单元、抓取组件以及堆叠单元;存料单元与工作台连接,且存料单元用于叠放膜电极及双极板;抓取组件与工作台可活动地连接,且抓取组件用于按序抓取膜电极及双极板;堆叠单元与工作台连接,且堆叠单元用于接收抓取组件按序释放的膜电极及双极板,并形成电堆。该燃料电池电堆堆叠装置结构简单,使用灵活方便,能够在提高堆叠效率同时,控制使用成本。
Resumen de: CN223066200U
本实用新型提供一种阳极水分盖板及包含其的燃料电池,其中,阳极水分盖板用于燃料电池,阳极水分盖板包括第一本体和第二本体,第一本体包裹于第二本体的外周侧;其中第一本体的材料为塑料,第二本体的材料为金属。采用上述结构形式,在保留注塑件成本低、重量小和成型能力强等优点的同时,大大提升了零件的结构强度,从而提高了阳极水分盖板承压能力,降低了阳极水分盖板发生变形的可能性,进而有利于提高阳极水分盖板的使用寿命。
Resumen de: CN120248361A
本发明属于燃料电池技术领域,公开了一种具有质子导电性能的金属有机骨架材料及其制备方法和应用。以吡唑并3,4‑c吡啶为配体,双核亚铜簇为连接点,通过配体和双核亚铜簇构筑的二维层状结构,形成亚铜多氮杂环金属有机骨架,对亚铜多氮杂环金属有机骨架进行氧化,使氧化后的亚铜多氮杂环金属有机骨架中存在二价铜离子和一价铜离子,到具有质子导电性能的金属有机骨架材料。本发明采用金属后合成修饰氧化技术能够显著地提升金属有机骨架材料的质子导电性能,并与商业化Nafion质子电导率相媲美的,氧化后的样品表现出极高的化学稳定性,改善了以往研究的非氟碳氢聚合物质子交换膜和无机固体酸稳定性差的问题。
Resumen de: CN120261644A
本发明涉及燃料电池领域,公开了一种沿膜厚方向定向排列MXene的质子交换膜的制备方法,包括:步骤一:通过直流磁控溅射于基底表面沉积Ti3AlC2薄膜;步骤二:使用NH4HF2溶液对Ti3AlC2薄膜进行刻蚀,制得MXene膜;步骤三:沿径向对MXene膜进行切割;步骤四:先对步骤三所得MXene膜进行羧基化,再用含胺基的聚合物对MXene膜进行修饰形成N‑Ti键;步骤五:将修饰后的MXene膜浸泡在Nafion溶液中,经干燥、热压、热处理,制得沿膜厚方向定向排列MXene的质子交换膜。本发明质子交换膜基于Nafion和MXene,其中MXene沿膜厚方向有序定向排列,可有效减少质子传输曲率;并且经过修饰后的MXene具有大量的质子交换容量,且能够改善Nafion基质的热稳定性。
Resumen de: CN120261640A
本申请公开了一种目标设备的供电方法,其中,上述方法包括:确定实时环境湿度,在实时环境湿度满足湿度条件的情况下,从空气中提取制氢水和氮气;在制氢水的含量达到水分含量阈值的情况下,基于水分进行电解水制氢,获得氢气,并将氢气存储在固态储氢材料中;确定固态储氢材料中氢气的实时存储量,在实时存储量满足供电条件的情况下,按照设定的燃料反应条件,控制氢气和氮气进行氨合成反应,获得氨气;在所述氨气的浓度满足设定的浓度条件的情况下,将所述氨气存储至氨燃料电池模块,以使得所述氨燃料电池模块基于所述氨气进行发电,获得电能,并将所述电能输出至待供电的目标设备。解决了相关技术中设备供电过程中资源消耗较高的问题。
Resumen de: AU2023406548A1
The present invention relates to compositions with low electrical conductivity which comprise a hydroxylamine-containing molecule in combination with a yellow metal corrosion inhibitor such as a triazole, wherein the weight ratio of the yellow metal corrosion inhibitor to the hydroxylamine- containing molecule is from 1 :20 to 20:1; and wherein the composition has an electrical conductivity at 25 °C of less than 200 μS/cm. These compositions can effectively provide ferrous metal corrosion inhibition in heat-transfer fluids at low electrical conductivity and maintain a low electrical conductivity which does not alter substantially with aging. They are thus particularly useful as heat-transfer fluids, for example in fuel cells or battery electric vehicles. The invention further relates to methods for the preparation of said compositions, and to uses employing said compositions.
Resumen de: CN223066196U
本实用新型涉及燃料电池技术领域,具体公开了一种水热交换器和燃料电池空气系统,水热交换器包括冷却壳体和换热壳体,冷却壳体设置冷却液通道,换热壳体设置在冷却壳体内侧,换热壳体设置换热腔,换热腔内填充有蓄热材料,换热壳体与冷却壳体共同形成有降温通道,冷却液和蓄热材料共同对降温通道内的空气降温,换热壳体还设置有升温分水通道,升温分水通道内设置有分水挡板分离出空气中的水分,蓄热材料对升温分水通道内的空气升温。蓄热材料利用降温过程中吸收的能量对升温分水通道内的空气升温,以提高能量回收效率,分水挡板将升温分水通道内的空气中的水分分离。集成了现有技术中多个零部件的功能,有利于降低零部件的数量,节约布置空间。
Resumen de: CN223066209U
本实用新型公开了一种用于电堆箱的预留检修机构,设置有电堆箱壳体,所述电堆箱壳体的侧面开设有检修口,且检修口的外侧罩设有防护盖板,所述防护盖板安装于电堆箱壳体的侧面,且防护盖板边缘处的电堆箱壳体上开设有安装槽;包括:限位机构,贯穿于所述防护盖板的内部,所述限位机构用于防护盖板和电堆箱壳体之间的锁紧;扩展组件,设置在所述电堆箱壳体的侧壁,所述扩展组件用于扩大检修口的面积,且检修口和扩展组件均罩设于防护盖板内。该用于电堆箱的预留检修机构,在电堆箱壳体上预留维修窗口,仅需打开维修窗口外侧的盖板,便可实现对电堆箱内部的维修,因此大大方便了后期的维修维保,并且操作便捷,能够节省大量时间。
Resumen de: CN223066198U
本实用新型公开一种双堆燃料电池系统进气集成模块,其特征在于:所述的进气集成模块包括集成壳体(1),所述集成壳体(1)的一侧连接有空入接头(2)和氢入汇流管(3),空入接头(2)与开设在集成壳体(1)侧板上的空气入口(4)相连通,空气入口(4)通过空气管路与开设在集成壳体(1)另一个侧板上的两个空气出口(5)相连通,氢入汇流管(3)与开设在集成壳体(1)侧板上的氢气入口(6)相连通,氢气入口(6)通过氢气管路与开设在集成壳体(1)另一个侧板上的两个氢气出口(7)相连通。
Resumen de: CN120261619A
本发明属于固体氧化物燃料电池技术领域,涉及一种基于流量均匀分配的固体氧化物燃料电池堆进气歧管,包括两条燃料和空气进气歧管,所述燃料和空气进气歧管上端面为电池堆的气体进口面,下端面为封闭面,存在与电池堆各层单电池结构的相交面,所述相交面为进气歧管分配给各层电池的气流进口面。本发明能够均匀的向各层电池分配燃料与空气,使各层电池能够充分进行电化学反应,在一定程度上解决了电池堆内部各层单电池性能均一性问题。
Resumen de: CN120250398A
本发明公开了一种碳纤维纸及其制备方法和质子交换膜燃料电池,涉及燃料电池技术领域。该制备方法包括:将含有短切聚丙烯腈基碳纤维的碳纤维浆料过滤并进行湿法成型,得到湿碳纤维层;向湿碳纤维层中加入改性增强剂溶液,随后加热烘干和按压,得到碳纤维原纸;将碳纤维原纸浸入树脂溶液中浸渍后烘干,进行热压固化、碳化和石墨化处理,制备得到燃料电池用碳纤维纸。本发明中可以使改性增强剂及功能性填料更容易粘接在碳纤维交叉连接之处,一方面增强通电网络,提升产品的导电、导热性能,另一方面,还可以避免常规功能性填料在树脂浸胶阶段加入所导致的孔隙填充,对产品的孔隙及透气性能产生负面影响。
Resumen de: CN120261638A
本发明提供了一种检测方法和检测装置。检测方法包括:使燃料电池系统处于试运行状态,并向燃料电池系统加载测试电流,获取第一状态下和第二状态下分别对应的至少两个供气部件在不同加载电流下的平均开度的曲线,以得到第一开度曲线和第二开度曲线;根据第一开度曲线和第二开度曲线,确定至少两个供气部件的最大开度曲线;使燃料电池系统处于工作状态,并获取至少两个供气部件的实时平均开度值;将实时平均开度值与最大开度曲线上与实时电流相对应的开度值进行比较,以确定供气部件是否有异常。通过本发明提供的技术方案,能够解决现有技术中的燃料电池系统的供气部件异常无法被准确识别的技术问题。
Resumen de: CN120246296A
本发明公开了一种基于可逆电化学循环的超长航时无人机动力系统,属于航空动力领域。本发明采用前置双发动力系统,位于两侧机身前侧;太阳能电池板配备单个最大功率点追踪器MPPT,质子交换膜氢燃料电池/电解槽布置在两侧机身。其利用太阳能和氢能清洁无污染的特性,在有光照时,太阳能电池板发电带动电机,电机带动螺旋桨产生推力,且电解槽利用太阳能电池板产生的电能电解水制氢;在无光照时,利用储存氢能在燃料电池中发电带动电机,从而带动螺旋桨产生推力,同时收集产生的水。本发明利用电解槽电解水储氢弥补太阳能发电间歇性和波动性缺点,同时利用太阳能的“无穷无尽”解决电解水制氢技术需要较高能量输入的问题。
Resumen de: CN120261634A
本发明涉及氢燃料热管理技术领域,具体为一种氢燃料热管理系统中电导率传感器的供电方法及装置,供电方法包括以下步骤:第一步:电导率传感器实时监测冷却液的电导率;第二步:根据监测到的冷却液的电导率数据,预测氢燃料热管理系统中燃料电池运行时间与冷却液的电导率的变化趋势;第三步:动态调整电导率传感器的供电时间。本发明能延长电极寿命:通过减少电导率传感器的通电时间,有效降低电极的极化腐蚀;提高监测效率:基于电导率的现值和预测值动态调整供电时间,确保监测数据的准确性和及时性;智能控制:结合机器学习算法,实现对冷却液电导率的智能预测和供电管理;能够有效地提高系统的安全性和可靠性,同时降低维护成本。
Resumen de: CN120253833A
本发明属于燃料电池领域,公开了一种催化层在线表面缺陷快速检测方法、CCM全自动产线及生成方法,包括:步骤S1,实时捕获催化层表面状态图像;步骤S2,获取图像特征信息;步骤S3,图像信息的反馈;步骤S4,图像的分析;步骤S5,图像分析结果反馈;步骤S6,催化层合格率统计;步骤S7,生产工艺的优化。本发明可以实现对催化层微裂纹或孔洞等缺陷的在线分析和反馈,将裂纹缺陷以实际参数的形式表征出来,并实时反馈到生产工艺链上的排错系统,达到自动、及时、在线筛查和去除不合格品的有益效果,避免后续更高成本的影响。
Resumen de: CN120261609A
本申请属于燃料电池调控领域,具体公开了一种分区双极板、电池、电堆和多区域温度梯级调控系统。本申请通过沿气体流动方向自上而下逐级换热,形成水冷流道温度可控递增,配备相应温度梯级调控控制策略,结合回热和梯级温控技术,从而大幅降低工程实现时的复杂性与能量损耗,并在优化电池局部性能均衡的同时实现整体运行性能的提升。该系统不仅适用于单个电池,也适用于整个电堆。为车载燃料电池系统的高效稳定运行提供了有力支持,尤其在跨湿度环境和高负载条件下,展现出卓越的性能提升能力。
Resumen de: CN120261602A
本发明提供一种新型光催化燃料电池阳极材料ZnIn2S4/TiO2NTs/Ti mesh的制备方法及其在光催化燃料电池系统中发电并去除污染物的应用,属于环境工程技术领域。制备方法:该发明以钛网为基底,先采用阳极氧化法制备二氧化钛纳米管阵列(TiO2NTs),再通过一步水热法将ZnIn2S4负载到TiO2NTs,最终得到ZnIn2S4/TiO2NTs/Ti mesh复合光催化燃料电池阳极材料。该发明制备工艺简单,设备要求少,绿色环保,成本低廉。将制备的ZnIn2S4/TiO2NTs/Ti mesh材料作为光阳极材料,铂片作为阴极构建光催化燃料电池体系,该光催化燃料电池具备良好的降解和产电能力。在模拟太阳光照射下,以浓度为10 mg/L 2,4‑二氯苯酚(2,4‑DCP)为底物时,150 min内降解率达到约90%,开路电压0.4 V,光电流密度0.22 mA/cm2。
Resumen de: CN120261631A
本发明公开了一种快速启动沉积物微生物燃料电池的方法,该方法采集高有机质含量的沉积物,并添加外源有机物与生物膜促进剂,构建优化的预培养环境进行阳极预培养,然后利用该阳极构建沉积物微生物燃料电池。该方法实现了预培养阳极的微生物群落优化、提高了微生物的附着能力,进而提高了预培养阳极的性能;并且通过标准化流程和自动化设备控制环境条件,精确控制预培养时间,避免预培养过程中的阳极表面堵塞,提高了预培养过程的稳定性和重复性;利用本方法预培养阳极构建的沉积物微生物燃料电池,能够直接投入运行,提高监测的时效性和准确性,减少现场等待时间,提高工作效率。
Resumen de: CN120261648A
本发明提供一种低成本的液流电池及其应用,低成本的液流电池的正极电解液的氧化还原活性物质中含有具有受阻胺的羟胺环状结构基团,所述含有具有受阻胺的羟胺环状结构基团优选为基于1‑羟基‑2,2,6,6‑四取代的哌啶基团、1‑氧自由基‑2,2,6,6‑四取代的哌啶基团和1‑氧代‑2,2,6,6‑四取代的哌啶鎓基团中的一种或多种;其负极电解液的氧化还原活性物质中含有钛元素、钒元素、铬元素、铁元素和锌元素中的一种或多种。本发明低成本的液流电池具有输出电压高、能量密度高、环境友好和成本低廉的优点,在储能领域具有良好的应用前景和大规模推广潜力。
Resumen de: CN120261594A
本发明公开了一种自排水功能的纳米串珠结构催化层及其制备方法与应用。将六水合硝酸锌和2‑甲基咪唑分别溶解于甲醇,通过搅拌混合获得2‑甲基咪唑锌盐;将铁盐水溶液与2‑甲基咪唑锌盐搅拌混合,静置后获得Fe‑N‑C前驱体溶液;随后将Fe‑N‑C前驱体溶液、聚丙烯酸溶液、乙炔黑分散液等体积混合均匀,搅拌获得纺丝溶液;通过静电纺丝获得纳米纤维催化层,再煅烧处理,获得纳米串珠结构催化层。本发明的纳米串珠结构催化层由纳米纤维构成,单根纳米纤维为串珠结构,其组装的燃料电池在高电流密度区域具有较好传质性能,且长时间放电后无水淹现象。
Resumen de: CN120245679A
本发明公开了一种热管理系统的控制方法和车辆,涉及燃料电池车余热回收领域,所述方法包括:响应整车端加热需求,获取燃料电池发动机的出水温度;整车端加热需求包括空调制热请求、电池系统请求、储热装置请求;若出水温度大于或等于第一温度阈值,获取燃料电池发动机的进水温度,并根据出水温度和进水温度确定进出水变化率;基于进出水变化率调整比例阀开度;基于空调制热请求、电池系统请求或储热装置请求,控制电池回路中的第一水泵、储热装置回路中的第二水泵或空调回路中的第三水泵开启,调整八通阀的工作模式,以实现多种燃料电池发动机余热加热模式。上述方案实现智能化热量分配,降低了整车能耗。
Resumen de: CN120261622A
本发明涉及交通运输技术领域,公开了一种自检优化燃料电池进气系统,包括监测模块用于监测进气管道中的杂质参数和燃料电池电堆的工作状态参数;过滤模块由机械预过滤层、高效颗粒空气过滤层和吸附层组成,用于对进气管道中的杂质进行过滤;反馈调节模块与监测模块信号连接,用于根据杂质浓度变化率和燃料电池电堆的电压波动调整进气流量;数据传输模块用于将监测模块采集的数据发送至数据处理模块;数据处理模块用于根据监测模块采集的数据进行分析处理,判断过滤是否达标,以及根据过滤效果进行预警。本方案能够实时监测进气管道中杂质的成分和含量,实时调控进气流量,设计多层过滤防护屏障,减少杂质气体进入电堆,提高燃料电池的使用寿命。
Resumen de: CN120261612A
本发明涉及电力行业储能技术领域,具体为一种有机液储氢供能装置,包括储存单元用于常温常压储存富氢有机载体和贫氢有机载体;第一预热器用于对有机液体反应前进行预热作业;催化加氢反应器用于将氢储存在有机液体中进行储存作业;第一换热冷却器用于将有加氢产物进行降温初步分离氢气与含氢的液态混合物。本发明的优点在于:通过储存单元、第一预热器、催化加氢反应器、第一换热冷却器、储氢罐、第二预热器、催化脱氢反应器、第二换热冷却器、气液分离器、加压装置、燃料电池堆、储热罐和第三预热器之间的配合,充分且更加高效的将反应所产生的热量进行回收从而进行重复利用,大大减少能源的浪费,节约相应的成本。
Resumen de: CN120261613A
本发明公开了一种热氢协同‑并行储能的绿色氢能高效储运系统及方法,包括二氧化碳高温热泵调节单元连接热氢反应器;二氧化碳高温热泵调节单元中设置有压缩机,压缩机串联有气体冷却器,气体冷却器串联有回热器,回热器串联有电子膨胀阀,电子膨胀阀串联有气体加热器,气体加热器串联有电子调节阀,电子调节阀并联混合管和回热器的低压侧,回热器的低压侧串联混合管,混合管串联压缩机,压缩机、电子膨胀阀和电子调节阀均连接PID控制模块;热氢反应器连接气体冷却器冷侧出口和气体加热器热侧入口。本发明利用二氧化碳热泵辅助回收反应产生的废热,生产高温二氧化碳为反应供热,实现了热氢协同‑并行储能,降低了化学储氢中电能消耗与余热浪费。
Resumen de: CN120261620A
本申请涉及燃料电池电堆技术领域,揭示了一种非对称多堆燃料电池系统及其控制方法。所述系统包括氢气供给系统、小功率燃料电池电堆、大功率燃料电池电堆、空气供给系统、第一循环系统、第二循环系统、热管理系统以及混排系统。本申请可以使得小功率燃料电池电堆和大功率燃料电池电堆在反应过程中剩余未反应的混合气体能够被循环利用,提高能源的利用率。进一步地,通过热管理系统来使得本申请的非对称燃料电池电堆也能够在特殊环境下得到有效的启动运行,进而提高燃料电池系统在搭载场景的整体温度适应性,而无需依赖于动力电池的充放电来辅助燃料电池电堆的启动。
Resumen de: CN120242881A
本申请公开了一种甲醇制氢发电储能装置,其包括制氢反应筒,其内壁嵌设有催化体,制氢反应筒的壁内设有进气管,进气管的一端与催化体连通,进气管另一端连接有汽化管,汽化管包裹在制氢反应筒的外壁,汽化管一端连接有甲醇水进水管;加热件,设于催化体内;钯膜管,设于制氢反应筒空腔内并且一端穿出制氢反应筒;尾气出气管,设于制氢反应筒空腔内并且一端穿出制氢反应筒;燃烧筒,包裹于制氢反应筒的外周,燃烧筒内燃烧产生的热量传递至制氢反应筒,由制氢反应筒对催化体进行保温或预热;汽化管利用燃烧筒燃烧产生的热量将甲醇水进行汽化。本申请能够快速高效对反应温度进行控制,极大缩短反应启动时间,提高经济效益。
Resumen de: CN120261624A
本申请涉及燃料电池系统及其阳极子系统和停机吹扫控制方法,特别是提出一种用于燃料电池系统的阳极子系统,其包括:从燃料气体源通向燃料电池系统的电堆的燃料气体供给管路;从阳极侧排放出口通向外部排放装置的排放管路;以及将从排放管路中分离出来的一部分气体返回至燃料气体供给管路的再循环管路,其中,在燃料气体供给管路和/或再循环管路与排放管路之间配置有旁通管路,所述旁通管路中设置有流路开关部件,在流路开关部件的流路切换作用下,旁通管路能够以可控的方式使燃料气体供给管路和/或再循环管路中的气体在不经过电堆的情况下流入到排放管路中。本申请可以有效避免在阳极子系统的吹扫时将其中的水分不必要地带入到电堆中等问题。
Resumen de: CN120261598A
本发明涉及一种顶端包覆金属的竹节状碳纳米管材料的制备方法及其应用,属于燃料电池技术领域。所述方法包括以下步骤:S1、将金属盐和双氰胺溶解于无水乙醇溶液中,将得到的混合溶液超声,烘干,得到固体混合物;S2、将步骤S1得到的固体混合物充分研磨后置于管式炉中进行热解,得到所述顶端包覆金属的竹节状碳纳米管材料。本发明工艺简单、成本低廉、适合批量生产,在碱性条件下表现出良好的催化氧还原反应(ORR)性能,可满足燃料电池用氧还原催化剂的商业化大规模生产与应用。
Resumen de: CN120266299A
一种燃料电池装置的控制方法,具备当储氢器的氢量降低时使燃料电池装置的输出降低的步骤、当回收燃料电池装置的排热的热介质的温度上升时使燃料电池装置的输出降低的步骤、以及当电池装置的壳体内或壳体外的气温上升时使燃料电池装置的输出降低的步骤中的至少2个步骤。该控制方法,在至少2个步骤一同被执行时,以成为在各步骤中执行的燃料电池装置的输出降低量中最大的输出降低量的方式,使燃料电池装置的输出降低。
Resumen de: CN120247818A
本申请涉及水系有机液流电池电解液技术领域,公开了一种有机活性物质及基于其的制备方法和负极电解液,其中,所述有机活性物质的制备方法为包括:将物质A、物质B和Pd催化剂分散于有机溶剂中,搅拌反应,得到混合液,固液分离,干燥,将得到的沉淀分散于浓硫酸中,回流反应,反应结束后降低温度,离心,收集固体沉淀,得到所述有机活性物质。通过该方法制备的活性有机物在电池反应过程中,单分子能够转移4个电子,能够有效提高电解液的能量密度。此外磺酸化还能够有效提高活性有机物在水系溶剂中的溶解度,进一步提高电解液的能量密度。
Resumen de: CN120261626A
本发明涉及一种燃料电池低温冷启动热管理系统,包括吹扫模块、燃料电池电堆、水箱、水泵、冷却回路、冷启动加热回路、节温器、温度传感器、燃料电池系统控制器FCU,冷却回路上设有散热器,冷启动加热回路上设有PTC加热器,用于在低温环境下对冷却液辅助加热,水泵进口连接水箱,水泵出口接管连接三通阀进口,三通阀两出口分别连接冷却回路、冷启动加热回路,冷却回路、冷启动加热回路同时连接节温器,节温器出口接管连接燃料电池电堆的冷却液进口,燃料电池电堆的冷却液出口接管连接水箱进水口,燃料电池电堆的冷却液进、出口接管上均安装有温度传感器。该系统及其控制方法有利于提高低温冷启动成功率,缩短低温冷启动时间,提高冷启动性能。
Resumen de: WO2025142851A1
Provided is a method for recovering a fluorine-containing polymer wherein the recovered fluorine-containing polymer is resistant to swelling. The method according to the present invention for recovering a fluorine-containing polymer is a method that recovers a fluorine-containing polymer from a membrane-electrode assembly comprising: a cathode and anode having a catalyst layer that contains a catalyst and a fluorine-containing polymer having a sulfonic acid group; and, disposed between the cathode and anode, an electrolyte membrane containing a fluorine-containing polymer having a sulfonic acid group. After the membrane-electrode assembly has been brought into contact with a first solution selected from a solution A comprising only water and a solution B containing water and an alcohol, the membrane-electrode assembly is mixed with a second solution containing water and an alcohol to obtain a mixed solution containing the fluorine-containing polymer, the second solution, and insoluble matter. The insoluble matter contained in the mixed solution is removed and the fluorine-containing polymer contained in the mixed solution from which the insoluble matter has been removed is recovered.
Resumen de: WO2025143135A1
This electrochemical cell device comprises an electrochemical cell and a gas supply unit that supplies gas to the electrochemical cell. The electrochemical cell has: a flow path member having a gas flow path, a gas introduction part, and a gas discharge part; and an element part positioned on the flow path member. The gas introduction part introduces the gas into the gas flow path. The gas discharge part discharges the gas from the gas flow path. At least one of the gas introduction part and the gas discharge part has an adjustment part for adjusting a pressure loss generated during passage of the gas. In the adjustment part, the introduction direction of the gas introduced from the gas supply part to the gas introduction part and/or the discharge direction of the gas discharged from the gas discharge part is orthogonal to the direction of flow of the gas in the gas flow path.
Resumen de: WO2025142931A1
Resumen de: WO2025142876A1
A first end sheet (2) and a second end sheet (6) respectively have: left protrusions (21, 61) which are positioned at the left of a cell laminate (4) and which protrude leftward; left engagement holes (2g1, 6g1) which are provided to the left protrusions (21, 61) and with which a first fastening bolt (10a1) is engaged; right protrusions (22, 62) which are positioned at the right of the cell laminate (4) and which protrude rightward; and right engagement holes (2g2, 6g2) which are provided to the right protrusions (22, 62) and with which a second fastening bolt (10a2) is engaged. The left protrusions (21, 61) and the right protrusions (22, 62) are provided at different positions in the vertical direction.
Resumen de: WO2025139001A1
Provided are a method for selectively removing enriched and segregated elements on the surface of a perovskite-based air electrode, and the use thereof. The method comprises: treating a perovskite-based air electrode or electrode powder in an alkali liquor, and then washing and drying same, wherein the concentration of the alkali liquor is 0.01-10 mol L-1; the pH value of the alkali liquor is greater than 7; and the treatment time is 1-600 min. The method greatly increases the active sites on the surface of the electrode, significantly improves the intrinsic activity, and also improves the stability and water resistance of the electrode. The method can effectively improve the peak power density of a solid oxide fuel cell and the current density of a solid oxide electrolytic cell, and can also improve the long-term stability of the cell and the electrolytic cell. The air electrode obtained by means of the method is used in the solid oxide fuel cell and the solid oxide electrolytic cell.
Resumen de: WO2025138891A1
The present application relates to the technical field of fuel cells, and discloses a combustor and an SOFC system. The combustor comprises a first pipe fitting, the first pipe fitting being provided with a first chamber; a second pipe fitting, the end of the second pipe fitting entering the first chamber being provided with a release member used for gas distribution; and a rectification member, arranged in the first chamber and connected to the second pipe fitting so as to define a second chamber used for gas combustion, the release member being located in the second chamber, and the second chamber being communicated with the first chamber. According to the combustor provided by embodiments of the present application, the structure is optimized, the large-range combustion load adjustment of the combustor from temperature rise to power generation is improved when the combustor is applied to an SOFC system, and the combustion effect is also enhanced.
Resumen de: WO2025137830A1
A composite ion exchange membrane, a preparation method therefor and a use thereof, and a zinc-iodine flow battery. By introducing halogen adducts onto a porous membrane, a composite membrane based on a series of localized high iodine concentration (LHIC) coatings is constructed to suppress the problem of crossover of active polyiodide compounds in a catholyte. Specifically, metal oxides exhibit a strong physicochemical adsorption effect toward halogens, and halogen oxide adducts are formed, the halogen oxide adducts becoming effective halogen carriers. An LHIC coating is constructed on the porous membrane by utilizing the strong adsorption characteristic of the carriers and halogen (such as iodine), thereby enhancing the selectivity of the porous membrane toward iodine species. On the basis of Donnan exclusion and concentration gradient effects, a constructed localized high-concentration membrane can effectively suppress the diffusion of halogens from a positive electrode in a zinc-iodine battery/zinc-bromine battery, mitigating the problem of capacity loss of a zinc-iodine/zinc-bromine flow battery, and achieving long-term cyclic stability.
Resumen de: WO2025143963A1
The present invention relates to a method and an apparatus for inspecting a planar SOFC cell, wherein pinholes, if present in an electrolyte membrane of the SOFC cell, can be measured using plasma breakdown to determine whether the pinholes are present and the location of the pinholes, external factors such as temperature changes do not have any effect, thus making pressure stabilization time unnecessary, and it does not take much time to form a vacuum since the volume requiring a vacuum is small, which has the advantage of enabling quicker inspections than a pressure change method.
Resumen de: WO2025142022A1
This work vehicle comprises: a fuel cell; a hydrogen tank that accommodates hydrogen to be supplied to the fuel cell; a sensor that detects the state of hydrogen in the hydrogen tank; and a notification device that provides notification of information corresponding to a detection value from the sensor.
Resumen de: WO2025142025A1
This work machine comprises: a vehicle body capable of traveling; a tank 13 mounted on the vehicle body; a fuel cell 24 mounted on the vehicle body and generating power with hydrogen supplied from the tank 13; a valve 60 capable of blocking supply of hydrogen from the tank 13 to the fuel cell 24; and a detection device 80 provided in the vehicle body. The vehicle body travels on the basis of detection information from the detection device 80, and the valve 60 is closed when it is determined that a travel state of the vehicle body obtained from the detection information is dangerous.
Resumen de: WO2025142007A1
This work vehicle includes: a body; a fuel cell mounted on the body; a tank for storing fuel that is supplied to the fuel cell; and a first loading port and a second loading port for loading fuel into the tank.
Resumen de: WO2025142002A1
A work machine comprises: a vehicle body 11; a fuel cell 24; a battery 30; a motor 31; a first power converter (converter 26); and a second power converter (inverter 27). The vehicle body 11 has a vehicle body frame 41 and a support structure 50 for attaching the first power converter and the second power converter to the vehicle body frame 41. The support structure 50 has: a base 53 attached to the vehicle body frame 41; a first support 51 which has a first erected part erected from the base 53 and in which the first power converter is attached to and supported by the first erected part; and a second support 52 which has a second erected part erected from the base 53 and in which the second power converter is attached to and supported by the second erected part.
Resumen de: WO2025142287A1
Provided is an ion analysis device capable of performing measurements using a sample liquid with a smaller liquid volume than conventional methods. The ion analysis device comprises: a measurement electrode provided with a response unit which responds to ions; a reference electrode provided with a liquid junction section; a measurement flow path in which the response membrane and the liquid junction section are disposed; and a calculation unit that calculates the ion concentration in the sample liquid on the basis of the potential difference between the measurement electrode and the reference electrode, the device further comprising a hydrophilic section connecting the response unit and the liquid junction section inside the measurement flow path.
Resumen de: WO2025141996A1
A work vehicle comprising: a vehicle body; a fuel cell that is installed in the vehicle body; a battery unit that stores power generated by the fuel cell; a motor that is installed in the vehicle body and that is driven via the power stored in the battery unit; a machine case that is disposed above the battery unit; and a cover that covers the machine case.
Resumen de: WO2025141992A1
A work vehicle 1 according to the present disclosure comprises: an FC module 24; a vehicle body 11 on which the FC module 24 is mounted; and a discharge pipe 50 which has a discharge port 56 that discharges waste water from the FC module 24 to the outside. The discharge pipe 50 includes an upright pipe 52 which guides waste water upwards and discharges the guided waste water from the discharge port 56.
Resumen de: WO2025143958A1
Provided is a gas diffusion layer for a fuel cell. The gas diffusion layer comprises a carbon substrate and a microporous layer formed on the carbon substrate. The microporous layer contains carbon particles and a water-repellent resin that binds the carbon particles. The microporous layer contains a radical scavenger including nano-sized cerium oxide particles that have a controlled particle shape, which is rectangular parallelepiped, a cube, an octahedron, or a polyhedron having nine or more surfaces, and are doped with at least one non-metallic element selected from among nitrogen, phosphorus, sulfur, chlorine, and fluorine and/or at least one metal element selected from among La, Pr, Sm, Eu, Gd, Y, Zr, and Nb. The gas diffusion layer can effectively improve the durability of a fuel cell manufactured using same.
Resumen de: WO2025143949A1
Disclosed are a gas diffusion layer and a fuel cell comprising same. The gas diffusion layer has a horizontal gas permeability (InP) of 10 to 100×10-12m2 and a vertical gas permeability (ThP) of 0.02 to 1×10}-12m2.
Resumen de: WO2025143763A1
A membrane humidifier, in which a baffle is provided, for a fuel cell comprises: a mid-case provided with a fluid moving hole through which a fluid passes; a fluid moving part disposed in the fluid moving hole of the mid-case; and a cartridge disposed in the mid-case and provided with a humidification membrane, wherein the fluid moving part includes: a baffle provided in the fluid moving hole and provided with multiple windows; and a mid-end cap connected to the mid-case from the outside of the fluid moving hole.
Resumen de: WO2025143748A1
The present invention relates to: a method for manufacturing a permanganate solution-supported electrode as an electrode for a redox flow battery; and an electrode. An electrode is manufactured by preparing a permanganate solution according to the concentration of permanganate, immersing a porous carbon electrode for a predetermined time, drying same, and then allowing manganese oxide to be supported on the surface of the porous carbon electrode through a heat treatment process, and the electrode is used for an electrode for a redox flow battery.
Resumen de: WO2025143473A1
A fuel cell lifespan prediction device according to one embodiment may comprise: an information collection unit for measuring the voltage of each of a plurality of unit cells provided in a fuel cell stack; a cell prediction model unit for generating a cell degradation prediction model so as to define a degradation pattern of each unit cell on the basis of the voltage measured in the unit cell; a lifespan prediction unit for predicting the lifespan of each unit cell on the basis of the cell degradation prediction model, and outputting the time required for the lifespan of each unit cell to reach a failure determination condition; and a stack prediction model unit for generating an integrated degradation prediction model so as to define a degradation pattern of the fuel cell stack on the basis of the lifespan of each unit cell.
Resumen de: WO2025141953A1
A fuel cell system (1) comprises an FC stack (11) that generates electric power upon receiving supply of hydrogen and air, but does not comprise a DC-DC converter. The fuel cell system comprises: a hydrogen system (21) that supplies hydrogen to the FC stack (11); and a control device (20) that controls an injector (53) of the hydrogen system (21). When the FC stack (11) stops intermittently, the control device (20) controls the injector (53) so as to lower the outlet hydrogen pressure at an ejector (54) of the hydrogen system (21) to a level higher than a prescribed cutoff hydrogen pressure. Prior to lowering the outlet hydrogen pressure to a level higher than the cutoff hydrogen pressure, the control device (20) controls the injector (53) so as to temporarily lower the outlet hydrogen pressure to the cutoff hydrogen pressure.
Resumen de: WO2025142043A1
This work vehicle comprises a body, a fuel cell installed in the body, a tank for storing fuel to be supplied to the fuel cell, supply piping that is connected to the tank and that supplies fuel to the tank, and a frame on which the tank and the supply piping are mounted and which can be removed from the body.
Resumen de: WO2025142044A1
A work vehicle 1 according to the present disclosure comprises: an FC module 24; a motor 31 that is driven by power outputted from the FC module 24; a hydrogen tank 13 that stores hydrogen which is fuel of the FC module 24; and an FC system ECU 71 that calculates power which is generatable by the FC module 24 in a case where hydrogen is used until the hydrogen amount in the hydrogen tank 13 reaches a prescribed amount from the present amount.
Resumen de: WO2025142005A1
The present disclosure relates to a work vehicle. A work vehicle according to the present disclosure comprises: a vehicle body; a fuel cell that generates power using hydrogen as fuel; a tank that stores hydrogen; a case that houses the tank; and a ventilation device that includes a fan which allows air in the case to flow outside. Furthermore, a work vehicle according to the present disclosure comprises: a vehicle body; a fuel cell that generates power using, as fuel, hydrogen which is gaseous fuel; a tank that stores hydrogen; piping which is connected to the tank and through which hydrogen can pass; and a first outer tube and a second outer tube that cover at least a portion of the outer side of the piping.
Resumen de: WO2025142047A1
A work vehicle 1 according to the present disclosure comprises: a fuel cell (FC) module 24; a hydrogen tank 13 that stores hydrogen which is a fuel for the FC module 24; a motor 31 that is driven by power output from the FC module 24; and an FC system ECU 71 that can acquire a consumption command. When the FC system ECU 71 acquires the consumption command, the FC module 24 generates power until the hydrogen amount of the hydrogen tank 13 becomes a prescribed amount or less.
Resumen de: WO2025138421A1
Disclosed in the present invention is a combined power supply system based on a heat engine and a solid oxide fuel cell, comprising a gas turbine generator module, a heat exchange module, and a fuel cell supply module. The gas turbine generator module is coupled with the heat exchange module by means of a turbine; the turbine performs work to generate power for primary power generation, and is connected to the heat exchange module to heat air; the heat exchange module is connected to the fuel cell supply module to output the heated air to a cathode of the solid oxide fuel cell of the fuel cell supply module; a basic hydrocarbon fuel is input into an anode of the solid oxide fuel cell by means of a pipe; an output end of the solid oxide fuel cell is connected to a combustion chamber to perform oxygen-deficient combustion for power generation; and by connecting the turbine, a product which fails to be sufficiently combusted is re-combusted to perform work. The present invention promotes the transformation and upgrading of fossil fuel power plants, avoids resource waste, further improves the power generation efficiency, and is more energy-saving and environmentally-friendly.
Resumen de: WO2025143385A1
The present invention relates to an electricity generator using composite carbon and, more particularly, to a technology enabling electricity to be generated through a chemical reaction between carbon and metal, wherein, rather than as simple structures, the carbon is applied as composite carbon members in a form that can maximize the degree of activation of the chemical reaction, thereby enabling electricity to be stably generated for a long time and facilitating series or parallel provision. The present invention comprises: a main body having an accommodation space therein; a metal member, which is provided in the accommodation space of the main body and has a negative polarity; and a composite carbon member, which is provided in the accommodation space of the main body and has a positive polarity, wherein electrical energy is generated by a chemical reaction between the metal member and the composite carbon member, and the composite carbon member has a plurality of pores formed therein by mixing two kinds of carbon materials and undergoing foaming.
Resumen de: WO2025144859A1
Methods, systems, and apparatus for modular fuel cell architectures for power generation. In some implementations, an array of modules is configured to output an AC voltage as a combination of multiple AC module voltages generated based on DC input from one or more fuel cell stacks. Each of the modules can include a plurality of input ports configured to receive the DC input from the one or more fuel cell stacks. In some cases, the modules are configured to receive different DC input voltages from electrical taps at different intermediate locations among fuel cells of a fuel cell stack that are electrically coupled in series. In some cases, the modules are configured to selectively receive power from multiple fuel cell stacks or multiple fuel cell strings coupled together in parallel. The modules include a power output connection and a local control device configured to control the module.
Resumen de: WO2025143901A1
Disclosed are an electrode for a vanadium redox flow battery and a vanadium redox flow battery comprising same. The disclosed electrode for a vanadium redox flow battery comprises: a first carbon fiber having a diameter of 9-11 ㎛; and a second carbon fiber having a diameter of 6-8 ㎛.
Resumen de: WO2025143398A1
The present invention relates to an ion conductor dispersion composition, a polymer electrolyte membrane, a manufacturing method thereof, and a membrane-electrode assembly comprising same, and more specifically, to an ion conductor dispersion composition, a polymer electrolyte membrane, a manufacturing method thereof, and a membrane-electrode assembly comprising same, wherein an environmentally-friendly additive solvent is used instead of a conventional chemical-based solvent to improve the solubility and impregnability of the polymer, thereby improving electrochemical and mechanical stability, while being friendly to the environment.
Resumen de: WO2025143244A1
An electrochemical cell according to the present invention comprises a metal plate and an element part. The metal plate has a first surface, a second surface, and a plurality of through holes which include at least one first hole. The second surface is located on the opposite side from the first surface. The plurality of through holes each have a first opening which is located on the first surface. The element part has a first layer which faces the first surface, a solid electrolyte layer, and a first electrode which is located on the opposite side of the solid electrolyte layer from the first layer. The first layer has a protrusion part which extends into the first hole. The protrusion part covers the edge of the first opening of the first hole and at least a portion of the wall surface of the first hole.
Resumen de: AU2024259888A1
Abstract The present invention relates to a laminate of multiple perforated layers each having a two-dimensional periodic structure of openings with said openings having different dimensions. Moreover, the present invention relates to an assembly comprising a bipolar plate and the laminate according to the present invention as well as an electrochemical apparatus comprising the laminate or the assembly according to the present invention. Abstract The present invention relates to a laminate of multiple perforated layers each having a two-dimensional periodic structure of openings with said openings having different dimensions. Moreover, the present invention relates to an assembly comprising a bipolar plate and the laminate according to the present invention as well as an electrochemical apparatus comprising the laminate or the assembly according to the present invention. ov b s t r a c t o v h e p r e s e n t i n v e n t i o n r e l a t e s t o a l a m i n a t e o f m u l t i p l e p e r f o r a t e d l a y e r s e a c h h a v i n g a t w o - d i m e n s i o n a l p e r i o d i c s t r u c t u r e o f o p e n i n g s w i t h s a i d o p e n i n g s h a v i n g d i f f e r e n t d i m e n s i o n s o r e o v e r , t h e p r e s e n t i n v e n t i o n r e l a t e s t o a n a s s e m b l y c o m p r i s i n g a b i p o l a r p l a t e a n d t h e l a m i n a t e a c c o r d i n g t o t h e p r e s e n t i n v e n t i o n a s w e l l a s a n e l e c t r o c h e m i c a l a p p a
Resumen de: AU2024209402A1
In the present invention, a first hydrogen-reserving unit stores hydrogen and has a first filling hole that allows filling with hydrogen. A second hydrogen-reserving unit stores hydrogen and has a second filling hole that allows filling with hydrogen. A fuel cell uses the hydrogen to generate electricity. Piping connects the fuel cell and each of the first and second hydrogen-reserving units and channels the hydrogen. A valve is provided to the piping at a location between the first and second hydrogen-reserving units. The valve is configured to be capable of preventing hydrogen from being channeled between the first and second hydrogen-reserving units.
Resumen de: WO2025134921A1
As shown in fig. 1, a carbon fiber-resin composite sheet 10 according to the present invention is composed of a sheet containing a carbon fiber and a resin, and has a first portion 12 and a second portion 14 which are continuous and distinguished in a plane direction, wherein the density of the first portion 12 is greater than the density of the second portion 14, and the first portion 12 and the second portion 14 each number 10 or less.
Resumen de: AU2023300562A1
Bipolar plates (1) adapted for use in an electrolyser cell stack (4) and wherein each plate comprises a plate midplane (2) whereby the plate (1) comprises spaced apart uniform spacers (7) extending in opposed directions from the midplane (2). All spacers (7) are arranged along concentric circles (8) in the midplane (2) with spacers (7) alternatingly protruding in opposite directions relative to the midplane (2) along each concentric circle (8) and an even number of spacers (7) are provided in each circumferential circle (8), apart from an innermost circle (9) which comprises a single spacer (7).
Resumen de: CN119421812A
The present disclosure relates to a computer-implemented method of controlling a fuel cell electric vehicle (FCEV) power system, the power system including an energy storage system and a fuel cell, in which when power consumption of the power system exceeds a power capacity of the power system, the fuel cell is connected to the energy storage system. And controlling the fuel cell to adopt a power mode when reaching the initial position of the upcoming road path.
Resumen de: US2025170923A1
The present disclosure relates to a method of counteracting degradation of a fuel cell system of a vehicle. A processor device is used for performing the method. The processor device estimates a standstill average power needs of the vehicle by estimating the average power that the vehicle will consume during a predetermined time period during which the vehicle will be at a standstill. An idling power extractable from the fuel cell system is determined. Said idling power is compared with said estimated standstill average power needs. Based on the comparison, a duration for which the fuel cell system should be kept turned on to fulfil said estimated standstill average power needs is determined. The fuel cell system is controlled to be kept turned on for the determined duration.
Resumen de: JP2025099373A
【課題】水素吸蔵合金が収容された水素貯蔵タンクの圧力の変化を抑制する。【解決手段】水素貯蔵システム100は、水素吸蔵合金11が収容された水素貯蔵タンク10と、水素を貯留可能な第1水素ホルダ73及び第2水素ホルダ74と、水素貯蔵タンク10内の圧力を検出する第1圧力センサ57と、水素貯蔵タンク10と第1水素ホルダ73及び第2水素ホルダ74との連通状態を制御するコントローラ60と、を備え、コントローラ60は、第1圧力センサ57により検出された値が第1閾値を下回った場合、第1水素ホルダ73及び第2水素ホルダ74のうち、水素貯蔵タンク10よりも圧力が高い水素ホルダを水素貯蔵タンク10と連通させ、第1圧力センサ57により検出された値が第2閾値を上回った場合、第1水素ホルダ73及び第2水素ホルダ74のうち、水素貯蔵タンク10よりも圧力が低い水素ホルダを水素貯蔵タンク10と連通させる。【選択図】図1
Resumen de: CN119522129A
Systems and methods for operating a combined cycle power plant while increasing the CO2 content in the flue gas produced by the power plant are provided. The CO2 content is increased by using a combination of exhaust gas recirculation and oxygen-enriched combustion. The oxygen-containing gas stream used to conduct the oxygen-enriched combustion can be produced by an integrated pressure swing adsorption process that allows the production of a commercial grade nitrogen gas stream (95 vol% or higher N2) while also providing an oxygen-containing gas stream with an oxygen content of between 25 vol% and 48 vol% as well as a higher O2 recovery.
Resumen de: CN118974578A
The invention relates to a method for controlling the operation of at least two fuel cell systems (FCS1, FCS2) wherein each fuel cell system is adapted to operate with an adjustable operating dynamics and/or in an adjustable operating window defining operating constraints of the fuel cell system, wherein an increased operating dynamics and/or operating window is associated with an increased expected degradation of the fuel cell system, and wherein a reduced operating dynamics and/or operating window is associated with a reduced expected degradation of the fuel cell system, the method comprising:-obtaining (S1) an estimated actual state of health of each fuel cell system (FCS1, FCS2), comparing (S2) the actual states of health of the fuel cell systems (FCS1, FCS2), and when the comparison indicates a predefined difference between the actual states of health of the fuel cell systems (FCS1, FCS2): identifying (S3) a first of the at least two fuel cell systems (FCS1, FCS2) having the lowest actual state of health of the at least two fuel cell systems (FCS1, FCS2); comparing (S4) the actual state of health of the first fuel cell system with a determined expected state of health of the first fuel cell system, the expected state of health being based on a historical usage of the first fuel cell system, and when the actual state of health of the first fuel cell system is poorer than its expected state of health, determining (S4) the actual state of health of the first fuel cell syste
Resumen de: WO2024003169A1
The invention relates to a fuel cell system (1) comprising an expansion machine (2) with a high-pressure side (3a) and a low-pressure side (3b) for performing mechanical work, and comprising multiple fuel cells (4) stacked on top of one another, which communicate fluidically with the high-pressure side of the expansion machine (2) via a gas path (5), such that, during operation of the fuel cell system (1), exhaust gas discharged from the fuel cells (4) into the gas path (5) and containing water drives the expansion machine (2). The fuel cell system (1) comprises a water separator (6) arranged in the gas path (5) for separating water from the exhaust gas, and a valve unit (7) arranged between the water separator (6) and the high-pressure side (3a) of the expansion machine (2) for adjusting an amount of exhaust gas to be supplied to the expansion machine (2). The fuel cell system (1) also comprises a bypass gas path (8) through which the exhaust gas can flow, which branches off from the gas path (5) between the fuel cells (4) and the water separator (6) and fluidically communicates with the low-pressure side (3b) of the expansion machine (2), such that exhaust gas can bypass the expansion machine (2) via the bypass gas path (8). In addition, a bypass valve unit (9) is arranged in the bypass gas path (8) for adjusting the amount of exhaust gas flowing through the bypass gas path (8).
Resumen de: JP2025099441A
【課題】大電流放電が要求された場合であっても、電源供給が安定して行うことができ、また、充電効率が良好な電力供給装置を提供すること。【解決手段】電力を供給する入力電源と負荷との間の蓄電池装置は、制御回路6を介してレドックスフロー電池1と二次電池3とが並列接続となるように構成されており、レドックスフロー電池1の充電電圧の上限は、二次電池3の充電電圧の上限よりも高くなるように構成され、制御回路6は、レドックスフロー電池1と二次電池3との共通電圧を計測する電圧センサー5を備え、電圧センサー5の電圧値に基づき、電磁開閉スイッチ素子MC2を開閉操作することにより、充電時にレドックスフロー電池1と二次電池3とが、単接続、並列接続とを切り替え可能に構成され、電磁開閉スイッチ素子MC2と並列接続となるように、二次電池3からの出力電流方向を順方向とするバイパスダイオード4を備えることを特徴とする。【選択図】図1
Resumen de: JP2025099432A
【課題】燃料電池の耐久性を向上する。【解決手段】燃料電池100は、電解質膜107の両面に電極が接合された膜電極接合体115と、担体およびセリウムを含むセリウム複合体と、を備え、セリウム複合体中のセリウムの含有量に対する担体の含有量の質量比が15以上100以下である。【選択図】なし
Resumen de: JP2025099579A
【課題】本発明は、硬化物の低アウトガス性に優れるとともにリン元素が溶出しない光硬化性樹脂組成物を提供することを目的とする。【解決手段】下記の(A)~(C)成分を含み、(A)成分100質量部に対し(C)成分を1~20質量部含む、光硬化性樹脂組成物。(A)成分:(メタ)アクリロイル基を1以上と、-[CH2C(CH3)2]-単位を含むポリイソブチレン樹脂(B)成分:イソボルニル(メタ)アクリレート(C)成分:ケタール系光ラジカル重合開始剤【選択図】 なし
Resumen de: WO2025135161A1
Provided is a display device capable of accurately grasping an operating state or performance evaluation of a measurement subject by utilizing a current-voltage characteristic graph or the like. The display device comprises a processing unit 4 for causing a display screen to display at least one characteristic graph among: a current-voltage characteristic graph indicating the characteristic of a voltage value of a direct current voltage between terminals T1, T2 with respect to a current value of a direct current inputted/outputted through a measurement subject DUT1 via the terminals; a current-power characteristic graph indicating the characteristic of a power value of power inputted/outputted via the terminals with respect to the current value of the direct current that is inputted/outputted; and a current-impedance characteristic graph indicating the characteristic of the impedance of the measurement subject DUT1 with respect to the current value of the direct current that is inputted/outputted. When one measurement point among a plurality of measurement points on one characteristic graph displayed on the display screen is selected, the processing unit 4 displays, on the display screen, a Cole-Cole plot of the measurement subject DUT1 when a direct current of a current value corresponding to the selected measurement point is flowing.
Resumen de: AU2025204349A1
Abstract: A system for extracting hydrogen gas from a liquid hydrogen carrier may include a hydrogen gas reactor, a catalyst for facilitating extraction of the hydrogen gas from the liquid hydrogen carrier, and a reservoir for containing the liquid hydrogen carrier and a spend liquid hydrogen carrier. The system may be configured to regulate a flow of liquid hydrogen carrier in and out of the hydrogen gas reactor, to move a catalyst relative to a volume of the liquid hydrogen carrier, and to provide a continuous flow of the hydrogen gas, in response to a demand for the hydrogen gas. Abstract: A system for extracting hydrogen gas from a liquid hydrogen carrier may include a hydrogen gas reactor, a catalyst for facilitating extraction of the hydrogen gas from the liquid hydrogen carrier, and a reservoir for containing the liquid hydrogen carrier and a spend liquid hydrogen carrier. The system may be configured to regulate a flow of liquid hydrogen carrier in and out of the hydrogen gas reactor, to move a catalyst relative to a volume of the liquid hydrogen carrier, and to provide a continuous flow of the hydrogen gas, in response to a demand for the hydrogen gas. un b s t r a c t : s y s t e m f o r e x t r a c t i n g h y d r o g e n g a s f r o m a l i q u i d h y d r o g e n c a r r i e r m a y i n c l u d e a h y d r o g e n g a s r e a c t o r , a c a t a l y s t f o r f a c i l i t a t i n g e x t r a c t i o n o f t h e h y d r o g e n g a s f r o m t h e l i q u i d h y
Resumen de: AU2023413828A1
A distribution arrangement (69a, 69b, 121a, 123a, 125a, 127a) configured to be positioned between two corrugated heat transfer plates (5) is provided. The distribution arrangement (69a, 69b) comprises a base portion (71) including a slab (73) with opposing front and back surfaces (79, 81). A front surface (89) and a back surface (93) of the base portion (71) comprise at least a part of the front surface (79) and the back surface (81), respectively, of the slab (73). The base portion (71) is provided with a through secondary hole (85) which extends through the front and back surfaces (89, 93) of the base portion (71) so as to form a direct secondary flow path (DS) through the base portion (71), a non-through first secondary cavity (97) which extends through the front surface (89) of the base portion (71), and at least one first secondary channel (101) extending inside the slab (73). Said at least one first secondary channel (101) connects the secondary hole (85) and the first secondary cavity (97) to form a first transferred secondary flow path (TS1) through the base portion (71).
Resumen de: AU2023413832A1
A sealing arrangement (S1, S2) for sealing between two corrugated heat transfer plates (5, 90, 92) is provided. It comprises an annular outer field gasket part (86) enclosing an outer field gasket area (AO), and a plurality of annular ring gasket parts (49) arranged outside the outer field gasket area (AO). A first, a third and a fifth ring gasket part (49a, 49c, 49e) of said plurality of ring gasket parts (49) are arranged on one side of a transverse center axis (TA) of the outer field gasket area (AO). A second and a fourth ring gasket part (49b, 49d) of said plurality of ring gasket parts (49) are arranged on the other side of the transverse center axis (TA). The third and fifth ring gasket parts (49c, 49e) are arranged on opposite sides of a longitudinal center axis (LA) of said outer field gasket area (AO). The sealing arrangement (S1, S2) further comprises a separation means (6) extending within, and closing, the outer field gasket area (AO). The separation means (6) includes a membrane (45).
Resumen de: US2025214860A1
A method for producing a proton-containing oxide that includes reacting a basic oxide with a carboxylic acid melt having a pKa of 4 or more to introduce protons into the basic oxide to obtain a proton-containing oxide, a dense body of the proton-containing basic composite oxide, and a fuel cell, a hydrogen production cell, a hydrogen sensor, or an ammonia synthesis cell, and the method for producing the same.
Resumen de: US2025216471A1
A control device for a DCDC converter comprises an upper bridge switch for a step-down mode, a lower bridge switch for the step-down mode, and an inductor. The control device is configured to conduct the upper bridge switch for the step-down mode and to disconnect the lower bridge switch for the step-down mode within a first period. The control device is further configured to disconnect the upper bridge switch for the step-down mode and to conduct the lower bridge switch for the step-down mode within a second period, such that a current passing through the inductor within the second period changes from a positive current to a negative current. A zero current period that the inductor current is disconnected is eliminated by changing the inductor current to a negative value, to avoid operations of the DCDC converter in an intermittent current mode.
Resumen de: US2025215200A1
A sealing apparatus is provided. The sealing apparatus is arranged between two members facing each other for sealing a space between the two members. The sealing apparatus comprises a sealing body in contact with the space, in which the sealing body has a tensile strength of 10 MPa or more measured in accordance with the provisions of JIS K 6251: 2017, an elongation at break of 200% or more measured in accordance with the provisions of JIS K 6251: 2017, a TR10 temperature of −40° C. or lower in a low-temperature elastic recovery test, measured in accordance with the provisions of JIS K 6261-4: 2017, and a compression set at 100° C. with an elapsed time of 70 hours in a shape of a G25 O-ring as described in the provisions of JIS B 2401-1: 2012, measured in accordance with the provisions of JIS K 6262: 2013, of 40% or less.
Resumen de: US2025215225A1
The present invention relates to a method for the preparation of a membrane (M), the membrane (M) comprising a sulfonated poly(arylene ether sulfone) polymer (sP) and a non-sulfonated poly(arylene sulfone) polymer (P), to the membrane (M) obtained by the method and to the use of the membrane (M) as ultrafiltration membrane and/or for haemodialysis applications.
Resumen de: US2025215152A1
A polyaryletherketone with a wide molecular weight distribution and a preparation method therefor. The polyaryletherketone has a Tg of at least 143° C., a Tm of at least 330° C., a crystallinity of at least 20%, a PDI of 2.5-2.9, and a gel content of as low as 0.2%. An extrusion blending or solution blending method is used to prepare the polyaryletherketone with the wide molecular weight distribution and without a high branching degree. When the viscosity of the polyaryletherketone is the same at low shear strength, the viscosity at high shear strength is smaller, such that the processing difficulty of a product can be significantly reduced, expanding the applicable range of the product. The gel content of the polyaryletherketone is remarkably reduced, resulting in a more streamlined process in the preparation of a molded product without significant fish-eye appearances on a film due to aggregation of the gel.
Resumen de: US2025214784A1
A method and an apparatus for the production of modules or precursors of modules, in particular of fuel or battery cells containing layer material. The method includes conveying individual anode layers to a first transfer location for transfer to a first layer turner; conveying individual cathode layers to a second transfer location for transfer to a second layer turner; turning picked-up anode or cathode layers by a respective angle of rotation to a respective first or second delivery location; reciprocating the anode or cathode layers by a respective angle of rotation to a respective first or second delivery location; and transferring the anode or cathode layers to respective first or second layer turners at the respective first and second delivery locations.
Resumen de: US2025214139A1
The present invention concerns a double passivation galvanic displacement (GD) synthesis method for production of high performance, supported noble metal-M alloy composite material, where M is an electrochemically less noble metal, compared to the noble metal, the supported noble metal-M alloy composite material obtained by the synthesis, and the use of such composite material as electrocatalyst material.
Resumen de: US2025214034A1
Hydrogen gas purifier electrochemical cells, systems for purifying hydrogen gas, and methods for purifying hydrogen gas are provided. The cells, systems, and methods employ double membrane electrode (DMEA) electrochemical cells that enhance purification while avoiding the complexity and cost of conventional cells. The purity of the hydrogen gas produced by the cells, systems, and methods can be enhanced by removing at least some intermediate gas impurities from the cells. The purity of the hydrogen gas produced by the cells, systems, and methods can also be enhanced be introducing hydrogen gas to the cells to replenish any lost hydrogen. Water electrolyzing electrochemical cells and methods of electrolyzing water to produce hydrogen gas are also disclosed.
Resumen de: US2025216477A1
An electric circuit system including a plurality of electric paths in which a plurality of potential difference generating units are connected in series, and which have one pole serving as a common electrode, an earth fault detection circuit which is provided between an intermediate potential portion of each electric path and earth, and which is used to detect an earth fault of each electric path, and a control device for detecting an earth fault of each electric path by comparing each measured value measured by the earth fault detection circuit with a threshold for determining an earth fault, wherein the control device comprises a potential difference acquiring unit for acquiring a potential difference of the intermediate potential portions of the plurality of electric paths, and a threshold setting unit for setting the threshold on the basis of the potential differences acquired by the potential difference acquiring unit.
Resumen de: US2025214961A1
Pyridinium derivatives, methods of making the pyridinium derivatives, and electrochemical cells that use the pyridinium derivatives as anolytes are provided. The pyridinium derivatives have a redox core with two or more pyridinium groups and substituents at pyridinium ring nitrogen atoms. The pyridinium derivatives can be made by reacting pyridyl reactant molecules having two or more pyridyl groups with water-soluble derivatizing reactant molecules via a hydrothermal synthesis.
Resumen de: US2025215993A1
A fluid control device includes a housing portion including an inlet port and an outlet port, and a valve portion fixedly coupled to an internal surface of the housing portion, in which the valve portion includes a lower plunger module, an upper plunger module, an elastic member including one side configured to press the lower plunger module downward and the other side configured to press the upper plunger module upward, and a solenoid, in which the lower plunger module includes a lower plunger member movable in an upward/downward direction H, and in which the upper plunger module includes an upper plunger member provided to be movable in the upward/downward direction H relative to the housing portion, and a core provided to be penetrated by a partial region of the upper plunger member and including at least a partial region surrounded by the solenoid.
Resumen de: US2025215590A1
An object of the present invention is to provide an electrolyte membrane having a good durability when performing water electrolysis. The gist of the present invention is an electrolyte membrane including: a first electrolyte layer having a first main surface and a second main surface; and a second electrolyte layer provided on the first main surface of the first electrolyte layer; wherein the first electrolyte layer has a thickness of 40 μm or more and 250 μm or less, and contains a polymer electrolyte; and wherein the second electrolyte layer contains a polymer electrolyte and carbon particles.
Resumen de: US2025215273A1
A hot melt adhesive sheet according to the present invention is a hot melt adhesive sheet including a base material having at least one surface on which an adhesive layer made of a hot melt adhesive is disposed. The hot melt adhesive includes a crosslinked product of an adhesive composition including a crosslinking agent, and includes a polyurethane resin, an epoxy resin, and 6 mass parts or more and 14 mass parts or less of an isocyanate-based crosslinking agent based on 100 mass parts of the polyurethane resin. The polyurethane resin has a constituent unit derived from a polyol having a skeleton with 8 or more carbon atoms. The epoxy resin is a bisphenol A type epoxy resin having an epoxy equivalent of 450 g/eq or more and 3000 g/eq or less.
Resumen de: US2025219494A1
A turbomachine, in particular for a fuel cell system of a vehicle, such as a utility vehicle, has a rotor shaft, an expander wheel fastened on the rotor shaft, and an air bearing arrangement, which is configured to support the rotor shaft rotatably about a rotor axis, wherein a flow path is formed between the expander wheel and the air bearing arrangement. A flow generator is arranged in the flow path between the air bearing arrangement and the expander wheel and configured to generate, depending on a rotation of the rotor shaft, an air flow directed toward the expander wheel, for the purpose of building up a blocking pressure.
Resumen de: US2025219115A1
A system and method controls operation of a fuel cell system comprising a fuel cell unit that comprises a fuel cell stack comprising a cathode and an anode, and a cathode recirculation passage configured to divert a cathode exhaust flow to a cathode inlet line. A control system is configured to, responsive to a value of a power output that is requested from the fuel cell system being below a first threshold power level, control a target coolant inlet temperature of a coolant at a coolant inlet of the fuel cell stack and control an air pressure at the cathode. Responsive to the value of a power output being below at least one second threshold power level, additionally, an oxygen partial pressure in the air flow may be reduced by controlling a volume flow rate of a cathode exhaust flow that is directed to the cathode inlet line.
Resumen de: US2025219116A1
To provide a fuel cell system configured to suppress a deterioration of fuel cell catalysts and freezing of fuel cell components. A fuel cell system wherein the fuel cell system comprises a fuel cell, a fuel gas system and a controller; wherein the fuel gas system comprises at least an ejector, a circulation flow path, a first supply line and a second supply line; wherein the circulation flow path is configured to circulate a fuel gas, which is supplied from the ejector to the fuel cell, to the ejector through the fuel cell; wherein the first supply line is configured to supply the fuel gas to the ejector; and wherein the second supply line is configured to supply the fuel gas to the ejector and has a larger circulation gas flow rate than the first supply line.
Resumen de: US2025219112A1
A flow battery relies on slurry-type electrode in which particles may be selectively and temporarily plated (relative to a solid/standard electrode). Owing to the comparatively viscous nature of the slurry, specific accommodations for the electrolyte flowpaths must be made, thereby eliminating problematic reaction areas across certain facings of the solid electrode that might otherwise impede slurry flow and/or degrade performance of the battery. Methods of operating such a battery, storing electrical energy, and other related processes are also contemplated.
Resumen de: US2025219110A1
A fuel battery stack including a seal member that can be industrially advantageously manufactured and has excellent hydrofluoric acid resistance. A fuel battery including the fuel battery stack. The fuel battery stack is formed by stacking together a plurality of fuel battery cells, each including a pair of separators and a membrane electrode assembly held therebetween. Each of the separators has a seal member disposed thereon. The seal member is a cured product of a perfluoropolyether compound-containing curable composition.
Resumen de: US2025219108A1
A fuel cell bipolar plate includes a substrate, and one or more protective layers. The one or more protective layers are adjacent to the substrate, wherein the one or more protective layers contain a number of graphyne molecules, such that each graphyne-containing layer is configured to lower hydrogen adsorption into the substrate when compared to a substrate region free from the protective layers.
Resumen de: US2025219107A1
A fuel cell includes an anode catalyst layer, a cathode catalyst layer, an electrolyte membrane layer extending between the anode catalyst layer and the cathode catalyst layer, and a graphyne-based layer. The graphyne-based layer disposed between the cathode catalyst layer and the electrolyte membrane layer or the anode catalyst layer and the electrolyte membrane layer, the graphyne-based layer is configured to suppress crossover gases to enhance performance of the fuel cell. The anode catalyst layer configured to facilitate an electrochemical reaction converting a gaseous hydrogen atom to a proton and an electron.
Resumen de: US2025219109A1
An electrochemical cell includes a porous portion, a metal member, a sealing material, and an intermediate material. The porous portion is electrically conductive. The metal member contains chromium. The sealing material is located on the porous portion and on the metal member. The intermediate material is located between the metal member and the sealing material. The intermediate material includes two or more portions having different surface roughnesses or different thicknesses at different positions.
Resumen de: US2025219113A1
Disclosed herein are a metal-air fuel cell metal source material, a composite material comprising a metal selected from an alkali metal, an alkaline earth metal, aluminium, zinc, or iron, a conductive carbon material, and a binder, a redox-mediated metal-air fuel cell cartridge comprising a cartridge housing, and a composite material comprising a metal selected from an alkali metal, an alkaline earth metal, aluminium, zinc, or iron, a conductive carbon material, and a binder, and a redox-mediated metal-air fuel cell system comprising a redox flow cell and a first tank suitable to house an anolyte and a redox-mediated metal-air fuel cell cartridge. Also disclosed herein is a method of feeding a metal in a redox-mediated metal-air fuel cell system.
Resumen de: US2025219119A1
An electrolyte membrane includes a polymer electrolyte having a novel structure and a high-temperature polymer electrolyte membrane fuel cell including the same.
Resumen de: US2025219118A1
An electrochemical cell including an anode catalyst layer, a cathode catalyst layer, and an electrolyte membrane layer extending between the anode catalyst layer the cathode catalyst layer, and a graphyne-based layer. The graphyne-based layer is disposed between the cathode catalyst layer and the electrolyte membrane layer and/or the anode catalyst layer and the electrolyte membrane layer. The graphyne-based layer is configured to suppress crossover gases and metallic cation exchange to enhance performance and durability of the electrochemical cell.
Resumen de: US2025219122A1
Flow field plates for fuel cells may include an interior region bounded by an interior boundary that contains openings which, when the flow field plates are stacked, form plural headers extending along a fuel cell stack. A flow field may surround the interior boundary. The headers may include headers for fuel, oxidant and coolant for example. The flow field may include elements that direct flow of a reactant in a radial direction and/or in a circumferential direction. A fuel cell stack may be enclosed in a housing that compresses the stack. In some embodiments plural fuel cells are combined in a power unit in which the fuel cell stacks are received within a fuel cell block equipped with a fluid manifolding stack interface that provides fluid interfaces to the headers of the fuel cell stack.
Resumen de: US2025219121A1
Provided herein is a redox flow battery, comprising:a catholyte compartment, comprising a catholyte, and a cathode;an anolyte compartment, comprising an anolyte, and an anode comprising a first metal; andan ion selective membrane disposed between the cathode compartment and anode compartment,wherein:the first metal is selected from the group consisting of an alkali metal, an alkaline earth metal, a Group III metal, and a transition metal;the anolyte comprises an anodic redox mediator; andthe anodic redox mediator has a redox potential versus a standard hydrogen electrode that is more positive than a redox potential of the first metal versus a standard hydrogen electrode.
Resumen de: US2025219120A1
A catalyst composition comprising a polymer compound having a structure represented by the following general formula (I), a catalyst, and a catalyst support, and a polymer compound having a structure represented by the following general formula (I):wherein n is 1 to 2, o is 1 to 3, and p is 0 to 3, wherein the relationship: o+p≤4 is satisfied, andeach of B and C is independently a group having at least one member selected from the group consisting of an alkyl group, an alkyl group having an ether linkage, a cycloalkyl group, and an aromatic group, which is bonded to ring A through a single heteroatom, or a heterocycle having a heteroatom therein bonded to ring A, and the heterocycle and group of B and C optionally have a substituent,wherein B and C are the same or different, at least one of B and C has an aromatic ring, and at least one aromatic ring of B and C has at least one sulfonic acid group, andwherein carbons of ring A, except the carbons bonded to the principal chain and the carbons to which B and C are bonded, are optionally substituted by a halogen atom.
Resumen de: US2025219114A1
A fuel cell system and the method of controlling the fuel cell system improve next-time startability in the following manner. Hydrogen, air, generation water, and the like that remain inside a large-sized fuel cell system needs to be removed after finishing operation of the large-sized fuel cell system, such as a fuel cell system for generating electric power. To the present end, when an air compressor needs to be operated, one fuel cell module is selected as a power supply module, and an air compressor is operated by the power supply module. Thus, durability of a fuel cell stack is improved, and at the same time, a constant amount of generated electricity necessary to restart the large-sized fuel cell system is ensured.
Resumen de: US2025217702A1
A device and computer-implemented method for machine learning with time-series data representing observations related to a technical system. The comprising includes: providing (the time-series data, and model parameters of a distribution over the time-series data and over a first latent variable and over a second latent variable, and variational parameters of an approximate distribution over a second latent variable, sampling a value of the second latent variable from the approximate distribution over the second latent variable, finding a value of the first latent variable depending on a density of the distribution over the time-series data and over the first latent variable and over the value of the second latent variable, determining a Hessian depending on a second order Taylor approximation of the distribution over the time-series data and the first latent variable and the value of the second latent variable evaluated at the value of the first latent variable.
Resumen de: US2025219117A1
A fuel cell system includes a fuel cell, a fuel supply passage for supplying fuel to the fuel cell, an ejector provided to the fuel supply passage, and a circulation passage for circulating, to the ejector, the unused fuel discharged from the fuel cell, the fuel cell system supplying the fuel to the fuel cell through the fuel supply passage via the ejector. The fuel cell system includes: a bypass passage for supplying the fuel to the fuel cell without passing through the ejector; and a bypass flow regulating unit for regulating the flow rate of the fuel in the bypass passage.
Resumen de: US2025219111A1
The present invention relates to a redox flow battery cell stack having a streamlined shape design that allows an improved electrolyte distribution, and decreases the pressure drop thereof, through increasing the size of the cell at the inlet and middle portion and decreasing the size at the outlet portion. The redox flow battery cell stack comprises at least one membrane; at least two flow frames disposed on both sides of the membrane; at least two electrodes disposed in cavities inside the flow frames; at least two gaskets between said frames, at least two bipolar plates and at least two outer frames; and two inlets and two outlets for circulating electrolytes; characterized in that said electrodes have a streamlined design; wherein the length thereof is larger than the width thereof, and the inlet and middle portions having dimensions larger than the outlet thereof.
Resumen de: AU2023389049A1
The invention relates to a method for producing flat fuel cell components (6), in particular bipolar plates, from thermoplastic material with an additional component that has good electrical and thermal conductivity, wherein the flat fuel cell component is produced by means of injection moulding using an injection moulding device (1) which has at least one injection unit (2) and at least one mould unit (3) with a wall surrounding a respective cavity. Efficient production of flat fuel cell components is achieved in that the melted thermoplastic material with the additional component is filled as melt mass by means of the at least one injection unit (2) under pressure into the hollow space of the respective cavity (31) of the at least one mould unit (3), said hollow space corresponding unchanged to the geometry of the fuel cell component, and the heat transfer via the wall (30) is adapted to the thermal conductivity and thermal capacity and filling speed of the melt mass in such a manner that the respective cavity (31) is completely filled with this as moulding mass (5) before the temperature of the melt mass falls below its melting temperature.
Resumen de: DE102024200024A1
Die vorgestellte Erfindung betrifft ein Betriebsverfahren (100) zum Betreiben eines Brennstoffzellensystems (200), wobei das Betriebsverfahren (100) umfasst:- Messen (101) eines Sauerstoffgehalts im Abgas des Brennstoffzellensystems (200), durch einen im Abgastrakt (203) des Brennstoffzellensystems (200) angeordneten Sauerstoffkonzentrationssensor (205),- Ermitteln (103) eines Systembrennstoffnutzungsgrades des Brennstoffzellensystems (200) anhand des gemessenen Sauerstoffgehalts,- Einstellen (105) des Brennstoffzellensystems (200) in Abhängigkeit des ermittelten Systembrennstoffnutzungsgrades.
Resumen de: DE102023213340A1
Die Erfindung betrifft eine Zelllage (100) für einen elektrochemischen Zellenstapel (10, 60), insbesondere einen Brennstoffzellenstapel (10) oder einen Elektrolysezellenstapel (60), wenigstens umfassend einen Zellrahmen (120) zum radialen (Rr) Flüssigkeitsdichten eines elektrochemisch aktiven Bereichs im Zellenstapel (10, 60), sowie eine innerhalb des Zellrahmens (120) eingerichtete Membran (130) für eine elektrochemische Funktion des Zellenstapels (10, 60), wobei eine Fixierung der Membran (130) am/im Zellrahmen (120) als ein im Wesentlichen flüssigkeitsdichter Direktverbund (101) der Membran (130) mit dem Zellrahmen (120) ausgebildet ist.
Resumen de: DE102024200041A1
Die Erfindung geht aus von einem elektrochemischen System (10a; 10b; 10c; 10d; 10e; 10f; 10g) mit einer ersten elektrochemischen Einheit (12a; 12b; 12c; 12d; 12e; 12f) und mit zumindest einer zu der ersten elektrochemischen Einheit (12a; 12b; 12c; 12d; 12e; 12f) fluidtechnisch parallel geschalteten weiteren elektrochemischen Einheit (14a, 16a; 14b, 16b; 14c, 16c; 14d, 16d; 14e, 16e; 14f, 16f).Es wird vorgeschlagen, dass das elektrochemische System (10a; 10b; 10c; 10d; 10e; 10f; 10g) ein zentrales Fluidversorgungsmodul (18a; 18b; 18c; 18d; 18e; 18f; 18g) mit einer, insbesondere einzelnen, Fluidfördereinheit (20a; 20b; 20c; 20d; 20e; 20f; 20g) zu einer Versorgung der ersten elektrochemischen Einheit (12a; 12b; 12c; 12d; 12e; 12f) und der zumindest einen weiteren elektrochemischen Einheit (14a, 16a; 14b, 16b; 14c, 16c; 14d, 16d; 14e, 16e; 14f, 16f) mit einem sauerstoffhaltigen Fluid umfasst.
Resumen de: DE102023213334A1
Elektrochemische Zelle (2) mit einer zwischen zwei Bipolarplatten (10) angeordneten Membranelektrodenanordnung (6). Die Membranelektrodenanordnung (6) weist eine mit zwei Elektroden (7, 8) beschichtete Membran (5) und eine Rahmenstruktur (15) auf. Die Rahmenstruktur (15) fasst die beschichtete Membran (5) an deren Umfang ein. An zumindest einer der Bipolarplatten (10) ist eine Dichtsicke (101) ausgebildet, welche mit der Rahmenstruktur (15) dichtend zusammenwirkt. Benachbart zur Dichtsicke (101) ist eine Stützstruktur (30) zwischen mindestens einer der Bipolarplatten (10) und der Rahmenstruktur (15) angeordnet.
Resumen de: DE102023213339A1
Die Erfindung betrifft eine Zelllage (100) für einen elektrochemischen Zellenstapel (10, 60), insbesondere einen Brennstoffzellenstapel (10) oder einen Elektrolysezellenstapel (60), wenigstens umfassend einen in Umfangsrichtung (Ur) der Zelllage (100) umlaufenden Zellrahmen (120) zum radialen (Rr) Flüssigkeitsdichten wenigstens eines Elektrodenraums (12/13, 62/63) des Zellenstapels (10, 60), wobei ein repräsentatives Volumenelement eines Zellrahmenkerns (121) des Zellrahmens (120) steifer als ein gleich großes repräsentatives Volumenelement eines Zellrahmenmantels (122) des Zellrahmens (120) ausgebildet ist, in welchen der Zellrahmenkern (121) wenigstens eingebettet ist.
Resumen de: DE102024200039A1
Die Erfindung geht aus von einer Haltevorrichtung (10) für zumindest eine Fluidfördereinheit (12, 14) eines elektrochemischen Systems (16), mit zumindest einer Stützeinheit (18) zu einer zumindest teilweisen Aufnahme einer Gewichtskraft der zumindest einen Fluidfördereinheit (12, 14).Es wird vorgeschlagen, dass die Haltevorrichtung (10) zumindest eine Antivibrationseinheit (20) umfasst, um einer Übertragung von Vibrationen der zumindest einen Fluidfördereinheit (12, 14) auf die Stützeinheit (18) entgegenzuwirken.
Resumen de: DE102024211969A1
Es wird eine Steuerungsvorrichtung für einen Gleichspannungswandler (DCDC-Wandler) vorgeschlagen, wobei der Gleichspannungswandler (DCD-Wandler) einen oberen Brückenschalter für den Tiefsetzmodus, einen unteren Brückenschalter für den Tiefsetzmodus sowie eine Induktionsspule umfasst, wobei die Steuerungsvorrichtung konfiguriert ist, um: während des ersten Zeitabschnitts den oberen Brückenschalter für den Tiefsetzmodus einzuschalten und den unteren Brückenschalter für den Tiefsetzmodus auszuschalten; und während des zweiten Zeitabschnitts den oberen Brückenschalter für den Tiefsetzmodus auszuschalten und den unteren Brückenschalter für den Tiefsetzmodus einzuschalten, sodass sich während des zweiten Zeitabschnitts der durch die Induktionsspule fließende Strom von einem positiven zu einem negativen Strom ändert. Durch das Ermöglichen negativer Werte für den Induktivitätsstrom wird der Zeitabschnitt mit einem Strom von 0 eliminiert, in dem der Induktivitätsstrom unterbrochen wäre, wodurch ein Betrieb des Gleichspannungswandlers im diskontinuierlichen Strommodus vermieden wird.
Resumen de: DE102023213335A1
Die Erfindung betrifft einen Zellenstapel (12) mit einer Vielzahl von übereinandergestapelten elektrochemischen Zellen (10). In dem Zellenstapel (12) sind zumindest ein Einlasskanal (30) und zumindest ein Auslasskanal (32) zur Zu- und Abfuhr eines Mediums zu den Zellen (10) ausgebildet. Der Einlasskanal (30) und der Auslasskanal (32) werden durch jeweilige Ausnehmungen in den Zellen (10) gebildet. Der Einlasskanal (30) und der Auslasskanal (32) weisen bezüglich des Zellenstapels (12) jeweils ein offenes Ende (52) und ein geschlossenes Ende (50) auf. Sowohl das offene Ende (52) des Einlasskanals (30) als auch das offene Ende (52) des Auslasskanals (32) sind an einer gemeinsamen ersten Seite (48) des Zellenstapels (12) angeordnet. Ein Rohr (60) ist in dem Einasskanal (30) angeordnet, wobei das Rohr (60) von dem offenen Ende (52) bis nahezu zu dem geschlossenen Ende (50) des Einlasskanals (30) ragt. Das Rohr weist (60) nahe des geschlossenen Endes (50) zumindest eine Öffnung (62, 63) auf.
Resumen de: DE102024200030A1
Die vorgestellte Erfindung betrifft ein Betriebsverfahren (100) zum Betreiben eines Brennstoffzellensystems (200), wobei das Betriebsverfahren (100) umfasst:- Messen (101) eines Sauerstoffgehalts im Luftpfad des Brennstoffzellensystems (200), durch mindestens einen im Luftpfad des Brennstoffzellensystems (200) angeordneten Sauerstoffkonzentrationssensor (203, 209),- Ermitteln (103) eines einem Brennstoffzellenstack des Brennstoffzellensystems (200) zugeführten Luftvolumenstroms anhand des gemessenen Sauerstoffgehalts,- Einstellen (105) des Brennstoffzellensystems (200) in Abhängigkeit des ermittelten Luftvolumenstroms.
Resumen de: DE102024100006A1
Die Erfindung betrifft eine Generatoreinheit für ein Flugzeug, aufweisend eine elektrische Maschine (1) und eine Brennstoffzelle (3), sowie aufweisend einen rotierbaren Kompressor (5), eine Brennkammer (7), und eine Turbine (9), wobei die Turbine (9) über eine Welle mit der elektrischen Maschine (1) drehmomentübertragend koppelbar ist, und aufweisend eine Rückführleitung (11) zur Rückführung von Abgasluft der Brennstoffzelle (3) in den Gasstrom vorderhalb der Brennstoffzelle (3) sowie aufweisend eine Zufuhrleitung (13) zur Zuführung zumindest eines Teils der Abgasluft der Brennkammer (7) zur Brennstoffzelle (3), sowie aufweisend eine erste Bypassleitung (12), die ausgehend von der Zufuhrleitung (13) um die Brennstoffzelle (3) führt.
Resumen de: WO2025141081A1
The invention relates to a peripheral zone which comprises at least one plate through-hole (28a, 28b, 28c), an inner rim (31; 131), extending between the plate hole (28a, 28b, 28c) and the circulation field (23; 123), and an outer rim (32; 132). The inner and outer rims together define the plate hole (28a, 28b). The peripheral zone (21; 121) comprises at least one fin (38) integral with, projecting from and secant with the outer rim (32). The outer rim (32) receives an outer portion (43) of a peripheral seal (40) and the fin (38, 138; 238a, 238b) receives an extension (46) of the peripheral seal (40) when the peripheral seal (40) and the plate (13) are integrated with the fuel cell.
Resumen de: WO2025141076A1
The invention relates to a guide (50C) for a polar separator of an electrochemical cell, which guide comprises walls (52H; 52C) arranged side-by-side along a surface plane (P11H; P11C), so as to define channels (57C) for guiding the functional fluid, each channel being defined by and between two walls. Each wall comprises an application surface (63C) which is coplanar with the surface plane and via which the wall bears against a receiving surface (41H). The guide comprises an anchoring mat (51C) interconnecting the walls. The walls and the anchoring mat together form a single monolithic piece made of joint material. The anchoring mat extends from the walls beyond the surface plane, so that it can be housed in an anchoring cavity, in order to anchor the guide (50C) received at the receiving location.
Resumen de: WO2025141069A1
The invention relates to a method for recycling residues of a catalyst ink comprising catalyst particles, an electrolyte polymer, and water. The method comprises providing an effluent containing the catalyst ink residues, filtering the effluent through a filter membrane, leading to the formation of a retentate containing the catalyst particles contained in the effluent, all or part of the electrolyte polymer, and water, and then, preferably, the diafiltration thereof by adding water. Filtration and diafiltration are preferably tangential and dynamic. The ink residues may originate from the cleaning of a catalyst ink production and/or deposition plant, or from the dissolution of ink layers on the surface of a fuel cell membrane electrode assembly. The invention further relates to a composition for recycling and to a method for producing a new ink incorporating the composition for recycling.
Resumen de: DE102024200020A1
Die Erfindung geht aus von einem Lastverteilungsverfahren für ein SOFC-Cluster (10), welches mehrere SOFC-Einheiten (12) aufweist, mit dem eine Betriebslast des SOFC-Clusters (10) auf die einzelnen SOFC-Einheiten (12) des SOFC-Clusters (10) aufgeteilt wird.Es wird vorgeschlagen, dass eine individuelle Betriebslast der einzelnen SOFC-Einheiten des SOFC-Clusters durch eine Optimierung eines Ergebnisses einer Zielfunktion des SOFC-Clusters ermittelt wird.
Resumen de: WO2025141167A1
The separator plate (15, 17) comprises: - an active zone (39); - a homogenization zone (43); - an intermediate zone (45) positioned longitudinally between the active zone (39) and the homogenization zone (43); the homogenization zone (43) of the separator plate (15, 17) having a homogenization end wall (51) at a first altitude (a1); the intermediate zone (45) of the separator plate (15, 17) having an intermediate end wall (55) at a second altitude (a2) greater than the first altitude (a1), the intermediate end wall (55) being separated from the homogenization end wall (51) by a step (59); a buffer volume (60) for equalizing the distribution of the reactive fluid arriving from the homogenization zone (43) in the active channels (41) being defined between the intermediate end wall (55), the step (59) and the end of the active teeth.
Resumen de: WO2025141171A1
The separator plate (15, 17) comprises: - an active zone (39, 47); - a homogenization zone (68) having a field (C) in which a group of homogenization channels (69) is provided, the homogenization channels (69) being juxtaposed from a first side (01) of the field (C) in the transverse direction; each homogenization channel (69) having a rectilinear portion (75) which extends in an eigendirection and has a substantially constant width perpendicular to the eigendirection, two adjacent rectilinear portions (75) being separated by a tooth (79); the eigendirections of the rectilinear portions (75) of the homogenization channels (69) forming acute angles (a) with the longitudinal direction, at least two consecutive acute angles (a) being different, and at least some teeth (79) having divergent opposite edges (81, 83).
Resumen de: WO2025140933A1
A method of transporting hydrogen comprising: forming an alcohol from hydrogen and carbon dioxide; transporting said alcohol; breaking down said alcohol to form carbon dioxide and hydrogen; using said hydrogen as a fuel; and capturing said carbon dioxide to transport for reuse in generating more alcohol.
Resumen de: WO2025141108A1
The invention relates to a polar plate (7) for an electrochemical cell of a fuel cell, comprising a central portion (73) that forms a flow field (73.1) for a functional fluid, and a peripheral portion (74), which surrounds the central portion and which comprises two distribution holes (74.1, 74.2) arranged on either side of the central portion in order to feed and discharge the functional fluid, respectively, with respect to the flow field. For each distribution hole, the peripheral portion comprises a flow rim (74.1A, 74.2A), which partly defines the distribution hole on a portion of the distribution hole, facing the central portion, and a plurality of fluid passage openings (74.7, 74.8) which are all located between the flow rim of the distribution hole and the central portion, and each elongate in a main direction that is parallel to the flow rim.
Resumen de: WO2025141110A1
The invention relates to an interconnector partition plate (1) comprising an upper face and a lower face, parallel to each other and extending along a main plane, characterized in that it comprises a central part extending along the main plane and an edge integrally surrounding the central part, the edge being folded to form a non-zero angle A with the main plane. The invention also relates to the interconnector (100) for an electrolyser comprising the partition plate, an upper plate (101) in contact with the upper face (2) of the partition plate (1) and a lower plate (102) in contact with the lower face (3) of the partition plate (1). The invention also relates to a stack (300) comprising at least two interconnectors (100) and at least one elementary electrochemical cell (200) positioned between the interconnectors (100) and an electrolyser comprising the stack, an upper end plate (312) and a lower end plate (311).
Resumen de: WO2025141075A1
The peripheral seal (40) further comprises an electrically insulating pad (43, 45, 47, 49) at specific points which is integral with the sealing portion (41), the pad (43, 45, 47, 49) projecting from the sealing portion (41) towards an exterior of the sealing portion (41), in a direction of extent parallel to the seal plane (P40), the pad (43, 45, 47, 49) being configured to be in contact with the first polar plate when the peripheral seal (40) is integrated in the electrochemical cell.
Resumen de: WO2025141051A1
The present invention relates to a composition, preferably in the form of a paste or a solid, comprising at least one inorganic material based on glass and/or glass-ceramic, and at least one source of lanthanum, to a seal for an electrochemical device obtained from said composition, to a method for manufacturing said seal, to the use of said seal in an electrochemical device, and to an electrochemical device comprising at least said seal.
Resumen de: WO2025141011A1
A method for manufacturing an electrochemical cell, comprising the following steps: • - providing a first element (30, 30.1) comprising a first rib (34, 36, 34.1, 36.1, 34.2, 36.2) bordered by two first linking portions (37, 38, 39, 40, 37.1, 38.1, 39.1, 40.1, 37.2, 38.2, 39.2, 40.2); • - providing a second element (50, 50.1) comprising a second rib (54, 56, 54.1, 56.1, 54.2, 56.2) bordered by two second linking portions (57, 58, 59, 60, 57.1, 58.1, 59.1, 50.1, 57.2, 58.2, 59.2, 60.2); • - placing the first element (30, 30.1) opposite the second element (50, 50.1), and • - producing a first junction of a first linking portion (37, 38, 39, 40, 37.1, 38.1, 39.1, 40.1, 37.2, 38.2, 39.2, 40.2) on a second linking portion (57, 58, 59, 60, 57.1, 58.1, 59.1, 50.1, 57.2, 58.2, 59.2, 60.2) by a friction welding method. The invention further relates to an electrochemical cell thus obtained.
Resumen de: WO2025140958A1
The invention relates to a manifold base (2) for a solid oxide electrochemical reactor, wherein the base is formed from an assembly of layers of material (9) stacked in a sealed manner along a stacking direction, and: - at least one of these layers of material (9) comprises a longitudinal groove passing through the thickness of the layer of material (9), and forming a longitudinal flow duct that is substantially perpendicular to the stacking direction; - at least one of these layers of material (9) comprises a transverse port forming a transverse duct through the thickness of the layer of material (9), wherein this transverse duct extends substantially along the stacking direction and is arranged facing the longitudinal flow duct.
Resumen de: TW202425398A
According to an aspect, an electrochemical cell may include a vessel, at least two instances of an anode assembly, at least two instances of an oxygen evolution electrode (OEE), and a gas diffusion electrode (GDE). In the vessel, the GDE may be disposed between mirrored arrangements of the at least two instances of the OEE and the at least two instances of the anode assembly.
Resumen de: JP2025098899A
【課題】寸法公差等があった場合でも意図通りの性能を発揮し得る燃料電池システムを提供する。【解決手段】燃料電池積層体と、燃料電池積層体を収容する筐体と、筐体の上部に設けられ、筐体内における燃料電池積層体の動きを規制する規制機構と、を備える燃料電池システムにおいて、規制機構は、燃料電池積層体の上部に押し当てられるプッシュロッドと、プッシュロッドの保持及び位置調整をする偏芯軸受けと、を備え、偏芯軸受けは、外周が正円で、中心が外周の中心から離間している正円の第1貫通孔を有する第1部材と、外周が正円で、中心が外周の中心から離間している正円の第2貫通孔を有する第2部材と、を備え、第1部材が、筐体の上部に設けられた第3貫通孔に回転可能に嵌合し、第2部材が、第1部材の上部に設けられた第1貫通孔に回転可能に嵌合し、プッシュロッドが、第2貫通孔に摺動可能に支持されている燃料電池システム。【選択図】図3
Resumen de: EP4579824A1
A fuel cell separator material, with which a fuel cell separator having sufficient electrical conduction properties and also having improved drainage performance at the same time can be manufactured by a simple process, is provided.A fuel cell separator material includes: a composite material containing electrically conductive particles and a binder resin; and soluble resin layers located on both sides of the composite material.
Resumen de: GB2636801A
A bipolar plate for a fuel cell assembly has a bipolar frame configured with two reverse image faces of different function comprising; anode flow channels formed of a first portion AFC fluidly connected to second portion AFC’ regardless of gap G. The anode flow channels are fluidly connected to first anode flow passage 330 and second anode flow passage 335. The gap in each anode flow channel is positioned at least 85% downstream from one of the first and second anode flow passages. A cathode field (14, Figure 5C) has inlet cathode flow channels (iCFC, Figure 5C) open and fluidly connected to first cathode fluid passage (340, Figure 5C) but blocked from second cathode fluid passage (345, Figure 5C) via humps (H, Figure 5C); and outlet cathode flow channels (oCFC, Figure 5C) blocked by humps from the first cathode flow passage but open and fluidly connected to the second cathode flow passage. A first end of the bipolar frame includes at least one air inlet, at least one water inlet, and at least one hydrogen outlet; whilst a second end includes: at least one cathode fluid outlet, and at least one hydrogen inlet.
Resumen de: WO2024044784A1
A fuel cell system includes a plurality of fuel cell plates. A first plate of the fuel cell plates is connected to a plurality of plate supports located on a periphery of the first plate. Each support of the plurality of plate supports is electrically insulating and bounds an opening for receiving an aligning member therein.
Resumen de: GB2636809A
A fuel cell 1 includes an active layer having a membrane electrode assembly (MEA) between a second surface (254, Figure 7) of a first flow assembly (250, Figure 7) and a first surface (252, Figure 7) of a second flow assembly. Fuel and oxidant are supplied via galleries (230, Figure 7) to respective sides of the MEA. The first flow assembly includes a first frame (200A, Figure 6B) with a first fluid flow plate (100, Figures 6A, 6B and 7) configured with fluid flow channels (180, Figure 6B) having inlets (182, Figure 6A) and outlets (185, Figure 6A). The first flow assembly also has a pressure control passage 440 in fluid communication with an outlet and an active reduction zone 442 with flow reduction elements (445, Figure 11C) which are configured to reduce the cross-sectional area in the pressure control passage.
Resumen de: GB2636799A
Cooling a fuel cell utilises a water distribution cover 30 including a plurality of rivulets (800A-N, Fig 8A) which are fluidly connected to a plurality of fluid guides (700, Fig 7A-B) for passing cooling water to a cathode flow field 14. The fluid guides are fixed to a cathode cover 22 which in turn is affixed to a bipolar plate 13. The water distribution cover 30 includes a fluid conduit (802, Fig 8A) in fluid communication with the rivulets, each of which has a head (807, Fig 8B) and tail end (810, Fig 8A), and the rivulets are configured to align the tail ends with a respective fluid guide provided on the cover plate. The rivulets can form cathode inlets which have variable water pathways (e.g. width, depth, amplitude if sinusoidal) which are configured to deliver even quantities of water across the cathode flow field in each fuel cell forming a fuel cell stack.
Resumen de: GB2636807A
An air-shaping insert 700 is configured to mate with a duct 601 in a fuel cell stack 600, and comprises a multi-vane airflow assembly. The assembly comprises a front face acting as an inlet for the airflow and a back face acting as an outlet and supporting a plurality of vanes 703,705,707. The vanes each have a free end extending into the duct and have different lengths extending from the back face, with one or more of the vanes also having a curved body 703D. By shaping the inlet air flow to be distributed to a plurality of fuel cells within the fuel cell stack, power output has been shown to be improved compared with the power output in such a fuel cell stack without the air shaping insert. Mass volume of air from the first fuel cell in the fuel cell stack to the last fuel cell in the stack is evened out using the air shaping insert. At least one of the vanes may be split 703A,703B and joined by a bridging connector 703C, and one or more walls 704,(706, fig 7C),708 may be provided to direct airflow and/or provide anchoring for the vane.
Resumen de: GB2636806A
An end fuel cell assembly 10N has an anode face with a first end (18, Figure 3) having an anode outlet (315, Figure 3) fluidly connected to an anode inlet (325, Figure 3) across an anode face flow field (16, Figure 3). The end fuel cell assembly further includes an end plate 602 facing the anode flow field and a barrier limiting fluid flow to the anode flow field wherein the barrier reduces the volume of fluid in the anode flow field. The barrier may be an inlet barrier (326’, Figures 3 and 11) or an outlet barrier (316’, Figure 10). A further end fuel cell assembly 10A has a cathode face with a first end (18, Figures 5 and 8) having a cathode inlet (300, Figure 5) fluidly connected to a cathode outlet (320, Figure 5) across a cathode face flow field 14. The end fuel cell assembly further includes an end plate 604 facing the cathode flow field and an inlet stop (802, Figure 8) at the cathode inlet configured to limit fluid flow into a first cathode passage (340, Figures 5 and 8) wherein the inlet stop reduces the volume of fluid entering the cathode flow field.
Resumen de: GB2636800A
A high efficiency fuel cell (10, Figure 1) includes a bipolar frame (13, Figure 1) having an anode flow field (16, Figure 1) and a cathode flow field 14 on opposing sides. A first end 18 of the bipolar frame includes a single air inlet 300, a single water inlet 310, and a single hydrogen outlet 315 wherein the air inlet and water inlet are fluidly connected to one of the cathode or anode flow field. A second end 19 of the bipolar frame includes a single cathode fluid outlet 320, and a hydrogen inlet 325. The cathode flow field is fluidly connected to a cathode flow field outlet 345 which is fluidly connected to the cathode fluid outlet. The cathode outlet area is at least 20% larger than the cathode water inlet and air inlet area combined. A fuel cell stack (600, Figure 6) includes a plurality of high efficiency fuel cells; an air inlet manifold (300’, figure 6) and a cathode exhaust manifold (320’, Figure 6) each formed within the fuel cell stack and fluidly connected to the cathode flow field of each fuel cell in the stack.
Resumen de: GB2636803A
A fuel cell system includes means to separate water from the cathode exhaust stream that is integrated into a fuel cell stack for reducing its overall size. Fuel cell assemblies are compressed together to form a fuel cell stack 100, each fuel cell assembly comprising one or more frames supporting an MEA, a hydrogen outlet for collecting excess hydrogen from the anode side of the MEA, and a cathode exhaust outlet for collecting air and water from the cathode side of the MEA (figure 3). By aligning the cathode exhaust outlets of the fuel cell assemblies, a collection cavity 300 fluidly connected to each fuel cell assembly is formed in the fuel cell stack. A water outlet (170, figure 5A) is in fluid communication with the collection cavity, and a water collection ramp 252 fits within the collection cavity. Preferably, one or more water inlets are formed in each frame for supplying water to the cathode side of the MEA to provide cooling. The water collection ramp preferably comprises gutters (405, figures 6A-B) extending from at least one side thereof and may include a spine (410, figure 6B) and sawteeth (430, figure 6B) on opposing edges to encourage water flow.
Resumen de: GB2636804A
A fuel cell system includes means to separate water from the cathode exhaust stream that is integrated into a fuel cell stack for reducing its overall size. Fuel cell assemblies are compressed together to form a fuel cell stack 100, each fuel cell assembly comprising a frame supporting an MEA, a hydrogen outlet for collecting excess hydrogen from the anode side of the MEA, and a cathode exhaust outlet for collecting air and water from the cathode side of the MEA (figure 3). By aligning the cathode exhaust outlets of the fuel cell assemblies, a collection cavity 300 fluidly connected to each fuel cell assembly is formed in the fuel cell stack. A water outlet 170 is in fluid communication with the collection cavity, and a water collection means 250 fits within the collection cavity. Preferably, one or more water inlets are formed in each frame for supplying water to the cathode side of the MEA to provide cooling. The water collection means preferably comprises a body portion (252, figures 7A-B) fitting within the collection cavity. A fan (410, figure 7B) or stator (400, figure 7A) may be provided in a head portion positioned within or outside the collection cavity.
Resumen de: GB2636697A
A flow battery electrolyte storage arrangement 1 comprises a first pile 2 at least partly, but preferably completely, provided within a first bore 11, the first pile defining a first pile volume 3 that is at least partly filled with the electrolyte 4. Preferably, two electrolytes comprising an anolyte and catholyte are provided in first and second piles. The piles may comprise an internal lining and may include a cured material between the pile and its respective bore. Multiple piles for each electrolyte may be provided to increase capacity (figure 5). A flow battery (100, figure 2) comprising such a flow battery electrolyte storage arrangement is also described.
Resumen de: EP4579828A1
A system and method for controlling operation of a fuel cell system for a vehicle are provided. The fuel cell system comprises a fuel cell unit comprising a plurality of fuel cell stacks and an electrical circuit arranged to selectively connect the fuel cells stacks to a load. A control system comprises processing circuitry that is configured to obtain an actual or predicted value of requested power output that is requested from the fuel cell system; monitor a State of Health (SoH) of each of the plurality of fuel cell stacks; when the value of the requested power output is below a first threshold power level and at least two stacks out of the plurality of stacks are currently active, deactivate at least one first stack from the at least two currently active fuel cell stacks in an order of increasing SoH; and, when the value of the requested power output is above a second threshold power level, activate at least one second stack from the plurality of fuel cell stacks in an order of decreasing SoH.
Resumen de: EP4579825A1
Systems and methods for controlling operation of a fuel cell system comprising a fuel cell unit that comprises a fuel cell stack comprising a cathode and an anode, a cathode recirculation passage configured to divert a cathode exhaust flow to a cathode inlet line when reduction in oxygen partial pressure in an air flow fed to the cathode via the cathode inlet line is required, and an inert gas generating system configured to generate an inert gas to be supplied to the cathode inlet line when further reduction in oxygen partial pressure in the air flow is required. When the fuel cell system is or is expected to be operating with a reduced power demand, a value of a power output that is requested from the fuel cell system is compared to at least one threshold power level to determine whether to divert the cathode exhaust flow and/or the inert gas to the cathode inlet line.
Resumen de: CN119744458A
Molten carbonate fuel cell structures are provided that include a structured grid support layer at an interface between a cathode surface and a cathode current collector. The structured mesh layer may have a mesh open area of 25% to 45%. In addition to providing structural support, the structural grid layer may reduce or minimize ohmic resistance at the interface between the cathode and the cathode current collector.
Resumen de: WO2024041702A1
The invention relates to an aircraft fuel cell propulsion unit (10) comprising a fuel cell system (12) that includes at least one anode (14), at least one cathode (15) and a process gas device (17) for supplying fuel and ambient air to the anode (14) and the cathode (15) and evacuating spent process gases, further comprising a ram air duct (21) through which compressed ram air (22) flows, and a heat exchanger (20) which is located in the ram air duct (21) and is designed to give off heat generated by the fuel cell system (12) to the environment.
Resumen de: CN119768940A
The invention relates to a method (100) for protecting a fuel cell system (5), in particular switched off, comprising: determining (S20) state data, the state data describing influencing factors of moisture condensation in the fuel cell system; on the basis of the status data, barrier air is provided (S40 ') in at least a portion of the fuel cell system (5) and/or at least a portion of the fuel cell system (5) is purged (S40) by means of a gas from a pressure vessel of the vehicle.
Resumen de: EP4578725A1
A system and method are provided for controlling operation of a fuel cell system for a vehicle, comprising a fuel cell unit that comprises a fuel cell stack and a coolant system. A control system is configured to preemptively determine that a fuel cell system power ramp-down event will occur when a decrease in power of the fuel cell system would be required as the vehicle is approaching a portion of a route associated with a low power demand from the fuel cell system. The fuel cell system is controlled by reducing a target inlet coolant temperature, and by applying a first response strategy that involves continuously reducing a flow rate of the coolant flow, and/or a second response strategy that may involve continuously and gradually increasing the flow rate of the coolant flow and then, in some situations, continuously and gradually decreasing the flow rate of the coolant flow.
Resumen de: WO2024041918A1
The invention relates to a fuel cell device (10) and to a method for producing such a fuel cell device (10), comprising at least one component (14, 18, 36, 39), in particular a processor unit (14), preferably a heat exchanger (18, 36, 39), which is at least partly made of steel. The steel of the at least one component (14, 18, 36, 39) is intended to be at least partly covered, preferably coated, with a metal material (56) and/or a ceramic material (58).
Resumen de: GB2636681A
An electrolyser system (10) is described. The system (10) comprises at least one electrolyser (20), where the electrolyser (20) comprises at least one steam inlet (41) and at least one off-gas outlet (38; 39). A turbocharger (62) is also present for compressing off-gas from the electrolyser (20). The turbocharger (62) comprises a drive fluid inlet, a drive fluid outlet, a compression fluid inlet, a compressed fluid outlet, a compressor (13) and a turbine (12). The turbine (12) is configured to drive the compressor (13). The drive fluid outlet of the turbocharger (62) is fluidically connected to the at least one steam inlet (41) of the electrolyser (20). The at least one off-gas outlet (38; 39) of the electrolyser (20) is fluidically connected to the compression fluid inlet of the turbocharger (62). The system (10) can further comprise a steam source fluidically connected to the drive fluid inlet of the turbocharger (62) for powering the turbine (12) using pressurised steam.
Resumen de: EP4579826A1
A fuel cell system includes a fuel cell unit (20) having a substantially rectangular parallelepiped shape, the fuel cell unit (20) including:a plurality of power generation modules (30) each including a fuel cell stack that generates power using fuel gas and oxidant gas, and a heat-insulating module case that accommodates the fuel cell stack;a plurality of fuel supply systems including a plurality of fuel supply lines that supply the fuel gas to each of the plurality of power generation modules (30);a plurality of oxidant gas supply systems including a plurality of oxidant gas supply lines that supply the oxidant gas to each of the plurality of power generation modules (30); anda frame (21) to which the plurality of power generation modules (30), the plurality of fuel supply systems, and the plurality of oxidant gas supply systems are fixed.
Resumen de: EP4579978A1
A system and method are disclosed. An illustrative system includes a power demand input to receive information related to a power demand, an output terminal that provides communication capabilities with a fuel cell and an additional energy source, where the output terminal is used to provide a control output to the fuel cell and the additional energy source, and where the control output includes a first composition defining a first power to originate from the fuel cell and a second composition defining a second power to originate from the additional energy source. The system may further include a processing unit that adjusts one or both of the first composition and the second composition to optimize a ratio of the first composition and the second composition.
Resumen de: EP4579977A1
A system and method are disclosed. An illustrative method includes receiving information about a power demand for an output power of a first fuel cell and an output power of an additional energy source, generating control information that optimizes a ratio of the output power of the first fuel cell and the output power of the additional energy source to meet the power demand, and delivering a control output to the first fuel cell and the additional energy source according to the control information that optimizes the ratio of the output power of the first fuel cell and the output power of the additional energy source.
Resumen de: EP4579827A1
A system and method for controlling operation of a fuel cell system comprising a fuel cell unit that comprises a fuel cell stack comprising a cathode and an anode, and a cathode recirculation passage configured to divert a cathode exhaust flow to a cathode inlet line. A control system is configured to, responsive to a value of a power output that is requested from the fuel cell system being below a first threshold power level, control a target coolant inlet temperature of a coolant at a coolant inlet of the fuel cell stack and control an air pressure at the cathode. Responsive to the value of a power output being below at least one second threshold power level, additionally, an oxygen partial pressure in the air flow may be reduced by controlling a volume flow rate of a cathode exhaust flow that is directed to the cathode inlet line.
Resumen de: JP2025098900A
【課題】寸法公差等があっても意図通りの性能を発揮し得る燃料電池システムを提供する。【解決手段】燃料電池セルを積層した燃料電池積層体2と、燃料電池積層体2を収容する筐体3と、筐体3の上部に設けられ、筐体3内における燃料電池積層体2の動きを規制する規制機構6と、を備える燃料電池システム1において、燃料電池積層体2は、底部が固定部材4に固定され、筐体3は、底部に開口部を有する箱形状であり、規制機構6は、燃料電池積層体2の上部に押し当てられるプッシュロッド11と、プッシュロッド11を保持する球面滑り軸受10と、を備え、球面滑り軸受10は、プッシュロッド11が貫通する貫通孔を有し外周の一部に球面部7Aを有する筒体7と、球面部7Aを保持する保持部8、9と、を備え、球面部7Aの少なくとも一部は筐体3に接触している燃料電池システム。【選択図】図2
Resumen de: EP4578950A1
Provided is a new CueO mutant with improved activity compared with wild-type CueO. The protein according to one or more embodiments of the present invention comprises an amino acid sequence 1 or 2 and has laccase activity: 1 an amino acid sequence containing at least a region of positions 29-516 in SEQ ID NO: 14 with mutations (a) and (b): (a) a substitution of D360 with an amino acid other than D; and (b) one or more selected from a substitution of G304 with an amino acid other than G, a substitution of D373 with an amino acid other than D, and a substitution of Q374 with an amino acid other than Q; or 2 an amino acid sequence 90% or more identical to the sequence 1, and having residues corresponding to positions 360, 304, 373, and 374 of SEQ ID NO: 14 identical to those of the sequence 1.
Resumen de: CN120237251A
本发明涉及包含具有新结构的聚合物电解质的高温聚合物电解质膜燃料电池用电解质膜。具体而言,本发明公开了包含具有新结构的聚合物电解质的电解质膜,以及包含该电解质膜的高温聚合物电解质膜燃料电池。
Resumen de: WO2023222981A1
The main subject matter of the invention is a flexible electrical conductor (70) comprising: an assembly (72) comprising a flexible conductive core (74) made of a first metal material and a sheath (79) covering the conductive core (74) and made of a second metal material having an electrical resistivity higher than the electrical resistivity of the first metal material; a first connection strip (78) formed at least in part by the second metal material and connected to a first end (72a) of the assembly (72), wherein, at the first end (72a) of the assembly (72), the sheath (79) and the first connection strip (78) are bonded by TIG welding, and the conductive core (74) and the first connection strip (78) are bonded by fillet-brazing or soldering.
Resumen de: US2025201880A1
To provide a fuel cell system configured to increase efficiency. A fuel cell system, wherein the fuel cell system comprises a fuel cell, a cooling system and a control device; wherein the cooling system comprises a cooling water pump and a reserve tank; wherein, when a temperature of cooling water is equal to or lower than a low-temperature determination threshold value, the control device is configured to perform temperature increase control for increasing the temperature of the cooling water to a target temperature; wherein, after the temperature increase control, the control device is configured to cool the temperature of the cooling water to a normal use temperature lower than the target temperature; and wherein the target temperature is set based on at least one of a pressure resistance of the cooling system or an operating pressure of the reserve tank.
Resumen de: JP2025097563A
【課題】特定電極と導電性部材との間で効率的な電流経路を確保しつつ、特定電極と導電性部材との電気的接続の確保とガス流通性の低下の抑制との両立を図る。【解決手段】電気化学反応単セルは、電解質層と空気極と燃料極と金属支持体とを備える。金属支持体には、特定電極に対向する第1の表面から、第1の表面とは反対側の第2の表面まで貫通する複数の貫通孔が形成されている。少なくとも1つの貫通孔を形成する金属支持体の内周面には、特定電極に電気的に接続されるとともに、内周面における第2の表面側の端部まで延びる導体膜が形成されている。金属支持体の第1の表面のうち、導体膜が形成された少なくとも1つの貫通孔の周囲部分の少なくとも一部は、導体膜を介さずに特定電極に対向しており、導体膜が形成された少なくとも1つの貫通孔の第2の表面側の端部から特定電極まで延びるガス流路が形成されている。【選択図】図6
Resumen de: US2025201881A1
According to one embodiment, a fuel cell system includes: a fuel cell stack; a storage part that stores a water component including circulating water supplied to the fuel cell stack, and generated water generated in and discharged from the fuel cell stack; a gas outlet pipe that sends a gas discharged from the fuel cell stack to the storage part; a pressure acquisition part that acquires a pressure of the gas discharged from the fuel cell stack; a drain pipe connected to the storage part to allow the water component discharged from the storage part to flow therethrough; a drain valve on the drain pipe; and a control device. The control device controls opening and closing of the drain valve based on a pressure of a gas acquired by the pressure acquisition part.
Resumen de: JP2025097632A
【課題】スタックの熱を利用できる電気化学スタック、ホットモジュール及び水素製造装置を提供する。【解決手段】電気化学スタックは、2つの電極を隔離する電解質を含むセルが複数直列に接続される固体酸化物形のスタックと、スタックに配置され電極に電気的に接続される端子と、セルに供給されるガスが流れる管と、を備える。端子はスタックの外に出た部分を有し、端子は管を流れるガスに端子の熱を伝える伝達部を含み、伝達部と管は電気的に絶縁されている。【選択図】図1
Resumen de: JP2025097557A
【課題】基材からのコーティング層の剥離を抑制する。【解決手段】電気化学反応セル用部材は、電気化学反応セルに電気的に接続される。電気化学反応セル用部材は、金属製の基材と、基材の表面の少なくとも一部を覆うコーティング層と、基材とコーティング層との間に位置する酸化被膜とを備えている。酸化被膜は、大きい複数の凸部を有している。複数の凸部は、900℃での3000時間相当の通電処理後において、コーティング層に食い込んでおり、基材の表面よりも高低差が大きい。【選択図】図8
Resumen de: JP2025097628A
【課題】スタックの熱を利用できる電気化学スタック、ホットモジュール及び水素製造装置を提供する。【解決手段】電気化学スタックは、2つの電極を隔離する固体酸化物形の電解質を含むセルが複数直列に接続されるスタックと、スタックに配置され電極に電気的に接続される端子と、スタックに供給されるガスが流れる管と、スタックに設けられた通路と、を備える。通路はセルと管とにつながり、端子は一部が中空であり、管および通路は、端子の中空の部分につながっている。【選択図】図1
Resumen de: CN119678275A
Fibers are disclosed comprising a composition containing a fluorinated polymer comprising a plurality of ion exchange groups, or a precursor thereof, and an aromatic polyamide-imide polymer. These fibers are obtained by electrospinning or strong spinning a composition containing a fluorinated polymer comprising a plurality of ion exchange groups or a precursor thereof and an aromatic polyamide-imide polymer. These fibers may be arranged in webs suitable for making composite membranes. The composite ion exchange membrane is particularly suitable for a proton exchange fuel cell or a filtering device.
Resumen de: CN119325655A
The present invention relates to a fuel cell bipolar plate and a fuel cell bipolar plate coating method, the fuel cell bipolar plate having corrosion resistance and high conductivity, and provides a fuel cell bipolar plate comprising: a metal substrate; and a coating layer formed on the metal substrate and composed of a mixture of a binder resin and a filler, the filler including a sheet-like carbon material and a particulate carbon material, in which the filler is surrounded by the binder resin so that the filler is dispersed inside the coating layer, and the filler is exposed to the outside on a surface of the coating layer.
Resumen de: EP4576278A1
Oxygen electrodes, production methods and reversible, alkaline or anion exchange membrane (AEM) electrochemical devices are provided. The oxygen electrodes are operable in the reversible devices both as cathodes of a fuel cell supporting an oxygen reduction reaction (ORR), and as anodes of an electrolyzer supporting an oxygen evolution reaction (OER). The oxygen electrodes comprise a substrate layer which may be a porous transport layer (PTL), possibly coated and/or hydrophobized, or a membrane; and a blend of catalysts which is deposited on the substrate layer to form a catalyst layer, and includes ORR catalyst (e.g., a platinum group metal), OER catalyst (e.g., nickel-based particles), and possibly binders such as ionomers, PTFE or other polymers that are resistant in alkaline environment, but with the catalyst layer and the substrate layer being devoid of elemental carbon.
Resumen de: CN120237230A
本发明提出了一种带有气体流量分配功能的平行流场,能够有效地提高燃料电池峰功率密度,主要包括流场进气口、平行流场和流场出气口,多根平行流道分别与平行流场的进气口连接,多根平行流道合流后与平行流场出气口连接,流场进气口、出气口以及多根流道的顶部高度相等,平行流场的进气口设有宽度渐变收缩段和或宽度折线收缩段,渐变收缩段和折线收缩段的宽度均沿气体进气口的流动方向逐渐变小。本发明提出的平行流场结构改善了传统平行流场的流体分布不均匀和易发生水淹的问题,提升了平行流场的传质特性,进而提升了燃料电池的峰功率密度。
Resumen de: CN120230996A
本发明公开了一种燃料电池金属极板复合涂层的制备方法,它包括如下步骤:S1.金属基材预处理;S2.金属基材等离子清洗;S3.在真空镀膜设备中采用阴极电弧离子镀,在金属基材表面由内向外依次沉积过渡层、中间层、外层涂层,其中所述过渡层为纯金属涂层,所述中间层为金属氮化物涂层,所述外层涂层为由金属涂层和三元涂层周期性交替沉积的的循环层,其中所述过渡层厚度为10~200nm;所述中间层厚度为100~500nm;所述外层涂层厚度为200~1000nm。
Resumen de: CN120237672A
本发明公开了一种氢储能发电系统及其发电方法。该发电系统包括电能供应单元、电网单元、电解水单元、燃料电池单元和纯水单元;其中,电能供应单元与电解水单元连接,用于将电能供应单元产生的电网无法消纳的电能提供给电解水单元进行电解水制取氢气和氧气;电解水单元与燃料电池连接,用于将电解水单元制取的氢气和氧气提供给燃料电池单元作为反应原料;在电能供应单元不能满足电网单元的需求时,燃料电池单元将其产生的电能供应给电网单元;纯水单元用于回收燃料电池单元产生的水并为电解水单元提供电解液用水。本发明通过综合利用电解水产生的氧气,提高燃料电池单元的阴极反应气的氧含量,从而提高氢储能发电系统效率。
Resumen de: WO2024054505A2
A bipolar flow field plate for an electrochemical fuel cell comprises fuel supply channels formed on the first surface of the bipolar flow field plate, having a constant cross-section along the length of bipolar flow field plate, oxidant supply channels formed on another surface of the bipolar flow field plate, opposite to the first surface, and having a constant cross-section along the length of the bipolar flow field plate and coolant flow channels provided within the bipolar flow field plate, wherein at least two adjacent coolant flow channels in the active area of the bipolar flow field plate communicate to each other through a flow sharing portion. The size of the flow sharing portion can vary according to the coolant flow sharing needs. The projections of the bipolar flow field plate which form the coolant flow channels can be provided with pillars along the flow sharing portions of the plate.
Resumen de: CN120237246A
本发明提出了一种电网扰动下燃料电池电压控制方法及系统,属于燃料电池电压控制技术领域;通过电网扰动检测组件检测到的电网运行状态判断是否存在低压穿越下的电网扰动,当存在扰动时,采用微分跟踪器对现状态下的电压进行跟踪和滤波,并基于扰动观测器对燃料电池的不确定性因素进行观测;随后,将微分跟踪器和扰动观测器所得结果输入非线性误差反馈补偿器,以生成反应气体补偿量,并调整反应气体过量系数和反应气体循环率,使电压恢复稳定,实现电压控制。本发明能够在出现低压穿越的电网扰动下,实现对燃料电池电压的快速、有效控制,从而延长燃料电池的使用寿命并维持燃料电池的工作环境持续保持稳定。
Resumen de: WO2024121055A1
In order to create a method for assembling a stack of electrochemical units of an electrochemical device, wherein the electrochemical units follow each other along a stacking direction and wherein each of the electrochemical units comprises a bipolar plate and a sealing arrangement, in which method leaks in the seal between the sealing arrangements and the adjacent bipolar plates are reliably avoided, it is proposed that the method comprises the following: a) providing bipolar plates which each have a primary side and a secondary side; b) providing sealing arrangements which each have a primary side and a secondary side; c) bringing the primary side of a sealing arrangement and the primary side of a first adjacent bipolar plate into contact, wherein the primary side of the sealing arrangement and the primary side of the bipolar plate are positioned relative to each other while maintaining a first offset tolerance; d) bringing the secondary side of the sealing arrangement and the secondary side of a second adjacent bipolar plate into contact, wherein the secondary side of the sealing arrangement and the secondary side of the bipolar plate are positioned relative to each other while maintaining a second offset tolerance; - repeating steps c) and d) until all of the sealing arrangements have been brought into contact with the bipolar plates to be contacted in each case; wherein the first offset tolerance is lower than the second offset tolerance.
Resumen de: CN120237222A
本发明涉及新能源材料技术领域,具体来说是PtCoRu/碳纳米管电催化剂及其制备方法和应用。本发明将制备ZIF‑67后产生的钴废液、铂源和三氯化钌共同浸渍在商业碳纳米管上,在惰性气氛下热处理获得PtCoRu/碳纳米管电催化剂,PtCoRu/碳纳米管电催化剂为氮掺杂的PtCoRu/CNT复合材料,实现了甲醇和乙醇在酸性介质中的高效电催化氧化。本发明以制备ZIF‑67后产生的钴废液为制备多元贵金属催化剂的原料,在避免处理钴废液产生的经济成本同时,避免了合成的多元贵金属基复合材料活性不足问题,同时解决了有机溶液使用和后续处理成本问题。
Resumen de: CN120237236A
本发明提供一种燃料电池混合供电系统及其区间效率调控方法,该系统采用两段恒定进料的调控方式,设置了两个储能设备储存氨能与氢能,并设定了区间效率调控策略,根据调控策略兼顾了蓄电池的SOC健康度。相较于传统的实时在线进料调控以及限制阀门开度以减少燃料消耗的控制方式以及调控策略,该控制方式能够有效地减少外部扰动对进料量产生实时波动从而对催化裂解器的影响以及多个阀门实时调控对燃烧器和发电装置的影响,提升发电系统的鲁棒性;同时所提出的调控策略在“V”型输出特性的混合系统中能够有效地提升整体系统的发电效率,降低了动力电池的容量以及充放电峰值功率,减少了氨的需求量以及经济成本。
Resumen de: CN120237229A
本发明公开了一种适用于质子交换膜制备的全氟磺酸树脂分散液及其制备方法,属于全氟磺酸树脂分散液技术领域,用于解决现有技术中制备的全氟磺酸离子交换树脂的热稳定性差的技术问题。一种适用于质子交换膜制备的全氟磺酸树脂分散液的制备方法,包括以下步骤:S1、去离子水、CF2=CFO(CF2)3COOCH3、CF2=CFOCF2CF2CF3和耐高温涂料加入到聚合反应釜中、混匀,得到预聚体;反应体系在高温高压反应,得到全氟磺酸树脂乳液;全氟磺酸树脂乳液经后工艺处理,制备得到全氟磺酸树脂聚合物。由本发明中的全氟磺酸树脂分散液制备的全氟磺酸树脂薄膜在具备优良的吸水率时,仍然兼具优良的机械性能和热稳定性。
Resumen de: CN120237242A
本发明涉及一种燃料电池系统停机吹扫方法及其最优策略确定方法,所述停机吹扫方法具体如下:当燃料电池系统正常运行结束时,准备执行吹扫过程,通过燃料电池DC/DC变换器使工作电流降低到I吹扫,此时通过单片电压巡检器CVM监测当前的单片电压,并记录为V0;计算吹扫完成时,对应的吹扫阶段的单片电压降低量ΔV;根据吹扫阶段的单片电压降低量ΔV,计算吹扫完成时的单片电压V1;当电压巡检器CVM监测到当前的单片电压为V1时停止吹扫,然后完成关机过程。无需使用复杂的设备检测电堆内阻值,仅利用单片电压巡检器监测单片电压,则可准确判断吹扫是否完成,本发明采用的燃料电池系统停机吹扫方法简单易行,有效降低使用成本,同时保证了吹扫的完成度。
Resumen de: CN120237241A
本申请涉及用于操作燃料电池系统的系统和方法,尤其是用于控制燃料电池系统的操作的系统和方法,该燃料电池系统包括燃料电池单元,该燃料电池单元包括燃料电池堆,该燃料电池堆包括:阴极和阳极;阴极再循环通道,该阴极再循环通道被配置为当需要降低经由阴极入口管线馈送到阴极的空气流中的氧分压时将阴极排气流转移到阴极入口管线;以及惰性气体生成系统,该惰性气体生成系统被配置为当需要进一步降低空气流中的氧分压时生成要供应给阴极入口管线的惰性气体。当燃料电池系统正在或预计以降低的功率需求操作时,将从燃料电池系统请求的功率输出的值与至少一个阈值功率电平进行比较以确定是否将阴极排气流和/或惰性气体转移到阴极入口管线。
Resumen de: CN120237924A
提出了一种用于DCDC转换器的控制装置,所述DCDC转换器包括针对降压模式的上桥开关、针对降压模式的下桥开关以及电感,所述控制装置被配置为:在第一时段内使针对降压模式的所述上桥开关导通并且使针对降压模式的所述下桥开关断开;并且在第二时段内使针对降压模式的所述上桥开关断开并且使针对降压模式的所述下桥开关导通,使得在所述第二时段内通过所述电感的电流从正电流变为负电流。通过使电感电流变为负值而消除了将电感电流断开的0电流时段,从而避免了DCDC转换器在断续电流模式中操作。
Resumen de: CN120237232A
本发明公开了一种固定式燃料电池发电装置的热能管理系统,包括:燃料电池、冷却液循环泵、风冷散热器,其特征是:还包括冷却液三通阀、液/液换热器、热水循环泵、生活热水装置;当生活热水装置需要热量时,通过切换冷却液三通阀的流向,使燃料电池的冷却液流过液/液换热器,将热量传入生活热水装置;当生活热水装置不再需要热量时,通过切换冷却液三通阀的流向,使燃料电池的冷却液流过风冷散热器,将热量直接排放到空气中;本发明的有益效果是:可以充分利用燃料电池发电时的伴热为生活热水装置提供所需热量。
Resumen de: CN120237234A
本发明公开了一种固体氧化物燃料电池及电解池可逆运行系统,其特征是:包括固体氧化物电堆、电堆加热器、氧气极风机、氧气极换热器、氧气极电加热器、氢气极水泵、氢气极换热器、氢气极电加热器、气液分离器、冷凝水电控阀、氢气压缩机、氢气循环泵、阳极废气电控阀、氢气瓶、氢气电控阀、流量控制器;本发明的有益效果是,既可以工作在电解水制氢模式,固体氧化物电堆作为电解池使用,利用废弃的光电风电,进行电解水制氢并储存;也可以工作在发电模式,固体氧化物电堆作为燃料电池使用,利用之前电解水制氢并已经储存的氢气,进行燃料电池发电后输入电网。
Resumen de: CN120237237A
本发明提供了一种固体氧化物燃料电池发电装置的温控系统,包括固体氧化物电堆、热盒、预热器、换热器、风机、助燃空气流量计、助燃空气电控阀、阴极空气流量计、阴极空气电控阀;本发明的有益效果是,在冷启动阶段,通过预热器向热盒内输入高温的燃烧尾气,燃烧尾气环绕在固体氧化物电堆四周使其升温,并可控制电堆的升温速率;在发电阶段,如果电堆温度低于设定值,则可以再次开启预热器,向热盒内输入高温的燃烧尾气,使电堆温度上升至设定工作温度;如果电堆温度高于设定值,则可以停止向预热器内输入燃料,仅通过预热器向热盒内输入室温空气,使电堆温度下降至设定工作温度,从而使电堆始终处于最佳工作温度。
Resumen de: WO2024059106A1
A fuel cell stack comprising a compression plate assembly comprising a second end plate having a first planar surface and an opposing second planar surface, wherein the first planar surface is adjacent a fuel cell stack and the second planar surface is adjacent a compression housing, wherein the compression housing comprises: a spring recess and a plurality of discrete grooves on its inner axial surface of the spring recess; a spring assembly in the spring recess; a load disc in the spring recess and in contact with the spring assembly; and a resilient retaining apparatus in the spring recess and in contact with the load disc; wherein the resilient retaining apparatus engages with one of the plurality of discrete grooves and the load disc and the spring assembly are physically separated from the inner axial surface of the spring recess.
Resumen de: CN120237255A
本发明涉及一种基于氨燃料的固体氧化物燃料电池联产系统,包括固体氧化物燃料电池、后燃室、燃气轮机和余热锅炉,固体氧化物燃料电池的阳极入口连接有氨燃料进管,固体氧化物燃料电池的阴极入口连接有空气进管,所述氨燃料进管上设有燃料压缩机和燃料预热器,所述空气进管上设有空气压缩机和空气预热器;所述固体氧化物燃料电池的阴极出口、阳极出口均连接至后燃室的入口,所述后燃室的烟气出口连接至燃气轮机,所述燃气轮机的排气口依次连接燃料预热器、空气预热器和余热锅炉。本发明固体氧化物燃料电池以氨燃料为核心,燃料储运便捷,运行灵活性强,实现多能联产价值,具备低成本、低污染、高性能的特点。
Resumen de: CN120232965A
本发明公开了一种双信号检测甘蔗梢腐病自供能生物传感器,包括:所述自供能生物传感器包括阳极、阴极和电解液,所述阳极为CuCo‑MOF/AuNPs/GOD生物阳极,所述阴极为CuCo‑MOF/AuNPs/DNA链生物传感器,所述电解液包括葡萄糖、MB、PBS缓冲溶液。本发明的自供能生物传感器,通过电化学与比色检测两种互不干扰的模式进行分析,可有效验证检测结果是否为假阳性信号。无需外接电源,可实现实时户外检测。其材料来源广泛,组装过程简单,可实现准确快捷的检测。具有灵敏度高、选择性好以及可实时检测的优点,可用于甘蔗梢腐病的准确检测。
Resumen de: CN120237233A
本发明公开了一种电堆温度的控制方法和装置、存储介质及电子设备。其中,该方法包括:获取冷却液的冷却液温度、冷却水泵的冷却水泵转速和节温器的节温器开度;利用在线辨识算法基于冷却液温度、冷却水泵转速和节温器开度,确定目标关系;基于目标关系,根根据电堆温度目标值和当前实时获取的冷却液温度和冷却水泵转速确定节温器的目标节温器开度;基于目标节温器开度对节温器进行控制,以控制冷却液流量的比值,进而控制电堆入口冷却液温度从而使电堆温度保持在电堆温度目标值。本发明解决了电堆温度稳定性较差的技术问题。
Resumen de: CN120231653A
本发明涉及一种基于低温氨重整的固体氧化物燃料电池‑燃气涡轮‑有机朗肯循环混合发电系统。该系统包括液氨罐、平板式换热器、缓冲罐、三通阀、燃料压缩机、氨重整器、换热器、净化器、固体氧化物燃料电池、空气压缩机、混合室、电力电子转换器、燃气涡轮、燃烧室、发电机、水泵、工质泵、水箱、工质储存罐、冷却器、工质蒸发器、膨胀机。本发明以液氨为原料实现现场低温氨重整制氢,有效克服储氢、运氢技术难题,避免氨燃料直接用于燃料电池产生氮氧化物的可能。本发明将系统热量进行充分回收利用,有效减少燃料用量和氮氧化物的排放,提高系统经济性和环保性。
Resumen de: CN120237256A
本发明公开了一种燃料电池电堆堆叠壳体定位装置,包括底座(1),底座(1)底部的两侧均设有侧架(2),底座(1)上放置有电芯(6),两侧的侧架(2)之间设有固定靠板(3),固定靠板(3)位于侧架(2)的后方,用于顶住电芯(6),同时在侧架(2)上设有夹紧机构(4),夹紧机构(4)对称设置在两边的侧架(2)上,从两侧对电芯(6)进行夹紧固定,放置底座(1)上设有用于抬升电芯(6)的举升机构(5);利用专用工装对壳体进行举升和夹紧定位,配合堆芯举升机构(5),实现电堆堆芯堆叠过程堆芯与壳体存在一定的间隙,避免堆叠过中堆芯与壳体刮蹭、磕碰等导致的堆芯歪斜和密封不良等问题。
Resumen de: CN120237252A
本发明公开了一种聚苯并咪唑改性离子交换膜及其制备和应用。聚苯并咪唑改性离子交换膜,包括含聚苯并咪唑的多孔隙基膜,所述多孔隙基膜的表面接枝有磺酸改性层,磺酸改性层外表面涂覆有氟化铝层。该膜的制备方法为:将聚苯并咪唑基膜浸入乙酸铵水溶液中反应,反应后取出基膜烘干得预处理基膜;将预处理基膜浸入磺酸基团接枝溶液中,加热反应,反应后清洗基膜并烘干得到磺酸改性基膜;将磺酸改性基膜浸入氟化铝的乙醇溶液中反应,反应后取出膜,清洗烘干后即得。该膜可用于液流电池的组装。本发明克服了磺酸改性层与金属氟化物不兼容的问题,筛选适当的磺化剂和金属氟化物组合,成功获得了一种可用于液流电池的高性能离子交换膜。
Resumen de: CN120237227A
本发明属于一种内增湿燃料电池,特别涉及一种多孔金属双极板燃料电池的流场结构,包括其原理、材料、流场形式及整堆结构。通过辅助系统对多孔金属双极板两侧的反应气和循环水之间分别进行压力和流速的控制,使循环水在多孔金属双极板的微孔形成双向动态渗透,以实现气体增湿和排出多余生成水的动态平衡,实现电池内部的增湿与排水双重功效,省去增湿装置,所述三种流场形式,适用于不同的场景,有效延长电池使用寿命,而且减小系统能耗,此外,多孔金属板的物理性能优于多孔石墨板,在氢气、氧气作为反应气时,燃料电池能实现全封闭运行,可以应用于深海的潜水、高空的低温、太空的宇航以、剧烈冲击及高频振动等极端环境中提供电力。
Resumen de: CN120237228A
本发明属于一种内增湿燃料电池,特别涉及一种多孔金属双极板燃料电池。通过供气、循环水等辅助系统对多孔金属双极板两侧的反应气和循环水之间分别进行压力和流速的控制,使循环水在多孔金属双极板的微孔形成双向渗透,以实现气体增湿和排出多余生成水的动态平衡,本发明采用的多孔金属双极板实现电池内部的增湿与排水双重功效,省去增湿装置,不仅增湿均匀,排水及时,功率输出的动态响应快,有效延长电池使用寿命,而且减小系统体积和系统能耗,此外,多孔金属板的物理性能优于多孔石墨板,在氢气、氧气作为反应气时,燃料电池能实现全封闭运行,可以应用于深海的潜水、高空低温的飞行、太空的宇航以及剧烈振动等极端环境中提供电力。
Resumen de: CN120237250A
本发明提供了一种固体氧化物燃料电池发电装置的防爆结构,其特征是:包括机柜、机柜盖板、通风窗、顶盖、尾气排放管、温区分隔板、接口组件、常温组件区、高温组件区、助燃空气进气管;本发明的有益效果是,将固体氧化物电堆、重整制氢器等,有氢气泄漏隐患的高温组件区,设置在机柜上部;而将风机、电控板等,有产生电火花隐患的常温组件区设置在机柜下部;当高温组件区有氢气泄露时,由于氢气比重最轻,会快速向机柜顶部逸散,而不会向机柜下部逸散;这样就避免了氢气等可燃气体逸散到常温组件区,也就从根本上消除了因电控元器件产生火花而导致氢气燃爆的可能。
Resumen de: CN120237243A
本发明涉及化学电池技术领域,具体而言,涉及一种钒液电堆储能系统控制方法及系统、设备、介质,主要包括获取若干目标数据及目标数据对应的判断阈值,根据目标数据及目标数据的判断阈值得到当前目标数据的异常率;建立异常率评价模型并设置评价值阈值,通过异常率评价模型得到评价值,通过评价值与评价值阈值对比,通过上述方法,对异常数据进行了进一步的分析,基于异常的目标数据的分析结果,进行进一步的告警,并且根据分析的结果,去控制所需要的监控时长,一方面可以安装转动式的监控,可以不用使用专门的监控设备来监控电堆,节约成本,另一方面,也对转动式的监控设备给出了对电堆监控时长的合理控制,避免其余地方未得到监控。
Resumen de: CN120229755A
本发明属于全钒液流电池技术领域,涉及一种钒电解液及固体硫酸氧钒的制备方法,钒电解液制备方法包括:基于钒钼酸盐溶液和反萃试剂中pH值调节,实现萃取有机相对钒钼酸盐溶液中钒、钼元素共萃及钼、钒元素顺次反萃和回收,钒、钼元素萃取用萃取有机相的组成相同;将回收后的钒产物提纯后制备钒电解液。本发明解决了现有技术中难以实现各种钒钼元素同步回收、钒元素回收利用困难、钒回收率低、回收产品纯度低、环境污染大、对钒原材料纯度要求高、钒原材料提纯制备工艺步骤复杂及难以从钒钼同源物料分离钒的问题,克服了现有技术对钒钼酸盐溶液各元素分离效果差导致的收率低、产品纯度低的缺陷。
Resumen de: CN120230320A
本申请公开了一种用于制备质子传导膜的方法和质子传导膜。本申请的方法包括:提供包含聚偏氟乙烯、水溶性成核剂、聚乙烯吡咯烷酮的铸膜液;使铸膜液在支撑体表面流涎形成铸膜液薄层;加热铸膜液薄层,以使晶核生长并去除其中的有机溶剂,制得薄膜;将薄膜置于去离子水中,以去除水溶性成核剂,制得多孔膜;将多孔膜置于引发体系中,以使多孔膜中包含的聚乙烯吡咯烷酮发生交联反应,制得质子传导膜。本申请实施例的方法利用聚偏氟乙烯、水溶性成核剂、聚乙烯吡咯烷酮制备质子传导膜,提高了质子传导膜的物理和化学稳定性、选择性和电导率。
Resumen de: CN120237247A
本申请提供了一种燃料电池系统的冷却控制方法和燃料电池系统,该方法利用控制器,基于电堆的进口的冷却液温度的目标值、电堆的出口的冷却液温度的测量值以及散热器出口的冷却液温度的测量值确定三通阀的各个时刻的第一开度;在系统的当前运行状态满足三通阀反馈调节的允许条件时,基于电堆的进口的冷却液温度的目标值和测量值的差值的比例项和相对于时刻的积分项来确定三通阀的各个时刻的第二开度;根据当前时刻的三通阀的第一开度和第二开度的和对差值的相对于时刻的积分项的上一时刻的积分累计值进行维持或抑制的处理,再据此确定当前时刻的三通阀的处理后的第二开度并确定三通阀的当前时刻的目标开度以实现电堆进口冷却液温度的快速调节。
Resumen de: CN120237248A
本申请提供了一种燃料电池系统的温度控制方法和燃料电池系统。温度控制方法包括利用处理器执行如下处理:根据电堆的冷却液出口温度目标值及其第一关联参数,确定电堆冷却液出口温度修正值,并使用电堆传热模型和泵模型,确定泵的转速的目标值;根据电堆冷却液进口温度目标值及其第二关联参数,确定电堆冷却液进口温度修正值,并使用三通阀传热模型和三通阀流量模型,确定三通阀开度的目标值;根据散热器出口冷却液温度目标值及其第三关联参数,确定散热器出口冷却液温度修正值,并使用散热器传热模型和风扇流量模型,计算风扇转速的目标值;根据各个目标值来调节泵的转速、三通阀开度以及风扇转速,以实现燃料电池系统工作温度的同步调节。
Resumen de: CN120237254A
本发明涉及液流电池领域,公开了一种液流电池系统结构,包括:第一储罐的第一端通过正极电解液输出管路与电堆正极输入端连接,其第二端通过正极电解液回流管路与电堆正极输出端连接;第二储罐的第一端通过负极电解液输出管路与电堆负极输入端连接,其第二端通过负极电解液回流管路与电堆负极输出端连接;多腔体OCV电池模块的第一端、第二端分别与正极电解液输出管路、正极电解液回流管路对应连接,其第三端、第四端分别与负极电解液输出管路、负极电解液回流管路对应连接;多腔体OCV电池模块将第一储罐泵出的正极电解液液流、第二储罐泵出的负极电解液液流降压后输送至其内部的多腔体OCV电池,从而实现降低循环泵的功耗,提高电池系统整体效率。
Resumen de: CN120237244A
本申请涉及一种燃料电池温度控制方法、装置、电子设备及车辆,涉及电池技术领域,该方法包括:获取燃料电池的运行参数;基于燃料电池的运行参数,确定燃料电池的流阻系数、燃料电池的入口温度控制误差和散热器出口温度;基于燃料电池的流阻系数、燃料电池的入口温度控制误差和散热器出口温度,确定三通阀的目标开度。由此,考虑到了在燃料电池的使用过程中流阻系数对燃料电池温度的影响,基于燃料电池的流阻系数、燃料电池的入口温度控制误差和散热器出口温度多个因素,确定三通阀的目标开度,提升了燃料电池温度控制的准确性。
Resumen de: CN120237225A
本发明属于固体氧化物电池技术领域,涉及一种质子传导型可逆固体氧化物电池用氧电极材料,为钙钛矿型氧化物,化学式为PrzBa1‑0.5zSr1‑0.5zCouFe2‑u‑x‑yMxYyO5+δ;式中,M为Nb、Ta、Zr、Hf、Mo、W中的任意一种,0.05≤x≤0.2,0.05≤y≤0.15,0.98≤z≤1.02,1.48≤u≤1.52,δ表示非化学计量氧空位。本发明通过M和Y以特定比例共掺杂制得的氧电极材料具有较低的热膨胀系数,与电解质BCZYYb匹配性佳;其用在质子传导型固体氧化物燃料电池中和质子传导型固体氧化物电解池中,均具有良好的电化学性能;且该氧电极材料具有优异的长期工作稳定性。
Resumen de: CN120237231A
本发明公开了一种自带便捷安装组件的氢燃料电池双极板及安装方法,应用在氢燃料电池双极板技术领域,其技术方案要点是:包括阳极板、阴极板以及膜电极;所述阳极板以及所述阴极板均包括基体以及外扩倾斜对称固定连接于所述基体两侧的倾斜导向块,所述倾斜导向块上固定连接有与所述基体平行设置的定位固定块,所述定位固定块上设有定位互锁结构,所述膜电极包括基膜部以及凸出对称固定连接于所述基膜部两侧,且多边形构造的自拉伸块,所述基体上开设有与所述自拉伸块配合的自拉伸槽;具有的技术效果是:结构简单,安装便捷。
Resumen de: SE2351527A1
A system and method are provided for controlling operation of a fuel cell system for a vehicle, comprising a fuel cell unit that comprises a fuel cell stack and a coolant system. A control system is configured to preemptively determine that a fuel cell system power ramp-down event will occur when a decrease in power of the fuel cell system would be required as the vehicle is approaching a portion of a route associated with a low power demand from the fuel cell system. The fuel cell system is controlled by reducing a target inlet coolant temperature, and by applying a first response strategy that involves continuously reducing a flow rate of the coolant flow, and/or a second response strategy that may involve continuously and gradually increasing the flow rate of the coolant flow and then, in some situations, continuously and gradually decreasing the flow rate of the coolant flow.
Resumen de: CN120237245A
本申请涉及用于操作燃料电池系统的系统和方法,尤其是一种用于控制燃料电池系统的操作的系统和方法,所述燃料电池系统包括:燃料电池单元,所述燃料电池单元包括燃料电池堆,所述燃料电池堆包括阴极和阳极;以及阴极再循环通道,所述阴极再循环通道被配置成将阴极废气流转向到阴极入口管线。控制系统被配置成响应于从所述燃料电池系统请求的功率输出的值低于第一阈值功率水平,控制所述燃料电池堆的冷却剂入口处的冷却剂的目标冷却剂入口温度并控制所述阴极处的空气压力。响应于功率输出的所述值低于至少一个第二阈值功率水平,另外,可通过控制被引导到所述阴极入口管线的阴极废气流的体积流速来降低空气流中的氧分压。
Resumen de: CN120237235A
本发明提供了一种耦合固体氧化物燃料电池的液态有机储氢脱氢系统、方法及应用。本发明的系统包括:储氢单元,其用于存储液态有机富氢材料;脱氢单元,其用于使所述液态有机富氢材料进行脱氢反应,得到氢气和有机储氢材料;燃烧单元,其包括固体氧化物燃料电池,所述固体氧化物燃料电池以所述脱氢单元产生的氢气为燃料进行燃烧并产生燃烧尾气;热量分配单元,其包括多个热量分配装置,其中至少1个热量分配装置用于将脱氢得到的有机储氢材料冷却后产生的热量和所述燃烧尾气的热量汇集并传输至所述脱氢单元和固体氧化物燃料电池。
Resumen de: WO2024179633A1
The invention relates to a separator plate (28), comprising a half-plate (3, 4) with an active field (2), a frame arrangement (11) surrounding the active field (2), and a sealing arrangement (15, 15') which is assigned to the frame arrangement (11) and which comprises a seal (16, 16') which extends in a wave shape in a top view of a plane spanned by the separator plate (28). A three-dimensional support structure (29) is formed in the half-plate (3, 4) in the region of the sealing arrangement (15, 15'), wherein the support structure (29) is formed projecting out of the plane spanned by the separator plate (28). The invention also relates to a bipolar plate (1, 1 '), to a method for producing sealing arrangements (15, 15') on a separator plate (28) or on a bipolar plate (1, 1 '), and to an electrochemical cell (40).
Resumen de: WO2024106305A1
This gasket device (30) comprises a first gasket (40) formed of an elastomer and a separator (32) having one pair of faces (32a, 32b) arranged back to back. The first gasket (40) has an annular shape and is attached to the face (32a) of the separator (32) so as to surround an opening (40a). The first gasket (40) has a lip (45) that protrudes in the direction facing the face (32a) of the separator (32) and extends annularly. The height of the lip (45) on the opening (40a) side is different from that on the side opposite to the opening (40a) side.
Resumen de: CN120229151A
本发明公开了一种电动汽车的燃料电池增程器热管理系统,包括,包含高温冷却液回路、低温冷却液回路和控制器。高温冷却液回路由高温散热器、用于与高温质子交换膜燃料电池及金属氢化物储氢罐换热的换热结构、耦合换热器相连,设置四通阀和多个三通阀构成循环回路,控制高温质子交换膜燃料电池及金属氢化物储氢罐的热耦合。低温冷却液回路设置低温散热器、动力电池换热结构构成循环通过耦合换热器与高温冷却液回路热耦合。控制器控制各组件工作状态,高温质子交换膜燃料电池工作温度不低于金属氢化物储氢罐的脱附温度。本发明还公开了相应的燃料电池增程器热管理方法。本发明提高了具有燃料电池增程器的车辆余热利用效率。
Resumen de: CN120237239A
本发明公开了一种防止燃料电池冷启动结冰的优化方法,涉及燃料电池技术领域,所述优化方法包括以下步骤:S1、采集环境温度和电堆内部结冰状况数据,分析产水速率和温升融冰能力;S2、构建能够反映环境温度、电堆内部结冰状况与理想电流密度之间关系的预测模型;S3、将环境温度和电堆内部结冰状况,输入预测模型,进行燃料电池参数的调节;通过模型预测的电流密度曲线间接控制空气温度,将电堆产水‑融冰平衡转化为流量分配优化问题,并结合电压波动前馈补偿,实现了温度与电化学状态的协同控制,不仅优化了燃料电池在冷启动过程中的性能表现,还增强了系统的稳定性和输出效率,为燃料电池在低温环境下的应用提供了有力的技术支持。
Resumen de: CN120237238A
本公开提供一种电堆低温启动的方法及电堆系统,包括:实时检测电堆内部温度和电压;响应于所述电堆温度低于第一预设温度,向所述电堆的阳极和阴极通入氢气,同时开启吹扫单元,使氢气与所述电堆中的空气反应;响应于所述电堆温度达到第二预设温度时,停止对所述电堆的阴极供氢;在所述停止对所述电堆的阴极供氢之前,运行第一预设放电步骤,将所述电堆的电流密度加载至第一电流密度;响应于所述电堆温度达到第三预设温度,运行第二预设放电步骤,将所述电堆的电流密度加载至第二电流密度;响应于电堆温度达到第四预设温度,回收所述电堆排气的热量为电堆进行加热。
Resumen de: CN120237253A
本申请公开钒液电池技术领域的一种钒液电池的制作方法,包括如下步骤:S1、在正极电解液中添加磷酸(H3PO4)与柠檬酸(摩尔比1:2~4),负极电解液采用紫外光(强度50~60mW/cm2)照射负极电解液60~80min;S2、电极为梯度电极,表层:Bi@MnO2异质结催化剂层,厚度50±5nm;中层:垂直排列石墨烯阵列,层间距2~5nm;底层:石墨烯气凝胶导流层,孔隙率90%、孔径10~50μm;所述电极经氩气等离子处理10~20分钟,并同步施加脉冲电化学氧化;S3:双极板的流道为三级分形树状结构,满足:主通道宽度2~3mm,分支比例系数0.7~0.8,分支角度45~50°,流道表面涂覆SiO2/PTFE超疏水涂层。通过磷酸‑柠檬酸协同络合与光化学还原的耦合,实现电解液长效稳定与高纯度调控。
Resumen de: CN223049103U
本实用新型涉及一种燃料电池用集成式多引射器组件,它包括氢关断阀、氢比例阀、引射器体、引射器出口与压力泄放阀;在引射器体上开设有进口流道、连接流道、喷射流道、氢比例阀安装孔与回流口;在引射器体上固定有氢关断阀,喷射流道的数量为至少两个,在对应每个喷射流道的进气口位置的引射器体上均开设有一个氢比例阀安装孔,在每个氢比例阀安装孔上均安装有一个氢比例阀,氢比例阀具有喷嘴,所有氢比例阀的喷嘴孔径均各不相等。使用本实用新型可以在增大引射器引射能力范围的同时集成供氢回路中的氢气关断控制功能和入堆压力超压泄放功能,提升功能集成度;本实用新型能有效节省电堆空间、减轻电堆重量。
Resumen de: CN223052161U
本实用新型公开了一种膜电极热压的模具,涉及膜电极生产技术领域,包括热压模具底板,所述热压模具底板的一侧开设有限制凹槽,所述限制凹槽的内部固定连接有凹槽凸起,所述限制凹槽的内部安装有硅胶垫,所述热压模具底板对角的两个角部均开设有连接孔,本实用新型通过凹槽凸起的设置,将封边完成的五合一使用定位杆安放在热压模具底板上,凹槽凸起刚好为三合一衔接处,略微的凸起可增加其与热压机接触的压力,使封口处的热熔胶更加贴合,可以有效的防止空气进入,并且挤压通过加热所产生的气泡,预防气泡的产生。
Resumen de: CN223048903U
本实用新型涉及一种氢喷射器线圈部件防护结构,安装固定板固定在氢喷射器主体的外部,在氢喷射器主体的外部套装有线圈骨架,在线圈骨架上安装有漆包线绕组,在线圈骨架的外部套装有导磁壳体,在导磁壳体的外部套装有线圈包塑;在氢喷射器主体的上端部固定有锁紧螺帽,在锁紧螺帽与线圈包塑之间安装有第一O形密封圈,第一O形密封圈与锁紧螺帽的下端面以及线圈包塑的上端面接触;在安装固定板、氢喷射器主体与线圈包塑之间安装有第二O形密封圈,第二O形密封圈与安装固定板的上表面、氢喷射器主体的外圆以及线圈包塑的下端部内圆接触。本实用新型可以提高氢喷射器线圈部件的防护性能、保证氢喷射器在各种高温、高湿以及温度交变等各种恶劣工况中工作的可靠性。
Resumen de: CN120237249A
本发明提供了一种氢燃料电池的氢气供给控制系统、方法、电池及交通工具,该控制系统包括:反步法控制器;该反步法控制器与氢气循环泵连接,以氢气在氢气供应管道的压差为输入及以电堆的阳极通道氢气分压作为反馈输入来实现对氢气过量比进行反步法控制,氢气供应管道的压差通过氢气过量比获得。利用上述技术方案,可实现对氢气过量比的高精度跟踪控制,从而提升了氢气过量比在动态工况下的控制精度和响应速度。
Resumen de: CN223052164U
本实用新型公开了一种氢燃料电池电堆堆芯堆叠限位装置,包括封装本体,封装本体顶端可拆卸连接有第一固定架和第二固定架,第一固定架和第二固定架两端接触构成限位框架,限位框架中部设有堆叠空间,堆芯顶部位于堆叠空间内,采用本实用新型的氢燃料电池电堆堆芯堆叠限位装置,避免堆芯倾覆,降低安全风险。
Resumen de: CN223051477U
本实用新型提供了一种燃料电池系统气体分配模块测试装置,涉及燃料电池技术领域,包括:气体分配模块的上出气口依次连接第二流量计、第一背压阀和尾排装置;下出气口依次连接第三流量计、第二背压阀和尾排装置;气体分配模块的进气口、中冷器、空压机和空气过滤器依次连接;空压机和空气过滤器之间设置有第一流量计;中冷器分别与辅助散热器、辅助水泵连接;空压机分别与辅助散热器、辅助水泵连接;辅助散热器与辅助水泵相连接,辅助散热器与辅助水泵之间连接辅助水箱。通过该装置能够前期校核气体分配模块设计是否合理且满足设计需求,不需要连接燃料电池堆进行测试,进而降低测试成本。
Resumen de: CN223052162U
本实用新型提供了一种阳极气体扩散层结构及抗反极膜电极,本实用新型在阳极基底层的一侧设置阳极微孔层,另一侧设置阳极抗反极层。抗反极更直接接触加湿气体,提升了膜电极的抗反极能力,延迟了碳腐蚀的发生时间;抗反极涂层与催化剂无直接接触,避免了其对燃料电池性能的屏蔽效应,提升电池性能;抗反极涂层单独制备,更方便实现GDL的反极性能平面梯度化设计,在阳极出口区域、靠近流场边缘区域喷涂更多抗反极催化剂,有效节约成本。
Resumen de: CN223052163U
本实用新型涉及燃料电池领域,具体来说是一种双堆燃料电池空气系统,包括第一电堆、第二电堆、进气系统以及排气系统;所述进气系统包括主进气管道,所述主进气管道分别通过一个分支进气管道与第一电堆和第二电堆相连接;所述排气系统包括主出气管道,所述第一电堆和第二电堆分别通过一个分支出气管道与主出气管道相连接;与第一电堆相连接的分支出气管道上设有第二节气门阀;与第二电堆相连接的分支出气管道上设有第四节气门阀;本实用新型通过第二节气门阀和第四节气门阀的配合使用,在后续使用时,可以根据需要控制第二节气门阀和第四节气门阀的开度,从而保证第一电堆与第二电堆工作压力的一致性。
Resumen de: TW202433786A
Embodiments disclose a stacking apparatus including a stacking module including a stacking stage and a stacking head for stacking an anode plate, a cathode plate, and a separation film on the stacking stage, an anode plate supply module for supplying the anode plate, and a cathode plate supply module for supplying the cathode plate, wherein the anode plate supply module includes a plurality of first storage units, a plurality of 1-1 pickup units each picking up the anode plate from the plurality of first storage units, and a first alignment stage providing the anode plate to the stacking head; the cathode plate supply module includes a plurality of second storage units, a plurality of 2-1 pickup units each picking up the cathode plate from the plurality of second storage units, and a second alignment stage providing the cathode plate to the stacking head; the anode plate picked up by the 1-1 pickup unit and the anode plate picked up by the 2-1 pickup unit are alternately disposed on the first alignment stage.
Resumen de: WO2025135372A1
The present invention relates to a dead-end operation-type air-cooled fuel cell system. The dead-end operation-type air-cooled fuel cell system according to one embodiment of the present invention may comprise: a fuel cell stack including a plurality of fuel cells, and a hydrogen discharge line in which a hydrogen discharge valve is provided and which is connected to a hydrogen discharge manifold; an air supply unit for supplying air to the fuel cell stack; a hydrogen supply unit for supplying hydrogen to the fuel cell stack; a cooling unit including a cooling fan for supplying cooling air to the fuel cell stack, and a temperature sensor provided between the fuel cell stack and the cooling fan so as to measure the exhaust temperature of the cooling air discharged from the fuel cell stack; a voltage measurement unit for measuring the voltage of the fuel cell stack; and a control unit which is connected to each of the fuel cell stack, the air supply unit, the hydrogen supply unit, the cooling unit and the voltage measurement unit, and which controls that the hydrogen discharge valve is repeatedly opened and closed at hydrogen discharge valve opening and closing time intervals from closing of the hydrogen discharge value to re-opening of the hydrogen discharge valve.
Resumen de: DE102024137598A1
Ein Brennstoffzellenstapel umfasst gestapelte einzelne Zellen. Jede der einzelnen Zellen umfasst eine Energieerzeugungseinheit und zwei Separatoren, die die Energieerzeugungseinheit sandwichartig anordnen. Eine Oberfläche von jedem der Separatoren, die der Energieerzeugungseinheit zugewandt ist, hat Gaskanäle und Rippen, die abwechselnd angeordnet sind. Die Rippen erstrecken sich entlang der Gaskanäle. Jeder der Gaskanäle umfasst zumindest eine erste Erstreckung und eine zweite Erstreckung. Zumindest einer der Gaskanäle umfasst eine inselförmige Verzweigungsrippe, die in einem gekrümmten Abschnitt angeordnet ist. Die Verzweigungsrippe lässt den Gaskanal in zwei Verzweigungskanäle verzweigen. Die Verzweigungskanäle umfassen einen äußeren Kanal und einen inneren Kanal.
Resumen de: KR20250096912A
항공용 연료전지 시스템의 수소 공급 장치 및 의 제어방법이 개시된다. 본 실시 예는 스택이 장착된 항공용 드론 또는 지상에서 스택이 구비된 전기 자동차와 같이 다양한 용도로 사용되는 스택으로 안정적인 수소 공급을 도모하여 스택의 작동 효율을 최적의 상태로 유지할 수 있다.
Resumen de: WO2024100371A1
A method of reducing the greenhouse gas impact of livestock farming includes feeding a fuel gas comprising one or more hydrocarbons to an anode of a solid oxide fuel cell stack, withdrawing air, that includes methane originating from livestock, from a livestock housing or enclosure and feeding the withdrawn air to a cathode of the solid oxide fuel cell stack. The oxygen in the air is allowed exothermically to react with the one or more hydrocarbons in the fuel gas to form at the anode a heated first exhaust stream comprising water and carbon dioxide and at the cathode a heated second exhaust stream comprising methane, thereby generating an electrical current from the solid oxide fuel cell stack through an external electrical circuit. At least the heated second exhaust stream is fed to a combustor and combusted, producing a heated tail gas stream.
Resumen de: KR20250097016A
본 발명은 연료전지 스택의 열화 모사 방법에 관한 것으로, 상세하게는 실제 차량에서 열화가 발생하는 연료전지 스택의 운전 조건을 구현하여 스택의 엔드셀 열화를 모사함으로써 스택의 열화를 신속하게 평가할 수 있도록 하며 스택의 개선 사양에 대한 유효성 또한 신속하게 검증할 수 있도록 하는 연료전지 스택의 열화 모사 방법을 제공함에 목적이 있다.
Resumen de: WO2025135432A1
An apparatus for predicting the lifespan of a fuel cell according to an embodiment of the present invention may be provided, the apparatus comprising: an information collection unit for measuring the voltage of each of multiple unit cells provided in a fuel cell stack; a cell prediction modeling unit for generating a cell degradation prediction model to define a degradation pattern of each unit cell on the basis of the voltage measured in the unit cell; a cell prediction correction unit for generating a cell degradation correction model for correcting the degradation pattern to reflect the dependency of a degradation pattern of one unit cell to that of another unit cell among degradation patterns of the multiple unit cells; and a lifespan prediction unit for predicting the lifespan of each unit cell on the basis of the cell degradation correction model, and outputting the time until the unit cell with the predicted lifespan reaches a failure determination condition.
Resumen de: WO2024150467A1
Provided is a solid electrochemical device comprising: a solid electrolyte which has a first main surface and a second main surface that is opposite from the first main surface; a first electrode which has a third main surface and a fourth main surface that is opposite from the third main surface and which is provided such that the third main surface faces the first main surface; a first current collector which has a fifth main surface and a sixth main surface that is opposite from the fifth main surface and which is provided such that the fifth main surface faces the fourth main surface; and a first interconnector which has a seventh main surface and which is provided such that the seventh main surface faces the sixth main surface, wherein the seventh main surface of the first interconnector is a flat surface, the first current collector includes a first porous metal body that has a three-dimensional network structure, and the fifth main surface has a plurality of first through-holes that are formed so as to extend along a first direction from the fifth main surface to the sixth main surface.
Resumen de: KR20250097551A
본 발명의 고체 산화물 연료전지는 애노드의 일 측이 금속 메쉬에 의해 지지되며, 이에 따라 상업용 음극 지지형 고체산화물 연료전지보다 57% 감소된 셀 두께로 3.2배 높은 기계적 강도를 가져 기계적 견고성이 향상되는 효과가 있다.
Resumen de: KR20250097466A
본 발명은 지르코늄(Zr) 기반 금속 유기 골격체에 아민기 및 설포네이트기가 기능화된 금속 유기 골격체, 이를 제조하는 방법, 상기 금속 유기 골격체를 포함하는 복합막 및 상기 복합막을 포함하는 징크-브롬(Zn-Br) 레독스 흐름/무흐름 전지에 관한 것이다.
Resumen de: US2024154136A1
A cross-flow interconnect and a fuel cell stack including the same, the interconnect including fuel inlets and outlets that extend through the interconnect adjacent to opposing first and second peripheral edges of the interconnect; an air side; and an opposing fuel side. The air side includes an air flow field including air channels that extend in a first direction, from a third peripheral edge of the interconnect to an opposing fourth peripheral edge of the interconnect; and riser seal surfaces disposed on two opposing sides of the air flow field and in which the fuel inlets and outlets are formed. The fuel side includes a fuel flow field including fuel channels that extend in a second direction substantially perpendicular to the first direction, between the fuel inlets and outlets; and a perimeter seal surface surrounding the fuel flow field and the fuel inlets and outlets.
Resumen de: MA69807A1
The present invention provides a joining and sealing arrangement for joining and sealing together a hydrogen separation membrane to a metallic connector comprising: a metallic hydrogen separation membrane mounted on or against a connector formation of the connector about a longitudinal axis, the connector being formed of a different metal to the hydrogen separation membrane, the hydrogen separation membrane having an outer diameter (D) about the longitudinal axis, the hydrogen separation membrane and the connector formation contacting at a connection interface in which an end face of the hydrogen separation membrane is proximate to, substantially abuts or overlaps an adjoining face of the connector formation; a connection that connects the hydrogen separation membrane and the connector formation about the connection interface; and a constriction collar configured to extend from at least the connection interface and extend axially over the hydrogen separation membrane relative to the longitudinal axis, the constriction collar comprising: an expansion section configured to axially extend over the hydrogen separation membrane relative to the longitudinal axis from a constriction end to an expanded diameter, the constriction end being configured to extend around the hydrogen separation membrane at or proximate the connection interface relative to the longitudinal axis and having an inner surface defining a constriction diameter (C) that is configured to extend around the outer su
Resumen de: KR20250097565A
본 발명은 자동 소화 장치를 포함하는 연료전지 시스템에 관한 것으로, 본 발명의 일실시예에 따른 자동 소화 장치를 포함하는 연료전지 시스템은 케이스 및 케이스 내부에 수용되는 연료전지 팩을 포함하는 연료전지 발전부, 연료전지 팩의 공기유입 매니폴드의 제1 공기 유입구에 연결되고 공기공급밸브가 설치된 공기 공급라인을 포함하는 공기 공급부, 연료전지 팩의 수소 유입 매니폴드의 제1 수소 유입구 연결되고 수소공급밸브가 설치된 수소 공급라인을 포함하는 수소 공급부, 연료전지 발전부에 연결되는 냉각수를 공급하는 물 공급라인, 냉각수가 배출되는 물 배출라인 및 일단이 물 공급라인에 연결되고 타단이 공기 공급밸브와 연료전지 발전부 사이의 공기 공급라인에 연결되며 제1 소화수공급밸브가 설치되는 제1 소화수공급라인을 포함하는 냉각부 및 연료전지 발전부, 수소 공급부 및 냉각부의 가동상태를 모니터링하고 제어하는 제어부를 포함할 수 있다.
Resumen de: KR20250097637A
본 발명은 수소 가스를 이용한 연료전지 시스템의 공기 냉각장치에 관한 것으로, 상세하게는 연료전지 스택에 공기(Air)를 공급하는 공기 블로워의 모터가 수용되고 수소 공급부에서 공급되는 수소가 통과되는 제1 수소 통로(HP1)가 형성된 제1 냉각자켓, 제1 냉각자켓에 일단이 연결되는 제1 수소 배관, 제1 수소 배관(20)의 타단에 연결되어 제1 수소 통로(HP1)를 통과한 수소가 통과되고 연료전지 스택에 연결되는 제2 수소 통로(HP2) 및 제2 수소 통로(HP2)에 둘러싸여 공기 블로워에서 공급된 공기(Air)가 통과되고 연료전지 스택에 연결되는 제1 공기 통로(AP1)가 형성된 제2 냉각자켓을 포함하는 수소 가스를 이용한 연료전지 시스템의 공기 냉각장치에 관한 것이다.
Resumen de: KR20250096911A
항공용 연료전지 시스템의 수소 공급 장치가 개시된다. 본 실시 예는 항공용 드론에 설치된 스택에서 최소한의 중량 및 크기를 갖도록 모듈화된 상태로 조립되어 스택의 안정적인 작동을 도모할 수 있다.
Resumen de: JP2025096810A
【課題】空間効率が高い構造の電源装置を提供すること。【解決手段】電源装置1~5は、電池スタック10と、電池スタック10に隣接して設けられたクランク状壁部群とを備えている。電源装置1~5のクランク状壁部群はそれぞれ、クランク状壁部群106、206、406、506である。クランク状壁部群106、206、406、506はいずれも、第1壁部、第2壁部、第3壁部を有する。第1壁部は、X方向またはY方向である第1の方向に延びている。第2壁部は、第1壁部の一端から、第1の方向と交差する第2の方向に延びている。第3壁部は、第2壁部の第1壁部から遠い側の端から、第2の方向と交差する第3の方向に延びている。【選択図】図1
Resumen de: US2025196723A1
The vehicle rear structure comprises a travel motor; a fuel cell configured to output power to the travel motor; a battery configured to output power to the motor; and a controller, wherein the controller is configured to at least temporarily perform protection control to operate the battery at an output power higher than a rated output power during hill climbing traveling.
Resumen de: TW202422920A
The present invention relates to a gas diffusion layer for fuel cells, wherein the gas diffusion layer comprises a microporous layer having a polymeric binder which is fluorine-free or has a lower proportion of fluorine-containing polymers than conventional binders. Furthermore, the present invention relates to a gas diffusion layers available by this method and a fuel cell containing such gas diffusion layer.
Resumen de: CN120221720A
本发明公开了一种燃料电池系统双比例阀故障诊断及控制方法,包括通过控制器调节燃料电池的电流密度和双比例阀组前端氢气压力,得到电流密度、氢气高压压力和占空比最小值的关系图MAP1以及电流密度、氢气高压压力和占空比最大值的关系图MAP2;控制器根据燃料电池当前的氢气高压压力和电流密度查询关系图MAP1和关系图MAP2,得到当前状态下双比例阀组的占空比最小值和占空比最大值;根据燃料电池当前的氢气高压压力和电流密度得到双比例阀组当前占空比,并与当前状态下双比例阀组的占空比最小值和占空比最大值进行比较,得到双比例阀组的故障情况并制定控制方法。本发明提升了燃料电池系统定位故障的能力,提升了系统运行的稳定性,减小系统宕机的风险。
Resumen de: CN120220843A
本发明公开了一种考虑粘结剂结构的气体扩散层重构和两相流模型结合方法,利用随机重构法建立一个气体扩散层纯纤维结构,采用形态学闭运算算法对粘结剂结构进行重构,通过对结构算子大小的调控,实现对粘结剂结构体积比和孔隙率的有效控制。基于重构真实结构气体扩散层,建立一个两相流模型,从而对液态水在气体扩散层内部的流动过程进行求解与计算。可以对燃料电池气体扩散层孔隙结构进行更精准的重构,获取因粘结剂存在而引发的气体扩散层结构参数变化,包括孔隙率、孔径、迂曲度等关键参数的改变。有助于直观、迅速、准确地获得气体扩散层内两相流动过程的特点,明确了其结构和两相流动过程之间的关系,对气体扩散层的结构提出优化。
Resumen de: CN120221732A
本发明涉及液流电池技术领域,具体地涉及一种液流电池的维护方法,该维护方法包括:液流电池放电后,向液流电池通入清洗液;所述清洗液包括:氧化剂和一价阳离子氢氧化物;氧化剂选自卤素的含氧酸盐、过氧化物中的一种或多种。采用本发明所述方法,对负极清洗以去除负极积累的负极活性物质的单质,从而恢复电池性能。
Resumen de: CN120221730A
本发明涉及液流电池技术领域,具体涉及一种液流电池电解液和锌镍单液流电池。该电解液包括溶剂、一价阳离子氢氧化物、锌离子源和聚乙二醇;所述电解液中,聚乙二醇浓度为1×10‑6‑12.5×10‑5mmol/L;聚乙二醇的平均分子量不低于3000g/mol。该液流电池电解液在提高液流电池的循环性能和电压效率的同时,还具有粘度低的优点。
Resumen de: FR3157684A1
Procédé de fabrication d’une cellule électrochimique comprenant les étapes: mise à disposition d’un premier élément (30, 30.1) comprenant une première nervure (34, 36, 34.1, 36.1, 34.2, 36.2) bordée par deux premières portions de liaison (37, 38, 39, 40, 37.1, 38.1, 39.1, 40.1, 37.2, 38.2, 39.2, 40.2);mise à disposition d’un deuxième élément (50, 50.1) comprenant une deuxième nervure (54, 56, 54.1, 56.1, 54.2, 56.2) bordée par deux deuxièmes portions de liaison (57, 58, 59, 60, 57.1, 58.1, 59.1, 50.1, 57.2, 58.2, 59.2, 60.2);présenter le premier élément (30, 30.1) en regard du deuxième élément (50, 50.1) réaliser une première jonction d’une première portion de liaison (37, 38, 39, 40, 37.1, 38.1, 39.1, 40.1, 37.2, 38.2, 39.2, 40.2) sur une deuxième portion de liaison (57, 58, 59, 60, 57.1, 58.1, 59.1, 50.1, 57.2, 58.2, 59.2, 60.2) par un procédé de soudage par friction. Cellule électrochimique ainsi obtenue Figure pour l’abrégé : Figure 6
Resumen de: FR3157213A1
Procédé de recyclage des résidus d’encre catalytique dans une installation de production et/ou de dépôt d’encre catalytique destinée aux piles à combustible L’invention concerne un procédé de recyclage des résidus d’encre catalytique, comprenant des particules catalytiques, un polymère électrolytique, de l’eau, en quantités relatives connues. On dispose d’un, ou l’on produit un effluent comprenant des résidus d’encre catalytique et de l’eau ou un mélange hydro-alcoolique d’eau et d’alcool A, on le chauffe à un point de température et à une pression provoquant l’évaporation d’eau et/ou d’alcool A on récupère le concentrat. Ce dernier contient les particules catalytiques et le polymère électrolytique sensiblement dans leurs quantités relatives connues dans l’encre catalytique. Ce concentrat est ensuite utilisé pour produire une encre fraîche, notamment en ajoutant ce concentrat à une encre en production. Figure pour l'abrégé : néant
Resumen de: FR3157682A1
Joint périphérique, séparateur polaire comprenant un tel joint, c ellule électrochimique comprenant un tel séparateur, pile à combustible comprenant un e tel le cellule et véhicule comprenant une telle pile La présente invention concerne un joint périphérique (40) s’étendant selon un plan de joint (P40) et comprenant une portion d’étanchéité (41) formant une boucle fermée parallèle au plan de joint (P40) et configurée pour être en contact avec une première plaque polaire d’une cellule électrochimique lorsque le joint périphérique (40) est intégré à la cellule électrochimique. Le joint périphérique (40) comprend en outre un patin (43, 45, 47, 49), ponctuel, électriquement isolant, venu de matière avec la portion d’étanchéité (41), le patin (43, 45, 47, 49) faisant saillie de la portion d’étanchéité (41) vers un extérieur de la portion d’étanchéité (41), selon une direction d’extension parallèle au plan de joint (P40), le patin (43, 45, 47, 49) étant configuré pour être en contact avec la première plaque polaire lorsque le joint périphérique (40) est intégré à la cellule électrochimique. Figure pour l'abrégé : Figure 2
Resumen de: FR3157677A1
Module d’électrolyse ou de co-électrolyse (SOEC) ou pile à combustible (SOFC) à sous-ensemble préassemblés d’empilement de cellules électrochimiques et à enceinte thermique logeant les sous-ensemble et avec trappe(s) de gestion de la thermique. L’invention concerne un module (1) destiné à fonctionner à haute température avec une enceinte thermique dans laquelle des sous-modules (SM1, SM2), à empilement de cellules électrochimiques sont logés. Au moins une trappe d’évacuation (110) de la chaleur dégagée à l’intérieur de l’enceinte par les sous-modules en fonctionnement permet de gérer la thermique au niveau d’un module. Figure pour l’abrégé : Fig. 7B
Resumen de: FR3157683A1
Guide et plaque polaire pour un séparateur polaire de cellule électrochimique, séparateur comprenant de tels guide et plaque polaire, et pile à combustible comprenant un tel séparateur Ce guide (50C) pour un séparateur polaire d’une cellule électrochimique comprend des murets (52H; 52C) agencés côte-à-côte suivant un plan de surface (P11H; P11C), de façon à délimiter des canaux (57C) pour assurer le guidage du fluide fonctionnel, chaque canal étant délimité entre, et par, deux murets. Chaque muret comprend une surface d’application (63C), coplanaire avec le plan de surface et par l’intermédiaire de laquelle le muret est en appui sur une surface de réception (41H). Le guide comprend un tapis d’ancrage (51C), reliant entre eux les murets. Les murets et le tapis d’ancrage constituent ensemble une unique pièce monolithique en matériau de joint. Le tapis d’ancrage s’étend à partir des murets par-delà le plan de surface, de façon à pouvoir être logé dans une cavité d’ancrage, afin d’ancrer le guide (50C) reçu sur l’emplacement de réception. Figure pour l'abrégé : Fig. 4
Resumen de: FR3157686A1
Plaque et joint périphérique pour une pile à combustible, séparateur polaire comprenant de tels plaque et joint, cellule électrochimique comprenant un tel séparateur, empilement et pile à combustible associés Une plaque (13) pour une pile à combustible comprend un champ de circulation (23) et une zone périphérique (21). La zone périphérique comprend au moins un orifice de plaque traversant (28a, 28b, 28c), un rebord interne (31 ; 131), s’étendant entre l’orifice de plaque (28a, 28b, 28c) et le champ de circulation (23 ; 123), et un rebord externe (32 ; 132). Les rebords interne et externe délimitent ensemble l’orifice de plaque (28a, 28b). La zone périphérique (21 ; 121) comprend au moins une ailette (38) venue de matière avec, faisant saillie depuis et sécante avec, le rebord externe (32). Le rebord externe (32) reçoit une partie externe (43) d’un joint périphérique (40) et l’ailette (38, 138 ; 238a, 238b) reçoit une extension (46) du joint périphérique (40) lorsque le joint périphérique (40) et la plaque (13) sont intégrés à la pile à combustible. Figure pour l'abrégé : Figure 2
Resumen de: FR3157407A1
Procédé de recyclage des résidus d’encre catalytique dans une installation de production et/ou dépôt d’encre catalytique destinée aux piles à combustible L’invention concerne un procédé de recyclage de résidus d’une encre catalytique comprenant particules catalytiques, polymère électrolytique, eau. Le procédé comprend le fait de disposer d’un effluent, contenant les résidus d’encre catalytique, sa filtration sur une membrane de filtration, qui génère la formation d’un rétentat contenant les particules catalytiques contenues dans l’effluent, tout ou partie du polymère électrolytique, et de l’eau, puis, de préférence sa diafiltration moyennant l’ajout d’eau. Filtration et diafiltration sont de préférence tangentielles et dynamiques. Les résidus d’encre peuvent être issus du nettoyage d’une installation de production et/ou de dépôt d’encre catalytique, ou de la dissolution de couches d’encre à la surface d’un assemblage membrane électrode de pile à combustible. L’invention concerne aussi une composition pour recyclage et un procédé de production d’une nouvelle encre incorporant la composition pour recyclage. Figure pour l'abrégé : néant
Resumen de: FR3157687A1
TITRE : Pile à combustible à plaque bipolaire munie d’une grille et procédé de fabrication associé L’invention concerne une pile à combustible comprenant une première plaque bipolaire (BP1) munis de canaux, une première électrode (AND) agencée en vis-à-vis des canaux de la première plaque bipolaire, une deuxième plaque bipolaire (BP2) munie de canaux, une deuxième électrode (CTH) agencée en vis-à-vis des canaux de la deuxième plaque bipolaire et, une membrane (MBN) à échange de protons, centrale, agencée entre la première électrode (AND) et la deuxième électrode (CTH) caractérisé en ce que la pile à combustible comprend au moins une grille (GR1, GR2) agencée sur l’une de la première plaque bipolaire (BP1) ou de la deuxième plaque bipolaire (BP2). L’invention concerne également un procédé de fabrication associé. Figure pour l’abrégé : Figure 2
Resumen de: WO2024110290A2
The present invention relates to a method, a control device (160) and a computer program for detecting a leak in a fuel-cell system and also to a leaktightness-analyzing device (180) and a fuel-cell system (100) and to a use of a hydrogen sensor (131), arranged in a fuel-cell system (100), for detecting a leak in the fuel-cell system (100). The method according to the invention comprises receiving a hydrogen signal from a hydrogen sensor (151), arranged in the exhaust system (150), sending a diagnostic signal, which causes the fuel-cell system (100) to change to a diagnostic operating mode if the hydrogen signal received indicates a hydrogen-concentration value in the exhaust system (150) that exceeds a predetermined hydrogen-concentration threshold value, detecting that a membrane of the fuel cell (110) of the fuel-cell system (100) is at least partially leaking if the hydrogen signal received during the diagnostic operation of the fuel-cell system (100) is substantially falling, or that a purging valve (137), arranged in the anode conducting system (130), is at least partially leaking if the hydrogen signal received during the diagnostic operation of the fuel-cell system (100) is substantially not falling, and sending a control signal which indicates that the membrane or the purging valve (137) is at least partially leaking.
Resumen de: CN120221709A
本申请涉及一种氢燃料电池发电系统的湿度控制方法及装置,应用于燃料电池技术领域,方法包括:在启动开机程序后,实时根据氢燃料电池发电系统的功率需求,设置氢燃料电池发电系统的运行电流密度,并设置怠速功率对应的电流密度为第一电流密度;若氢燃料电池发电系统的运行电流密度小于等于预设高电流密度,设置空气的入口压力大于氢气的入口压力;若运行电流密度大于预设高电流密度,设置氢气的入口压力大于空气的入口压力;在启动关机程序前,将运行电流密度降低至第一电流密度,设置氢气的入口压力大于空气的入口压力,并持续运行大于等于预设时间段后,启动关机程序。本申请可确保在低电流密度下电堆内部保持较高的湿度。
Resumen de: CN120221702A
本发明涉及液流电池储能技术领域,公开了一种全钒液流电池电极框和全钒液流电池,全钒液流电池电极框包括进液侧、出液侧和位于进液侧和出液侧之间的电极腔,进液侧设有依次连通的进液口、进液流道和进液缓冲槽,进液缓冲槽设置有沿X方向间隔布置的多个进液导流体,相邻两个进液导流体之间的间隙形成为进液通道,进液缓冲槽通过进液通道与电极腔相连通,其中,相邻两个进液导流体在X方向上的尺寸不相等。本发明能够提高进入电极腔中电解液分布的均匀性。
Resumen de: CN120204957A
本发明涉及液流电池技术领域,尤其涉及一种液流电池用双皮层多孔膜的制备方法和应用。S1、将琼脂糖与水混合,搅拌加热,得到凝胶,将凝胶静置除泡后刮涂在玻璃板上,刮涂厚度为50‑500μm;S2、将刮涂有凝胶的玻璃板在70‑85℃下加热2‑4min;S3、将树脂溶于溶剂中,得到制膜溶液;S4、将制膜溶液刮涂在凝胶薄膜上,刮涂厚度为50‑200μm,在空气中停留2‑30min,随后浸入水至少10min,得到所述双皮层多孔膜。本发明通过凝胶诱导相分离,同时结合非溶剂浸没相分离法得到具有两侧致密皮层,中间是多孔支撑层的结构,该结构显著降低膜污染和缓解活性离子互串。
Resumen de: CN120221673A
本发明提供固体氧化物燃料电池的阳极的制备方法,属于固体氧化物燃料电池技术领域,包括:制备阳极支撑体;制备电解质层,电解质层覆盖在阳极支撑体上;制备由氧化钇稳定化氧化锆、镍基纳米粒子以及铈锆复合氧化物组成的稀释层,稀释层覆盖在电解质层上;制备由镍基纳米粒子以及铈锆复合氧化物组成的催化剂层,催化剂层覆盖在稀释层上。
Resumen de: CN120221713A
本发明涉及燃料电池技术领域,特别涉及一种电堆的关机吹扫方法、装置、燃料电池系统及存储介质,其中,方法包括:获取当前环境温度、电堆的阴极需求空气摩尔量和电堆的当前吹扫参数;基于当前环境温度和电堆的阴极需求空气摩尔量,从预设的映射关系中确定第一目标吹扫参数,并基于当前环境温度确定目标高频阻抗;在根据当前吹扫参数和第一目标吹扫参数判定电堆满足预设的快速关机吹扫条件情况下,根据第一目标吹扫参数控制电堆执行吹扫动作,直至最终吹扫后高频阻抗达到目标高频阻抗,控制电堆关机。由此,解决了相关技术中膜电极水含量控制精度低、电堆关机吹扫时间过长等问题,提升膜电极水含量控制精度,缩短了电堆关机吹扫时间。
Resumen de: CN120210631A
本发明公开了一种钛基储氢合金材料及其制备方法和应用。所述钛基储氢合金材料的元素组成为Ti0.890Zr0.110Cr0.900Mn0.800Fe0.175(VFe)0.125+x wt.%Ce,其中,x为0~5。本发明的钛基储氢合金材料,表现出易活化且吸放氢性能优异(吸放氢平台压适宜、平台滞后小、可逆储氢容量大、吸放氢动力学快)的特性,能够满足重型机械的千瓦级燃料电池的应用条件,有利于拓宽Ti基AB2型储氢合金在千瓦级燃料电池方面的实际应用。
Resumen de: CN120209758A
本发明属于燃料电池技术领域,具体涉及一种耐湿热氢燃料电池用密封材料及其制备方法,其原料包括如下重量份的物质组成:结晶型聚酯30‑70份;非结晶型聚酯5‑30份;环氧树脂10‑20份;聚羟基烯烃低聚物1‑5份;封闭型交联剂0.5‑3.0份;无机填料10‑20份;抗水解剂0.5‑1.0;抗氧剂0.5‑2.0份;偶联剂0.5‑2.0份。该密封材料具有良好的初期粘接性和最终粘接性能,耐湿热劣化性优异。
Resumen de: CN120221705A
本发明公开了一种带有端板加热功能的燃料电池电堆。所述电堆由电堆本体、外部管路、控制器组成。电堆本体两侧为电堆端板,端板内部安装有控温矩阵和测温矩阵。控温矩阵由多组气体管路组成,每组管路由外部管路独立供气,混合气体可在管路内部发生氧化还原反应产生热量。测温矩阵由多个温度传感器组成,可监测端板不同区域的温度。外部管路由电堆氢气和空气出口经流量计和阀门,连接到端板内部的控温管路。外部管路可将电堆尾排气体导入到端板内部。控制器用于接收测温矩阵的测试结果,并根据温度分布情况,调节外部管路的三通阀和流量计,调节进入每段控温管路的流量,进而控制端板温度。
Resumen de: CN120222478A
本发明提供了一种燃料电池热电联供紧急优化调度方法及系统,该方法根据采集的电网运行参数确定电网处于异常状态时,基于预设故障响应机制将燃料电池热电联供系统的运行状态从电网并网状态切换到独立运行状态,并在独立运行状态下根据电网运行参数利用预设优化调度模型求解算法对预先构建的电网优化调度模型进行求解,得到电网能源优化调度方案,进而基于该电网能源优化调度方案对燃料电池热电联供系统进行能源分配,实现系统的快速响应避免电网故障的影响,保障关键负载的高效供电,并且通过优化调度模型生成电网能源优化调度方案进行能源的合理分配,提高系统的整体能源利用效率。
Resumen de: CN120221679A
本发明涉及全钒液流电池电极材料技术领域,公开了一种钒电池用催化改性石墨毡电极及其制备方法。针对现有石墨毡电极疏水性强、催化活性不足、碳纳米管负载不牢等问题,本发明通过以下步骤实现改进:步骤S1酸预处理石墨毡;步骤S2聚吡咯改性石墨毡;步骤S3碳纳米管改性石墨毡;步骤S4催化改性石墨毡。本发明制备的催化改性石墨毡通过氢键和π‑π共轭作用将羧基碳纳米管均匀负载于聚吡咯层,并经烧结工艺提升导电性。此外,利用表面活性剂静电作用,在碳纳米管表面进一步生长聚吡咯颗粒,增加活性位点。本发明通过聚吡咯的原位生长与碳纳米管的复合负载,结合烧结优化和表面活性剂调控,显著提高了电极的导电性、催化活性及耐冲刷性。
Resumen de: CN120209378A
本发明属于离子膜再利用技术领域,具体涉及一种采用废弃离子膜制备全氟磺酸溶液及全氟磺酸离子膜的方法。首先采用四丁基溴化铵‑乳酸的混合液温和去除废弃离子膜中的无机杂质,然后采用甜菜碱‑甘油的混合液高效去除废弃离子膜中的有机物,经1‑乙基‑3‑甲基咪唑醋酸盐‑乙二醇体系将全氟树脂高效溶解与PTFE增强网分离开,最后采用异丙醇‑水体系将全氟磺酸树脂与全氟羧酸树脂分隔开,在制备全氟磺酸离子交换膜时还额外添加了磷酸三乙酯和聚丙基硅倍半氧烷,磷酸三乙酯的添加增强制备的全氟磺酸离子膜的平滑度,聚丙基硅倍半氧烷的添加增强制备的全氟磺酸离子膜的拉伸强度;各个步骤之间协同作用,确保制备的离子膜的性能优异。
Resumen de: CN120221687A
本发明公开了一种直接氨固体氧化物燃料电池用析出型铁基阳极催化剂及其制备方法。所述铁基阳极催化剂的化学式为Pr0.5Sr1.4Fe1.5Mo0.5‑xCuxO6(0≤x≤0.15)。本发明通过超声‑分阶段pH梯度调控,生成了双钙钛矿前驱体,再结合多模态脉冲还原,获得高活性的Fe‑Cux合金,并使其原位锚定于双钙钛矿的骨架结构中,在燃料气氛围下,该合金能够活化析出。本发明方法可实现原子级的成分控制,制备的铁基催化剂通过A位Pr元素的引入显著改善了传统含Sr钙钛矿存在的Sr偏析情况,提高了材料复杂工况下长期稳定性,同时,高性能合金的析出使其克服了低催化活性在实际应用中的主要障碍,有较大的应用潜力。
Resumen de: CN120220340A
本发明涉及一种用于燃料电池发电车的氢气泄露风险监测系统及方法,该系统包括安装于车厢内的传感器模块以及安装于驾驶舱内的仿真模块、危险评估模块和报警模块,其中,传感器模块用于采集氢气浓度及位置信息,并将采集的信息传输至仿真模块;仿真模块用于模拟仿真氢气泄漏过程,并输出氢气质量演变仿真结果给危险评估模块;危险评估模块用于计算风险范围和安全距离,并传输至报警模块进行展示和预警提示。与现有技术相比,本发明通过传感器、仿真、评估三大模块的协同作用,实现了对氢气泄露的全程监测和量化风险预测,能够提前识别并有效预警氢气泄露引发的潜在风险,从而有效提升燃料电池车载氢气使用的安全性。
Resumen de: CN120213118A
本发明公开了一种对钛基储氢合金氢燃料电池系统在线实时检测方法,本发明利用SMF芯和TCF芯的有效折射率不同与对温度和应力的敏感度不同,双直径光纤光栅的反射光谱包含两种谐振峰,使用两个良好的谐振峰(对应于由SMF和TCF核心形成的FBG来解耦温度和应变信息),从而实现目标物理量的高精度检测。采用单模光纤涂覆铂负载氧化钨涂层,利用涂层材料与氢气在环境中发生放热反应,引起温度变化反映储氢系统周围的氢气浓度,本发明能够大大降低储氢电站中温度采集传感器使用数量和管理成本保障氢能源汽车使用时候的安全。
Resumen de: CN120221737A
本发明公开了一种新型钒液流电池电堆,属于液流电池技术领域,包括电堆组件、压力螺杆和压力容器。通过精简电堆结构,大幅降低电池电堆建设和维护成本,同时可以控制液流的流速和压强提高传质充放电效率,并减少电堆结构阻塞和电极板刻蚀的风险。
Resumen de: CN120209377A
本发明提供了一种离子交换膜及其制备方法、膜电极及应用,其中离子交换膜的制备方法包括:步骤S1,取模板剂于第一有机溶剂中进行分散处理,得到模板剂分散液;步骤S2,取模板剂分散液及离子交换树脂溶液依次进行混合及加热处理,得到离子交换膜前驱体;步骤S3,取离子交换膜前驱体于无机溶剂中进行刻蚀,得到离子交换膜;其中,模板剂为二维无机片状材料,二维无机片状材料选自层状双金属氢氧化物、蛭石、蒙脱土或膨润土中的一种或多种。采用本发明制备得到的离子交换膜,其内部含二维的连续传递通道,能够降低离子传输所需活化能,缩短离子传输路径,进而提高其离子电导率。
Resumen de: CN120208314A
本发明提供了一种三相传导空气电极材料及其制备方法、燃料电池及其电极,涉及燃料电池技术领域,旨在解决空气电极在中低温的温度下催化活性低的技术问题。本发明提供的三相传导空气电极材料的制备方法,以硝酸镨、硝酸镍、硝酸钴和硝酸钾作为原材料,这样可以通过在空气电极材料的PrNi0.5Co0.5O3钙钛矿结构中的A位引入低价态的钾元素,提高体系氧空位浓度,提高质子陶瓷燃料电池的氧还原反应催化活性。另一方面,通过对A位点的缺陷调控,诱导B位元素镍的原位析出,提高电极材料氧表面交换和体相扩散速率,促进氧还原反应催化活性。
Resumen de: CN120209213A
本发明提供了一种TEMPO聚合物及其制备方法和应用,所述聚合物包含式I所示结构,所述聚合物用途广泛,可用来制备液流电池的正极材料,也可以作为阻燃剂、光稳定剂、抗静电剂等用于高分子材料、涂料、颜料、油漆、油墨、粘合剂以延缓或阻止其老化,改善其使用性能、使用寿命以及抗静电性能,所述聚合物还可用于汽车内部或外部装饰材料、浮动装置、道路交通装置、农业制品、电器、家具、鞋类、卫生制品、保健制品等领域。#imgabs0#
Resumen de: CN120221700A
本发明公开了一种基于仿生结构的质子交换膜燃料电池双极板流道结构,包括阴极流场板本体及设置在阴极流场板本体内的多条气体流道,每条所述气体流道两端分别设有进气口、出气口;每条所述气体流道内设有多个鳍型导流块,且在鳍型导流块处设置流道侧缩形导流块;鳍型导流块和侧缩形导流块结合使用时,流道内的流场不仅能在垂直于流道方向上产生周期性强制对流,还能在平行于流道方向上产生周期性强制对流;在保持高气体通过性的同时,通过改变流道垂直截面积来加速流场,主动增强了气体向GDL层的对流效应。
Resumen de: CN120221712A
本发明涉及新能源技术领域,且公开了一种基于阳极催化法的燃料电池冷启动系统,包括电堆以及冷却液箱,所述电堆正面的一侧设置有第一冷却液口,所述电堆正面的另一侧设置有第二冷却液口,所述电堆的两侧以及底部设置有冷却板,所述冷却液箱正面底部的一侧设置有进水管,所述冷却液箱正面底部的另一侧设置有回水管,所述进水管的另一端与冷却板的进液口固定安装,所述回水管的另一端与冷却板的出液口固定安装,所述第一冷却液口以及第二冷却液口固定安装有连接导管。该一种基于阳极催化法的燃料电池冷启动系统,在液冷板加热和电堆怠速状态的放热共同作用下电堆小循环内的冷却液迅速升温。
Resumen de: CN120221710A
本发明涉及一种燃料电池系统及在线活化控制方法。包括电堆;空气系统,所述空气系统分别与所述电堆的空气入口和空气出口连接,用于向所述电堆提供反应所需空气;氢气系统,所述氢气系统分别与所述电堆的氢气入口和氢气出口连接,用于向所述电堆提供反应所需氢气;冷却系统,所述冷却系统与电堆的冷却通道连接,用于控制所述电堆的工作温度;控制器,所述控制器与所述空气系统、氢气系统和冷却系统电连接或信号连接,用于控制空气系统、氢气系统和冷却系统的运行;电压巡检器,所述电压巡检器与所述电堆电连接,用于采集电堆的单片电压并发送至控制器。本发明所提供的在线活化控制方法可以随时实施,不受运行工况的限制。
Resumen de: CN120221674A
本发明涉及能源储存和电池技术,具体涉及一种氧电极及其制备方法和应用与锌‑空液流电池。本发明所述氧电极包括气体扩散层和一体化催化层,所述一体化催化层包括层状泡沫镍和负载在所述层状泡沫镍上的Co3O4‑Fe活性材料。以本发明的一体化催化层制备氧电极,提升了氧电极的性能,采用该氧电极制备的液流电池尤其是锌‑空液流电池的放电性能和循环稳定性得到显著提升,具备更高功率应用的能力,并且具有长期稳定使用的特点。
Resumen de: CN120221726A
本发明涉及电化学技术领域,具体涉及一种正极复合膜电极及其应用、锌镍空气液流电池及电堆。该复合膜电极包括依次层叠设置的镍电极、氧还原催化层和气体扩散层;其中,氧还原催化层和气体扩散层组合成空气电极。所述氧还原催化层具有导电纳米聚合物纤维膜的核层和包覆在所述核层上的金属掺杂COP催化剂。本发明中的正极复合膜电极中的氧还原催化层不会出现脱落的问题,能够增强电池电堆的抗过充电能力,提高电池的循环寿命。
Resumen de: CN120221727A
一种基于离子选择膜电极的植物电池制备方法,属于电池领域。以石墨或铂等等材料为电极基底,对材料进行表面微纳序构,增大电极的比表面积,有利于提升放电时长和功率输出,以电沉积或涂覆的方法在石墨等正极负载活性物质,之后在上述所得正极上包裹阳离子选择膜,用于富集阳离子,最后将锌丝缠绕在正极表面,并且包裹阴离子选择膜,锌丝和阴离子选择膜组成负极,最终组成一体化电池,并且用于活体植物发供电测试。制备方法简单易操作、且可大批量制备,性能优越。
Resumen de: CN120221722A
本发明涉及一种用于控制用于车辆的燃料电池、尤其是氢燃料电池的阴极湿度的方法(100),该方法(100)包括以下步骤:S110检测燃料电池的电堆的当前输出功率;S120在当前输出功率低于第一功率阈值(S1)的情况下,检测电堆的湿度是否满足第一湿度条件;和S130如果不满足第一湿度条件,则提高电堆的当前输出功率。本发明还涉及一种相应的系统、一种相应的燃料电池和一种计算机程序产品。通过本发明的技术方案的实施例,不仅能够以特别简单的方式在无需加湿器的情况下降低阴极湿度控制的难度并避免“膜干”的问题,而且能够防止燃料电池长时间在低功率的范围下运行,由此提高了燃料电池的效率并且延长了燃料电池的使用寿命。
Resumen de: CN120221724A
本申请提供了一种燃料电池系统的排氮方法、装置、车辆和存储介质,该方法应用于燃料电池技术领域,该方法包括:获取燃料电池系统的电堆的渗氮速率;根据渗氮速率计算燃料电池系统的排氮阀的需求排气流量;根据需求排气流量和排氮阀的全开排气流量控制排氮阀执行目标排氮动作。该方法能够更加准确高效的达到排氮的目的,从而减少不必要排放,提高燃料电池氢气的利用率。
Resumen de: WO2024119514A1
Embodiments of the present application provide an integrated device, a cooling system, a cooling method and a terminal. The integrated device comprises a first circuit board, a temperature sensor and a humidity sensor. The dew point temperature of an environment in the integrated device is calculated according to the temperature and humidity measured by the temperature sensor and the humidity sensor, and the cooling mode of the integrated device is selected according to the dew point temperature so as to avoid condensation. The cooling system comprises an integrated device, a cooling pipeline, a valve and a heat exchange medium. Whether the heat exchange medium circulates in the cooling pipeline or not is controlled by means of the opening/closing of the valve, and the cooling mode of the integrated device is controlled, so as to avoid condensation and prevent the circuit board from being short-circuited. According to the solution provided by the present application, the integrated device only needs the IP52 protection grade, does not need a ventilation valve, a dispensing seal and a reversible moisture-absorbing material, and does not need spraying of a waterproof coating on the circuit board, thereby reducing the manufacturing and maintenance costs of the integrated device, achieving convenient disassembly, and good heat dissipation performance of the circuit board, and facilitating acquisition of better performance of the integrated device.
Resumen de: CN120209266A
本发明提供了一种高分子量超支化聚芳基哌啶阴离子交换膜及其制备方法和应用,涉及膜材料技术领域。本发明提供的高分子量超支化聚芳基哌啶阴离子交换膜,由支化单体自聚后或者支化单体与联苯单体和N‑甲基‑4‑哌啶酮共聚后,再经季铵化转化得到。该阴离子交换膜具有大于线性聚合物的自由体积,从而展现出超高的导电性能;高分子量的聚合物主链(Mn大于100K)使其具有优异的耐碱稳定性和力学强度;同时,该阴离子交换膜具有较低的吸水溶胀率以及尺寸稳定性,适用于电解水制氢和碱性燃料电池,具有广阔的应用前景。
Resumen de: CN120221734A
本发明涉及一种基于靶向氧化还原反应的高能量密度液流电池系统及其制备方法,液流电池系统包括正极电解液储液罐和负极电解液储液罐,正极电解液储液罐中储存有正极电解液,负极电解液储液罐中储存有负极电解液和固体增容材料,固体增容材料包含聚(2,5‑二羟基‑1,4‑苯醌‑3,6‑亚甲基),负极电解液中包含蒽醌‑2,7‑二磺酸二钠盐。与现有技术相比,本发明具有显著提高液流电池的整体能量密度等优点。
Resumen de: CN120205035A
本发明公开了硼氢化钠制氢机与燃料电池耦合集成系统,属于氢气制备及燃料电池技术领域。传统化石能源存在环境污染与短缺问题,本发明的耦合集成系统应运而生。其采用高比表面泡沫镍为载体的三维立体结构高活性钌基催化剂,实现‑40℃无热源启动制氢,解决低温离网供氢难题。系统中供氢模块以固态硼氢化钠片剂与醇类溶剂反应制氢并供给燃料电池堆,功率调节单元精确调控产氢速率及各参数确保功率匹配负载,储能缓冲单元平衡功率波动。自主研发的50W样机采用固态硼氢化钠片剂技术,安全便携。该系统在发电过程中无有害物质排放,无噪声污染,整机音频低于50分贝,为能源供应提供高效、清洁、安全且灵活的解决方案。
Resumen de: CN120221711A
本发明公开了一种燃料电池系统冷启动控制方法、装置、系统及电子设备。其中,该方法包括:接收到针对燃料电池系统的冷启动指令;响应于冷启动指令,对燃料电池系统中的电池堆进行预加热处理;在确定电池堆预加热完成的情况下,控制燃料电池系统执行冷启动操作,并获取电池堆的温度;基于电池堆的温度,确定燃料电池系统的冷启动状态,其中,冷启动状态用于指示冷启动是否成功。本发明解决了相关技术中的燃料电池系统冷启动控制方法,存在的燃料电池系统冷启动的效率低且功耗大的技术问题。
Resumen de: CN120221693A
本发明涉及一种电池的制备方法和电池。电池的制备方法包括:基于硝酸钡、六水合硝酸钴、九水合硝酸铁,硝酸氧锆和六水合硝酸钇,制备电池阴极;基于硝酸钡、硝酸氧锆、六水合硝酸铈、六水合硝酸钇和六水合硝酸镱,制备电池电解质;基于铝粉、铁粉、钴粉、镍粉、铬粉和钼粉,制备电池正极;基于电池阴极、电池阴极和电池电解质,制备电池。
Resumen de: CN120208162A
本发明公开了一种制取氢气的方法。所述方法包括:将常温下不活泼的碱金属与氢化物混合,使氢化物包覆于碱金属的表面形成包覆层,制得氢化物/碱金属混合物;将所述氢化物/碱金属混合物与水接触,使水先后分别与氢化物、碱金属进行反应,制得氢气。本发明提供的制取氢气的方法成本低,降低了氢气的使用成本,简单易于操作与控制,能够简单,高效的制取氢气;并且本发明的方法不需要经过任何复杂的预处理,可现场高效制备。本发明可以为便携式的、可穿戴的电子设备提供氢源,结合燃料电池提供电能,能够大幅度的延长上述电子设备的续航时间,适合于户外的,野外的,以及某些军事领域,结合燃料电池作为一种电源使用。
Resumen de: WO2024162969A1
A centrifugal blower system comprising a series of blower units, each blower unit in the series comprising a casing having an axial inlet and a radial outlet, an impeller disposed within the casing for drawing a gaseous medium at a first pressure into the axial inlet and expelling gaseous medium at a second higher pressure through the radial outlet and a motor for driving the impeller; and, a duct connecting the radial outlet of at least one blower unit in the series of blower units with the axial inlet of at least one other blower unit in the series of blower units, wherein the axial inlet of the at least one blower unit in the series of blower units is positioned substantially opposite to the axial inlet of the at least one other blower unit in the series of blower units.
Resumen de: JP2024077710A
To provide a carbon catalyst that exhibits high catalytic activity, an electrode, and a battery.SOLUTION: A carbon catalyst has a ratio L/La of at least 15, where L/La means a ratio of the average carbon mesh surface size L, obtained by a temperature-programmed desorption analysis capable of temperature raising to 1600°C, to the crystallite size La, obtained from a diffraction peak near a diffraction angle (2θ) of 43° in an X-ray diffraction pattern based on powder X-ray diffraction using a CuKα ray. The carbon catalyst has a BET specific surface area of at least 100 m2/g.SELECTED DRAWING: None
Resumen de: CN120221735A
本发明公开了一种液流电池系统及其温度管理方法,通过设置设置二级换热部件及辅助部件,具有间接循环加热和冷却功能,可以通过将间接加热部件或冷却部件和辅助部件与堆前或堆后温度值连锁控制,实现液流电池系统待机过程、运行过程、长时停机过程中正极或负极电解液预热、散热、低温保护;可以通过将加热部件和冷却部件与堆前温度或堆后温度进行双闭环连锁控制,实现升温或降温速率控制。通过本发明实施有利于改善系统电解液换热过程温度场的均一性,避免电解液局部温差过大引起的活性反应物质分解或析出等问题,可以增强系统在负载大幅变载和环境温度宽范围变化时的适应能力,提高液流电池系统运行稳定性和可靠性。
Resumen de: CN120214604A
本发明涉及一体式可再生燃料电池技术领域,具体涉及一种一体式可再生燃料电池的测试模式切换平台、系统及方法,一体式可再生燃料电池的测试模式切换平台包括多个控制管路,每个所述控制管路至少包括三个连接端口,三个连接端口分别用于与电解水测试台架、燃料电池测试台架、可再生燃料电池的接口连接,每个所述控制管路与电解水测试台架、燃料电池测试台架、可再生燃料电池连接的接口不同;所述控制管路上设置控制阀,所述控制阀用于控制可再生燃料电池与电解水测试台架连通或与燃料电池测试台架连通。本发明实现了电解水测试和燃料电池测试之间的切换,确保两种模式之间的连续切换和不间断运行,从而实现工程模拟的目标。
Resumen de: CN120221733A
本发明涉及液流电池技术领域,公开了一种锌镍单液流电池单体和锌镍单液流电池的电堆结构,所述单液流电池单体包括一体式电极框,所述一体式电极框的电极腔中装有镍电极、锌电极和将锌电极与镍电极分隔的隔膜,所述一体式电极框的两侧各自通过密封圈与极板密封连接。本发明具有降低生产成本,提升电堆装配效率的优势。
Resumen de: CN120208667A
本发明公开了一种用于热喷涂的固体氧化物燃料电池或电解池的电解质粉末及其制备方法与应用,属于电解质粉末技术领域。该电解质粉末的制备包括以下步骤:采用喷雾干燥法制备微米级电解质粉末;通过等离子球化或高温烧结‑破碎方式对微米级电解质粉末进行致密化处理;对致密化处理后的粉末进行筛分,得到粒径为5μm~50μm的电解质粉末。该方法改善了电解质粉末的粒径大小、球形度、流动性和致密度,能够提升电解质涂层致密度、均匀性以及电池的电化学和机械性能等,可满足SOFC/SOEC对高性能电解质涂层的需求。
Resumen de: CN120215573A
本申请涉及一种节气门控制方法、装置、设备、系统及车辆,涉及车辆控制技术领域。至少解决在控制节气门的开度时,确定的控制参数的准确度较低,导致对节气门的开度进行控制的准确度较低的技术问题。包括:基于节气门开度请求值和节气门开度实际值,确定电机的PWM占空比;基于节气门的当前控制状态,对PWM占空比进行限值处理,得到限值处理后的PWM占空比,当前控制状态为临界控制状态或非临界控制状态,临界控制状态用于表示节气门的复位装置产生的复位扭矩与流过节气门的空气产生的空气扭矩相等;基于当前控制状态、节气门开度请求值和限值处理后的PWM占空比,调节节气门的开启角度。用于提高对节气门的开度进行控制的准确度。
Resumen de: CN223038960U
本实用新型公开了一种全钒液流电池进出液结构,包括框体,框体的边侧设置有密封板,框体开设有通孔,密封板开设有板孔,框体设置有密封垫,密封板上设置有用于锁定密封垫安装位置的固定机构,固定机构包括固定板、固定块、锁紧板、定位板和牵引板,固定板位于密封板上,锁紧板板滑动设置于固定块的侧部,锁紧板板用于锁定固定块和固定板的相对位置。本实用新型通过利用密封板、固定板、固定块、定位板、锁紧板和牵引板的相互配合,牵引板带动定位板对固定块和锁紧板的相对位置进行限定,密封板对密封垫进行挤压限位,有利于对密封垫进行安装和拆卸,进而有利于对密封垫进行直接取下更换,便于提高密封垫的更换效率。
Resumen de: CN120221725A
本发明涉及一种用于甲烷干重整的圆管式固体氧化物燃料电池,属于固体氧化物燃料电池技术领域。所述电池为圆管结构,沿垂直于轴向方向自内而外依次设有进气内腔、阳极支撑体、功能层、电解质层、阴极反应层、出气外腔和外壳,在无氧环境中,将甲烷和二氧化碳混合气体经进气口通入进气内腔,加热使甲烷和二氧化碳混合气体在功能层发生反应,生成一氧化碳和氢离子,氢离子经电解质层传输至阴极反应层,反应生成氢气;上述反应过程中既实现甲烷干重整制氢和一氧化碳,还同时产生电能。将固体氧化物燃料电池技术与甲烷干重整技术结合,一方面可以产生电能,另一方面可以生成氢气和一氧化碳。
Resumen de: CN120221708A
本发明提供一种能够抑制燃料电池的催化剂的劣化和部件的结冰的燃料电池系统。上述燃料电池系统具备燃料电池、燃料气体系统以及控制部,上述燃料气体系统至少具备引射器、循环流路、第1供给线以及第2供给线,上述循环流路使从上述引射器向上述燃料电池供给的燃料气体经由上述燃料电池向上述引射器循环,上述第1供给线向上述引射器供给上述燃料气体,上述第2供给线向上述引射器供给上述燃料气体并且循环气体流量多于上述第1供给线。
Resumen de: CN120221697A
本发明提供了一种增强型质子交换膜、其制备方法和含其的液流电池。增强型质子交换膜的制备方法包括:(1)将涂膜溶液涂布在基材层上,制得全氟磺酸树脂/N,N‑二甲基甲酰胺湿膜,所述涂膜溶液为全氟磺酸树脂溶解于N,N‑二甲基甲酰胺所形成的溶液;(2)将膨体聚四氟乙烯膜覆盖在所述全氟磺酸树脂/N,N‑二甲基甲酰胺湿膜上,脱除N,N‑二甲基甲酰胺,得到第一复合膜;(3)再将涂膜溶液涂布在所述第一复合膜的膨体聚四氟乙烯膜的表面上,脱除N,N‑二甲基甲酰胺,再进行高温退火处理,得到所述增强型质子交换膜。本发明的方法制得的质子交换膜厚度低,阻钒性能优,机械强高和溶胀率低。
Resumen de: AU2023406548A1
The present invention relates to compositions with low electrical conductivity which comprise a hydroxylamine-containing molecule in combination with a yellow metal corrosion inhibitor such as a triazole, wherein the weight ratio of the yellow metal corrosion inhibitor to the hydroxylamine- containing molecule is from 1 :20 to 20:1; and wherein the composition has an electrical conductivity at 25 °C of less than 200 μS/cm. These compositions can effectively provide ferrous metal corrosion inhibition in heat-transfer fluids at low electrical conductivity and maintain a low electrical conductivity which does not alter substantially with aging. They are thus particularly useful as heat-transfer fluids, for example in fuel cells or battery electric vehicles. The invention further relates to methods for the preparation of said compositions, and to uses employing said compositions.
Resumen de: WO2024109995A2
The invention relates to a muffler (1) for an exhaust gas section of a fuel cell system (2), comprising a cavity (10), a muffler device (20) arranged within the cavity (10) for reducing the noise of the exhaust gas flow (S), and a water separating device (30) arranged within the cavity (10) upstream of the muffler device (20) for separating water from the exhaust gas flow (S), wherein the water separating device (30) has an impact element (32) arranged in the water separating chamber (31) for radially expanding the exhaust gas flow (S) flowing in through the inlet opening (11) and a funnel-shaped conducting element (33) downstream of the impact element (32) for radially tapering the exhaust gas flow (S) expanded by the impact element (32).
Resumen de: CN223038962U
本实用新型公开了一种氢燃料电池用多功能集成引射器,涉及氢燃料电池技术领域,本实用新型包括储氢罐、电堆、集成引射器以及冷却系统,所述集成引射器位于所述储氢罐与所述电堆之间,通过多功能集成引射器,集成多个组件,可以减少连接件数量,降低氢气泄露率的同时还可以降低体积;将氢加热器热源并入电堆冷却液进出口处,可以有效利用冷却液热量,提高冷启动成功率;另一方面氢加热器放置于引射器后端,减少加热后的氢气对引射器性能的影响。
Resumen de: CN223038963U
本实用新型公开了一种氢燃料电池用多功能集成中冷加湿器结构,涉及氢燃料电池技术领域,本实用新型包括储氢罐、氢气调节系统、集成中冷加湿器、空压机、空气流量计、空滤、箱体、电堆以及尾排装置,所述电堆位于所述箱体内,所述集成中冷加湿器所集成零部件包括氢气吹扫电磁阀、分流调节节气门、加湿器、背压节气门、空气主路节气门、旁通节气门、空气温度压力传感器、中冷器、中冷器冷却水路启闭阀,集成中冷加湿器将不同零部件集成为一体,整体具备了不同功能,只需做单一绝缘处理且绝缘处理方式简单,空气流动流道结构简单流动阻力较小,同时省去了不同总成间连接管路与连接接头等零部件。
Resumen de: CN223038961U
本实用新型提供一种燃料电池的极板结构及燃料电池。燃料电池的极板结构包括:板体;凸脊组件;所述凸脊组件包括多个分流凸脊。本实用新型提供的燃料电池的极板结构及燃料电池,在分流凸脊的端部设置导流部,并使导流部朝向流体的来流方向倾斜,即能够利用导流部的形状进一步限制流体流动至分流凸脊处的流量以使每个分流出口处的流体流量基本相等,各流道内气体压力、流量和速度分配均匀,也能够利用导流部对流体进行阻挡、反弹、分流、导向,降低流体在导流部处产生的应力集中程度,降低了流体在凸脊组件内的压力损失,从而减少电池内发生水淹现象的问题,从而简化燃料电池内部水管理,有效的提高了燃料电池的性能、稳定性和使用寿命。
Resumen de: CN223038965U
本实用新型公开了一种燃料电池,通过设置至少三个电堆堆栈结构,使得至少三个电堆堆栈结构沿电堆堆栈结构的高度方向依次堆叠设置,然后在各个电堆堆栈结构的外周形成多个沿其周向间隔分布的连接支座,并使得任意相邻的两个电堆堆栈结构之间通过对应的连接支座可拆卸连接,同时在使用电导通结构将各电堆堆栈结构依次电导通,使得本实用新型在使用时采用将至少三个电堆堆栈结构进行堆叠的方式,实现增大燃料电池的发电功率的功能,解决了现有技术中无法通过增加单个堆叠片数来满足发电的大功率需求的缺陷。
Resumen de: CN120221729A
本发明公开了一种Fe/g‑C3N4修饰阴极沉积型微生物燃料电池及其自驱动光电芬顿降解四环素的应用,属水体污染治理技术领域。所述Fe/g‑C3N4修饰阴极沉积型微生物燃料电池,包括:反应器,所述反应器内设置有阴极区和阳极区,所述阴极区包括水体以及固定于水体液面上的Fe/g‑C3N4修饰碳毡阴极,所述阳极区包括水体沉积物基质和埋置于水体沉积物基质的碳毡阳极,所述Fe/g‑C3N4修饰碳毡阴极和所述碳毡阳极通过连接外加电阻形成闭合电路。本发明与其他技术相比,在自然光照下,无需外加能源与H2O2,即可实现光电协同高效降解四环素,结构简单,建造和运行成本低廉,易于管理维护。
Resumen de: CN120221695A
本发明属于燃料电池领域,具体涉及一种一体式集流端板及空冷电堆与制备方法。本发明空冷电堆包括一体化集流端板和堆芯;所述一体化集流端板由绝缘端板和集流板组成;绝缘端板和集流板之间为一体成型结构;所述堆芯的两侧分别设置有一体化集流端板,所述堆芯两侧的一体化集流端板之间通过螺杆与螺母固定。本发明通过集流板与绝缘端板一体成型工艺,降低部分尺寸要求和加工困难;通过集流板与绝缘端板一体成型工艺,减少了生产步骤,提高了生产效率;一体式集流板采用注塑成型工艺,在整体重量方面极具优势,有利于提高电堆重量比功率;一体化集流端板只对其中堆芯侧(与双极板接触的面)进行表面处理,减低整体生产成本。
Resumen de: CN120221736A
本发明公开了一种液流电池系统及其温度控制方法,在正极电解液输送与温度管理单元中设置作为正极温控组件的正极加热器和正极冷却器,在负极电解液输送与温度管理单元中设置作为负极温控组件的负极加热器和负极冷却器。将正极温控组件与正极进堆或出堆温度或其温度调节速率进行闭环或开环管理,将负极温控组件与负极进堆或出堆温度或其温度调节速率进行闭环或开环管理,能够使温度和温度变化速率得到有效控制。通过本发明实施可以使得系统温度管理更加精细,提升系统在不同情况下的适应性,有利于提高电池性能和系统效率,运行过程能够根据需求调整运行模式,应用比较灵活;能够增强系统运行可靠性、提升系统寿命、提高系统效率。
Resumen de: CN120221701A
本发明属于燃料电池技术领域,公开了一种阴极开放式空冷燃料电池双极板及电池电堆。所述阴极开放式空冷燃料电池双极板包括一体成型设置的双极板本体和均热板组件,双极板本体的一面为阳极流场区域侧,另一面为阴极流场区域侧;阴极流场区域侧上设置有若干个空气流道,相邻两个空气流道之间的流道脊部上均设置有脊部开孔;均热板组件包括两个均热板,且均热板沿周向对称设置于圆环形流场结构的内侧。本发明的阴极开放式空冷燃料电池双极板无需改变电池电堆主体结构,易于加工成形,能够有效改善双极板脊部流动死区的气体分配,增强电池电堆风扇的强制对流效果,强化燃料电池的传质传热性能。
Resumen de: CN223035377U
本实用新型公开了一种垂直喷射比例阀及引射器套件,包括比例阀本体和引射器本体,所述引射器本体上开设有通孔,所述比例阀本体位于通孔内设置,所述比例阀本体位于引射器本体的内的一端设置有喷射头组件;所述喷射头组件包括与比例阀本体内壁滑动连接的滑块。本实用新型中,通过设置内嵌式的比例阀本体配合引射器本体,可以将比例阀直接嵌入安装在引射器本体内,并且搭配限位套实现对喷射头组件的固定,而通过设置弯头,可以改变比例阀本体向引射器本体内输送氢气时的排气方向,进而避免在引射器本体内形成气阻,确保引射器本体的通畅,该种设计不仅优化了比例阀与引射器组合安装时的结构,使得整体更为紧凑。
Resumen de: CN223026932U
本实用新型涉及气水分离器技术领域,提出了一种用于燃料电池的气水分离器结构,包括分离箱,所述分离箱的内侧壁固定安装有多个用于弯曲导向的导向板;该用于燃料电池的气水分离器结构,通过分离箱内部设置的多个导向板能够对气水进行分离作用,而气水分离后的液体可储存在储存箱内部,再通过驱动组件将储存箱内部液体输送至循环箱内部,使得循环箱内部的液体可通过驱动组件的作用,从第一循环板向多个导向板内部输入,对导向板进行降温,在通过第二循环板向外循环至循环箱内部,当循环箱内部的液体液面高于外溢组件时,便可向外排出,增加了整体分离器结构对气水分离过程中的效果和设备操作的便捷性。
Resumen de: CN223033466U
本实用新型公开了一种光伏液流电池电催化耦合联产氢气与高值化学品的反应系统,包括光伏供电系统以及与光伏供电系统电连接的液流电池耦合产氢与有机氧化系统和电解水制氢耦合氧化系统。本实用新型有效将绿电与绿储系统串联,可生产绿氢与高值的绿色化学品,实现可再生能源到绿色化学品的高效转化;本实用新型引入液流电池耦合制氢与有机氧化系统,利用液流电池的长时储能与大容量特性实现体系全天时长运行,并引入水分解制氢与有机氧化体系替代负极反应,实现了可再生电能的高效利用;反应系统适用性广泛,为可再生能源的合理利用及有机化学品绿色合成领域提供了新思路。
Resumen de: CN223027719U
本实用新型公开了一种狭缝直涂用垫片,其能够可靠将浆料中的气泡排出,确保浆料形成的涂层厚度均匀性好,且确保涂层的外观好、后续不易干裂。其包括垫板本体,所述垫板本体的长度方向一端设置有进料口,所述进料口用于连通上模的注塑料口,所述进料口连接排气过渡流道,所述排气过渡流道的长度方向的两侧分别设置有若干侧凸排气出口流道,所述排气出口流道的长度方向末端分别连接上模的对应排气通道,所述排气过渡流道的末端连接第一分流流道,所述第一分流流道朝向一侧开口布置、形成流道出口,所述垫板本体沿着长度方向间隔设置有N组分流流道,每组分流流道之间通过间隔齿间隔设置,所有分流流道的流道出口朝向相同。
Resumen de: FR3157685A1
L’invention concerne un procédé de préparation d’une membrane qui comprend les étapes qui sont successivement de préparer une couche de nanofibres de polyéthersulfone par électrofilage d’une solution de polyéthersulfone, de chauffer les nanofibres pour les ramollir, de refroidir les nanofibres et d’imprégner les nanofibres d’un ionomère pour former la membrane. Une telle membrane est constituée de nanofibres de polyéthersulfone qui présentent des points de jonction avec celles qui leur sont adjacentes. Elle a des propriétés de conductivité ionique et peut être utilisée dans une pile à combustible ou un électrolyseur.
Resumen de: CN120221675A
本发明涉及储能技术领域,提供一种锌镍单液流电池拉浆正极片及其制备方法、锌镍单液流电池和锌镍单液流电池电堆,本发明的锌镍单液流电池拉浆正极片,包括泡沫镍基底和分布在泡沫镍基底中的正极活性复合物,所述正极活性复合物包括正极活性物质、导电剂、聚丙烯酸钾和粘合剂,其中,正极活性复合物中,聚丙烯酸钾的含量为0.01~4.00wt%。本发明提供的锌镍单液流电池电堆拉浆正极片,实现了宽幅500mm的锌镍单液流电池电堆拉浆正极片的工业化批量生产,生产过程严谨,一致性好,具有高容量、高活性、高稳定性和低成本的优势。
Resumen de: CN120221680A
本发明公开了一种复合石墨毡电极及其制备方法,至少包括以下步骤:将聚丙烯腈溶解于溶剂中,加入金属源,超声分散形成均匀纺丝液,通过湿法纺丝制成复合纤维原丝,再利用针刺成型工艺将纤维原丝制成复合白毡,经预氧化、碳化、石墨化和高温水蒸气活化过程得到高稳定性的复合石墨毡电极。所有步骤均可兼容现有的石墨毡生产线和石墨毡高温活化线,无需复杂设备改造,在石墨毡生产和活化过程中同步实现金属氧化物原位改性的复合石墨毡电极的制备。本发明制备得到的复合石墨毡电极利用金属氧化物与含氧官能团的协同催化作用大大提高了电极的电化学活性。
Resumen de: CN120221714A
本发明公开了一种流动传质的液流电池流道及多孔电极联合测试系统及方法,属于液流电池领域,该测试系统包括控制系统、台架,以及设置在台架上的电解液循环装置,所述电解液循环装置包括压力输送装置和电解液储罐,电解液储罐用于储存电解液,电解液储罐的出口通过压力变送器与压力输送装置的入口连接,压力输送装置的出口对应连接待测电池正极或负极的进液口,电解液储罐的入口对应连接待测电池的正极或负极出液口;所述控制系统包括控制单元以及与其连接的充放电仪和信号采集与控制模块;该联合测试系统提高了流动传质特性对液流电池的流道和多孔电极的测试效率,有效缩短液流电池的研发周期、降低研发成本。
Resumen de: CN120221698A
本发明公开了一种空冷燃料电池电堆的堆芯、电堆及其热管理设计方法,属于燃料电池技术领域。所述空冷燃料电池电堆的堆芯,包括依次叠放的数个双极板和数个膜电极;所述双极板由阳极板和阴极板组合而成,所述阳极板远离所述阴极板的阳极面上设置有氢气流道,所述阴极板远离所述阳极板的阴极面上设置有空气流道;所述阳极板与所述阴极板之间设置有空冷流道。所述空冷燃料电池电堆,包括上述堆芯,且所述堆芯上所述空冷流道的开口方向与空冷风扇的送风方向相对。采用本发明的风冷燃料电池电堆可以解决阴极开放式空冷燃料电池极板结构存在的难以平衡氧气与膜水含量、对环境的敏感性、性能不稳定等问题,提升了电堆性能,延长了使用寿命。
Resumen de: KR20250096494A
본 발명은 공냉식 연료전지를 위한 방수 방진 시스템에 관한 것으로, 더욱 상세하게는 공냉식 연료전지의 오픈형 구조를 가지면서도 스택 내부로 수분 및 분진이 유입되는 것을 차단하도록 하여 물의 침투에 따른 쇼트 등의 문제, 분진의 퇴적에 의한 냉각 효율 하락의 문제를 해결하고, 화재 위험을 줄여 다양한 공간에 자유롭게 설치가 가능하도록 하는 공냉식 연료전지를 위한 방수 방진 시스템에 관한 것이다.
Resumen de: KR20250095772A
본 발명에서는 수소탱크의 외측에 형성되고, 내부에 상기 수소탱크와 충전구를 연결하는 제1배관라인 및 상기 수소탱크와 연료전지 스택을 연결하는 제2배관라인이 배관된 실린더 피트, 상기 연료전지 스택과 상기 실린더 피트 사이의 상기 제2배관라인의 도중에 설치되고, 액체수소를 상온으로 기화시키기 위한 기화기, 상기 연료전지 스택과 상기 기화기 사이의 상기 제2배관라인의 도중에 설치된 제1개폐밸브, 상기 실린더 피트 내 상기 제1배관라인의 도중에 설치된 제2개폐밸브, 상기 실린더 피트 내 상기 제2배관라인의 도중에 설치된 제3개폐밸브, 상기 수소탱크와 상기 제2개폐밸브 사이의 상기 제2배관라인으로부터 분기되어 상기 실린더 피트의 외부와 통하는 제1통기관, 상기 실린더 피트 내 상기 제1통기관의 도중에 설치된 제4개폐밸브, 상기 수소탱크의 내부와 상기 실린더 피트 내부를 연결하는 연통관, 상기 실린더 피트 내 상기 연통관의 단부에 설치되고, 상기 실린더 피트 내의 과압 가스를 방출하는 오버프레스밸브, 상기 제1 내지 제4개폐밸브의 작동을 제어하는 컨트롤 모듈을 포함하는 이동수단용 수소 충전 및 공급 시스템을 개시한다.
Resumen de: US2025210678A1
An electrochemical cell module includes a module housing and electrochemical cells located in the module housing and configured to generate power or hydrogen and to output an exhaust. The module also includes a vent housing attached to the module housing, an exhaust duct located in the vent housing, and a filter cartridge located in the exhaust duct. The exhaust duct contains an inlet that is configured to receive the exhaust from the module housing, and an outlet that is configured to direct the exhaust away from the module housing. The filter cartridge contains a particulate filter.
Resumen de: KR20250096016A
본 발명은, 연료전지 성능평가장치 제어 시스템 및 방법에 관한 것으로, 보다 상세하게는, 연료전지의 성능을 측정하는 평가장치, 상기 평가장치의 운전이 제어될 수 있도록 운전 신호를 생성하는 임베디드제어기 및 사용자 인터페이스가 마련되어, 상기 평가장치의 운전을 제어하는 제어 신호가 사용자에 의해 입력될 수 있도록 하는 컴퓨터제어기를 포함한다. 그리고, 상기 컴퓨터제어기와 임베디드제어기는, TCP/IP 네트워킹을 통해 상기 운전 신호와 제어 신호를 실시간으로 주고 받아 상기 운전 신호와 제어 신호가 동기화 될 수 있도록 하는 것을 특징으로 한다. 또한, 연료전지 성능평가장치 제어 시스템을 이용한 연료전지 성능평가장치 제어 방법에 있어서, 상기 컴퓨터제어기에 의해, 스크립트 형태의 제어 신호가 입력될 수 있도록 하는 제어신호입력단계, 상기 임베디드제어기에 의해, 상기 평가장치의 운전 신호가 복수개 생성될 수 있도록 하는 운전신호생성단계 및, 상기 컴퓨터제어기에 의해, 상기 평가장치에 의해 측정된 연료전지의 성능 측정 정보가 처리될 수 있도록 하는 정보처리단계를 포함하는 것을 특징으로 한다.
Resumen de: WO2024176959A1
Provided is a hollow fiber membrane module with which it is possible to limit manufacturing costs. The present invention is characterized in that: a case 100 has a first pipe part 111 and a second pipe part 112, and a holding member 210 which holds a plurality of hollow membranes 220 is provided in the case 100; the holding member 210 comprises a first plate part 211 and a second plate part 212 which are provided to as to sandwich the plurality of hollow fiber membranes 220 therebetween, and a connection part 215 which connects the plate parts; and a path from the first pipe part 111 to the first plate part 211 is formed between the first plate part 211 and the case 100, and a path from the second pipe part 112 to the second plate part 212 is formed between the second plate part 212 and the case 100.
Resumen de: WO2024176963A1
Provided is a hollow fiber membrane module which makes it possible to minimize a load imposed on a hollow fiber membrane. The present invention is characterized in that: the inner peripheral surface of a case 100 and a plurality of hollow fiber membranes 220 have provided therebetween a pair of planar parts 211, 212 that form a passage for a fluid flowing outside the hollow fiber membranes 220; the pair of planar parts 211, 212 are provided with a plurality of through-holes 211a, 212a that serve as passages for the fluid flowing outside the membranes; and in regions of the pair of planar parts 211, 212 where the plurality of through-holes 211a, 212a are provided, the total area occupied by the plurality of through-holes 211a, 212a accounts for 30% or more with respect to the total surface area of the sides where the plurality of hollow fiber membranes 220 are disposed, and the width of each of the through-holes in a direction parallel to the plurality of hollow fiber membranes 220 is 10 mm or less.
Resumen de: KR20250096495A
본 발명은 연료전지용 가스분배기에 관한 것으로, 더욱 상세하게는 고압의 가스를 2단으로 감압하여 연료전지로 공급하도록 하면서 1차로 감압된 가스를 중압버퍼탱크에 수용한 다음 중압버퍼탱크와 연결되는 2단감압부에 의해 사용압력으로 감압하여 연료전지에 공급하도록 함으로써, 고유량의 가스공급이 필요한 경우에도 부피 및 무게 증가를 최소화하면서 연료전지 가스 공급 시스템의 구성이 가능하도록 하는 연료전지용 가스분배기에 관한 것이다.
Resumen de: AU2023380022A1
A method of recycling a fluorinated polymer from a membrane comprising the fluorinated polymer, the fluorinated polymer comprising a fluorinated polymer backbone chain and a plurality of groups represented by formula -SO
Resumen de: WO2024176970A1
Provided is a hollow fiber membrane module in which the load on a hollow fiber membrane can be minimized. A hollow fiber membrane module 10 comprising: a plurality of hollow fiber membranes 220; a case 100 in which the plurality of hollow fiber membranes 220 are accommodated within an accommodation space of which the two ends are open; and a pair of sealing fixing parts 231, 232 that seal gaps between the plurality of hollow fiber membranes 220 in a state in which the hollow interiors of the plurality of hollow fiber membranes 220 are opened, the pair of sealing fixing parts 231, 232 being located on one side and the other side of the case 100, the hollow fiber membrane module 10 being characterized by comprising a holding member 210 that is provided inside the case 100 and holds the plurality of hollow fiber membranes 220, and the plurality of hollow fiber membranes 220 being fixed to the holding member 210 by the pair of sealing fixing parts 231, 232.
Resumen de: US2025201877A1
A cold start control method of a fuel cell stack, and system thereof, can include determining by a controller whether cold start is required, opening an air cut-off valve by the controller when the cold start is required, determining by the controller whether an output voltage of a fuel cell stack is recovered, and satisfying a cold start completion criteria of the fuel cell stack by controlling an opening amount of the air cut-off valve when the output voltage of the fuel cell stack is recovered.
Resumen de: KR20250096244A
실시 예의 연료 전지 장치는 복수의 단위 셀이 적층된 셀 스택과, 셀 스택으로부터 배출되는 미반응 수소와 응축수를 전달받은 부산물 저장부 및 셀 스택으로 재순환되지 않고 부산물 저장부로부터 받은 미반응 수소를 외부로 배출하는 배출부를 포함하고, 부산물 저장부는 셀 스택으로부터 유입되는 미반응 수소 및 응축수를 저장하는 제1 공간 및 제1 공간으로부터 미반응 수소 및 응축수가 유입되고 배출부와 연결된 배출구와 접하는 제2 공간을 갖는 하우징과, 하우징의 내부에서 제1 공간과 제2 공간 사이에 배치된 제1 격벽 및 제1 격벽과 제2 공간 사이에 배치되고, 미반응 수소를 포집하여 저장하는 제1 수소 저장부를 포함한다.
Resumen de: CN120221704A
本发明涉及液流电池技术领域,公开一种极框组件和锌镍空液流电池,包括板体和盖板,其中,板体中部和开设有电极腔,其中,所述板体上设有与所述电极腔的进出料端各自连通的气体进料部和气体出料部;盖板盖设在所述气体进料部和气体出料部上,所述盖板背离所述板体的一面设置有与所述电极腔的进出料端各自连通的电解液进料部和电解液出料部。本发明能够实现气相流体和液相流体的通入,具有简化的模块化设计,易于制造和组装,提高电池效率的优势。
Resumen de: CN120221694A
本发明涉及液流储能电池技术领域,公开了一种极板件、液流电池单体、锌镍空液流电池单体和锌镍空液流电池的电堆结构,包括极板本体和嵌装在所述极板本体中的集流体,所述集流体具有伸出所述极板本体设置的极耳。本发明具有简化电堆结构,降低接触电阻,提高电池性能和效率的优势。
Resumen de: CN120221731A
本发明涉及液流电池技术领域,具体涉及一种电解液和锌镍单液流电池,该电解液包括:溶剂、一价阳离子氢氧化物、锌离子源和添加剂;添加剂选自聚乙二醇和季铵盐;所述季铵盐结构式如式(1)所示;#imgabs0#式(1)中,R1、R2、R3、R4各自独立地选自碳原子数为2‑5的直链烷基;X‑为平衡电荷的阴离子,X选自I和/或Br;所述聚乙二醇的平均分子量不低于3000g/mol。该电解液粘度低、电导率高;用作锌镍单液流电池的电解液,不仅能够提高液流电池的电化学性能,还能够提高电解液循环泵的使用寿命。
Resumen de: CN120221738A
本发明公开了一种离散布置且带二次回收能量的兆瓦级氢燃料电池发电系统,包括氢燃料电池发电集装箱,所述氢燃料电池发电集装箱分为底部和顶部,氢燃料电池电堆单元框架、氢燃料电池冷却路零部件框架、氢燃料电池空气路零部件框架和氢燃料电池氢气路零部件框架拼接后固定在发电集装箱的底部,主散热器单元固定在发电集装箱的顶部。通过对电堆、空压机等零部件的离散布置,可以使氢燃料电池发电系统的散热效果更好,并且便于零部件的拆卸和更换,实现了兆瓦级氢燃料电池发电站的稳定运行。借助能量回收型空压机和涡轮发电机对电堆尾排空气的二次利用,进一步降低了氢燃料电池发电系统的能耗,提升了输出效率。
Resumen de: CN120221678A
本发明涉及气体扩散层和液流电池领域,具体涉及一种氧化石墨烯浆料、气体扩散层及其制备方法与应用和液流电池电极。本发明提供一种氧化石墨烯浆料,以重量份计,该氧化石墨烯浆料包括:氧化石墨烯0.01‑0.20份;含氟聚烯烃0.50‑1.50份;碳基导电剂0.20‑1.00份;溶剂30.00‑60.00份。本发明所述氧化石墨烯浆料包括氧化石墨烯与含氟聚烯烃,通过氧化石墨烯与含氟聚烯烃中氟原子的静电结合,制备得到导电性好、疏水性稳定的气体扩散层,应用于液流电池电极,特别是气液固三相反应的液流电池电极,能够有效提高液流电池的性能和循环使用寿命。
Resumen de: CN223038964U
本实用新型涉及车载电源技术领域,具体公开了一种车载充电设备用电源保护结构,包括:车顶箱,所述车顶箱包括车顶箱底盘和设置在所述车顶箱底盘顶部的车顶箱盖,所述车顶箱底盘的外表面设置有电源接头和电源插口,所述车顶箱底盘的底部开设有通风孔;内置电源,设置在所述车顶箱底盘的内部,所述内置电源包括若干液体电池、电源箱和显示组件,所述液体电池、电源箱和显示组件之间电性连接,所述电源接头和电源插口均与电源箱电性连接;本实用新型通过保护组件的设置,显著提高了电力系统的安全性,保证内置电源在安装后的稳定性,同时液体电池和氨酯泡沫化学稳定性强,预防内置电源在使用时发生燃烧的现象。
Resumen de: AU2023381536A1
The preset disclosure relates to an electrochemical cell stack, comprising a solid electrochemical cell (20), an electrically conductive separator plate (30); and a seal element (40). The separator plate comprises: a central portion (31) with a comparatively recessed support face (32) supporting the solid oxide cell, and an contact face (34), opposite the recessed support face, contacting an adjacent solid electrochemical cell; and a border portion (36) providing a comparatively raised top (37) and an upstanding sidewall (38). The seal element (40) extends between the raised top face of the border portion and an opposing support face (39) of adjacent separator plate. A separation distance between the recessed support face and the contact face of an adjacent separator plate as defined by a combined height of the seal element and the upstanding sidewall matches a thickness of the solid electrochemical cell.
Resumen de: CN120221699A
本发明涉及燃料电池流道技术领域,尤其涉及一种适用于低温环境的燃料电池流道,包括流场板,流场板上固定设置有电池流道,电池流道上套设有多个保温罩,电池流道两端均固定连接设置有密封机构,电池流道内穿设有拉绳,拉绳两端均设置有收线座,其中一个收线座上固定连接设置有放置座,拉绳位于放置座内的一端上固定连接设置有导向块,导向块一端外壁转动连接设置有流道清理机构,导向块内固定连接设置有传动机构,通过设置流道清理机构,在拉绳的带动下,流道清理机构能够在电池流道内进行移动。同时在传动机构的带动下,刷环在转动的同时进行往复移动,可以更加充分地清洁电池流道内壁,有效去除积垢,避免流道堵塞,保持电池性能。
Resumen de: US2025201876A1
Disclosed herein are aspects of an adaptive purge technique for purging fuel cells adjusts the time delay between subsequent purges based in part on one or more parameters of the fuel cells. A difference between two like parameters is measured before and after actuation of a valve used to permit entry of a purge gas. The degree of difference between the two parameters is used to determine a time delay, i.e., a time at which the valve should again be actuated to permit the next purge of the fuel cell. In additional to the time delay, the parameters may be used to determine a time interval, or duration, in which the valve is actuated to remain open during a purge event.
Resumen de: CN223038966U
本实用新型公开了一种用于电堆的支撑装置,包括:支撑架及支撑块,所述支撑架上设置有用于连接电堆的连接结构,所述支撑块上下可调地安装在所述支撑架上;其中,电堆支撑在所述支撑装置上时,所述电堆通过所述连接结构连接于所述支撑架,且所述支撑块能够调节至支撑在所述电堆的预设部位下方。本实用新型提供的方案,通过设置支撑装置支撑电堆可以避免电堆的不均衡受力,由此解决现有技术中所存在的电堆因塌腰、扭转及变形等问题导致的密封结构被破坏从而漏液的问题。
Resumen de: CN120221703A
本发明涉及液流电池技术领域,公开了一种电极框子模块、锌镍液流单电池和锌镍液流电池的电堆结构,所述电极框子模块包括基板和设置在所述基板上的焊接筋,所述基板沿Y方向依次设置有进液侧、电极放置腔和出液侧,其中,所述焊接筋围绕所述进液侧、电极放置腔和出液侧设置。本发明能够满足不同电极面容量需求,具有提升电堆组装的效率和密封性的优势。
Resumen de: CN120221682A
本申请提供了一种高温固体氧化物燃料电池阳极材料及其制备方法,高温固体氧化物燃料电池阳极材料的制备方法包括:将钡盐、锆盐、过渡金属盐置入球磨罐中;在球磨罐中加入乙醇,并通过球磨机球磨第一预定时间段,得到固液混合体;对固液混合体进行加热和烘干,得到质子‑电子混合导体材料的前驱体;对前驱体进行烧结,得到质子‑电子混合导体材料。通过本申请的技术方案,在工作温度下高温固体氧化物燃料电池阳极的稳定性大大提高。
Resumen de: CN120205406A
本申请涉及一种固体氧化物燃料电池连接体涂层的制备方法,属于燃料电池技术领域;包括:得到连接体;将涂层的原料进行混合,得到混合料;将混合料和有机浆料进行混合,得到丝网浆料;将丝网浆料印刷至连接体,后进行烘干,以使丝网浆料转换为前驱材料,得到附着有前驱材料的第一中间体;对第一中间体的前驱材料进行干压处理,以减小前驱材料的内部空隙,得到第二中间体;对第二中间体进行烧结,以使前驱材料转变为涂层,完成制备;通过丝网印刷的方式将涂层原料的混合物附着到连接件上,易于控制原料的成分和附着的厚度,进而控制最终涂层的组分和厚度,然后通过干压处理的方式,有效的减小了前驱材料的间隙,进而增大了最终涂层的致密度。
Resumen de: CN120221717A
本发明尤其是涉及燃料电池系统的气体压缩机的轴承故障的监测。具体地讲,本发明公开了一种用于监测燃料电池系统(1)的气体压缩机(131)的故障的方法,所述方法至少包括以下步骤:获取所述气体压缩机(131)的能够表征输入功率大小的电输入参数和能够表征所述气体压缩机(131)的输出动力特性的有效动力输出参数;和至少基于所述电输入参数和所述有效动力输出参数监测所述气体压缩机(131)的故障。本发明还公开了一种相应的控制器、一种相应的燃料电池系统(1)以及一种相应的计算机程序产品。根据本发明的某些示例性实施例,可以及时发现轴承的旋转方面、例如轴承方面的异常,方法简单,原则上通过现有的硬件设备就可实施。
Resumen de: CN120207572A
本申请提供一种氢燃料电池动力船舶,包括液货储存单元、裂解单元、分离单元、燃料电池单元。本申请采用液货作为燃料电池的基础,并通过燃料电池对船舶进行供电,解决了氢燃料电池船舶的续航问题。采用船舶上的液货作为原料进行发电,能够保证燃料电池的原料供应,同时实现零碳排放。通过燃料电池对船舶进行供电,取代了燃油船舶的主机、辅机等设备,燃料电池设备重量低于主机、辅机等原有燃料动力系统的设备重量,降低了空船重量,且增加了舱容,优化船舶稳性性能。
Resumen de: CN120210753A
本发明涉及固体氧化物燃料电池技术领域,尤其是涉及一种SOFC连接体用锰钴尖晶石涂层的制备方法及涂层。其包括基体处理、靶材清洗、高功率脉冲磁控溅射沉积MnCo合金涂层及热转化形成(Mn,Co)3O4尖晶石涂层。本发明通过优化工艺参数,显著提高了涂层的均匀性、致密性和高温抗氧化性能,解决了传统直流磁控溅射存在的阴影效应和涂层缺陷问题。所得涂层厚度为4.8‑5.3μm,表面粗糙度低于1μm,在800℃下长期服役840小时后仍能有效抑制Cr元素外扩散,ASR值低于30 mΩ·cm²。本发明制备工艺简单,适合工业化生产,具有较高的实用价值和推广前景。
Resumen de: WO2024110187A1
The present invention relates to a sensor unit for a fluid conduction unit used to discharge liquid, e.g. for a fluid conduction unit used to discharge liquid from a fuel cell device, the sensor unit comprising the following: at least one liquid level detection zone.
Resumen de: TW202436696A
The present invention relates to a method of operating a cell stack of cell units, each cell unit in the cell stack comprising: a cell layer comprising an electrochemically active cell area, the cell layer having a first side and a second side; a separator plate electrically connected to the cell layer, the separator plate having a first side and a second side, the second side of the separator plate extending across and facing the first side of the cell layer in a spaced arrangement to form a first fluid volume and, the first side of the separator plate comprising protrusions directed away from the first side of the cell layer and towards a second side of a cell layer of a neighbouring cell unit to form a second fluid volume, the method comprising: providing a first fluid to the first fluid volume; providing a second fluid to the second fluid volume; and regulating a pressure difference between the first fluid volume and the second fluid volume to maintain a spaced arrangement that forms the first fluid volume.
Resumen de: CN120221696A
本发明公开了一种适用于燃料电池的多孔材料嵌入微流道结构极板,属于燃料电池技术领域。本发明适用于燃料电池的多孔材料嵌入微流道结构极板上设有流场槽,所述流场槽内设有多孔流场,所述多孔流场为具有连续孔结构的多孔材料,所述多孔材料表面加工有构成气体传输路径的微流道,多孔材料的连续孔结构在毛细力作用下构成液态水传输路径,本发明提升了流场中气体分布的均匀性,同时有效避免了传统流道中可能出现的水分积聚,大幅降低了燃料电池厚度和体积,进而可以大幅提升功率密度,有效缩短电子横向传输距离,降低欧姆损失。
Resumen de: CN120221715A
本发明公开了一种甲醇重整燃料电池发电系统功率控制方法,涉及发电系统功率控制技术领域,本发明通过构建覆盖甲醇重整全过程与燃料电池电化学转换全过程的数字孪生模型,实现了对系统内在动态耦合关系的精准表征,从而有效消除了传统控制中因重整反应延时导致的供氢滞后问题,使燃料电池输出功率能与负载需求保持高度同步;采用Smith预测器对甲醇重整固有延时进行在线估计与补偿,结合多目标模型预测控制MPC在经济性和设备健康状态约束下进行实时优化调度,不仅提高了发电效率,还显著降低了燃料消耗和运行成本,增强了系统对负载波动的抑制能力。
Resumen de: CN120221723A
本发明公开了一种适用于高原的离网型氢电互补供能系统及其供能方法,系统包括可再生能源发电储能系统、电解水制氢制氧系统、燃料电池热电联供系统、用户供电系统、用户供氧系统以及用户供热系统;可再生能源发电储能系统的电能输出端通过电缆分别与电解水制氢制氧系统和用户供电系统连接;电解水制氢制氧系统通过管道与用户供氧系统和燃料电池热电联供系统分别连接;燃料电池热电联供系统的供电输出端与用户供电系统连接,燃料电池热电联供系统的供热输出端与用户供热系统连接。本发明实现了零碳能源输入的联合供电、多需求供给的系统,解决高原地区可再生能源电力和消纳在时间和空间上的不匹配的问题。
Resumen de: CN120206782A
本发明液流电池双极板整形装置和工艺,其中整形装置包括:机架,顶板上竖直设置有四根立柱,所述立柱顶部水平安装有横梁板,所述横梁板中部竖直安装有作用缸,所述作用缸朝下的下压头压接压板组件;底平台,水平设置在所述机架的顶板上,所述底平台的顶面上摆设有石棉垫板框,需要矫形的液流电池双极板片材放置到所述石棉垫板框内,所述石棉垫板框的厚度与所述液流电池双极板片材适配,所述压板组件将所述液流电池双极板片材平压到所述底平台的顶面上;调温组件,对所述底平台和所述压板组件进行加热。本发明对碳塑复合双极板进行热整形,使得双极板片材翘曲度合格,提高产品良率。
Resumen de: US2025210684A1
A fuel cell system includes a fuel cell unit having a substantially rectangular parallelepiped shape, the fuel cell unit including:a plurality of power generation modules each including a fuel cell stack that generates power using fuel gas and oxidant gas, and a heat-insulating module case that accommodates the fuel cell stack;a plurality of fuel supply systems including a plurality of fuel supply lines that supply the fuel gas to each of the plurality of power generation modules;a plurality of oxidant gas supply systems including a plurality of oxidant gas supply lines that supply the oxidant gas to each of the plurality of power generation modules; anda frame to which the plurality of power generation modules, the plurality of fuel supply systems, and the plurality of oxidant gas supply systems are fixed.
Resumen de: US2025210686A1
Provided is fuel cell system including a fuel cell module including a fuel cell stack that generates power using fuel gas supplied to an anode and oxidant gas supplied to a cathode, a combustion unit that burns combustible gas from a combustion gas inlet, and a heat-insulating module case that accommodates the fuel cell stack and the combustion unit. The system also includes a hydrogen supply system including a hydrogen supply line connected to the fuel cell module connecting with an inlet of the anode and a hydrogen supply source, and a hydrogen blower provided in the hydrogen supply line having a governor upstream of the hydrogen blower. Also included is a circulation system the circulation system distributing hydrogen off-gas discharged from the outlet of the anode and having passed through the heat exchanger to the combustion gas line and a reflux line.
Resumen de: CN120221716A
本发明属于燃料电池领域,具体涉及一种燃料电池系统测试设备及其使用方法。在测试间内设置有氢气输送管道和燃料电池系统测试模块;所述氢气输送管道由测试间外的气源提供氢气,通过管道连接至测试间内部后与室外连接;所述氢气输送管道还与燃料电池系统测试模块连接;所述燃料电池系统测试模块包括高压散热器、低压供电电源、高压供电及负载系统、电压变换器DCF和燃料电池系统。本发明采用车规级的氢气浓度传感器作为检测元件,如果氢浓度到达一级报警值发出警告,氢浓度到二级与三级报警值,发出警告并立刻切断进入测试间的氢气和排空测试间氢管路的氢气。能够有效的在测试过程中提高安全性。
Resumen de: CN120208695A
本发明公开了一种用于液流电池的不对称无机陶瓷膜及其制备方法,属于电池隔膜技术领域。用于液流电池的不对称无机陶瓷膜包括基底层、过渡层和选择层;基底层为厚度为0.5~2 mm、孔径为0.5~3 μm的氧化铝陶瓷片;过渡层的材质为氧化铝,其厚度为10~30 μm,孔径为80~120 nm;选择层为单层或多层结构,选择层中各层的材质为氧化铝、氧化钛和氧化锆中的至少一种,每一层的厚度为0.5~5 μm,孔径为2~10 nm。本发明的用于液流电池的不对称无机陶瓷膜携带大量的羟基基团,这些呈电负性的羟基基团通过道南效应可以排斥锌酸根离子,从而有效避免金属锌的不规则沉积,进而有效抵御锌枝晶对隔膜的刺穿。
Resumen de: US2025210682A1
A cell monitoring device for a fuel cell is mounted to a plurality of unit cells stacked in a first direction. The cell monitoring device includes a support part fitted and fixed to tabs protruding in a second direction, intersecting the first direction, from separators included in each of the plurality of unit cells and includes a connector coupled to the tabs while being supported by the support part. The support part includes a body fitted and fixed to portions of upper sides or lower sides of the tabs and includes a plurality of partition walls that extend from the body in a third direction, intersecting each of the first and second directions, to define spaces in which other portions of the tabs are disposed and are arranged in the same direction as a direction in which the separators are arranged.
Resumen de: CN120221718A
本公开提出了用于燃料电池系统的压力传感器的故障识别方法。该故障识别方法包括:当燃料电池系统的停机时间大于等于停机时间阈值时,计算第一压力传感器、第二压力传感器、第三压力传感器和第四压力传感器测量的压力值的平均值;将第一压力传感器、第二压力传感器、第三压力传感器和第四压力传感器测量的压力值与平均值进行比较;以及如果第一压力传感器、第二压力传感器、第三压力传感器和第四压力传感器中的任一个测量的压力值与平均值之间的差值的绝对值大于等于第三压差阈值,则识别出对应的压力传感器发生故障。根据本公开的故障识别方法能够在燃料电池系统启动之前自动识别压力传感器是否发生故障。
Resumen de: CN120221676A
本发明涉及镍基电池领域,公开了一种镍基电池正极活性复合物、镍基电池正极片及其制备方法和应用。本发明的镍基电池正极活性复合物包括正极活性物质、导电剂、聚丙烯酸钾和粘合剂,其中,正极活性复合物中,聚丙烯酸钾的含量为0.01~4.00wt%。本发明的镍基电池正极片包括正极基底和本发明所述的正极活性复合物。本发明的镍基电池正极片的制备方法包括:制备含有本发明所述的正极活性复合物的正极浆料;将所述正极浆料分布在正极基底上或者分布在正极基体孔道内,烘干、压片成型。采用本发明的镍基电池正极活性复合物制备的电极稳定性好,电极性能好。
Resumen de: CN120210993A
本发明公开了一种锌溴液流电池用复合电极材料及其制备方法和应用,制备方法包括以下步骤:S1,将铜盐、锌盐、钠盐和蒸馏水在室温下搅拌均匀,在空气中陈化,之后经过滤、洗涤、烘干后得到锌铜复合盐;S2,将聚合物在搅拌条件下加入到有机溶剂中,并在水浴条件下搅拌后获得纺丝液;之后加入锌铜复合盐,搅拌后进行超声分散,得到复合纺丝液;S3,利用高压静电纺丝将复合纺丝液制成前驱体纳米纤维材料;S4,将所述前驱体纳米纤维材料在气氛炉中进行预氧化和碳化处理,碳化处理后的材料经清洗、干燥后获得锌溴液流电池用复合电极材料。本发明能解决锌溴液流电池中溴电极反应在电极材料表面活性低、电催化性能不稳定、溴渗透等问题。
Resumen de: CN120221721A
本公开提出了一种燃料电池系统的阴极压力控制方法和控制器。该阴极压力控制方法包括:获取燃料电池电堆的电流设定点;基于电流设定点计算空气质量流量设定点和背压设定点;基于空气质量流量设定点和背压设定点计算空气压缩机转速设定点和背压阀开度设定点;以及如果背压阀开度设定点小于等于开度阈值,则将空气压缩机转速设定点和背压阀开度设定点自动调整为新的空气压缩机转速设定点和新的背压阀开度设定点。根据本公开的阴极压力控制方法特别适于燃料电池系统的高海拔运行工况,避免了燃料电池系统因无法满足背压而出现水管理问题。
Resumen de: CN119463815A
The invention relates to the technical field of hydrogen fuel cells, and discloses hydrogen fuel cell cooling liquid and a preparation method thereof. The hydrogen fuel cell cooling liquid is prepared from the following substances in parts by weight: 60 to 90 parts by weight of water, 5 to 20 parts by weight of carbon nano modified propylene glycol ether, 0.5 to 5 parts by weight of 1-butyl-3-methylimidazolium tetrafluoroborate, 3 to 12 parts by weight of polyethylene glycol, 0.5 to 5 parts by weight of organic boric acid ester, 0.1 to 3 parts by weight of polyacrylic acid, 0.1 to 0.8 part by weight of quaternary ammonium salt and 0.01 to 0.4 part by weight of silver nanoparticles. The hydrogen fuel cell cooling liquid provided by the invention has multiple functions of freezing prevention, cooling, corrosion prevention, scale prevention, bacteria prevention and the like, and also has the characteristics of low conductivity and high membrane electrode compatibility.
Resumen de: US2025210677A1
A processing circuitry of a fuel cell pump is configured to execute a process including a rapid acceleration rotation start and subsequent low acceleration rotation start when a detected temperature is lower than or equal to a preset temperature, and to execute a normal start mode process in other cases. The processing circuitry is configured to, in the rapid acceleration rotation start, set a value of a starting current supplied to a motor and a rotational acceleration of the motor to be greater than those in the normal start mode process. The processing circuitry is configured to, in the low acceleration rotation start, set the value of the starting current supplied to the motor to be greater than that in the normal start mode process, and set the rotational acceleration of the motor to be lower than that at the execution of the rapid acceleration rotation start.
Resumen de: CN120221706A
本发明涉及一种用于燃料电池系统的冷却液泄漏诊断方法,包括以下步骤:获取所述燃料电池系统的冷却回路的冷却液在冷却液入口处的实际入口压力和用于驱动所述冷却液流动的冷却液泵的实际转速;根据所述冷却液的入口压力关于所述冷却液泵的转速的变化曲线获取对应于所述实际转速的入口压力裕度,所述入口压力裕度具有额定压力上限和额定压力下限;比较所述实际入口压力与所述入口压力裕度,当所述实际入口压力小于所述入口压力裕度的所述额定压力下限时,判断所述燃料电池系统发生冷却液泄漏。还涉及一种却回路和燃料电池系统。可以在燃料电池系统的不同负载的情况下准确诊断出冷却液的泄露问题,有效地避免燃料电池系统由于冷却液泄漏而受损坏。
Resumen de: CN120221685A
本发明涉及电化学技术领域,具体涉及一种核壳纤维催化层及其制备方法与应用、膜电极和锌空液流电池。该催化层包括具有聚合物纳米纤维的核层和包覆在所述核层上的金属掺杂COP催化剂;所述催化层具有导电性。本发明中的核壳纤维催化层具有纳米纤维膜的柔性和孔隙结构,多孔的结构可以加快物质传递,有利于活性物质快速的扩散到活性位点,进而加速反应速率。
Nº publicación: CN120221728A 27/06/2025
Solicitante:
青岛大学
Resumen de: CN120221728A
本发明属于生物燃料电池技术领域,具体涉及一种基于仿漆酶纳米酶构筑生物阳极的生物燃料电池及其应用,该生物燃料电池包括:阳极,为负载氧化亚铜纳米粒子的仿漆酶纳米酶生物阳极;阳极电解液,为含有1~2mM邻苯二酚的PBS缓冲液,电解液的pH值为7~9;阴极,为依次负载多壁纳米管和胆红素氧化酶的电极;阴极电解液,为PBS缓冲液。本发明构建了仿漆酶纳米酶生物燃料电池,具有优异的电催化活性,能够用于催化邻苯二酚氧化。在1.5mM邻苯二酚溶液中,该生物燃料电池的输出电位为640mV,最大功率密度为13μWcm‑2,且具有很好的稳定性。
