Energía solar térmica de concentración

Resultados 86 resultados
LastUpdate Última actualización 19/04/2024 [06:49:00]
pdfxls
Solicitudes publicadas en los últimos 60 días / Applications published in the last 60 days
previousPage Resultados 25 a 50 de 86 nextPage

POLY-LAYERED, POLY-DIMENSIONAL SOLAR-STACK STRUCTURE

NºPublicación:  US2024106391A1 28/03/2024
Solicitante:
NJIE MOHAMMED ALBOURY [US]
Njie Mohammed Alboury
US_2024106391_PA

Resumen de: US2024106391A1

A poly-layered, poly-dimensional solar photovoltaic stack structure may be provided in a tower form. A plurality of solar panels may be stacked on top of one another to create a solar stack tower. Using the solar stack tower, reflection, refraction, diffusion, and transportation of light may transmit photons from a higher area of photon saturation to a lower area of photon saturation. The solar stack tower may provide an enclosed structure, protecting and insulating the solar panels from heat, moisture, dust, and other elements that usually damage solar panels over time.

SOLAR ENERGY COLLECTION SYSTEM AND RELATED METHODS

NºPublicación:  US2024102698A1 28/03/2024
Solicitante:
KONG MUN CHEW [SG]
Kong Mun Chew

Resumen de: US2024102698A1

An energy collection system including a collection apparatus having a light concentrating lens is disclosed. The light concentrating lens can include a light receiving surface and a light exiting surface opposite the light receiving surface. The light exiting surface includes a curved shape configured to direct light passing through the lens to a focal point. The energy collection system further includes a concentrator apparatus having a conduit and an energy absorbing medium within the conduit to convert the solar energy to thermal energy.

CSP SYSTEM, SENSOR ARRANGEMENT, METHOD AND USE

NºPublicación:  EP4341619A1 27/03/2024
Solicitante:
CAMBRAS GMBH [DE]
Cambras GmbH
CN_117693653_PA

Resumen de: AU2022276120A1

The invention relates to a concentrated solar power (CSP) system, comprising a reflector, a receiver tube, a shadow receiver arranged and adapted to receive the, preferably full, shadow of the receiver tube; a first digital camera fixedly attached to the CSP system and arranged and configured to acquire a first image of the reflector and of the shadow receiver, and a controller. The controller is configured to identify a first portion of the first image that comprises the reflector and a second portion of the first image that comprises the shadow receiver, determine a degree of soiling of the reflector based on the first portion of the first image and, preferably, ignore all information contained in the second portion of the first image for determining said degree of soiling, and determine an adjustment of the orientation of the reflector based on the second portion of the first image and, preferably, ignore all information contained in the first portion of the first image for determining said adjustment.

一种聚光式太阳能集热加热原油装置

NºPublicación:  CN117760097A 26/03/2024
Solicitante:
中国石油化工股份有限公司中国石油化工股份有限公司西北油田分公司
CN_117760097_PA

Resumen de: CN117760097A

本发明提供一种聚光式太阳能集热加热原油装置,其特征在于,包括:聚光板,所述聚光板呈马鞍状;集热器,所述集热器设置在所述聚光板的朝向阳光的一侧,用于吸收所述聚光板聚集的太阳能;加热管,所述加热管与所述集热器连接,构造成闭环管路。本发明通过设置马鞍状的聚光板,使聚光板能够适应多种不同角度的太阳光,将太阳光聚集到集热器上,从而提高本发明对太阳光的利用率。同时,本发明通过设置第一调节机构和第二调节机构,能够对聚光板的角度进行调整,进一步提高本发明对太阳光的利用率。

一种高效率光伏温差发电太阳能热水器

NºPublicación:  CN117760098A 26/03/2024
Solicitante:
国网河南省电力公司登封市供电公司
CN_117760098_PA

Resumen de: CN117760098A

本发明提供一种高效率光伏温差发电太阳能热水器,包括水箱,所述水箱连接方形吸热管,所述方形吸热管内设置温差发电板,温差发电板上方为热水侧,下方为冷水侧;热水侧上端出口伸至水箱内顶部;冷水侧上端出口在水箱底部,下端与热水侧联通;冷水侧上方设置进水口,进水口联通水箱外部,水箱上方设置出水口;所述热水侧设置光伏板,所述光伏板及温差发电板通过导线连接蓄电设备;吸热管上方设置一排与吸热管平行的椭圆形透明柱,所述椭圆形透明柱对阳光进行折射,产生条状光斑,所述条状光斑照射在吸热管上。

一种具有集热补光功能的立柱式土壤蓄热循环系统

NºPublicación:  CN117760102A 26/03/2024
Solicitante:
北京市农林科学院
CN_117760102_PA

Resumen de: CN117760102A

本发明公开一种具有集热补光功能的立柱式土壤蓄热循环系统,涉及农业工程技术领域,包括立柱装置、反射镜面和地埋管装置,立柱装置靠近后墙固定,供水段管和回水段管与立柱装置连接,分光集热流体和热沉积球被置于立柱装置及地埋管装置中。本发明汇集吸热、蓄热、放热为一体,通过分光集热流体具有滤光特性及热沉积球吸热下沉的性质,白天集热并给温室作物补光;夜间释放热量给温室增温。提高地温,减少病害,提高能源使用效率。

SISTEMA PARA MODERAR LA ABSORCION DE ENERGIA EN LA SUPERFICIE TERRESTRE CON UNA RED DE FORZAMIENTO PROGRAMABLE DE PANELES DE CONTROL CLIMATICO

NºPublicación:  PE20240599A1 25/03/2024
Solicitante:
LAWRENCE DOUGLAS [US]
LAWRENCE, Douglas
AU_2022340717_PA

Resumen de: AU2022340717A1

A dynamic controllable system (10) for moderating energy absorption at the earth's surface includes a series of panel units (110, 610) mounted above the earth's surface over land and water masses. Each panel unit (110, 610) supports rotatable shafts (112, 612), with panels (100, 600) joined to or integrally formed with the shafts (112, 612). Each panel (forcing) (100, 600) has a radiation reflective surface (102, 602) and a radiation emissive surface (104, 604) opposite the radiation reflective surface (102, 602). The panels (100, 602) are selectively rotated into a predetermined one of a plurality of cardinal positions: reflective, emissive and neutral, or into an intermediate position between two of the cardinal positions. The programmable controller (130) receives various data including top of atmosphere satellite data, air temperature and relative humidity at panel units, weather data, time of day, position of panel units, radiation insolation, and combinations thereof. Responsive to real-time data, both local and regional, the programmable controller directs rotational orientation of panels within the panel units, causing a desired reflection of shortwave and longwave radiation away from the earth's surface.

一种基于张拉膜结构的蝶式太阳能聚光器

NºPublicación:  CN117739534A 22/03/2024
Solicitante:
武汉速安达建筑橡塑制品有限公司
CN_117739534_PA

Resumen de: CN117739534A

本发明公开了一种基于张拉膜结构的蝶式太阳能聚光器,包括聚光镜;设于聚光镜抛物面的焦线处的集热器;聚光镜包括基座以及镜片,基座包括蝶式支撑骨架以及设于蝶式支撑骨架上的张拉膜,镜片内设有电加热带且其形状与蝶式支撑骨架的凹面形状相适配,并将镜片固接于张拉膜上,对镜片的凹面进行纳米喷镀形成反射镜面。本发明的聚光镜通过蝶式支撑骨架、张拉膜结构形成并采用纳米喷镀技术形成凹面反射镜,多材料复合结构提高了聚光镜的聚光性能和整体强度,重量是传统蝶式聚光镜1/20,成本是传统1/10,而且重量轻,安装方便、成本低,重量是传统蝶式聚光镜1/20,成本是传统1/10。

一种聚光集热和发电的太阳能综合利用装置

NºPublicación:  CN117739533A 22/03/2024
Solicitante:
航天智讯新能源(山东)有限公司
CN_117739533_PA

Resumen de: CN117739533A

本发明涉及太阳能技术领域,尤其涉及一种聚光集热和发电的太阳能综合利用装置,包括:支座;机壳,设置在所述支座上;保温板,设置于所述机壳四周,并与所述机壳连接;驱动组件,设置在所述机壳内部;充能组件,设置在所述机壳顶部。本发明通过在机壳的顶部设置传感器,使聚光集热和发电的太阳能综合利用装置能够根据不同时间段确定光照的位置,进而通过电机运转,带动转动杆水平转动,以此来实现集热器对太阳能的吸收功能,增加了对太阳能的转化效率。

SOLAR HEAT COLLECTING STRUCTURE

NºPublicación:  KR20240037546A 22/03/2024
Solicitante:
주식회사디케이

Resumen de: KR20240037546A

본 발명은 자연에너지를 환경오염물 발생 없이 생산할 수 있으며 특히 설치가 용이하고 생산비를 최소화시킨 친환경 자연에너지 집열구조체를 얻기 위한 것이바, 외부돔과, 상기 외부돔내에 형성된 집광부; 상기 집광부를 고정하는 지지프레임과. 상기 집광부에 의해 태양광이 집광되는 위치에 배치되는 집열부; 및 상기 집열부를 감싸며 배치되고, 내부에 열 매체가 순환하도록 가열라인과, 유입라인과, 배출라인으로 형성된 태양열 집열로를 포함한 친환경 자연에너지 생성장치에 있어서, 상기 집열부는 전방에는 석영렌즈와 상기 석영렌즈를 고정하는 고정하우징과 상기 고정하우징에 진공밀착되며 중앙에 원뿔형 홈이 형성된 카본집열뭉치부로 이루어져 상기 카본집열뭉치부에서 발생된 열에너지를 내부에 열 매체가 순환하도록 가열라인과, 유입라인과, 배출라인으로 이루어지도록 형성한 친환경적이며 설치가 용이하고 효율을 증대시킨 매우 유용한 발명인 것이다.

Heliostato bifacial

NºPublicación:  ES2963006A1 22/03/2024
Solicitante:
CENTRO DE INVESTIG ENERGETICAS MEDIOAMBIENTALES Y TECNOLOGICAS CIEMAT [ES]
UNIV DE GRANADA [ES]
Centro de Investigaciones Energ\u00E9ticas Medioambientales y Tecnol\u00F3gicas (CIEMAT),
Universidad de Granada

换热装置及热水器

NºPublicación:  CN117739545A 22/03/2024
Solicitante:
青岛海尔新能源电器有限公司青岛经济技术开发区海尔热水器有限公司郑州海尔新能源科技有限公司海尔智家股份有限公司
CN_117739545_PA

Resumen de: CN117739545A

本申请属于家用电器技术领域,具体涉及一种换热装置及热水器。本申请旨在解决现有热水器的蒸发器吸热形式单一、影响热水器的工作效率的问题。本申请热水器的换热装置包括换热器本体以及反射机构,反射机构包括驱动器以及安装于换热器本体下侧的反射板,驱动器与反射板传动连接,以驱动反射板相对于换热器本体移动;在反射板的至少部分伸出至换热器本体的外侧时,反射板反射的光线射向换热器本体的下侧,使得换热器本体不仅可以与空气换热而吸收空气能,还可以从反射的太阳能光线中吸收太阳能热量,提高换热装置吸热形式的多样化,进而利于提高热水器的工作效率。

HELIOSTAT

NºPublicación:  US2024094500A1 21/03/2024
Solicitante:
HERNANDEZ JORGE SIMON [US]
Hernandez Jorge Simon

Resumen de: US2024094500A1

A method and apparatus for collecting radiation by reflecting, redirecting, focusing, and transitioning the radiation, comprising providing a first reflective focusing surface, receiving full-spectrum light with the first surface, focusing the light onto a second reflective focusing surface after passing through a filtering surface, and allowing the two reflective surfaces to reflect visible light from one surface to the other and out an exit, while infrared light is minimized via the filtering surface.

HELIOSTAT ARRANGEMENT

NºPublicación:  WO2024056209A1 21/03/2024
Solicitante:
ADAMS BERNHARD WERNER [DE]
ADAMS, Bernhard Werner
WO_2024056209_PA

Resumen de: WO2024056209A1

A concentrated solar power facility comprises a sun light collector (105) having a sun light collecting area; a plurality of mirror arrangements for reflecting sun light onto the sun light collector (105); a plurality of light modulating retroreflectors (307) for reflecting modulated light from the sun light collector (105) back to the mirrors (304, 305); a plurality of light sensors arranged to receive light reflected back to the mirrors (304, 305) and to output a light detection signal in response to the reception of modulated light reflected back to the mirrors (304, 305) and a light signal evaluation stage for demodulating the light detection signal and for generating a mirror adjustment signal light signal. At least a part of the retroreflectors (307) is arranged adjacent to and in front of or within the sun light collecting area and in the optical path of light concentrated from a plurality of mirrors (304, 305) directed towards the sun light collecting area, is made from a material having low absorption for visible sunlight, is preferably at least temporarily shielded from and/or cooled against thermal radiation from the sun light collecting area and is modulating light with marginal or no absorption.

SOLAR ENERGY UTILIZATION DEVICE AND COMBINED STRUCTURE OF SOLAR ENERGY UTILIZATION DEVICE

NºPublicación:  EP4340216A1 20/03/2024
Solicitante:
BOLYMEDIA HOLDINGS CO LTD [US]
Bolymedia Holdings Co. Ltd
EP_4340216_PA

Resumen de: EP4340216A1

Disclosed are a solar energy utilization apparatus and a combined structure thereof. The solar energy utilization apparatus comprises a transparent top cover, a reflection groove and a light energy utilization unit. The transparent top cover is provided with a first transparent part recessed inward and a second transparent part protruding upward from the recess of the first transparent part; and based on such structure, sunlight reflected and refracted to the outer side of the transparent top cover can be re-refracted from other regions to the inner side of the transparent top cover, thereby improving the quantity of light refracted into the transparent top cover. Moreover, at least one liquid light-condensing cavity is formed in the reflection groove and the transparent top cover, and a transparent liquid is filled in the liquid light-condensing cavity; the liquid light-condensing cavity can enable at least a part of sunlight emitted from the transparent liquid to the inner wall of the liquid light-condensing cavity to form a total reflection phenomenon, so that more sunlight can be converged on the light energy utilization unit, reducing the sunlight refracted out of the apparatus from the liquid light-condensing cavity and the transparent top cover, and improving the concentrating efficiency.

集热/回热一体式聚光集热太阳能反应器及其工作方法

NºPublicación:  CN117722775A 19/03/2024
Solicitante:
西安交通大学
CN_117722775_PA

Resumen de: CN117722775A

本发明公开了一种集热/回热一体式聚光集热太阳能反应器及其工作方法,包括复合抛物面二次聚光器、反应器外壳及碟式/槽式聚光器;复合抛物面二次聚光器连接于反应器外壳上,所述反应器外壳内自上到下依次设置有上第一隔热层、多孔活性吸收体以及第二隔热层,所述多孔活性吸收体为中空结构,所述第一隔热层上设有通孔,碟式/槽式聚光器聚集的太阳辐射经复合抛物面二次聚光器二次聚光至多孔活性吸收体上,所述多孔活性吸收体与反应器外壳之间设置有桶状的回热结构层,反应器外壳的外壁上设置有若干原料气入口,该反应器及其工作方法具有太阳能利用效率高、利用充分且稳定的特点。

秩序化構造体を使用したエネルギー・リレー内の横方向エネルギー局在化のためのシステムおよび方法

NºPublicación:  JP2024038228A 19/03/2024
Solicitante:
ライトフィールドラボ、インコーポレイテッド
JP_2024038228_PA

Resumen de: US2023408737A1

Disclosed are systems for directing energy according to holographic projection. Configurations of waveguide arrays are disclosed for improved efficiency and resolution of propagated energy through, tessellation of shaped energy waveguides.

碟式聚光镜自清洁装置及复合碟式聚光集热系统

NºPublicación:  CN117722776A 19/03/2024
Solicitante:
山东中科蓝天科技有限公司
CN_117722776_PA

Resumen de: CN117722776A

本发明公开了碟式聚光镜自清洁装置及复合碟式聚光集热系统,包括聚光镜本体,聚光镜本体的上方设置有对聚光镜本体表面转动清洁的转动清洁机构,聚光镜本体的下方设置有支柱管,且转动清洁机构可通过升降机构下降至支柱管的内部,转动清洁机构包括转轴、第一清洁件和第二清洁件,第一清洁件设置在转轴底部的一侧且位于聚光镜本体的上方,第二清洁件设置在转轴底部的另一侧且位于聚光镜本体的上方。本发明针对现有技术中太阳能聚光镜的自清洁组件一般都是设置在表面,会对聚光镜进行遮挡,而影响聚光镜的聚光效果等问题进行改进。本发明具有隐藏式设置的特点,在无需清洁时,清洁组件可进行隐藏,避免清洁组件位于聚光镜的表面造成遮挡等优点。

一种吸热器以及光热系统

NºPublicación:  CN117704655A 15/03/2024
Solicitante:
杭州华鼎新能源有限公司
CN_117704655_PA

Resumen de: CN117704655A

本发明公开了一种吸热器以及光热系统,涉及太阳能光热发电技术领域,包括安装架、进盐管、出盐管、排盐管道系统以及若干吸热模块,所述安装架呈柱状体,所述吸热模块在所述安装架上分成若干路连通形成若干吸热通路,每个所述吸热通路呈螺旋形;所述进盐管与每个所述吸热通路最下一层的吸热模块连通,所有的吸热通路在所述安装架内于最上一层吸热模块的上方由所述出盐管向下输出;所述排盐管道系统位于最下一层吸热模块的下方,所述吸热模块连通所述排盐管道系统,所述排盐管道系统与外部管路连通。本发明在保证熔盐流道长度的同时,在晚上,管路系统中的熔盐可自行回流至熔盐储罐。

一种适用于钙循环储能的回转式光热煅烧装置及应用

NºPublicación:  CN117704813A 15/03/2024
Solicitante:
华中科技大学
CN_117704813_PA

Resumen de: CN117704813A

本发明涉及热化学储能领域,公开了一种适用于钙循环储能的回转式光热煅烧装置及应用。该装置包括:光热煅烧炉和传动机构;光热煅烧炉为套管式结构,包含煅烧炉外管和煅烧炉内管;煅烧炉外管和煅烧炉内管的中间夹层填充有相变传热工质;垂直于煅烧炉内管的内壁面上,且于煅烧炉内管径向垂直方向上设置有导流挡板;光热煅烧炉靠近进口端的水平高度高于光热煅烧炉靠近出口端的水平高度;传动机构设置在煅烧炉外管的中部,用于控制光热煅烧炉进行旋转。本发明通过设置有传动机构,使光热煅烧炉在运行过程中发生旋转,导流挡板搅动碳酸钙颗粒,强化煅烧炉与颗粒传热,提高碳酸钙颗粒吸热分解转化率,实现物料的连续进出,提升实用性和能量利用率。

一种光伏热混合太阳能收集器

NºPublicación:  CN117704648A 15/03/2024
Solicitante:
扬州市职业大学(扬州开放大学)
CN_117704648_PA

Resumen de: CN117704648A

本发明涉及太阳能收集技术领域的一种光伏热混合太阳能收集器,包括安装架结构,安装架结构包括有支撑架,支撑架上设置有摇摆架,摇摆架的两端均设置有水箱;安装架结构上以水箱轴线方向线性阵列设置有多个收集结构,收集结构包括设置在摇摆架上的反光罩,反光罩上固定连接有设置在反光罩内部的集热管,集热管的两端贯穿伸进水箱内,反光罩远离集热管的一侧面设置有发热板;还包括有能驱动反光罩进行转动的驱动机构,本发明可以实现光伏和光热一体化。

免维护定日镜双推杆驱动装置

NºPublicación:  CN117704653A 15/03/2024
Solicitante:
中电建(西安)港航船舶科技有限公司
CN_117704653_PA

Resumen de: CN117704653A

本发明公开了一种免维护定日镜双推杆驱动装置,包括支撑座、立柱、第一推杆模块和第二推杆模块;支撑座设置在立柱顶端,并与立柱转动连接;第一推杆模块与支撑座转动连接,并与支撑座上的定日模块连接,用于带动定日模块转动;第二推杆模块固定设置于支撑座上,用于在定日模块转动至预设位置时,带动支撑座转动,使定日模块的镜面向下。本发明的免维护定日镜双推杆驱动装置中的定日模块的俯仰角度在0°~180°之间,从而在非工作状态时,可将镜面朝下,避免灰尘、沙土等的沉积,保证镜面反射效率的同时,降低了清洗频率及清洗难度,且结构简单、易于批量生产。

一种太阳能转化为高温热能的加温装置

NºPublicación:  CN117704650A 15/03/2024
Solicitante:
安徽星露科技发展有限公司
CN_117704650_PA

Resumen de: CN117704650A

本发明涉及太阳能加温技术领域,且公开了一种太阳能转化为高温热能的加温装置,解决了目前太阳能转换为高温热能加温装置,加热方式单一,加热效率较低,且不便于根据太阳光线变化进行移动的问题,其包括底座,所述底座上端中部连接有转动组件,所述转动组件上端连接有支撑杆,本发明,通过电机带动第三齿轮旋转,使弧形光伏板位置发生移动,可以跟随太阳光的照射变化进行改变,最大程度吸收太阳光,提高光热转化效率,因光伏板呈弧形结构设置,聚集的太阳光使吸热壳体内部充满高温气体,加热管内部的水体加热,高温气体通过输送管输送至加热箱内部处,实现太阳光对水体和物体同时加热,提高太阳能的加热温度和加热效率。

一种综合供能系统

NºPublicación:  CN117704651A 15/03/2024
Solicitante:
山东鑫光节能科技有限公司
CN_117704651_PA

Resumen de: CN117704651A

本发明属于供能技术领域,具体涉及一种综合供能系统。所述系统包括光伏发电子系统、空气源子系统、高斯瓦米子系统;所述光伏发电子系统用于为所述空气源子系统及用户子系统提供电能;所述高斯瓦米循环子系统用于为所述用户子系统提供电能,同时,用于提供冷能给用户子系统用于产品保鲜;所述空气源子系统用于取暖或制冷;用户温度在25℃‑45℃范围内,空气源子系统吸收空气中的热量为用户端制冷;用户温度在‑30℃‑5℃范围内,空气源子系统通过储热罐与用户端连接,产生热量用于供热;若储热罐小于预设温度,空气源子系统利用抛物线槽式集热器中加热了的工质作为热源,产生热量供给用户端供热。

Compactable RF Membrane Antenna

Nº publicación: US2024088539A1 14/03/2024

Solicitante:

LGARDE INC [US]
L'Garde, Inc

US_2022209390_A1

Resumen de: US2024088539A1

Exemplary embodiments are described herein for compactable antennas. Exemplary compactable antennas include a support structure and a reflector surface. The support structure may directly or indirectly define the reflector shape. Exemplary embodiments comprise deployable support structures to permit the compactable antenna to have a smaller volume stowed configuration and a larger volume deployed configuration.
